PROAIM P-WNG Manual instruction

PROAIM WING HANDHELD STEADYCAM 2
IT IS IMPORTANT THAT YOU READ AND UNDERSTAND THIS GUIDE BEFORE ATTEMPTING TO
ASSEMBLE AND USE YOUR NEW PROAIM WING HANDHELD STEADYCAM.
SHOULD YOU NEED ADDITIONAL INFORMATION, TECHNICAL ASSISTANCE IS AVAILABLE 'ON
LINE' BY CONTACTING OUR SALES REPRESENTATIVE.
INTRODUCTION
The new HAND HELD PROAIM WING with new design of weight disc and gimbal. The PROAIM
WING is a lightweight stabilizer for cameras up to 3.5kg. The Quick release plate of the PROAIM
WING HANDHELD STEADYCAM is High quality quick release universal system for camera.
WHAT’S IN THE BOX
Please inspect the contents of your shipped package to ensure you have received all that is pic-
tured and listed below. The grey foam shipping /storage container has been especially designed
to protect your purchase while in transit and is a good place to keep your PROAIM WING
HANDHELD STEADYCAM when not in use.
CONTENTS OF SHIPPING BOX :
 PROAIM Wing Handheld stabilizer
 Quick Release plate with adapter
 4 x Counter Weight discs
 Weight Shank
 Docking stand
 Handle
 Accessory Mounng
plate
 Adapter for Accessory
Mounng plate
 Storage Case
ASSEMBLING THE PROAIM WING HANDHELD STEADYCAM
 Screw-in the handle to the stabilizer Arm.
 Now loosen the red knob as shown in the image, remove the camera mounng plate and se-
cure your camera on it with the help of screw driver.

PROAIM WING HANDHELD STEADYCAM 3
If you wish to aach provided Quick release on the wing steadycam, follow these steps:
 Loosen the ratchet knob and release the QR plate by pressing the pin. Aach the camera
plate of Wing Stabilizer to the base of QR Adapter.
 Re-aach the camera plate to Stabilizer and secure it by ghtening the red knob as shown in
the image.
 Secure your camera on QR plate, insert the camera set up to QR Adapter and ghten the
ratchet knob to secure.
 Now aach the weight disc to weight shank as per your requirement. then loosen the red
knob, insert the weight shank to the base of stabilizer and ghten the knob to secure.
 Take the accessory mounng plate adapter & knob, aach accessory mount plate to stabilizer
with the help of adapter and knob. Tighten it properly to secure.

PROAIM WING HANDHELD STEADYCAM 4
 Place the handle of stabilizer on provided docking stand for balancing.
 Camera plate has also back & forth adjustment for
quick balancing.
 You can adjust the handle back & forth for balancing.
MAINTENANCE
Bearing Maintenance
The Main Bearing on your PROAIM WING STABILIZER is of metal construcon and parally en-
closed by the Bearing assembly.
If aer a period of me your bearings don’t turn smoothly, lubricate with a minimum of light ma-
chine oil. Light lubricang oil can also be used on the Yoke and Handle Bearings.
Be sure to keep oil away from your camera, & clean up any over spill.
Cleaning
Do not use solvents or harsh cleaners of any kind on your PROAIM WING STABILIZER.
If the unit becomes dirty, use a damp so cloth or sponge and a mild detergent to gently clean
external parts.
Storage
Should you need to store your PROAIM WING STABILIZER for a long period of me then place the
unit upright in a dry or low to normal humidity area whenever possible. If you are unable to nd
this kind of environment then we suggest you store the unit in an airght plasc container or bag.
Standing the unit upright is preferred as it alleviates stress on the system.

PROAIM WING HANDHELD STEADYCAM 5
Pracce makes perfect - Walking the line
Pracce this simple exercise to master your PROAIM WING STABILIZER
with professional results.
Using masking or gaers tape, create a cross mark on a at and even wall.
The mark becomes your framing center. On the oor leading up to the
cross mark, lay a straight tape line of about 20 feet. Pracce walking the
line, while keeping the cross mark center framed and in focus. With a bit
of eort, dramac uid like movements will become second nature and
provide producon value to all your set ups.
Note:
The PROAIM WING STABILIZER doesn’t work under water, nor is it waterproof. Avoid direct expo-
sure to rain, water spray or any harsh environment.
The bearings are not sand proof. Avoid geng dirt or sand in them.
YOUR PROAIM WING HANDHELD STEADYCAM
ALL DRESSED UP AND READY TO GO
WARRANTY
We oer a limited me warranty for our products. For Mechanical products we provide a 6
month warranty & for electronic products we provide a 3 month warranty from the date of pur-
chase.

PROAIM WING HANDHELD STEADYCAM 6
We will repair or replace your product, free of charge, in the event of a defect in materials or
crasmanship obtained during normal use or handling based on the user manual. Please note
that we will not cover any shipping costs for returning the product to us. If any VAT or import du-
es are applied to the return, we will also charge these costs to the customer.
The warranty does not include, by the way of example, damage caused by products that we do-
not supply or from mishandling in transit, accident, misuse, neglect, lack of care of the product ,
or service by anyone other than our company.
We are not liable for incidental or consequenal damages resulng from the use of the unit or
occurring due to any breach of this warranty.
Replacement parts of the product will be provided at nominal cost (covering the cost price of the
replacement parts only) to the customers aer the Warranty Period has expired. We will cover
the complete cost of sending replacement parts within the warranty period. Aer that, Nominal
cost of the product & Actual shipping cost will be charged.
Donot send the unit to us without rst geng a response and geng the approval to send back
the item.
In case of any kind of dissasfacon, we urge you to Contact us immediately and we shall do our
best to help you out.
For any other assistance you can reach us via email.
