Procom V50HYLC Assembly instructions

Installation Instructions and Homeowner s Manual
ANSI/UL1278. MOVABLE AND WALL-OR CEILING HUNG ELECTRIC ROOM HEATERS
INSTALLER: DO NOT DISCARD THIS MANUAL-LEAVE FOR HOME OWNER
CUSTOMER PLEASE RETAIN THIS MANUALFOR FUTURE USE
WARNING!
IFTHEINFORMATION IN THIS MANUALISNOT FOLLOWED EXACTLY,AFIRE MAYRESULT
CAUSING PROPERTYDAMAGE, PERSONALINJURYOR LOSS OF LIFE.
FOR YOUR SAFETY
DO NOT STORE
OR USE GASOLINE OR OTHER
FLAMMABLE VAPORS OR LIQUIDS
IN THE VICINITYOF THIS OR ANY
OTHER APPLIANCE
Freestanding
Electric Fireplace
V50HYLC SHOWN

PLEASE READ THE INSTALLATION & OPERATION INSTRUCTIONS BEFORE
USING THIS APPLIANCE
WE ARE PLEASED THATYOU HAVE CHOSEN TO PURCHASE AN ELECTRIC FIREPLACE MANUFACTURED BY
NANJING PRO-COM ELECTRIC APPLIANCE CO., LTD
IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to
follow these instructions may result in a possible electric shock, fire hazard and will void the
warranty.
Important instructions ……………………………………………………………………2
General…………………………………………………………………………………..2
Locating Your Electric Fireplace………………………………………………………2
Clearance To Combustibles…………………………………………………………...3
Electrical Connections…..………………………………………………… ………….3
Electrical Specifications………………………………………………………………..3
Service Instructions…………………………………………………………………………..3
Replacing Light Bulbs…………………………………………………………………..3
Glass Information……………………………………………………………………….4
Maintenance of Motors…………………………………………………………………4
Electrical Wiring Diagram………………………………………………………………4
Operating Instructions……………………………………………………………………….5
On/Off Switch…………………………………………………………………………...5
Heater Control…………………………………………………………………………..5
Instructions for power…………………………………………………………………..5、6
Specifications………………………………………………………………………..….6
Replacement Parts List (V50HYLC) ………………………………………………………7
Replacement Parts Pictures…………………………………………………………...7、8
Replacement Parts List (V50HYLD)…………………………………………………………9
Replacement Parts Pictures……………………………….………………………....9、10
1

GENERAL
2
1.
Read all instructions before using this appliance.
2.
This applianceis hot when in use. Toavoid burns,do
not let bare skin touchhot surfaces. Keep
combustible materials, such as furniture,pillows,
bedding, papers, clothes, and curtains at least 3
feet(1m.) from the front of this appliance.
3.
CAUTION: Extreme caution is
necessarywhen any
heater is used
by or near children or invalids and
whenever the heater is leftOperating
and unattended.
4.
Always unplug heater when notin
use.
5.
Do not operate any heater with a
damaged cordorplug or
after the
heater malfunctions,has
been
dropped or damaged in any manner.
6.
Any repairs tothis applianceshouldbe carried out by
a qualified service person.
7.
Under no circumstances should this electric fireplace
be modified. Partshaving to be remove
dfor
servicingmust be replacedprior tooperating this
electric fireplace again.
8. Do not use outdoors.
9.
This heater is not intended for use in bathrooms,
laundryareas or similar indoor locations. Never use
this appliance near a bathtub or vicinity of water.
10.
Do not run cordundercarpeting. Do not cover cord
with throw rugs, runners or the like. Arrange
cord
away from traffic areas and where it will not be
tripped over.
11.
Todisconnect this appliance,turn controls to the off
position and remove plug from outlet.
12. Connect to properly grounded outlets only.
13.
When this applianceis installed, it must be
electrically groundedin accordance with local
codes with the current CSAC22.1 Canadian local
codes of for USAinstallations. Follow loca
lcodes
and National Electrical Code,
ANSI/NFPA
NO.70 and Canadian Code: CZ 22.2 NO.0.
14.
Do not insert orallow foreign objectsto enter any
ventilation or exhaust openingas this may cause
electric shock, fire or damage to the appliance.
15. Toprevent fire, do
not block air intakes or exhaust
in any manner.Do notuse on softsurfaces, such
as a bed, where openings may become blocked.
16.
Cautionthis appliance getshot and it contains
internal partsthat could arc orspark.
Do notuse it
in areas where gasoline,p
aint, or flammable
liquids are used or stored. This electric fireplace
should not be used as adrying rackfor clothing
.
Also, do not have Christmas stockings or
decorations hung on or near it.
17.
Use this appliance only asdescribed in this
manual. All other
uses not recommendedby the
manufacturer may cause fire, electric shock, or
injury.
18.
Avoid the use of an extension cord becauseit may
overheat and cause afire hazard.
However if you
must use an extension cord, thecord shall be
NO.16, 1900 Watts. The ext
ension cord must be a
three wire cordwith groundingtype plug andcord
connector.
19. SAVE THESE INSTRUCTIONS.
LOCATING YOUR ELECTRIC
FIREPLACE
Your new freestanding electric fireplace may be
installed virtually anywhere in your home.
However when choosing a location for your
new electric fireplace, ensure that the general
instructions arefollowed. For best effect results, install
the electric fireplace out of direct sunlight.

CLEARANCE TO COMBUSTIBLES
ELECTRICALCONNECTION
A15 AMP,120Volt,
60Hz circuit with aproperly grounded
outlet is required. Preferably,the heater
will beon a
dedicated circuit. Other applianceson thesame circuit
may cause the circuit breakerto trip or the fuse to blow
when the heater is onoperation. The unit comes standard
with a6 (1828mm) long three wirecord exiting from the
rear of the fireplace
.Plan the installation to avoid the use
of an extension cord. If anextended
cord must be used, it
must be amini
mum16 AWG three wirewith grounding
type plug connector and rated no less than 1900 Watts.
Back………………2”/50.8mm
Sides……………..6”/156.4mm
Floor……………..0”/0mm
Top……………….24”/610mm
WARNING:
Electrical outlet wiring
must comply with local building
codes and all otherapplicable
regulationsto reduce the risk of
fire, electrical shock and injury.
WARNING: Do not use this
fireplace
if any part of it has been
underwater.Immediately call a
qu
alified service technician to
inspect the fireplace
and replace
any part of the electrical system if
necessary.
ELECTRICALSPECIFICATIONS
Voltage………………120 VAC/60Hz
Total Amps…………..11.3 Amps
Total Watts…………..1345 Watts
Heater Ratings………1200 Watts
WARNING: Disconnect power
beforeattemptingany
maintenance or cleaningto
reduce the risk offire,electrical
shock or personal injury
REPLACING LIGHT BULBS
This fireplace uses two clear 120 Volt, 60Watt, E-
12
socket base light bulbs (small ba
se, chandelier candle
type).The
60 Watt bulbs are located under the log
set/ember bed. Forconvenience,if oneof the bulbs
burns out, it may be agoodidea to replace both of the
light bulbs.
1. Turn offpower to the unit by unplugging the power
cord.
2. Let fireplace cool if it has been operating.
3. Open the front door by pulling the handle.
4.
Removethe two screws that secure the log set in
position.
WARNING: Do not exceed 60
Watts per bulb. Use of higher
rated bulbs may result in afi
re
causing property damage and
personal injury.
3
5. Remove the twoscrews of the front baffle and
take them out.
6. Examine the bulbs to determine which
one
needs to be replaced.
7.
While holding the socket, unscrew the defective
bulb(s).
8.
Install the new light bulb(s) by holding the socket
and screwing them in.
9. Reinstall the baffle
log set and screen. Follow
the above procedure in reverse order.

MAINTENANCE OF MOTORS
The motors used on both blowers
fan and flame
simulator assembly are prelubricated for
the
extended warrantyof themotor,no further
lubrication
is required. However,periodicclea
ning/vacuuming of
the fan/heater unit is recommended.
WARNING: Make sure that the
power is turned off before
proceeding.
Any electrical repairs or rewiring of this unitshould be carried out by alicensed electrician and
accordance
with national and local codes.
If repairing or replacing any electrical component orwiring,
please referto
schematic diagram below.
GLASS INFORMATION
1.
Under no circumstancesshould this
product be operated with missing o
r
broken glass.
2. Do not strike or slam the glass.
3.
Do not use abrasive cleanersto clean the
glass.
4.
Replacement glass is available from the
manufacturer and replacementshouldbe
carried out by a qualified service person.
4

This section provides easy step by step instructions for operating your fireplace.
1. Make sure the unit is unplugged from the power source (see warning on page 6)
2. Plug the heater into a 15AMP/120volt outlet. If the cord does not reach, you may use an extension
cord rated for a minimum of 1900 watts.
To access the controls, open the door of the fireplace at the front of the unit (see Figure A).
FigureA
A. PROPER WAYTO INSTALLING HANDLE
B. MAIN ON/OFF SWITCH
The on/off switch supplies power to all fireplace functions (heater/flame).
C. HEATER ON/OFFSWITCH 1
The HEATER ON/OFF SWITCH 1 supplies power to the heater fan and the heater element.
NOTE: When switched ON, the heater fan and the heater element will operate. But it gives an
output of 600W. It is just half of the total power.
D. HEATER ON/OFFSWITCH 2
The HEATER ON/OFF SWITCH 2supplies powerto the heater element, and the remaining
voltage to the heater.
NOTE: When switched ON, the heater fan and the heaterelement will still operate.But itgives
an anotheroutput of600W.Then, the heater willarriveitstotalvalue of 1200W.The heater fan
and the heater element will not operate if SWITCH 2 is ON but SWITCH 1 is OFF.
E. INSTRUCTIONS FOR POWER
Figure B
5
Inserthandle sthreadi
ng tip
into the hole, turn slightlythe
handleto proper position and
make threading tip get through
the hole,screwing the nut
supplied. See Figure B

This heater is for use on 120 voltsonly.The cord has aplug as shown at A in the following figure.
An adapter as shownat Cis available for connecting three-blade grounding-type plugs to
two-slot receptacles. The green grounding lug extending from the adapter must be connected to
apermanent ground such as aproperly grounded outlet box. The adapter shouldnotbe used if
a three-slot grounded receptacle is available.
Warning: Before servicing this heater be sure to unplug heater from wall outlet. Do not only turn offheater
from the main “ON/OFF”switch, be sure to unplug this heater.
(Adaptor NOT permitted in Canada)
Under CZ22.2 NO. 0 standard
SPECIFICATIONS:
Model:V50HYLC
Voltage: 120V/60HZ Total Amps: 11.3A
Total Watts: 1345W Heating Ratings: 1200W
Dimensions, Inches (H x W X D)
Fireplace 24-3/4”x23-3/8”x13-3/8”
Carton 27-1/2”x29-3/8”x15-3/8”
Weight, Pounds
Fireplace 35
Shipping 45
5
Model: V50HYLD
Voltage: 120V/60HZ Total Amps: 11.3A
Total Watts: 1345W Heating Ratings: 1200W
Dimensions, Inches (H x W X D)
Fireplace 24-7/8”x23-7/8”x13-7
/8”
Carton 27-1/2”x29-3/8”x15-3/8”
Weight, Pounds
Fireplace 35
Shipping 45
6

V50HYLC
Item # Part Description Part Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
VC Top Panel Right Part
Fan/Heater Assembly
Synchronization Motor-120Volt AC w/Terminal
Cord Power 16/3 HPN w/Terminals
ON/OFF Switch
VC Top Panel Left Part
VC Top Panel (Middle Part)
Flame Generator Assembly
Light Bulb Socket
Right Side-panel
Left Side-panel
Door
Door Pivot
Door Adorning
Leg(s)
Back Panel
Electrothermal Hood
Door Knob
Knob Dressing
Air Transfer Panel
Glistening Paper
VL107-02Q
NFHTX186/V
VL051-01
NFHL008-A
VL067-01
VL107-02Q
VL107-02P
VB17001-C-3
VL054-01
VL102-01
VL101-01
VL108-01
VL111-01P
VL117-01-A
SL017-04A
VL109-01
VL035
VCL008
VCL008-01
VCL011
VB17001-C-4
7

4
2
3
9
5
8OR 22
8
REPLACEMENT PARTS PICTURES OF V50HYLC

V50HYLD
Item # Part Description Part Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Top Panel
Fan/Heater Assembly
Synchronization Motor-120Volt AC w/Terminal
Cord Power 16/3 HPN w/Terminals
ON/OFF Switch
Left Side Panel
Right Side Panel
Flame Generator Assembly
Light Bulb Socket w/Wiring Assembly
Door
Door Pivot
Door Knob
Knob Dressing
Legs
Electrothermal Hood
Back Panel
Door Adorning
Cross Band
Air Transfer Panel
Glistening Paper
VL107-02F
NFHTX186/VB17-000G
VL051-01
NFHL008-A
VL067-01
VL101-01P
VL101-02P
VB17001-C-3
VL054-01
VL108-01
VL111-01P
VCL008
VCL008-01
VCL019-01
VL035
VL109-03
VL117-01-A
VL113-01G
VCL011
VB17001-C-4
9

4
2
3
9
5
8OR 21
10
REPLACEMENT PARTS PICTURES OF V50HYLD
