PRO SIGNAL PSG08046 User manual

1
2 to 1 1080p Full HD HDMI Switch
PSG08046
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

2
IMPORTANT SAFETY INFORMATION
Please read these instructions carefully before use and retain for future reference.
When using electrical appliances basic safety precautions should always be followed.
• To prevent fire or shock hazard, do not expose this product to rain or moisture.
• Beware of static electricity which may damage the device. Use ESD precautions
when installing.
WHAT'S INCLUDED
• HDMI Splitter unit
• Instruction manual
• Multifunctional on switching : intelligent or mechanical.
• Support highest video resolution 1080p.
• Support 250MHz/2.5Gbps per channel (7.5Gbps all channel) bandwidth.
• Support 12bit per channel (36bit all channel) deep colour.
• HDCP pass-through.
• Support uncompressed audio such as LPCM.
• Support compressed audio such as DTS Digital, Dolby Digital (including DTS-HD
and Dolby True HD).
• Support 3D all format, including [email protected]/24Hz, [email protected]/60Hz/50Hz,
bandwidth up to 250MHz.
This HDMI Switcher not only has the key press switching function, but also has
intelligent function.
This kind of HDMI Amplifier Switcher routes high definition video (in multiple resolutions
up to 1080p) and digital audio from any one of the several sources to display units.
All inputs accommodate the connections of the high definition video sources
simultaneously, compatible with HD-DVD, SKY-STB, PS3, Xbox360 etc.
OVERVIEW
FEATURES

3
OPERATION
CONNECTIONS
• Once the source device is connected and powered on, the switcher will
automatically select this source.
• When the source device is turned off or disconnected, the switcher will select the
next active source device in sequence automatically.
Note: Source devices may require powering off completely not just putting into standby
mode for the intelligent switch function to operate correctly depending on the source
devices.
• To manually switch between connected live inputs press the 'Source' button in
sequence.
PSG3429
• Connect the HDMI input source into the HDMI switcher using suitable HDMI cables
* Please refer to connection diagram section.
• For long HDMI cable (over 5metres), it is recommended to use a 5V DC 5W power
supply (not included) connected to the switch unit DC input jack.

4
CLEANING & MAINTENANCE
Clean the outside plastic casing with a soft cloth lightly moistened with mild soap and
water. Never use any abrasive or solvents.
SPECIFICATIONS
INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF ELECTRICAL &
ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical & Electronic
Equipment (WEEE). Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used. Contact your local
authority for details of recycling schemes in your area.
Made in China
PO Box 13362 Dublin 2
PR2 9PP
Man Rev 1.0
Signal Input/Output
Input Video Signal 5 Volts p-p (TTL)
Max single link range 1920 x 1080p
Output Video HDMI Type A 19 pin
Operating Frequency
Vertical Frequency Range 50/60Hz
Video Amplier Bandwidth 2.5Gbps/250MHz
Resolutions (HDTV)
Interlaced (50&60Hz) 480i, 576i, 1080i
Mechanical
Dimensions (WxHxD) 86x16x44mm
Weight 42g
Progressive (50&60Hz) 480p, 576p, 720p, 1080p
Environmental
Operating Temperature 0oC to +70oC
Operating Humidity 10% to 85 % RH (no condensation)
Storage Temperature -10oC to +80oC
Storage Humidity 5% to 90% RH (no condensation)
Power Requirement
External Power No power required
