PRO SIGNAL PSG3062 User manual

PSG3062
HDMI 1.4 6x2 MATRIX

WHAT’s IN THE BOX
OVERVIEW
IMPORTANT SAFETY INFORMATION
INSTALLATION
• This device can connect and switch six HDMI sources to two HD displays.
• Either one or two of the inputs can be switched to both displays simultaneously.
• Can be used with DVD, Blue-Ray DVD, STB, HD Player, PS3, PS4, XBOX, PC etc.
• The output signals can be same or different. It can select input signal sources with a
given order of priority.
• Main unit.
• PSU.
• Remote Control.
• User’s Manual.
Please read these instructions carefully before use and retain for future reference.
• Please make sure all devices you wish to connect have been powered off.
• Connect six source devices to the switcher inputs using appropriate HDMI cables up
to 15m in length.
• Connect both the outputs to two display using appropriate HDMI cables up to 15m
long.
• Connect the PSU power cable to the converter and connect to a mains supply.
• The power LED lights when the power is applied and the mains is switched on.
• Both analogue RCA or digital TOSLINK audio output can also be connected.
(6) ARC SELECTION
(7) OUTPUT A SELECT
(8) POWER INDICATOR
(9) RESET BUTTON
(10) POWER SWITCH
(1) AUDIO OUTPUT
(2) OUTPUT B SELECTION
(3) REMOTE CONTROL RECEIVER
(4) OUTPUT A SELECTION
(5) LED
(1) DC POWER INPUT PORT
(2) TOSLINK DIGITAL AUDIO OUTPUT
(3) COAXIAL DIGITAL AUDIO OUTPUT
(4) ANALOGUE AUDIO OUTPUT
(5) HDMI OUTPUT PORT B
(6) HDMI OUTPUT PORT A
(7) HDMI INPUT PORT 6
(8) HDMI INPUT PORT 5
(9) HDMI INPUT PORT 4
(10) HDMI INPUT PORT 3
(11) HDMI INPUT PORT 2
(12) HDMI INPUT PORT 1
(5)
(5)
(4)
(4)
(3)
(3)
(2)
(2)
(1)
(1)
(6)
(6)
(7)
(7)
(8)
(8)
(9)
(9)
(10)(11)(12)
• When using electrical appliances basic safety precautions should always be followed.
• Check that the voltage indicated on the rating plate corresponds with that of the local
network before connecting the power supply to the mains power supply.

FEATURES
• When the 6 input ports are separately connected to 6 signal sources with HDMI
cables, the HDMI Matrix automatically recognizes the last connected port and
switches its input signal to 2 displays.
• The required input signal sources can be selected by using the remote control or
pushing front panel button in order to make 2 displays show 2 independent signals.
• Works with all HDCP-enabled source devices and display devices with HDMI Port.
• Supports high resolutions up to 1920*1200, including 480i/p, 576i/p, 720i/p, 1080i and
1080p, 3840x2160@25/30Hz.
• Switch easily between any 6 HDMI sources.
• The 2 displays can get the same or different signals without mutual interaction.
• Connects easily to dual-channel audio receiver device.
• Supports HDMI 1.4.
• HDCP compliant.
• Support DVI device with DVI to HDMI adapter.
• Plug-and-play - no setup required.
• Metal casing design and overall shielding without signal interference.
• LED indicates signal /power mode.
SPECIFICATIONS
Power requirement 5V DC @ 2A
Output DDC signal 5 Volts p-p (TTL)
Max baud rate 10.2Gbps
Max bandwidth 340MHz
Deep Colour 36 bit
Max Single Link Range 3840x2160
Dimensions 270 x 130 x 20mm
Weight (not inc PSU) 1.08kg
Operating Temperature 0oC to +70oC
Operating Humidity 10% to 85% RH (no condensation)

INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF ELECTRICAL &
ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical & Electronic
Equipment (WEEE). Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used. Contact your local
authority for details of recycling schemes in your area.
Made in China. PR2 9PP
Man Rev 1.0
MAINTENANCE
• Clean the outside casing with a soft cloth lightly moistened with mild soap and water.
Never use any abrasive or solvents.
• Do not allow moisture to enter the casing.
