PROAIM ST-LHWK-01 User manual

1
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Hawk Lite Body Support Stabilizing Vest Rig (ST-LHWK-01)
Assembly Manua l
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
What’s In The Box
Shoulder Strap
Bungee rubber strap Bag
Jacket 1 x T-Type
Allen key-5mm

2
Hawk Lite Body Support Rig Setup
 Wear the jacket and buckle up from the
waist.
 Now, loosen or ghten the adjustable straps
around the chest according to your comfort,
as shown in the image.
 Use the strap to properly adjust the chest
Velcro.
 Loosen or ghten the adjustable straps
around the waist according to your comfort,
as shown in the image.
 Now, secure the bungee rubber strap and
hook by locking them.
 Aach the Bungee rubber straps with the
hook present at the back of the jacket, as
shown in the image.
NOTE: The bungee rubber strap is the
connector between the arm and the back rod.

3
 Follow the same process to aach the second
arm.
NOTE: Bungee rubber straps linked to the
exible arms and the starring should be
securely fastened to the rig using the included
Sca clamps, which clamp to the unique frog
clamps.
 Securely re-ghten the rod clamp with the
Allen key.
 Loosen the rod clamp to properly posion the
Bungee rubber strap using the Allen key.
 The height of the rod holding the camera can
be adjusted using the provided knob as per
your shoong requirement.
 Follow the same process to posion the
second Bungee rubber strap.
 The extension arm's posion can be adjusted
using the knob present on it.

4
 Loosen and later re-ghten the knob aer
adjusng the height of the extension arm.
 Open the clamp by loosening it, as shown in
the image.
 Now, detach both arm clamps by pressing the
frog clamps.
 Follow the same process for the second
extension arm, as shown in the image.
 Aach the opened clamp with the star ring
(Not Included) and properly ghten it.
 Follow the same process for aaching the
second clamp with the star ring
(Not Included).

5
YOUR PROAIM HAWK LITE BODY SUPPORT STABILIZING VEST RIG
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
 Now, aach the frog clamps of both the arms
with the hook present on the star ring
(Not Included).
 The starring (Not Included) has been
appropriately aached to the camera
(Not Included).
NOTE: It also features seamless weight
adjustment for payloads of up to 5kg /11lb-
15kg /33lb via easy extension and retracon of
the two provided telescopic arms.
 Remove the quick-release plate
(Not Included) by loosening its knob for
aaching the star ring (Not Included) to a
gimbal (Not Included).

6
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and
evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
