PRO SIGNAL PSG3036 User manual

PSG3036
HDMI 1080P 3x1 SWITCH + REMOTE

WHAT’s IN THE BOX
OVERVIEW
IMPORTANT SAFETY INFORMATION
INSTALLATION
• This is a high performance mini HDMI Amplier Switcher with both key-press
switching function, and also IR remote control and intelligent function.
• When the power supply of the source equipment is switched on, this device will
respond automatically. In addition, it is equipped with standard IR extender receiver.
• The HDMI Amplier Switcher routes high denition video (in multiple resolutions up to
1080p) and digital audio from any one of the sources to a high denition display unit.
• All high denition video source inputs are connected simultaneously, compatible with
HD-DVD, SKY-STB, PS3, Xbox360 etc.
• If the power supply to the source device is left on when in standby mode, this switcher
will not operate intelligently but will require manual operation using the remote control
or key press.
• Main unit.
• PSU
• IR extender
• Remote control
• User Manual.
Please read these instructions carefully before use and retain for future reference.
• Please make sure all devices you wish to connect have been powered off.
• Connect the source devices to the switcher using appropriate HDMI cable (Max 10m).
• Connect the HDMI output to the display (Max 10m).
• Three input sources and one output display can be connected.
• Connect the IR extender receiver to the switcher.
• Connect the PSU output to the switcher and plug into the mains supply and turn the
power on.
• Always disconnect the power to the switcher before making or removing any
connections including the IR extender receiver.
• When using electrical appliances basic safety precautions should always be followed.
• Check that the voltage indicated on the rating plate corresponds with that of the local
network before connecting the power supply to the mains power supply.

SPECIFICATIONS
• This Mini HDMI Amplier Switcher has many operational features:
• Multifunctional on switching: intelligent or mechanical using the select button or
remote control.
• IR extender receiver (included).
• IR remote (included).
• Supports video resolution of 1080p.
• Supports 250MHz/2.5Gbps per channel (7.5Gbps all channel) bandwidth.
• Supports 12bit per channel (36bit all channel) deep colourTM.
• HDCP pass-through.
• Supports uncompressed audio such as LPCM.
• Supports compressed audio such as DTS Digital, Dolby Digital (including DTS-HD
and Dolby True HD).
• Support 3D formats, including [email protected]/24Hz, [email protected]/60Hz/50Hz,
bandwidth up to 250MHz.
FEATURES
Signal Inputs/Output
Input DDC Signal 5 volts p-p (TTL)
Maximum Single Link Range 1920x1080p
Output Video HDMI
Operating Frequency
Vertical Frequency Range 50/60Hz
Video Amplier Bandwidth 2.5Gbps/250MHz
Resolutions (HDTV)
Interlaced (50&60Hz) 480i, 576i, 1080i
Progressive (50&60Hz) 480p, 576p, 720p, 1080p
Power and Environment
Dimensions 80×58×18mm
Weight 55g
External Power Requirements 5V DC @ 1A
Operating Temperature 0oC to +45oC
Operating Humidity 10% to 85% RH (no condensation)

INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF ELECTRICAL &
ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical & Electronic
Equipment (WEEE). Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used. Contact your local
authority for details of recycling schemes in your area.
Made in China. PR2 9PP
Man Rev 1.0
MAINTENANCE
• Clean the outside plastic casing with a soft cloth lightly moistened with mild soap and
water. Never use any abrasive or solvents.
