Procom PRO-COM SFE23RE-C User manual

1
PRO-COM
SFE23RE-W
SFE23RE-C
SFE23RE-O
SFE23RE-DO
Installation InstructionsandOwner sManual
ANSI/UL1278. MOVABLEANDWALL-OR CEILINGHUNGELECTRIC ROOM HEATERS
INSTALLER:DONOTDISCARD THISMANUAL-LEAVE FORHOMEOWNER
Freestanding
ElectricFireplace
SFE33RE-W
SFE33RE-C
SFE33RE-O
SFE33RE-DO
SFE23RESHOWN
WARNING! IFTHEINFORMATIONINTHISMANUALISNOTFOLLOWED EXACTLY,AFIRE
MAYRESULTCAUSINGPROPERTY, PERSONAL INJURYOR LOSS OF LIFE.
FOR YOUR SAFETY
DO NOTSTORE
OR USE GASOLINEOR OTHER
FLAMMABLE VAPORSOR LIQUIDS
IN THE VICINITY OF THISORANY
OTHERAPPLIANCE
PC-FE23A610-0506

2
ImportantInstructions ….…………………………………………………………....2
LocatingYourElectricFireplace ........3
ClearanceToCombustibles .......3
ElectricalConnections .. ......3
ElectricalSpecifications ... ......3
ServiceInstructions…………………………………………………………….…......3
Replacing LightBulbs .........3
Maintenance ofMotors ........... .4
Glass Information ........... ..4
ElectricalWiring Diagram ........ ....... 4
OperatingInstructions………………………………………………………....…........5
Specification........………………………………………………………………...........7
ReplacementParts..……………………………………………………........7
ReplacementPartsList........................ ..8
Installingdecoratinglogs..……………………………………………………........9
1
TABLEOFCONTENTS
PLEASEREADTHE INSTALLATION&OPERATIONINSTRUCTIONS
BEFOREUSING THISAPPLIANCE
WE AREPLEASEDTHATYOUHAVE CHOSEN TOPURCHASEAN ELECTRIC FIREPLACEMANU-
FACTUREDBYNANJINGPRO-COM ELECTRICAPPLIANCECO.,LTD
IMPORTANT:Read allinstructionsand warningscarefullybefore starting installation.Failure tofollow
theseinstructionsmayresultin apossibleelectricshock,firehazardand willvoid the warranty.

3
IMPORTANTINSTRUCTIONS
Whenusingelectrical appliances, basicprecautions
should alwaysbefollowedtoreducethe risk of fire,
electricshock,andinjuryto persons,includingthe
following:
1.Read all instructionsbeforeusing thisheater.
2.Thisapplianceishot whenin use.Toavoid
burns,do not comeincontactwith heater. Keep
combustible materials, suchasfurniture,
pillows, bedding,papers, clothes,and curtains
at least 3feet(1m.)fromthefrontoftheheater.
3.Extremecaution is necessarywhenanyheater
isusedbyornearchildrenor invalidsandwhen-
everthe heaterisleft operatingand unattended.
4.Alwaysunplugheaterwhennot inuse.
5.Donotoperateanyheater with a damaged cord
orplugorafterthe heatermalfunctions, has
been dropped ordamaged in anymanner.
6.Anyrepairsto thisapplianceshould be carried
outbyaqualified service person.
7.Under no circumstances shouldthiselectric fire-
placebemodified. Partshavingto beremoved
for servicingmustbereplacedpriortooperat-
ingthiselectricfireplaceagain.
8.Do notuseoutdoors.
9.This heaterisnotintendedfor useinbathrooms,
laundryareasorsimilarindoor locations. Never
usethisappliance nearabathtub orotherwa-
tercontainer.
10.Do notrun cordundercarpeting.Do notcover
cordwiththrowrugs, runners orsimilar
coverings.Arrangecordawayfrom trafficareas
and whereitwill notbe tripped over.
11.Todisconnect heater,turncontrols toOFF,then
removeplug fromoutlet.
12.Connecttoproperlygrounded outlets only.
13.Whenthisapplianceisinstalled,it mustbeelectri-
callygrounded inaccordance withlocalcodes with
thecurrentCSAC22.1 Canadianlocalcodesfor
USAinstallations. FollowlocalcodesandNational
Electrical Code,ANSI/NFPANO.70 and Canadian
Cord: CZ22.2NO.0.
14. Do notinsertorallowforeign objectstoenter any
ventilation orexhaust openingasthismaycause
electric shock, fireordamage tothe heater.
15.Topreventapossible fire,donotblockairintakes
orexhaust in anymanner. Do notuseon soft
surfaces,suchasabed,whereopeningsmay
becomeblocked.
16.Thisheatergetshot anditcontainsinternalparts
that sparksandarcs.Donotuseit in areas where
gasoline,paint, orflammableliquidsareused or
stored.
17.Use thisheateronlyasdescribed in thismanual.
Otherusesnot recommendedbythemanufac-
turer maycausefire, electricshock, orinjury.
18.Avoidthe useof an extension cordbecause it may
overheatand causeariskoffire.Howeverifyou
mustusean extension cord,thecordshall be No.
14AWG minimumsize andrated not less than 1900
watt. The extensioncord must be a three wire cord
withgroundingtype plugandcordconnector.
19. Thiselectricfireplaceheatershouldnot beused
asadryingrackforclothing.Also,do nothang
Christmasstockingsordecorationson ornearit.
20.SAVETHESEINSTRUCTIONS.
2

4
CLEARANCE TOCOMBUSTIBLES
ELECTRICALCONNECTION
A15AMP,120 Volt,60Hzcircuitwithaproperlygrounded outlet
isrequired.Preferably,thefireplacewillbeonadedicated
circuit.Otherappliancesonthesamecircuitmaycausethe
circuit breaker totripor thefusetoblowwhen the heater is on
operation. Theunitcomesstandardwith a6’(1828mm)long
three wirecordexiting fromthe rearofthe fireplace.Plan the
installation toavoidthe useofan extensioncord. If anextention
cordmust be used,itmust beaminumum14 AWGthreewire
withgroundingtypeplugconnectorand rated nolessthan
1900Watts.Thecordshallnot bemorethan20feetinlength.
ELECTRICALSPECIFICATIONS
SERVICEINSTRUCTIONS
WARNING:Disconnectpower before
attemptinganymaintenanceor clean-
ingtoreducetheriskoffire,electri-
calshock or personalinjury.
REPLACINGLIGHT BULBS
Thisfireplaceuses fourclear120Volt,60Watt,E-
12 socketbaselightbulbs(small base,chandelier
candletype).The60 Wattbulbsarelocatedunder
the log set/ember bed.For convenience,if one of
the bulbsburnsout, it may be agood idea tore-
placeall ofthe lightbulbs.
1.Turnoff powertotheunit byunplugging the power cord.
2.Let fireplacecoolifithasbeenoperating.
3.Removethe twoscrewson the top cornerofscreen.Pull
thescreen upwardslightly,andthenpullout.
4.Removethe fourscrewsthatsecurethelogset/em-
berbed in position.
5. Removelogset/emberbedandgrateassembly.
6.Examine the bulb(s)todetermine which bulbsneed
tobe replaced.
7.While holding the socket,unscrewdefective bulb(s)
counterclockwise.
8.Install the newlightbulb(s) byholding the socket and
screwing clockwise.
9.Reinstallthelogset/emberbed,grateassemblyand
screen.Followthe aboveprocedurein reverseorder.
WARNING: Donotexceed60
Watts perbulb. Theuse of
higher ratedbulbsmayresult
inafire causingproperty
damageandpersonalinjury.
Sides....................................0 mm0inches
Floor.....................................0mm0inches
Top........................................0mm0inches
Voltage:120VAC, 60 Hz
TotalAmps:11.5 Amps
TotalWatts:1380Watts
HeaterRating:1200Watts
WARNING:Electricaloutlet wir-
ingmustcomplywithlocalbuild-
ingcodesandall otherappliable
regulations toreduce therisk of
fire, electrical shock and injury.
WARNING:Donotusethisfire-
placeifanypartofithasbeen
underwater.Immediatlycalla
quilifiedservicetechnitiantoin-
spectthefireplaceandreplace
anypart of the electrical system
if necessary.
3
LOCATING YOUR ELECTRIC FIREPLACE
Yournewfreestanding electric fireplacemaybe installed vir-
tuallyanywherein yourhome.Howeverwhen choosinga
location foryournewelectricfireplace,ensurethat thegen-
eral instructionsarefollowed.Forbest effect results, install
theelectric fireplaceoutofdirect sunlight.

5
MAINTENANCE OFMOTORS
Themotors usedonthefan andflamegenera-
torassemblyare prelubricated for extended
bearinglifeandrequireno further lubrication.
However,periodiccleaning/vacuumingofthe
fan/heater unitisrecommended.
WARNING: Makesurethatthe
poweristurnedoffbefore
proceeding.
GLASSINFORMATION
1.Underno circumstancesshouldthisproduct be
operatedwithmissingorbrokenglass.
2.Donotstrikeorslamthe glass.
3.Do notuseabrasive cleanerstoclean the glass.
4.Replacementglass isavailablefromthe manu-
facturerandreplacementshouldbe carried out
by aqualified serviceperson.
ELECTRICALWIRINGDIAGRAM
Anyelectrical repairs orrewiringofthisunit shouldbecarriedout byalicensedelectricianinaccordance
withnationalandlocal codes.
Ifrepairingorreplacing anyelectricalcomponentorwiring,theoriginal wire
routing, colorcoding andsecuring locationmustbefollowed.
4
WireGauge:
Power Cord14AWG
Heater Element 16AWG
Other Wire18AWG
Model:SFE23RE,SFE33RE
Voltage:120 VAC,60Hz
Total Amps: 11.5Amps
Total Watts:1380Watts
HeaterRating:1200Watts

6
Operating Instructions
Beforeprogramming yourtransmitteryou must
firstinsertthreetriple “AAA”batteries.
Makesurethe main poweron/off swithis in “ON”
position.
1.TheModesetting:
Pressthe “SET”button, thenthe “AUTO”light
willflash. Pressthe “SET”buttonagain,and
then the “MANUAL”light will alsoflash.The
“AUTO”lightand the “MANUAL”lightwill flash
alternatelyand continuously.Nextpress “EN-
TER”button toselect the automode ormanual
mode.
a.When selecting “AUTO”mode:
Select “AUTO”and press the “ENTER”button
toactivate ,then pressthe “SET”button, next
the ‘Temperature’, ‘Flame’, ‘Light’, ’lamp’sym-
bols willflashalternately.Nextpressthe
button orthe button toselect the desired
temperaturesetting.When the temperature
setting hasbeenselected,press the “SET”
buttontolockin the temperaturesetting,next
set thefollowingfunctionsthat appearonthe
transmitter. When the last functionsetting has
beencompleted,press the “ENTER”button,
andthesymbolswillstopflashing.
b.Whenselecting “MANUAL”mode:
Select “MANUAL”andpress the “ENTER”but-
tontoconfirm, then press the “SET”button,
the ‘Flame’, ‘Light’, ‘lamp’, ‘Heating level’sym-
bols willflashalternately. The nextsymbol will
flash automaticallysetthe functionsasthey
appear. When the lastfunction setting has
beencompleted,press the “ENTER”button,
andthesymbolswillstopflashing.
5
HeaterFrontView
RemoteControlFront RemoteControlBack

7
(Adaptor NOTpermittedin Canada)
Under CZ22.2NO. 0standard
6
6.Flame Effectsetting:
(1)Flamespeed
After selecting MANUALmodeorAUTO mode,the
flamesymbolwillflash, forslowflameeffect,press
button,forfaster flameeffect,press button.
(2)Flamebrightness
Press “SET”button,when the lampsymbol flashes,
press buttontodecreasetheflamebrightness
and buttontoincreasethe flamebrightness.
7.ForFlameEffectonly:
Select MANUAL mode,thensetthe Heatinglevelto
no heating level or selectAUTOmode and then set
temperaturetolowest setting.
8.Manual ON/OFF button
Ifyoucan’tfind your Remote Control orthe Remote
Controlis damaged,you can usemanualON/OFF
buttonto manualturnon/turnoffyourheater.
2.TheClock setting:
Pressthe “CLOCK”button, thefigureshownonclockwill
flash. Press or tosetthehour.Afterthehourhas
beenset,pressthe “CLOCK”buttonagainto setthe
minutes.Aftertheminuteshasbeenset,pressthe “CLOCK”
button,the clockwill indicatetheset time.
3.TheTimer setting:
Pressthe “TIMER”button,the word “TIMER”will appearon
the transmitter, nextpress or toadjustthe time,to
add30minutes incrementspress thebuttonagain. After
thetimerhasbeenset,press “TIMER”buttonagain, the
word “TIMER”will flash and the timerwill returntotime.
4.Key-Press Lock setting (childproof):
Tolock,press the “LOCK”button,therewillbea symbol,
whichmeansthat the transmitter isinalock position.To
unlock, press onceimmediatelyfollowed bypressing
the “LOCK”button .
5.Heating Levelsetting
Select the MANUAL model and press SETtochossethe
heating level setting,the “ “ symbol will flash.Then
press or toselect full,half orno heating.

8
SPECIFICATIONS:
Model: SFE23RE-W(-C,-O,-DO)
Voltage: 120V/60HZTotal Amps:11.5A
TotalWatts: 1380WHeatingRatings:1200W
Dimensions,Inches(H xWXD)
Fireplace38x39 1/2x15 5/8
Carton421/2x41 3/8x17 5/16
Weight,Pounds
Fireplace98
Shipping 115
Model: SFE33RE-W(-C,-O,-DO)
Voltage: 120V/60HZTotal Amps:11.5A
TotalWatts: 1380WHeatingRatings:1200W
Dimensions,Inches(H xWXD)
Fireplace431/2x52 3/4x1615/16
Carton HEATER: 283/4x351/2x173/4
MANTEL: 11x56 x241/2
Weight,Pounds
Fireplace210
Shipping 230
ReplacementParts
7
(Logs forSFE23)
171819
(Logs forSFE33)
202122
171819

9
ReplacementPartsList
SFE23RE-X* SFE33RE-X*
ItemPartDescription PartNumber
SFE23RE-X*SFE33RE-X*
1LogSetFE23A400FE33A400
2ControlBoxNAEY11-ANAEY11-A
3ReceiverNAEY11-CSNAEY11-CS
4FanHeaterAssembly NFHTX186/
VB17-000G
NFHTX186/V-
B17-000G
5DCMotorFE23A304FE23A304
6PowerCordw/TerminalNFHL008-ANFHL008-A
7LightBulbSocket
w/WiringAssembly FE23A306FE23A306
8OverCurrentProtectorFE23A305FE23A305
9ACMotorw/TerminalVL051-01VL051-01
10FlamegeneratorAssyFE23A205FE33A205
11 Emberbed generator
Assy FE23A207FE33A207
12LightBulbVL055-01VL055-01
13RemoteControlNAEY11-BPRNAEY11-BPR
14MantelAssyFE23A500-X*FE33A500-X*
15LouverASSYFE23A109-AFE33109-A
16ViewingDoorFE23A130-WFE33A130-W
17Log1FE23A403FE33A403
18Log2FE23A404FE33A404
19Log3FE23A405FE33A405
20Log4FE33A406
21Log5FE33A407
22Log6FE33A408
*-X specify-W(White), -C(Cherry), -O(Oak), -DO(Dark Oak)
whenordering
8
*-X represents -W(White), -C(Cherry),-O(Oak), -DO(Dark Oak)

10
Installing decoratinglogs
3.Placeone end oflog3ontotheholeon grate,
withtheother end placed onlog1(where marked).
(SeeFIG4).
Installinglogs forSFE23RE:
4.Insertthepinonlog6totherecessed holeon
log 4,and place log 6asfigureshows.(See FIG9).
Installinglogs forSFE33RE:
FIG 1- Logsfor SFE23RE
1.Insert the twopinson log 1tothetworecessed
holesatthemiddleofgrate. (SeeFIG2).
2.Insertthe pinononeendoflog2totherecessed
holeonlog1,withtheother end of log 2placed
on theember bed (wheremarked). (See FIG3).
FIG 5- Logsfor SFE33RE
1.Place log1,log2andlog3intothe correspond-
ingholes ongrate.(See FIG6).
2.Insertthe pinononeendoflog4totherecessed
holeonlog1,withtheother end of log 4placed
where marked.(SeeFIG7).
3.Insertthe pinononeendoflog5totherecessed
holeonlog2,withtheother end of log 5placed
wheremarked.(See FIG8).
FIG2
FIG3
FIG4
FIG9
FIG8
FIG7
FIG6
9
1
2
123
123
1
123
41253
4123
641253
123
456
