probst TSZ-UNI User manual

5310.0338
V6
GB
Operating Instructions
Translation of original operating instructions
Concrete Step Handles
TSZ-UNI

Contents
2 / 26
5310.0338
V6
GB
Contents
1EC-Declaration of Conformity ............................................................................................................................... 3
2Safety...................................................................................................................................................................... 4
2.1 Safety symbols................................................................................................................................................4
2.2 Explanation of basic concepts .......................................................................................................................4
2.3 Definition skilled worker / specialist ..............................................................................................................4
2.3.1 Explanation of the pictograms.................................................................................................................. 5
2.4 Safety Marking................................................................................................................................................6
2.5 Personal safety requirements ........................................................................................................................ 7
2.6 Protective equipment..................................................................................................................................... 7
2.7 Accident prevention ....................................................................................................................................... 7
2.8 Function Control............................................................................................................................................. 7
2.8.1 General ....................................................................................................................................................... 7
2.9 Safety procedures ..........................................................................................................................................8
2.9.1 General .......................................................................................................................................................8
2.9.2 Carrier / Lifting device................................................................................................................................8
3General.................................................................................................................................................................... 9
3.1 Authorized use................................................................................................................................................9
3.2 Survey and construction ............................................................................................................................... 11
3.3 Accessoires .................................................................................................................................................... 11
3.4 Technical data................................................................................................................................................ 11
4Installation.............................................................................................................................................................12
4.1 Mechanical connection .................................................................................................................................12
4.1.1 Lifting eye / Suspension bolt ....................................................................................................................12
4.1.2 Load hook and chains ...............................................................................................................................12
4.1.3 Rotators (optional)...................................................................................................................................12
4.1.4 Fork sleeves (optional) .............................................................................................................................13
4.2 Installation of the steelfinger grippers WB-SQ ............................................................................................13
5Adjustments .......................................................................................................................................................... 15
5.1 Adjustment of the gripping range ................................................................................................................15
5.2 Accessoires–HVA for batch processing .......................................................................................................17
6Operation ..............................................................................................................................................................18
6.1 Gripping, moving and laying of gripping goods.......................................................................................... 18
6.2 Picture of the automatic release .................................................................................................................20
6.3 Operation: Steelfinger grippers WB-SQ........................................................................................................21
7Maintenance and care ......................................................................................................................................... 23
7.1 Maintenance ................................................................................................................................................. 23
7.1.1 Mechanical .................................................................................................................................................... 23
7.1.2 Additional with steelfinger grippers (WB-SQ)....................................................................................... 24
7.2 Trouble shooting .......................................................................................................................................... 25
7.3 Repairs .......................................................................................................................................................... 25
7.4 Safety procedures ........................................................................................................................................ 25
7.5 Hints to the type plate..................................................................................................................................26
7.6 Hints to the renting/leasing of PROBST devices .........................................................................................26

EC-Declaration of Conformity
3 / 26
5310.0338
V6
GB
1EC-Declaration of Conformity
Description:
Type:
Order number:
Concrete Step Handles
TSZ-UNI
5310.0338
Manufacturer:
Probst GmbH
Gottlieb-Daimler-Straße 6
71729 Erdmannhausen, Germany
[e-mail]
www.probst-handling.com
The machine described above complies with the relevant requirements of the following EU directives:
EC-machinery directive 2006/42/EC
The following standards and technical specifications were used:
DIN EN ISO 12100
Safety of machinery - General principles for design - Risk assessment and risk reduction (ISO 12100:2010)
DIN EN ISO 13857
Safety of machinery - safety distances to prevent hazard zones being reached by upper and lower limbs (ISO 13857:2008)
Authorized person for EC-documentation:
Name: J. Holderied
Address: Probst GmbH; Gottlieb-Daimler-Straße 6; 71729 Erdmannhausen, Germany
Signature, information to the subscriber:
Erdmannhausen, 21.11.2018..........................................................................
(M. Probst, Managing director)

Safety
4 / 26
5310.0338
V6
GB
2Safety
2.1 Safety symbols
Danger to life!
Identifies imminent hazard. If you do not avoid the hazard, death or severe injury will result.
Hazardous situation!
Identifies a potentially hazardous situation. If you do not avoid the situation, injury or damage to property
can result.
Prohibition!
Identifies imminent a prohibition. If you do not avoid the prohibition, death and severe injury, or damage to
property will result.
Important information or useful hints for the usage.
2.2 Explanation of basic concepts
Gripping range:
•specify the minimum and maximum product measurements of the gripping good, which
can be gripped with this device.
Gripping good(s):
•is the product, which will be gripped or transported.
Opening width:
•consists of the gripping range and the measure to drive over the gripping good.
gripping range + measure to drive over the gripping good = opening width
Immersion depth:
•is the maximum gripping height of gripping goods, conditional of the height of the
gripping arms of the device.
Device:
•is the description for the gripping device.
Product dimensions:
•Are the dimensions of the gripping good (e.g. length, breadth, height
of the product).
Dead weight:
•is the own weight (without gripping good) of the device.
Carrying capacity/working
load limit (WLL*):
•specify the maximum possible load of the device (for lifting of gripping goods).
*= WLL →(english:) Working Load Limit
2.3 Definition skilled worker / specialist
Only skilled workers or specialists are allowed to carry out the installation-, maintenance-, and repair work on this device!
Skilled workers or specialists must have for the following points (if it applies for this
device), the necessary professional knowledge.
•for mechanic
•for hydraulics
•for pneumatics
•for electrics

Safety
5 / 26
5310.0338
V6
GB
2.3.1 Explanation of the pictograms
Automatic release is „empty“
Automatic release is „full“
Do not use damaged accessories, replace if necessary!
Do not hold limbs under the lifted load!
Risk of injury!
Allowed slings: hook and lifting strap.
Load securing chain (lashing chain) must not be used as sling
chain!
The load securing chain can break and the load would fall!
Risk of injury and death!
If the load falls into the load securing chain, the chain must be
checked professionally and replaced if necessary.
Do not continue to use damaged load-securing chains!

Safety
6 / 26
5310.0338
V6
GB
2.4 Safety Marking
PROHIBITION SIGN
Symbol
Meaning
Order-No.
Size
It is not allowed to stand under hanging loads. Danger to life!
2904.0210
2904.0209
2904.0204
Ø 30 mm
Ø 50 mm
Ø 80 mm
The transportation of non-rectangular goods is not allowed!
2904.0213
2904.0212
2904.0211
Ø30 mm
Ø50 mm
Ø80 mm
Do not lift any components off-centre (always in centre of gravity).
2904.0216
2904.0215
2904.0214
Ø30 mm
Ø50 mm
Ø80 mm
WARNING SIGN
Symbol
Meaning
Order-No.
Size
Danger of squeezing the hands.
2904.0221
2904.0220
2904.0107
30 x 30 mm
50 x 50 mm
80 x 80 mm
REGULATORY SIGN
Symbol
Meaning
Order-No.
Size
Each operator must have read and understood the operating
instructions (and all safety instructions).
2904.0665
2904.0666
Ø 30 mm
Ø 50 mm
The manual guiding of the device is only allowed at the red handles.
2904.0227
2904.0226
2904.0225
Ø 30 mm
Ø 50 mm
Ø 80 mm
OPTIONAL
Be sure that the fork sleeves are mechanically fixed (with locking
screw and safety chain or rope) to the lifting device.
2904.0223
2904.0222
Ø 50 mm
Ø 80 mm

Safety
7 / 26
5310.0338
V6
GB
2.5 Personal safety requirements
Each operator must have read and understood the operating instructions (and all safety instructions).
Only qualified, authorized personal is allowed to operate the device and all devices which are connected
(lifting device/carrier).
The manual guiding is only allowed for devices with handles.
2.6 Protective equipment
The protective equipment must consist, according to the safety regulations
of the following parts:
•Protective clothing
•Safety gloves
•Safety shoes
2.7 Accident prevention
•The workplace has to be covered for unauthorized persons, especially children.
•Take care in case of thunderstorm!
•The workplace must be sufficiently illuminated.
•Take care with handling wet, dirty and not solidified components.
•The working with the device in case of atmospheric editions under 3 °C (37,5 °F) is forbidden!
Because the goods could be fall down caused by dampness or freezing.
2.8 Function Control
2.8.1 General
•Before using the device check the functions and the working condition.
•Maintenance and lubrication are only permitted when device is shut down!
•Do not use the device, until all faults which can cause safety hazards are removed.
•If there are any cracks, splits or damaged parts on any parts of the device, immediately stop using it.
•The operating instructions must be available at the workplace every time.
•Do not remove the type plate of the machine.
•Unrecognisable information signs (such as regulatory or prohibition signs) must be replaced.

Safety
8 / 26
5310.0338
V6
GB
2.9 Safety procedures
2.9.1 General
•The use of the device is only permitted in proximity to the ground.
Do not swing it over people heads.
•The stay under lifted load is forbidden. Danger to Life!
•The manual guiding of the device is only allowed at the handles.
•While using the device the stay of persons in the working area is forbidden. Except it is indispensable,
caused of the way of using the device, e.g. if the device must be leaded by hand.
•The jerky lifting and lowering of the device with and without load. e.g. caused through driving fast with
the lifting equipment/carrier over uneven grounds is forbidden. Because the gripping good could fall
down. Unchecked movements of the device.
•Do not lift any components off-centre (always in centre
of gravity), because that could fall down.
•The device should not be opened if the opening path of
the gripping arm is blocked by a resistance (e.g. other
concrete blocks or the like)!
•The operator is not allowed to leave the control unit as
long as the device loaded with load. The load must always
be in the range of vision of the operator.
•Never exceed the carrying capacity/working load limit
(WLL) and the nominal width/gripping range of the
device.
•Fig. A
•Do not pull out stuck or tightened loads with the device.
•Never pull or drag loads sideways. Otherwise parts of the
device could be damaged.
(see Fig. A →)
2.9.2 Carrier / Lifting device
•The used carrier/lifting device (e.g. excavator) have to be in good, safe working condition.
•Only authorized and qualified persons are allowed to operate the carrier/lifting device.
•The operator of the carrier/lifting device must have all the necessary qualifications.
•Never exceed the maximum allowable carrying capacity/working load limit (WLL) of the carrier/lifting
device.

General
9 / 26
5310.0338
V6
GB
3General
3.1 Authorized use
The device TSZ-UNI is specially designed for gripping, transporting and the following laying of gripping
goods such as, steps, kerb stones, contact angle and L-stones. Via the assembly of the accessoire
“steelfinger grippers WB-SQ” ashlar rocks can also be gripped.
The device is used in conjunction with a corresponding lifting device (e.g. excavator).
•The device is only designed for the use specified in this documentation.
•Every other use is not authorized and is forbidden!
•All relevant safety regulations, corresponding legal regulations, especially regulations of the declaration
of conformity, and additional local health and safety regulations have to be observed.
Prior to every operation the user must ensure that:
•The equipment is suited to the intended operation, the functioning and the working condition of the
equipment is examined, and the load is suitable to be handled.
Any doubts about instructions should be raised with the manufacturer prior to use.
ATTENTION: The use of this device is only permitted in proximity to the ground (→chapter “Safety at
work”).
Only stone elements with parallel and plane surface are allowed to be picked-up and handled.
Because the gripping good could fall down.

General
10 / 26
5310.0338
V6
GB
NOT ALLOWED ACTIVITIES:
Unauthorized alterations of the device and the use of any self-made additional equipment could cause
danger and are therefore forbidden!
Never exceed the carrying capacity/working load limit (WLL) and the nominal width/gripping range of the
device.
All unauthorized transports with the device are strictly prohibited:
•The transport of people and animals.
•The gripping and transporting of other loads and materials than
described in this operating instruction.
•Never suspend any goods with ropes, chains or similar at the
device.
•Gripping of gripping goods with packaging foil, because they
could fall down.
•The gripping of gripping goods with treated surfaces (such as
painting/varnish, coating or the like), because they could fall
down. Treated surfaces lead to a reduction in the coefficient of
friction between the grippers and the gripping good.
•The gripping and transporting of non-rectangular and round
gripping goods, because they could fall down (see figure to the
right). ➔
•Transportation of material with “feet”, “bellies” and “blind
spacers”.

General
11 / 26
5310.0338
V6
GB
3.2 Survey and construction
1
2
3
6
5
4
7
1. Lifting eye for attaching to crane
hook
2. Handles for the guidance of the
device
3. Adjustment of gripping range
4. Spring bolt (for gripping range
adjustment)
5. Rubber gripper (exchangeable)
6. Montageplatte für HVA
7. Automatic release for the fully
automatic switch over from “full”
to “empty”
3.3 Accessoires
HVA-FTZ/TSZ
Laying in batch operation
TSZ-UNI-WB-SQ
Gripping of roughly-cut ashlar rocks
TSZ-UNI-ET
Fork sleeve
3.4 Technical data
Type
Gripping range W
Inside height E
Carrying capacity
(WLL)
Gripper length L
Dead weight
TSZ-UNI
50 –600 mm
(2 –23½“)
185 mm
(7¼“)
600 kg
(1.320 lbs)
350 mm
(13¾“)
31 kg
(68 lbs)

Installation
12 / 26
5310.0338
V6
GB
4Installation
4.1 Mechanical connection
Use only original accessories, in case of doubt consult the manufacturer.
Take care that the carrying capacity / working load limit (WLL) of the lifting device/carrier is not exceeded,
through the load of the device, the attaching devices (turning device, fork sleeves etc.) and the additional
load of the gripping goods!
Gripping devices always have to be gimballed, so they can swing freely in any position.
In no case it is allowed to mount gripping devices with lifting devices/carriers in a rigid way!
Break of the suspension may occur within short time. Death, severe injuries and material damage can
result!
4.1.1 Lifting eye / Suspension bolt
•The device is equipped with a lifting eye / suspension bolt and can be mounted on various carrier /
lifting devices.
•Take care that the lifting eye / suspension bolt is safely joined with the lifting tackle (e.g. crane hook,
belt) and cannot slide down.
4.1.2 Load hook and chains
Fit suspension ring in the load hook of the lifting device/carrier.
Ensure that the single chains strands are not twisted or knotted.
Attaching the device to the lifting device/carrier, take care that all local safety regulation is observed.
4.1.3 Rotators (optional)
When using rotators, a free-wheel throttle valve must be installed.
In order to prevent a sudden speedup and stopping the rotational movements, as this may damage the
device within a short time.

Installation
13 / 26
5310.0338
V6
GB
4.1.4 Fork sleeves (optional)
To establish a mechanical connection between the fork lift truck and the fork sleeves you have to put the
forks into the fork sleeves and fix it with the locking bolt or with a chain/rope, connected to the eyelet on the
fork sleeves and the lift frame.
It is definitely necessary to establish this connection. Otherwise the device could slide form the forks.
DANGER OF ACCIDENTS!
1
Fork (of fork lift truck)
2
locking bolt
3
Fork sleeve
4
Chain/rope
4.2 Installation of the steelfinger grippers WB-SQ

Installation
14 / 26
5310.0338
V6
GB

Adjustments
15 / 26
5310.0338
V6
GB
5Adjustments
5.1 Adjustment of the gripping range

Adjustments
16 / 26
5310.0338
V6
GB

Adjustments
17 / 26
5310.0338
V6
GB
5.2 Accessoires–HVA for batch processing

Operation
18 / 26
5310.0338
V6
GB
6Operation
6.1 Gripping, moving and laying of gripping goods

Operation
19 / 26
5310.0338
V6
GB

Operation
20 / 26
5310.0338
V6
GB
6.2 Picture of the automatic release
The device is equipped with an automatic release, that means the OPENING and CLOSING of the gripping arms results
through the set down and lifting of the device.
Pictures of the positions of the automatic release:
•Device is lifted through the lifting
equipment/carrier
•Gripping arms are opened
•Device is set up on the gripping good
•Gripping arms are opened
•Device is lifted through the lifting
equipment/carrier
•Gripping good is clamped and can be
transported to the destination
•With faulty switching, the
change-over switch must be
pushed back manually (e.g. with a
screwdriver) 1)
•Device is set down with the gripping good (on the
ground)
•Gripping arms are opening
•Device is lifted through the lifting
equipment/carrier
•Gripping arms are opened
(laydown position of the device on
the ground)
1) Otherwise there may be faulty switching and when setting down the load this can cause deformation or
damage of the automatic release!
The jerky lifting and lowering of the device with and without load. e.g. caused through driving fast with the
lifting equipment/carrier over uneven grounds is forbidden
When replacing a defective automatic release, it is
essential to ensure that the slots of the two clamping
pins always point downwards.
The position of the slots must not be above or center,
otherwise there is a risk that the automatic release may
jam when switching!
