probst KIG II User manual

5720.0208
V1
GB
Operating Instructions
Translation of original operating instructions
Cone Insert Clamp
KIG II

Bitte beachten Sie, dass das Produkt ohne vorliegende Betriebsanleitung in Landessprache nicht
eingesetzt / in Betrieb gesetzt werden darf. Sollten Sie mit der Lieferung des Produkts keine
Betriebsanleitung in Ihrer Landessprache erhalten haben, kontaktieren Sie uns bitte. In Länder der
EU / EFTA senden wir Ihnen diese kostenlos nach. Für Länder außerhalb der EU / EFTA erstellen wir
Ihnen gerne ein Angebot für eine Betriebsanleitung in Landessprache, falls die Übersetzung nicht
durch den Händler/Importeur organisiert werden kann.
Please note that the product may not be used / put into operation without these operating
instructions in the national language. If you did not receive operating instructions in your national
language with the delivery of the product, please contact us. In countries of the EU / EFTA we will
send them to you free of charge. For countries outside the EU / EFTA, we will be pleased to provide
you with an offer for an operating manual in the national language if the translation cannot be
organised by the dealer/importer.

Contents
2 / 17
5720.0208
V1
GB
Contents
1EC-Declaration of Conformity ............................................................................................................................... 3
2General.................................................................................................................................................................... 4
2.1 Authorized use................................................................................................................................................4
2.2 Survey and construction ................................................................................................................................ 5
2.3 Technical data.................................................................................................................................................6
2.4 Safety symbols................................................................................................................................................6
2.5 Explanation of basic concepts .......................................................................................................................6
2.6 Definition skilled worker / specialist ..............................................................................................................6
2.7 Safety Marking................................................................................................................................................ 7
3Safety...................................................................................................................................................................... 8
3.1 Personal safety requirements ........................................................................................................................8
3.2 Protective equipment.....................................................................................................................................8
3.3 Accident prevention .......................................................................................................................................8
3.4 Function Control.............................................................................................................................................8
3.4.1 General .......................................................................................................................................................8
3.5 Safety procedures ..........................................................................................................................................9
3.5.1 Lifting devices and forklift trucks .............................................................................................................9
3.5.2 General .......................................................................................................................................................9
3.5.3 Unauthorized alterations ..........................................................................................................................9
4Installation.............................................................................................................................................................10
4.1 Mechanical connection ................................................................................................................................ 10
4.1.1 Standard flange plate .............................................................................................................................. 10
4.1.2 Lifting eye / Suspension bolt ................................................................................................................... 10
4.1.3 Fork sleeves (optional) ............................................................................................................................. 11
5Operation ..............................................................................................................................................................12
5.1 Device operation ...........................................................................................................................................12
5.2 Picture of the automatic release ..................................................................................................................13
6Maintenance and care .......................................................................................................................................... 15
6.1 Maintenance ..................................................................................................................................................15
6.2 Mechanical .....................................................................................................................................................15
6.3 Trouble shooting .......................................................................................................................................... 16
6.4 Repairs .......................................................................................................................................................... 16
6.5 Safety procedures ........................................................................................................................................ 16
6.6 Hints to the type plate...................................................................................................................................17
6.7 Hints to the renting/leasing of PROBST devices ..........................................................................................17

EC-Declaration of Conformity / UKCA-Declaration of Conformity
Manufacturer:
Probst GmbH
Gottlieb-Daimler-Straße 6
71729 Erdmannhausen, Germany
[email protected]
www.probst-handling.com
Importer:
Probst Ltd
Unit 2 Fletcher House
Stafford Park 17
Telford Shropshire TF3 3DG, United Kingdom
www.probst-handling.co.uk
[e-mail]
The machine described above complies with the relevant requirements of the following EU directives:
The object of the declaration described above is in conformity with the relevant UK-Regulations and UK-Guidelines:
EC-machinery directive 2006/42/EC (Reference: OJ L 157, 09.06.2006)
UK-Regulation: Supply of Machinery (Safety) Regulations 2008 (SI 2008 No. 1597)
The following standards and technical specifications were used:
DIN EN ISO 12100
Safety of machinery - General principles for design - Risk assessment and risk reduction
UK-Regulation: BS EN ISO 12100-1:2003+A1:2009
DIN EN ISO 13857
Safety of machinery - safety distances to prevent hazard zones being reached by upper and lower limbs.
UK-Regulation: BS EN ISO 13857:2019
Authorized person for EC-documentation:
Name: Jean Holderied
Address: Probst GmbH; Gottlieb-Daimler-Straße 6; 71729 Erdmannhausen, Germany
Authorized person for UK-documentation:
Name: Nigel Hughes
Address: Probst Ltd ; Unit 2 Fletcher House; Stafford Park 17; Telford Shropshire TF3 3DG, United Kingdom
Signature, information to the subscriber:
Erdmannhausen, 02.08.2021..........................................................................
(Eric Wilhelm, Managing director)

General
4 / 17
5720.0208
V1
GB
2General
2.1 Authorized use
The device (KIG 2) is only suitable for symmetrical and asymmetrical cones with a cover hole diameter of 625 - 1000
mm.
Take care that the capacity and the gripping range of the device (KIG 2) is not exceeded.
This device (KIG 2) is specially designed for heavy and duty work with fork lift trucks or cranes.
The gripping goods (cones) have to be cured enough to resistant the necessary gripping force of the device.
This device is series equipped with the
following specifications:
●Crane eye for attaching the crane hook
●Fork sleeves for fork lift
●Automatic release (full automatic change-over from “full” to
“empty”)
●Exchangeable rubber metal bars for the gentle handling of cones
●The device is only designed for the use specified in this documentation.
●Every other use is not authorized and is forbidden!
●All relevant safety regulations, corresponding legal regulations, especially regulations of the declaration
of conformity, and additional local health and safety regulations have to be observed.
Prior to every operation the user must ensure that:
●The equipment is suited to the intended operation, the functioning and the working condition of the
equipment is examined, and the load is suitable to be handled.
Any doubts about instructions should be raised with the manufacturer prior to use.
ATTENTION: The use of this device is only permitted in proximity to the ground.
NOT ALLOWED ACTIVITIES:
Unauthorized alterations of the device and the use of any self-made additional equipment could cause
danger and are therefore forbidden!
Never exceed the carrying capacity/working load limit (WLL) and the nominal width/gripping range of the
device.
All unauthorized transports with the device are strictly prohibited:
The transport of people and animals.
The gripping and transporting of other loads and materials than described in this operating instructions.
Never suspend any goods with ropes, chains or similar at the device.
Gripping of gripping goods with packaging foil, because they could fall down.
The gripping of gripping goods with treated surfaces (such as painting/varnish, coating or the like), because
they could fall down. Treated surfaces lead to a reduction in the coefficient of friction between the
grippers and the gripping good.

General
5 / 17
5720.0208
V1
GB
2.2 Survey and construction
Fork sleeves
Rectangular
tube
Rubber gripper
Automatic release
Flange plate
Suspension lug
for crane hook
Kardan
Suspension

General
6 / 17
5720.0208
V1
GB
2.3 Technical data
Type:
ø-Range [mm]
Capacity [kg]
Dead weight [kg]
KIG 2
625 –1.000
2.000
300
2.4 Safety symbols
Danger to life!
Identifies imminent hazard. If you do not avoid the hazard, death or severe injury will result.
Hazardous situation!
Identifies a potentially hazardous situation. If you do not avoid the situation, injury or damage to property
can result.
Prohibition!
Identifies imminent a prohibition. If you do not avoid the prohibition, death and severe injury, or damage to
property will result.
Important information or useful hints for the usage.
2.5 Explanation of basic concepts
Gripping range:
●specify the minimum and maximum product measurements of the gripping good, which
can be gripped with this device.
Gripping good(s):
●is the product, which will be gripped or transported.
Opening width:
●consists of the gripping range and the measure to drive over the gripping good.
gripping range + measure to drive over the gripping good = opening width
Immersion depth:
●is the maximum gripping height of gripping goods, conditional of the height of the
gripping arms of the device.
Device:
●is the description for the gripping device.
Product dimensions:
●Are the dimensions of the gripping good (e.g. length, breadth, height
of the product).
Dead weight:
●is the own weight (without gripping good) of the device.
Carrying capacity/working
load limit (WLL*):
●specify the maximum possible load of the device (for lifting of gripping goods).
*= WLL (english:) Working Load Limit
2.6 Definition skilled worker / specialist
Only skilled workers or specialists are allowed to carry out the installation-, maintenance-, and repair work on this device!
Skilled workers or specialists must have for the following points (if it applies for this
device), the necessary professional knowledge.
●for mechanic
●for hydraulics

General
7 / 17
5720.0208
V1
GB
●for pneumatics
●for electrics
2.7 Safety Marking
PROHIBITION SIGN
Symbol
Meaning
Order-No.:
Size:
It is not allowed to be under hanging loads. Danger to life!
2904.0210
2904.0209
2904.0204
30 mm
50 mm
80 mm
WARNING SIGN
Symbol
Meaning
Order-No.:
Size:
Danger of squeezing the hands.
2904.0221
2904.0220
2904.0107
30 mm
50 mm
80 mm
REGULATORY SIGN
Symbol
Meaning
Order-No.:
Size:
Each operator must have read and understood the operating
instructions (and all safety instructions).
2904.0665
2904.0666
30 mm
50 mm
OPTIONAL
Be sure that the fork sleeves are mechanically fixed (with locking
screw and safety chain or rope) to the lifting device/carrier.
2904.0223
2904.0222
50 mm
80 mm

Safety
8 / 17
5720.0208
V1
GB
3Safety
3.1 Personal safety requirements
●Each operator must have read and understood the operating instructions (and all safety instructions).
●Only qualified, authorized personal is allowed to operate the device and all devices which are connected
(lifting device/carrier).
The manual guiding is only allowed for devices with handles.
3.2 Protective equipment
<
The protective equipment must consist, according to the safety regulations
of the following parts:
●Protective clothing
●Safety gloves
●Safety shoes
3.3 Accident prevention
●The workplace has to be covered for unauthorized persons, especially children.
●Take care in case of thunderstorm!
●The workplace has to be sufficiently illuminated.
●Take care with handling wet, dirty and not solidified components.
●The working with the device in case of atmospheric editions under 3 °C (37,5 °F) is forbidden!
Because the goods could be fall down caused by dampness or freezing.
3.4 Function Control
3.4.1 General
●Before using the device check the functions and the working condition.
●Maintenance and lubrication are only permitted when device is shut down!
●Do not use the device, until all faults which can cause safety hazards are removed.
●If there are any cracks, splits or damaged parts on any parts of the device, immediately stop using it.
●The operating instructions must be available at the workplace every time.
●Do not remove the type plate of the machine.
●Unrecognisable information signs (such as regulatory or prohibition signs) must be replaced.

Safety
9 / 17
5720.0208
V1
GB
3.5 Safety procedures
3.5.1 Lifting devices and forklift trucks
The lifting device / forklift truck including truss have to be in good, safe working condition.
Only authorized and qualified persons are allowed to operate the lifting device / forklift truck.
Never exceed the maximum allowable carrying capacity/working load limit (WLL) of the lifting device /
forklift truck!
3.5.2 General
●Do not swing it over people heads.
●The manual guiding of the device is only allowed at the handles.
●The operator is not allowed to leave the control unit as long as the device loaded with load. The load must
always be in the range of vision of the operator.
●While using the device the stay of persons in the working area is forbidden. Except it is indispensable, caused
of the way of using the device, e.g. if the device must be leaded by hand.
●The jerky lifting and lowering of the device with and without load. e.g. caused through driving fast with the
lifting equipment/carrier over uneven grounds is forbidden. Because the gripping good could fall down.
Unchecked movements of the device.
●The stay under lifted load is forbidden.
Danger to Life!
●Do not pull out stuck or tightened loads with the
device.
●Do not lift any components off-centre, because
that could fall down.
●The device should not be opened if the opening
path of the gripping arm is blocked by a resistance
(e.g. other concrete blocks or the like)!
●Never exceed the carrying capacity / working load
limit (WLL) and the nominal width of the device.
●Never pull or drag loads sideways. Otherwise parts
of the device could be damaged.
(see Fig. A )
Fig. A
3.5.3 Unauthorized alterations
All unauthorized alterations of the device and the use of any self-made additional equipment could cause
danger and are therefore forbidden!

Installation
10 / 17
5720.0208
V1
GB
4Installation
4.1 Mechanical connection
Use only original accessories, in case of doubt consult the manufacturer.
Take care that the carrying capacity / working load limit (WLL) of the lifting device/carrier is not exceeded,
through the load of the device, the attaching devices (turning device, fork sleeves etc.) and the additional
load of the gripping goods!
Mechanical gripping devices always have to be gimballed, so they can swing freely in any position.
In no case it is allowed to mount mechanical gripping devices with lifting devices/carriers in a rigid way!
Break of the suspension may occur within short time. Death, severe injuries and material damage can
result!
4.1.1 Standard flange plate
The device is attached to the lifting equipment/carrier with a standard flange plate or a custom made flange
plate connection.
Attaching the device to the lifting equipment/carrier take care that all local safety regulations are observed.
4.1.2 Lifting eye / Suspension bolt
The device is equipped with a lifting eye / suspension bolt and can be mounted on various carrier /
lifting devices.
Take care that the lifting eye / suspension bolt is safely joined with the lifting tackle (e.g. crane hook,
belt) and cannot slide down.

Installation
11 / 17
5720.0208
V1
GB
4.1.3 Fork sleeves (optional)
●To establish a mechanical connection between the fork lift and the fork sleeve you have to put the fork into
the fork sleeve and fix it with the locking bolt or with a chain/rope, connected to the eyelet on the fork
sleeves and the lift frame.
●It is definitely necessary to establish this connection. Otherwise the device could slide form the forks.
DANGER OF ACCIDENTS!
1
Fork (of fork lift truck)
2
locking bolt
3
Fork sleeve
4
Chain/rope
Adjustable
spacer
Adjustable spacer

Operation
12 / 17
5720.0208
V1
GB
5Operation
5.1 Device operation
●Connect the device (KIG 2) with the lifting equipment. The lifting equipment must be adjusted with carrying capacity of
the device (KIG 2)!
●Move the device (KIG 2) slowly down into the gripping good (cone), until the rectangular tube lays on the gripping
good (cone). Take care of stirrups!
●Lifting the device (KIG 2), the automatic release unlocks and the gripping good (cone) can be lifted.
●Now transport the gripping good (cone) carefully to the destination place.
●Setting down the device (KIG 2) the automatic release locks and the device (KIG 2) can be lifted without the gripping
good (cone).

Operation
13 / 17
5720.0208
V1
GB
5.2 Picture of the automatic release
The device is mounted with a automatic release, that means the opening and closing of the gripping arms results through
the set down and lifting of the device.
Pictures the positions of the automatic release


A
●Device is lifted through the
lifting equipment/carrier.
●Gripping arms are opened.
●Device is set up on the gripping
good.
●Gripping arms are opened.
●Device is lifted through the lifting
equipment/carrier.
●Gripping good is clamped and can be
transported to the destination.
B

/
●With faulty switching, the
change-over switch must be
pushed back manually (e.g.
with a screwdriver). 1)
●Device is set down with the
gripping good (on the ground).
●Gripping arms are opened.
●Device is lifted through the lifting
equipment/carrier.
●Gripping arms are opened.
(laydown position of the device on the
ground)
1) Otherwise there may be faulty switching and when setting down the load this can cause deformation or
damage of the automatic release!
The jerky lifting and lowering of the device with and without load. e.g. caused through driving fast with the
lifting equipment/carrier over uneven grounds is forbidden

Operation
14 / 17
5720.0208
V1
GB
When replacing a defective automatic release, it is essential
to ensure that the slots of the two clamping pins always
point downwards.
The position of the slots must not be above or center,
otherwise there is a risk that the automatic release may jam
when switching!

Maintenance and care
15 / 17
5720.0208
V1
GB
6Maintenance and care
6.1 Maintenance
To ensure the correct function, safety and service life of the device the following points must be executed in
the maintenance interval.
Used only original spare parts, otherwise the warranty expires.
All operations may only be made in closed state of the device!
For all operations you have to make sure, that the device will not close unintended. Danger of injury!!!
6.2 Mechanical
SERVICE INTERVAL
Maintenance work
First inspection after
25 operating hours
●Control and tighten all screws and connections.
(The implementation is only allowed by an expert).
All 50 operating hours
●Tighten all screws and connections (take care that the tightening torques according to
the property class of the screws are observed).
●Check all existing safety elements (such as linchpins) for perfect function and replace
defective safety elements. 1)
●Check all joints, bolts, guidance’s and gears for correct function, if necessary adjust or
replace it.
●Check all grippers (if available) for signs of wear.
●Grease all slidings (if available) when the device is in opened position with a spatula.
●Grease all grease nipples (if available) with a grease gun.
Minimum 1x per year
(at rough conditions shorten the
interval)
●Check of all the suspension parts, bolts and straps. Check for corrosion and safety by an
expert.
1)
AUTOMATIC-RELEASE
Never grease or oil the automatic-release!
Clean with high-pressure cleaner when the automatic-release is dirty.

Maintenance and care
16 / 17
5720.0208
V1
GB
6.3 Trouble shooting
ERROR
CAUSE
REPAIR
The clamping-power is not big enough,
the load is slipping out
(optional)
The grippers are worn
Replace the grippers
(optional)
The maximum load is exceed
Reduce the weight of. the load
(Adjustment of the opening width)
(optional)
The actual opening width is not
correct
Adjust the opening width
according to the load you want to
transport
(Property of material)
The surface of the material is dirty
or the material is not suitable /
allowed for this device.
Check the surface of the material
or ask the manufacturer, if you the
material is allowed for this device.
Unbalanced load
The device is not loaded
symmetrically
Adjust the position of the load
(Adjustment of the opening width)
(optional)
The adjustment of the opening
width is not symmetrical.
Correct the adjustment of the
opening width
Automatic release does not work
mechanical (optional)
Automatic release does not work
Clean automatic release with high
pressure-cleaner
Oil the automatic release (never
with grease)
Correct faulty switching (see
chapter “Picture of the automatic
release”)
Change the inset of the automatic
release
6.4 Repairs
●Only persons with the appropriate knowledge and ability are allowed to repair the device.
●Before the device is used again, it has to be checked by an expert.
6.5 Safety procedures
It is the contractor’s responsibility to ensure that the device is checked by an expert in periods of
max. 1 year and all recognized errors are removed (see BGR 500).
The corresponding legal regulations and the regulations of the declaration of conformity have to be
observed!
We recommend that after checking the device, the badge “Safety checked” is put on the device.
(Order-No.: 2904.0056+inspection sticker with date).
●You can receive these badges from us.

Maintenance and care
17 / 17
5720.0208
V1
GB
The check by an expert must be proved!
Device
Year
Date
Expert
Company
6.6 Hints to the type plate
Type, serial-number and production year are very important for the identification of your device. If you need
information to spare-parts, warranty or other specific details please refer to this information.
The maximum carrying capacity/working load limit (WLL) is the maximum load which can be handled with
the device. Do not exceed this carrying capacity/working load limit (WLL).
If you use the device in combination with other lifting equipment (Crane, chain hoist, forklift truck,
excavator) consider the deadweight of the device.
Example:
6.7 Hints to the renting/leasing of PROBST devices
With every renting/leasing of PROBST devices the original operating instructions must be included
unconditionally (in deviation of the users country's language, the respective translations of the original
operating instructions must be delivered additionally)!

400
122
1300
120
650
187
87
Bkl.
200
~ 1200
~ 642
463
Eigengewicht / Dead Weight:
Tragfähigkeit / Working Load Limit WLL:
lbs
lbs
kg /
Product Name:
kg /
Cone Insert Clamp KIG-II wih fork sleeves
~ 580
4.400
~ 260
2.000
4
3
C
B
A
B
D
F
7 5
1 3 5 7
F
4
2 6
8
E
D
8 6
C
E
1 2
A
Zust.
Gepr.
Erst.
Name
von
Blatt
Ers. f.
Ers. d.
Urspr.
Artikelnummer/Zeichnungsnummer
Benennung
© all rights reserved conform to ISO 16016
19.12.2017
19.12.2017 P.Hafenbrak
P.Hafenbrak
Koneninnengreifer KIG-II
Konus-Deckelöffnung 625 - 1.000 mm
Tragfähigkeit / WLL 2.000 kg
D57200208
57200067
1
1
Datum

siehe separate Liste
see separate list
siehe separate Liste
see separate list
siehe separate Liste
see separate list
siehe separate Liste
see separate list
47220121
40110119
40110059
57200139
4
3
C
B
A
B
D
F
7 5
1 3 5 7
F
4
2 6
8
E
D
8 6
C
E
1 2
A
Zust.
Gepr.
Erst.
Name
von
Blatt
Ers. f.
Ers. d.
Urspr.
Artikelnummer/Zeichnungsnummer
Benennung
© all rights reserved conform to ISO 16016
23.2.2018
23.2.2018 I.Krasnikov
I.Krasnikov
Koneninnengreifer KIG-II
Konus-Deckelöffnung 625 - 1.000 mm
Tragfähigkeit / WLL 2.000 kg
E57200208
57200067
1
1
Datum
