PROAIM DL-PLRS-P01 User manual

1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Polaris Pro Low-Prole Video Camera Dolly (DL-PLRS-P01)
Assembly Manual
2 x End Spacers
Proaim Polaris Pro
Low-Prole Middle Support
Low-Prole Knob

Polaris Pro Camera Dolly Setup
2
 Loosen the knob of the end spacers of the
Polaris pro camera dolly and mount it on the
light stand (Not Included).
NOTE: It comes with end-spacers that mount on
C-stands & tripods in seconds, allowing you to
start lming in a ash.
 After mounting the end spacers on the stand,
properly tighten it with the knob. Repeat the
same process to insert the second-end spacer.
 Loosen both the knobs of the clamp holder in
the end spacers, as shown in the image.
 After inserting the square speed rails
(Not Included) into the clamp holder, tighten
the knob of the clamp holder to secure the
assembly.
NOTE: The dolly has eight in-line skate wheels
that run smoothly on circular, triangular, and
square-speed rails and at surfaces.
 Now place the Polaris Pro dolly onto the
Square Speed rails (Not Included). Make sure
all wheels are aligned correctly on the track
and dolly runs smoothly.
Assembling of End Spacers

3
 Tighten the assembly from the bottom of the
Polaris Pro dolly using the locking knob of the
fluid head (Not Included).
 Now, aer mounng the Low-Prole Middle
Support, properly secure it by re-ghtening
the knob. Then align the center part and
aach it to the center support of the track.
 Remove the plate by pushing the pin of the
fluid head (Not Included), as shown in the
image.
 Remove the uid head (Not Included) by
loosening the locking knob and then insert it
into the canter bowl adapter of the Polaris Pro
Dolly.
 Align and place the Polaris Pro dolly onto the
Square Speed Rails (Not Included).
 After loosening the knob of the Low-Profile
Middle Support, mount it onto the C-stand
(Not Included).
Assembling of Fluid Head

4
 Align and place the wheels of the Polaris Pro
Dolly onto the speed rail track (Not Included).
 Now mount the camera (Not Included) onto
the fluid head (Not Included) by sliding.
 Secure the assembly with the help of the
locking knob of the fluid head.
 Fluid head (Not Included) plate has now been
properly aached to the camera
(Not Included).
Camera Mounng Setup
 Attach the plate of the fluid head
(Not Included) to the bottom of the camera
(Not Included), and then tighten it using the
screw driver.
Assembling of Speed rail track

5
 Secure and tighten the assembly using the
Low-Profile knob at the bottom of the dolly.
 Loosen and remove the Low-Profile knob of
the Polaris Pro dolly.
 Align and mount the Spinhawk (Not Included)
to the center bowl of the Polaris Pro dolly, as
shown in the image.
NOTE: Mount your uid head/gimbal/camera
setups directly to the Mitchell plaorm with the
help of the four-keyway locang slots without
sacricing stability. Mulple 1/4"-20 and 3/8"-16
threaded holes on the dolly plaorm allow you
to mount varied accessory conjuncons.

6
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
YOUR PROAIM POLARIS PRO LOW PROFILE VIDEO CAMERA DOLLY
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
