PRO SIGNAL PSG3057 User manual

PSG3057
HDMI 2.0 2x1 SWITCHER

WHAT’s IN THE BOX
OVERVIEW
IMPORTANT SAFETY INFORMATION
INSTALLATION
• This is a high performance mini HDMI Amplier Switcher with both key-press
switching function, remote control and also intelligent function.
• When the power supply of the source equipment is switched on, this device will
respond automatically.
• The HDMI Amplier Switcher routes high denition video (in multiple resolutions up to
1080p) and digital audio from any one of the sources to a high denition display unit.
• All high denition video source inputs are connected simultaneously, compatible with
DVD, Satellite Receiver, Set-top Box, DV Camera, A/V Receiver and other HDMI
enabled device etc.
• If the power supply to the source device is left on when in standby mode, this switcher
will not operate intelligently but will require manual operation using remote control or
panel key press.
• Main unit.
• PSU
• IR extender
• Remote control
• User Manual.
Please read these instructions carefully before use and retain for future reference.
• When using electrical appliances basic safety precautions should always be followed.
• Check that the voltage indicated on the rating plate corresponds with that of the local
network before connecting the power supply to the mains power supply.
• Please make sure all devices you wish to connect have been powered off.
• Connect the source devices to the switcher using appropriate HDMI cable (Max 5m).
• Connect the HDMI output to the display (Max 5m).
• Two input sources and one output display can be connected.
• Connect the IR extender receiver to the switcher.
• Connect the PSU output to the switcher and plug into the mains supply and turn the
power on.
• Always disconnect the power to the switcher before making or removing any
connections including the IR extender receiver.
IR Ext ------------------------------IR Receiver Extension Port
IR -------------------------------------------------IR Receiver Port
L1-L2 -----------------------------------HDMI Input1-2 Indicator
SELECT -----------------------------------Input Selector button
POWER ------------------------------------------Power Indicator
DC/5V --------------------------------------DC Power Input Port
HDMI OUTPUT ------------------------------HDMI Output Port
HDMI INPUT1-2 ------------------------------HDMI Input Ports

SPECIFICATIONS
FEATURES
Signal Inputs/Output
Input DDC Signal 5 volts p-p (TTL)
Maximum Single Link Range 3840x2160p
Output Video HDMI
Operating Frequency
Vertical Frequency Range 50/60Hz
Video Amplier Bandwidth 18Gbps/600MHz
Resolutions (HDTV)
Interlaced (50&60Hz) 480i, 576i, 1080i
Progressive (50&60Hz) 480p, 576p, 720p, 1080p
Power and Environment
Dimensions 100×48×25mm
Weight 130g
External Power Requirements 5V DC @ 1A
Operating Temperature 0oC to +70oC
Operating Humidity 10% to 85% RH (no condensation)
• Fully HDMI 2.0 specication compliant compatible with source device and high
denition display device, such as DVD and HDTV which have HDMI Ports or digital
ports and are compliant with HDCP 2.2 protocol and DVI 1.0.
• Support 3D frame sequential video format up to 1080p@60Hz.
• Support high resolution VESA mode video format up to QSXGA@60Hz and up to
4k2k@30Hz with 24bit RGB/YcbCR 4:4:4/YCBCR4:4:4, and up to 4k2k@60Hz with
12bit YCBCR 4:4:4.
• Supports LPCM 7.1CH, Dolby True HD, and DTS-HD Master Audio.
• Metal casing design and overall shielding without signal interference.
• LED indicates signal and power mode.

INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF ELECTRICAL &
ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical & Electronic
Equipment (WEEE). Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used. Contact your local
authority for details of recycling schemes in your area.
Made in China. PR2 9PP
Man Rev 1.0
MAINTENANCE
• Clean the outside casing with a soft cloth lightly moistened with mild soap and water.
Never use any abrasive or solvents.
• Do not allow moisture to enter the casing.
