probst VM-301-K-PAVERMAX User manual

5150.0022+5150.0023 (41500820)
V3
GB
Operating Instructions
Translation of original operating instructions
Installation Machine
VM-301-PAVERMAX / VM-301-K-PAVERMAX (Joystick JMS)

Bitte beachten Sie, dass das Produkt ohne vorliegende Betriebsanleitung in Landessprache nicht
eingesetzt / in Betrieb gesetzt werden darf. Sollten Sie mit der Lieferung des Produkts keine
Betriebsanleitung in Ihrer Landessprache erhalten haben, kontaktieren Sie uns bitte. In Länder der
EU / EFTA senden wir Ihnen diese kostenlos nach. Für Länder außerhalb der EU / EFTA erstellen wir
Ihnen gerne ein Angebot für eine Betriebsanleitung in Landessprache, falls die Übersetzung nicht
durch den Händler/Importeur organisiert werden kann.
Please note that the product may not be used / put into operation without these operating
instructions in the national language. If you did not receive operating instructions in your national
language with the delivery of the product, please contact us. In countries of the EU / EFTA we will
send them to you free of charge. For countries outside the EU / EFTA, we will be pleased to provide
you with an offer for an operating manual in the national language if the translation cannot be
organised by the dealer/importer.

EC-Declaration of Conformity
1 / 36
5150.0022+5150.0023 (41500820)
V3
GB
Contents
1EC-Declaration of Conformity ............................................................................................................................... 2
2Safety...................................................................................................................................................................... 3
2.1 Safety symbols................................................................................................................................................ 3
2.2 Definition skilled worker / specialist .............................................................................................................. 3
2.3 Safety Marking................................................................................................................................................4
2.4 Personal safety requirements ........................................................................................................................8
2.1 Protective equipment.....................................................................................................................................8
2.2 Accident prevention .......................................................................................................................................8
2.3 Function Control.............................................................................................................................................8
2.3.1 General .........................................................................................................................................................8
2.3.2 Hydraulic.......................................................................................................................................................9
2.4 Safety procedures ..........................................................................................................................................9
2.4.1 Installation machine ....................................................................................................................................9
2.4.2 Safety procedures using the VM-301-PAVERMAX .................................................................................... 10
3General....................................................................................................................................................................11
3.1 Authorized use............................................................................................................................................... 11
3.2 Survey and construction ...............................................................................................................................13
3.3 Technical data................................................................................................................................................14
4Description and Operation...................................................................................................................................15
4.1 Daily checks....................................................................................................................................................15
4.1.1 Fuel level......................................................................................................................................................15
4.1.2 Motor-oil level.............................................................................................................................................15
4.1.3 Hydraulic-oil level....................................................................................................................................... 16
4.1.4 Cooling-water level .................................................................................................................................... 16
4.1.5 Main switch .................................................................................................................................................17
4.1.6 Accelerator..................................................................................................................................................17
4.1.7 Control displays.......................................................................................................................................... 18
4.2 Starting the engine....................................................................................................................................... 19
4.3 Driving with the VM-301-PAVERMAX ........................................................................................................... 19
4.4 Fixing of attachments....................................................................................................................................21
4.5 Transportation of the VM-301-PAVERMAX...................................................................................................21
4.6 Bypass-valve (towing the VM-301-PAVERMAX ).......................................................................................... 23
4.7 Long-term storage of VM-301-PAVERMAX .................................................................................................. 24
5Maintenance and care ......................................................................................................................................... 25
5.1 Maintenance ................................................................................................................................................. 25
5.2 MECHNICAL .................................................................................................................................................. 25
5.3 HYDRAULIC...................................................................................................................................................26
5.4 Recharching of the battery .......................................................................................................................... 28
5.5 Lubrication Chart .......................................................................................................................................... 29
5.6 Trouble shooting .......................................................................................................................................... 32
5.7 Repairs .......................................................................................................................................................... 33
5.8 Safety procedures ........................................................................................................................................ 33
5.1 Hints to the identification plate ...................................................................................................................34
5.2 Hints to the renting/leasing of PROBST devices .........................................................................................34

EC-Declaration of Conformity
2 / 36
5150.0022+5150.0023 (41500820)
V3
GB
1EC-Declaration of Conformity
EC-Declaration of conformity
Description:
Type:
Order-Nr.:
Installation Machine
VM-301-PAVERMAX / VM-301-K-PAVERMAX
(Joystick JMS)
5150.0022+5150.0023 (41500820 )
Manufacturer:
Probst GmbH
Gottlieb-Daimler-Straße 6
71729 Erdmannhausen, Germany
[email protected] www.probst-handling.de
The machine described above complies with the relevant requirements of the following EU directives:
EC-machinery directive 2006/42/EG
2014/30/EU (Electromagnetic compatibility)
The following standards and technical specifications were used in extracts:
DIN EN ISO 12100
Safety of machinery - General principles for design - Risk assessment and risk reduction (ISO 12100:2010)
DIN EN ISO 13857
Safety of machinery ― Safety distances to prevent hazard zones being reached by upper and lower limbs (ISO
13857:2008)
DIN EN 60204-1 (IEC 60204-1)
Safety of machinery, electrical equipment of industrial machines. Part 1: General requirements
Authorized person for EC-documentation:
Name: J. Holderied
Address: Probst GmbH; Gottlieb-Daimler-Str. 6; 71729 Erdmannhausen, Germany
Signature, informations to the subscriber:
Erdmannhausen, 25.06.2018..........................................................................
(M. Probst, Managing director)

Safety
3 / 36
5150.0022+5150.0023 (41500820)
V3
GB
2Safety
2.1 Safety symbols
Danger to life!
Identifies imminent hazard. If you do not avoid the hazard, death or severe injury will result.
Hazardous situation!
Identifies a potentially hazardous situation. If you do not avoid the situation, injury or damage to property can
result.
Prohibition!
Identifies imminent a prohibition. If you do not avoid the prohibition, death and severe injury, or damage to
property will result.
Important information or useful tips for use.
2.2 Definition skilled worker / specialist
Only skilled workers or specialists is it allowed to carry out the installation,- maintenance, - and repair work on these
device!
Skilled workers or specialists must have for the following points (if it applies for
these device), the necessary professional knowledge.
●for mechanic
●for hydraulics
●for pneumatics
●for electrics

Safety
4 / 36
5150.0022+5150.0023 (41500820)
V3
GB
2.3 Safety Marking
WARNING SIGN
Symbol
Meaning
Order-No.
Size [mm]
Any staying under suspended device with and without load
is strictly forbidden. Danger to life!
2904.0210
2904.0209
2904.0204
Ø 30
Ø 50
Ø 80
Prohibition! Do not open while the engine is running.
2904.0259
70x115
Attention! –Pull hand brake in idle machine time. To drive
release handbrake.
2904.0267
45x80
Max. 650 kg (1,430 lbs)VM-301-K
Maximum weight paver load 380 kg (840 lbs) (837,8 lbs)
with counterbalance 440 kg (970 lbs)
2904.0623
40x160
Max. 600 kg (1,320 lbs)VM-301
Maximum weight paver load 320 kg (710 lbs)
with counterbalance 380 kg (840 lbs)
2904.0616
40x160
Warning –Warming up time with half throttle before doing
any driving:
Temperature more than 10° C: 5 Min.
Temperature less than 10° C: 10 Min
2904.0243
150x55
Fill-in only diesel –NO bio-diesel!
2904.0483
16x130
It is forbidden to ride on the installation machine.
2904.0762
Ø 50

Safety
5 / 36
5150.0022+5150.0023 (41500820)
V3
GB
WARNING SIGN
Symbol
Meaning
Order-No.
Size [mm]
Danger of squeezing the hands.
2904.0221
2904.0220
2904.0107
30
50
80
Danger: Injury of hands and fingers –belt drive
2904.0451
48x54
Warning for hot surfaces
2904.0396
31x27
Warning for electric voltage
2904.0397
31x27
Warning for battery acid.
2904.0551
30
Danger: Keep distance to the machine.
2904.0756
64x103

Safety
6 / 36
5150.0022+5150.0023 (41500820)
V3
GB
REGULATORY SIGN
Symbol
Meaning
Order-No.
Size [mm]
Directions of the joystick movements for the control the a
hydraulic installation clamp (HVZ) or the like (opening and
closing of gripping directions).
2904.0253
50x50
Joystick with function controls as well as activations of
additional functions or similar.
Function controls: for controlling of a hydraulic installation
clamp (HVZ) or similar.
Additional finctions:
- Rotating movement of a hydraulic rotator
- Vacuum operation (suction and release of load)
2904.0681
70x72
Driving direction forwards / backwards + correct operation of
the pedals
2904.0760
68x43
Lifting arm up / down
2904.0759
48x43
Short-manual
2904.0614
180x165
Regular Inspections
2904.0611
235x180
Each operator must have readand understood the operating
instructions (and all safety instructions).
2904.0665
2904.0666
Ø 30
Ø 50
Seat belt duty
On every drive with the machine the seat belt is to be applied.
2904.0450
Ø 52

Safety
7 / 36
5150.0022+5150.0023 (41500820)
V3
GB
INFORMATION SIGNS
Symbol
Meaning
Order-No.
Size [mm]
Engine speed regulation
2904.0485
30x90
Open engine cover
2904.0253
28x85
Button for horn / reset button: Press reset button for driving,
when the driving was stopped caused by the standing up of
the operator from the driver´s seat (triggered by the safety
seat switch). The reset button only works, when the operator
is sitting on the driver´s seat.
2904.0716
90x23
Position of the lashing eyes
2904.0755
Ø 60

Safety
8 / 36
5150.0022+5150.0023 (41500820)
V3
GB
2.4 Personal safety requirements
●Each operator must have read and understood the operating instructions (and all safety instructions).
●Only qualified, authorized personal is allowed to operate the device and all devices which are connected
(lifting equipment).
●The manual guiding is only allowed for machines with handles.
2.1 Protective equipment
<
The protective equipment must consist, according to the safety regulations of
the following parts:
●Protective clothing
●Safety gloves
●Safety shoes
2.2 Accident prevention
●The workplace has to be covered for unauthorized persons, especially children.
●Take care in case of thunderstorm!
●The workplace has to be sufficiently illuminated.
●Take care with handling wet, dirty and not solidified components.
●The working with the device in case of atmospheric editions under 3° C (37,5° F) is forbidden!
Because the goods could be fall down caused by dampness or freezing.
2.3 Function Control
2.3.1 General
●Before using the device check the functions and the working condition.
●Maintenance and lubrication are only permitted when device is shut down!
●Do not use the device, until all faults which can cause safety hazards are removed.
●If there are any cracks, splits or damaged parts on any parts of the device, immediately stop using it.
●The operating instructions must be available at the workplace every time.
●Do not remove the data-plates of the machine.
●Unrecognisable information signs must be replaced.

Safety
9 / 36
5150.0022+5150.0023 (41500820)
V3
GB
2.3.2 Hydraulic
●Check all hydraulic hoses and connection for tightness. Only experts are allowed to replace faulty parts
(depressurized)
●Ensure a clean working environment before opening the hydraulic connection.
●The hydraulic hoses must be free of breaks and abrasion. Take care that there are no outstanding edges,
where the hoses could hook in.
2.4 Safety procedures
2.4.1 Installation machine
●The installation machine has to be in good, safe working condition.
●Never exceed the maximum capacity of the installation machine!
●Only authorized and qualified personnel are allowed to operate the installation machine.
●The operator staff must have all the necessary qualifications.

Safety
10 / 36
5150.0022+5150.0023 (41500820)
V3
GB
2.4.2 Safety procedures using the VM-301-PAVERMAX
●The load has to be lowered down to approximately 20 cm above ground during driving actions.
●The max. carrying capacity with the laying machine VM-301-PAVERMAX , the attachments and the lifted
loads must not be exceeded!
●The driver has to pull the hand break before leaving the driver’s seat.
●During operation of the machine the driver is responsible for the safe condition of the machine.
●Driving around curves or on uneven ground max. speed must not exceed 7 km/h which is 1/3 of the max.
speed of the machine.
●No driving speed faster than walking speed when the machine is tilted sideways more than 20°.
●Driving actions of the machine without any lifting device attached not quicker than walking speed, danger
to tip over.
●When working on uneven ground always be beware of sufficient standing security.
●Never fill fuel into the tank while the engine is running. Danger of explosion.
●Never use starter spray, in winter always use winter gasoline.
●When working on the electric system always detach the battery.
●Never open the motor hood while the engine is running. Always keep the motor hood closed to avoid
injury and to limit noise emission.
●During the laying work personal is not allowed to be in the driving and working area generally, it is
forbidden to stand underneath suspended load.
●The driver must not leave the driver’s seat as long as load is suspended by the lifting device and the
engine is running.
●Never let the cross-stick or the pedals flip back to the neutral position to avoid hydraulic pressure shocks.
These pressure shocks could damage the components or release the suspended load.

General
11 / 36
5150.0022+5150.0023 (41500820)
V3
GB
3General
3.1 Authorized use
●The installation machine VM-301-PAVERMAX can only be used in the following way:
To lay concrete pavers with an Hydraulic Installation Clamp HVZ. To lay kerb stones by using the Kerb Stone
Laying Clamp VZ-HS. To sweep sand into the joints by using the Sweeping Broom EB 240. To lay elements by
using the Hydraulic Vacuum Units HVE or VPM.
●Exclusively lifting equipment from Probst can be operated with the VM-301-PAVERMAX . Before using any
lifting equipment always call Probst for approval.
●The installation machine VM-301-PAVERMAX is no crane equipment!
●All instructions, included in the manuals to the machine, have to be observed.
●Optional mounting kits for hydraulic activated vacuum devices at VM-301-K/VM-301:
- PJ-1650-H / mounting kit (Order.-Nr.: 41500755)
- SH-1000-MINI-H / mounting kit (Order.-Nr.: 41500756)
- VPM-2500-H / mounting kit (Order.-Nr.: 41500754)
- SH-1000-SUPER-JET-H/ mounting kit (Order.-Nr.: 41500753)
Life danger!
The use is strictly forbidden inside closed buildings or in other explosion or fire sensitive areas due to the use of
the gasoline engine.
It is not allowed to use the paver laying machine in public traffic –only construction sites or private ground!
●The machine is only designed for the use specified in this documentation.
●Every other use is not authorized and is forbidden!
●The using of the device for persons under the age of 16 is forbidden!
●All relevant safety regulations, especially regulations of the declaration of conformity, and additional local
health and safety regulations have to be observed.
Prior to every operation the user must ensure that:
the machine is suited to the intended operation,
the functioning and the working condition of the equipment is examined,
the loads are suitable to be handled.
Any doubts about instructions should be raised with the manufacturer prior to use.
NOT ALLOWED AKTIVITIES:
Unauthorized alterations of the device and the use of any self-made additional equipment
could cause danger and are therefore forbidden!!
Never exceed the carrying capacity and the nominal width/gripping range of the device.
All unauthorized transportations with the device are not allowed:
●Transportation of people and animals.
●Never suspend any goods with ropes, chains or similar at the device.

General
12 / 36
5150.0022+5150.0023 (41500820)
V3
GB
3.1.1 Optional accessoires
Type
Description
Best.-Nr
Cabin
Retrofit kit for VM-301 W/glazing and heating
(Retrofit only possible at Probst company)
4150.0690
Light package
VM-301
2 combi-headlights (near/far), 1 reversing light
4150.0738
Light package
VM-301-K
2 combi-headlights (near/far), 1 reversing light
4150.0692
Turning Light
With swing down foot inc. installation material
4150.0737
Exterior mirror
Retrofit kit
4150.0358
Mounting bracket
For light package and/or exterior rear-view mirrors (is only required once)
4150.0739
Extra weight
To increase the working load limit by 60 kg*
4150.0357
Diesel particle filter DPF
Retrofit kit for VM-301-K, VM-301 and VM-203
4150.0784
Filter Cartridge
for Diesel particle filter DPF
2690.0034
Windscreen washer
Without adjustable wiping interval. Retrofit kit for VM-301-K
4150.0788
Adapter QJ for Rotator Bini/Baltrotor
4011.0319
VM-301- JMS-V
Electronic joystick and armrest incl. installation kit. To control the main
gripping width, side gripping width, rotator and incl. vacuum function.
(Retrofitting possible only at Probst) Incl. installation.
4150.0820
* At adequate driving speed and lowered load. Max. weight of paver layer as per technical data.

General
13 / 36
5150.0022+5150.0023 (41500820)
V3
GB
3.2 Survey and construction
VM-301-PAVERMAX
VM-301-K-PAVERMAX

General
14 / 36
5150.0022+5150.0023 (41500820)
V3
GB
3.3 Technical data
Enginepower
18,7 kW / 25 hp
Equivalent noisepollution LpA:
79 dB
Vibrations:
Effective value of acceleration for the upper limbs:
< 2,5 m/s²
Effective value of acceleration for the body:
< 0,5 m/s²
Stearing
Double articulated stearing
Velocity adjustment
Hydrostat-continuously variable
Maximum speed:
approx. 20 km/h (15 m/ph)
Dimensions and weight
Height / Width / Length:
1,980 mm (78”) / 1,220 mm (48”)/ 3,610 mm (142”)
Dead weight:
1,080 kg (2,380 lbs) ** kg
1,200 kg (2,650 lbs) ***
Carrying capacity
600 kg (1,320 lbs) */** and 650 kg (1,430 lbs) */***
Maximum weight of stone formation
320 kg (710 lbs) */**
380 kg (840 lbs)
Max. lifting height:
1,600 mm (63”)
Turning radius inner front wheel / outer front wheel
700 mm (27”) / 1,900 mm (75”)
Turning radius overall:
2,450 mm (69”)
Ground clearance:
180 mm (7”)
Filling capacity:
Fuel tank
20 l
Motor oil SAE10W40
4,3 l
below 0°C:SAE10W, 0°-25°C:SAE20, over 25°C:SAE30
Hydraulic oil
18 l
HLP 46
Kubota Diesel motor D 1105
Technical data see: Kubota Diesel motor D 1105
Seat:
Height adjustable, , adjustable backrest, adjustable spring power
*At adequate driving speed and lowered load.
** VM-301-PAVERMAX
*** VM-301-K-PAVERMAX

Description and Operation
15 / 36
5150.0022+5150.0023 (41500820)
V3
GB
4Description and Operation
In conditional of the outdoor temperature it is absolute
necessary to keep the warm up times at every daily use
(before the first motion of travelling) of the installation
machine VM-301-PAVERMAX .
outdoor temperature over
10°C(50 F):
5 minutes
outdoor temperature
under 10°C(14 F):
10 minutes
Before using the installation machine VM-301-
PAVERMAX account the safety instructions and carry
out the maintenance work.
For a safety and trouble-free operation of the
installation machine VM-301-PAVERMAX is it necessary
to carry out the following the daily checks:
4.1 Daily checks
4.1.1 Fuel level
●Open the lock of the engine cover (1), open engine
cover by pulling the handle (2) and tip the engine
cover backwards.
●You can check the fuel level visually, because the
tank is transparent.
●With a full tank you can work approx. 10-12 hours.
4.1.2 Motor-oil level
●Installation machine VM-301-PAVERMAX has to
stand on even, levelled ground.
●Open the lock of the engine cover, open engine
cover by using handle and tip the engine cover
backwards.
●Pull the oil dip stick (4) out
●Oil level has to be between the two marks
●If oil is missing fill oil into the oil filler (5).
●If there is too much oil drain the oil out through the
oil drain screw on the bottom of the engine
(5)
(4)
2
1

Description and Operation
16 / 36
5150.0022+5150.0023 (41500820)
V3
GB
4.1.3 Hydraulic-oil level
●The installation machine VM-301-PAVERMAX has to
stand of even and levelled ground to check the
hydraulic oil.
●The lifting arm has to be completely lowered down.
●The oil level must be in the middle of the inspection
windows (6).
4.1.4 Cooling-water level
●The installation machine VM-301-PAVERMAX has to
be on even levelled ground
●Open the engine cover as described above
By all means read the safety instructions in the
Kubota engine manual carefully.
●Remove cover(7) on the water cooler (Caution
when engine is hot)
●Cooling water has to cover cooling fins. If not fill
only anti freeze to reach this level.
6
7
Air filter
cap
Fuel pump
Fuel pump
preliminary
Hydraulic oil
filter

Description and Operation
17 / 36
5150.0022+5150.0023 (41500820)
V3
GB
4.1.5 Main switch
●Before starting the VM-301-PAVERMAX put in the
main switch (8)
●The main switch is below the engine cover on the
right hand side.
4.1.6 Accelerator
Lever of the accelerator (9) has to stay in position by
the friction of the spring washers
To adjust the leaver of the accelerator the stop nut on
the inside of the leaver has to be tightened by a key size
13.
8
9

Description and Operation
18 / 36
5150.0022+5150.0023 (41500820)
V3
GB
4.1.7 Control displays
Oil pressure control
The oil control light (12) has to be illuminated when the ignition (13) is on step 1.
The light must not be illuminated when the motor is running.
Battery control
The battery control light (14) has to be illuminated when the ignition (13) is on step
1. The light must not be illuminated when the motor is running.
Temperature control
If the water temperature control display (15) is in the red section, the air filter has
to be cleaned or renewed. The cooling fins of the radiator have to be cleaned with
compressed air and the cooling water has to be checked.
If the temperature control display is still in the red section please contact a
qualified workshop.
Pre-heat
Turn ignition to step II until the pre-heat control display (17) is illuminated After a
short time (approx. 25 sec.) the pre-heat control display has to stop the
illumination. This means that the engine can be started now by turning the ignition
to step III
Fuse box
The fuse box is behind the covering of the control displays. For changing fuses
remove the fixing bolts at the control-displays covering.
Horn/Reset –driving (safety
seat switch)
Button for horn / reset button:
Press reset button each time for the driving, when the machine will be started and
when the driving was stopped caused by the standing up of the diver from the
driver´s seat (triggered by the seat switch).
The reset button only works, when the driver is sitting on the s seat.
(15)
(12)
(14)
(17)
(13)
Hour
meter
Horn/Reset driving
light
Turn signal indicator
Fuse box
