PROAIM CT-CMCL-01 User manual

1
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Camera Mount Clamps for Proaim Alpha
Stand (CT-CMCL-01)
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
What’s In The Box
Camera Mount Clamps for Alpha Stand
2 x Allen Key
(3/16”, & 4mm)
Assemb ly Manua l

2
Camera Mount Clamps Setup
• Open the Clamp by loosening its ratchet knob.
as shown in the image.
• Remove the bush from inside the Clamp.
Feature: Two mounng Clamps vercally aach
to your rod and provide a mount for a separately
available mounng rod and horseshoe camera
mount, allowing you to form a camera mounng
system.
• Mount the Clamp on the Alpha stand
(Not Included).
NOTE: The Clamp can slide up/down and rotate
360° while securely clamped to the mast of your
stand, ensuring a solid aachment with its
locking knobs.
• Aer mounng the Clamp, secure it by
ghtening the ratchet knob.
• Repeat the same process with the second
Clamp.
NOTE: Locking knob secures the stand in place,
ensuring strength with a high level of safety.
• Pull and loosen the second ratchet knob of the
Clamp and insert the rod (Not Included) in it.
• Insert rod in the second clamp.
NOTE: The Clamps incorporate 1/4"-20 and 3/8"-
16 mounng threads for accessory mounng.

3
Eortless Movement Camera Mount Clamps Slides Up or Down
Camera Mount Clamps 360° Rotaon

4
• Aer inserng the rod, properly secure it using
the ratchet knob, as shown in the image.
• Pull and loosen the ratchet knob of the
Horseshoe mount (Not Included).
• Slide the Horseshoe mount (Not Included) into
the rod and ghten the ratchet knob to secure
it.
• Mount the Mitchell plate mount
(Not Included) on the Horseshoe mount by
matching their threads and inserng bolts in
the threads.
• Aer inserng the bolts, ghten the bolts us-
ing the Allen key to secure the Mitchell plate.
• Now, loosen and remove the castle ring of the
uid head (Not Included).
• Aer removing the Castle ring, mount the uid
head on the Mitchell plate.
• Aer mounng the Fluid head (Not Included),
re-insert the castle ring from the boom, as
shown in the image.

5
• Properly ghten the Castle ring to completely
secure the uid head (Not Included).
• Press the knob of the Fluid head and remove
the top plate.
• Aer removing the plate, aach it to the
Camera (Not Included) by aligning their
threads.
• Aer aaching the plate, ghten the screws
using a screwdriver.
• Now, slide the Camera onto the uid head.
• Aer mounng the Camera (Not Included),
press the locking lever of the uid head to
secure it in its place, as shown in the image.
• The Camera is properly mounted.
• The setup is ready to use.

6
YOUR PROAIM CAMERA MOUNT CLAMPS FOR PROAIM ALPHA STAND
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and
evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our utmost
support and care unl you use our product.
