PROEL SESSION6 User manual

SESSION6
compact portable line array
USER MANUAL
MANUALE D'USO

FCC COMPLIANCE NOTICE
This device complies with part 15 of the FCC rules. Operaon is subject to the following two condions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operaon.
CAUTION: Changes or modicaons not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protecon against harmful interference in
a residenal installaon. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instrucon manual, may cause harmful interference to radio communicaons.
However, there is no guarantee that interference will not occur in a parcular installaon. If this equipment does
cause harmful interference to radio or television recepon, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separaon between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of
its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this
from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users should
contact either the retailer where they purchased this product, or their local government oce, for details of where and how they can
take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and condions of the
purchase contract. This product should not be mixed with other commercial wastes for disposal.
The lightning ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure, that may be of sucient magnitude to constute a risk of electric shock to persons.
The exclamaon point within an equilateral triangle is intended to alert the user to the presence of important operang and maintenance
(servicing) instrucons in the literature accompanying the appliance.
The informaon contained in this publicaon has been carefully prepared and checked. However no responsibility will be taken for any errors. All
rights are reserved and this document cannot be copied, photocopied or reproduced in part or completely without wrien consent being obtained
in advance from PROEL. PROEL reserves the right to make any aesthec, funconal or design modicaon to any of its products without any prior
noce. PROEL assumes no responsibility for the use or applicaon of the products or circuits described herein.
Il marchio riportato sul prodoo o sulla documentazione indica che il prodoo non deve essere smalto con altri riu domesci al
termine del ciclo di vita. Per evitare eventuali danni all’ambiente si invita l’utente a separare questo prodoo da altri pi di riu e di
riciclarlo in maniera responsabile per favorire il riulizzo sostenibile delle risorse materiali. Gli uten domesci sono invita a contaare
il rivenditore presso il quale è stato acquistato il prodoo o l’ucio locale preposto per tue le informazioni relave alla raccolta
dierenziata e al riciclaggio per questo po di prodoo. Gli uten aziendali sono invita a contaare il proprio fornitore e vericare i
termini e le condizioni del contrao di acquisto. Questo prodoo non deve essere smalto unitamente ad altri riu commerciali.
Il simbolo del lampo con freccia in un triangolo equilatero intende avverre l'ulizzatore per la presenza di "tensioni pericolose" non isolate
all'interno dell'involucro del prodoo, che possono avere una intensità suciente a costuire rischio di scossa elerica alle persone.
Il punto esclamavo in un triangolo equilatero intende avverre l'ulizzatore per la presenza di importan istruzioni per l'ulizzo e la
manutenzione nella documentazione che accompagna il prodoo.
Le informazioni contenute in questo documento sono state aentamente redae e controllate. Tuavia non è assunta alcuna responsabilità per
eventuali inesaezze. Tu i diri sono riserva e questo documento non può essere copiato, fotocopiato, riprodoo per intero o in parte senza
previo consenso scrio della PROEL. PROEL si riserva il dirio di apportare senza preavviso cambiamen e modiche esteche, funzionali o di
design a ciascun proprio prodoo. PROEL non assume alcuna responsabilità sull’uso o sull’applicazione dei prodo o dei circui qui descri.

4
Avvio Rapido: MODO STEREOQuick Start: STEREO MODE
SETUP PAGE 1/8
STEREO
PUSH TO EDIT
2
1
1) Connect a line level sound source to inputs LEFT & RIGHT.
Collegate una sorgente a livello linea agli ingressi
LEFT & RIGHT.
2) Connect the TOPS to the TOP LEFT and TOP RIGHT outputs.
Collegate i TOPS alle uscite TOP LEFT e TOP RIGHT.
3) Arrange the system at the correct height,
with the TOP’s lower speaker at the same
height of the lower listener’s ears.
con il primo altoparlante in basso del TOP
alla stessa altezza delle orecchie degli
ascoltatori più bassi.
4) In the SETUP MENU select the STEREO SETUP (page 1/8).
Nel MENU SETUP selezionate il SETUP STEREO (pagina 1/8).
B A

5
Avvio Rapido: MODO DUAL Quick Start: DUAL MODE
1) Connect the sound sources to CH1 and/or CH2 inputs, for example a microphone
4) In the SETUP MENU select the DUAL MODE (page 1/9).
Nel MENU SETUP selezionate il MODO DUAL (pagina 1/9).
5) In the IN LEVEL MENU set properly the INPUT LEVELS
for inputs 1&2 (page 2/9).
Nel MENU IN LEVEL impostate i LIVELLI DI INGRESSO
SETUP PAGE 1/9
DUAL
PUSH TO EDIT
+
IN LEVEL PAGE 2/9
GAIN 1:
LEVEL1:
GAIN 2:
LEVEL2:
MIC
0dB
MIC-20
0dB
PUSH TO SELECT
2) Connect the TOPS to the TOP LEFT and TOP RIGHT outputs.
Collegate i TOPS alle uscite TOP LEFT e TOP RIGHT.
3) Arrange the system at the correct height, with the TOP’s lower speaker
at the same height of the lower listener’s ears.
in basso del TOP alla stessa altezza delle orecchie degli
ascoltatori più bassi.
B A

6
Avvio Rapido: MODO MONOQuick Start: MONO MODE
4) In the SETUP MENU select the MONO MODE (page 1/9).
Nel MENU SETUP selezionate il MODO MONO (pagina 1/9).
5) In the IN LEVEL MENU set properly the INPUT LEVELS
for inputs 1&2 (page 2/9).
Nel MENU IN LEVEL
per gli ingressi 1&2 (pagina 2/9).
IN LEVEL PAGE 2/9
GAIN 1:
LEVEL1:
GAIN 2:
LEVEL2:
MIC
0dB
MIC-20
0dB
PUSH TO SELECT
SETUP PAGE 1/9
MONO
PUSH TO EDIT
+
Connect TOP A to the LEFT TOP OUTPUT using the supplied 4-wire cable.
Collegate tra loro i due TOPS con il TOP A in basso e il TOP B in alto (vedi pagina 14).
in dotazione.
1) Connect the sound sources to CH1 and/or CH2 inputs, for example a microphone
3) Arrange the system at the correct height, with the TOP’s lower speaker
at the same height of the lower listener’s ears.
in basso del TOP alla stessa altezza delle orecchie degli
ascoltatori più bassi.
B
A

7
Avvio Rapido: MODO DOUBLEQuick Start: DOUBLE MODE
1
SETUP PAGE 1/8
DOUBLE
PUSH TO EDIT
1) Connect a line level sound source to the
CH 1 input of both systems.
Collegate una sorgente a livello linea
all’ingresso CH1 di entrambi i sistemi.
4) In the SETUP MENU select the DOUBLE MODE (page 1/8).
Nel MENU SETUP selezionate il MODO DOUBLE (pagina 1/8).
TOP B on top (see page 14). Connect TOP A to the
LEFT TOP OUTPUT using the supplied 4-wire cable.
Collegate tra loro i due TOPS con il TOP A in basso
e il TOP B in alto (vedi pagina 14). Collegate il TOP A
in dotazione.
3) Arrange the system at the correct height, with the TOP’s lower speaker
at the same height of the lower listener’s ears.
in basso del TOP alla stessa altezza delle orecchie degli
ascoltatori più bassi.
B
A

8
INDICE
Avvio Rapido: MODO STEREO ................4
Avvio Rapido: MODO DUAL . . . . . . . . . . . . . . . . . . 5
Avvio Rapido: MODO MONO .................6
Avvio Rapido: MODO DOUBLE................7
ACCESSORI FORNITI ........................9
ACCESSORI OPZIONALI ......................9
CONNESSIONI (FIG.1) ......................10
PANNELLO DI CONTROLLO (FIG.2) ............11
FUNZIONI DSP (FIG.3)......................12
CONNESSIONE MODO STEREO & DUAL .......14
COLLEGAMENTO TOP MODO MONO & DOUBLE 14
SPECIFICHE TECNICHE .....................16
DIMENSIONI .............................17
AVVERTENZE PER LA SICUREZZA .............24
IN CASO DI GUASTO .......................24
PROBLEMATICHE COMUNI..................24
CONFORMITÀ CE..........................24
IMBALLAGGIO, TRASPORTO E RECLAMI .......25
GARANZIE E RESI .........................25
INSTALLAZIONE E LIMITAZIONI D’USO.........25
ALIMENTAZIONE E MANUTENZIONE ..........25
INFORMAZIONI GENERALI ..................26
ISTRUZIONI ( FIG. 1 / 2 ) ....................26
IMPOSTAZIONI DSP ( FIG.3 ).................28
INDEX
Quick Start: STEREO MODE ..................4
Quick Start: DUAL MODE ....................5
Quick Start: MONO MODE ...................6
Quick Start: DOUBLE MODE .................7
SUPPLIED ACCESSORIES .....................9
OPTIONAL ACCESSORIES ....................9
CONNECTIONS (FIG.1) .....................10
CONTROL PANEL (FIG.2)....................11
DSP OPERATIONS (FIG.3) ...................12
STEREO & DUAL MODE CONNECTION.........14
MONO & DOUBLE MODE TOP LINKING........14
TECHNICAL SPECIFICATIONS ................16
DIMENSIONS.............................17
SAFETY AND PRECAUTIONS .................18
IN CASE OF FAULT .........................18
TROUBLESHOOTING .......................18
CE CONFORMITY..........................18
PACKAGING, SHIPPING AND COMPLAINT ......19
WARRANTY AND PRODUCTS RETURN .........19
INSTALLATION AND DISCLAIMER .............19
POWER SUPPLY AND MAINTENANCE .........19
GENERAL INFORMATION ...................20
INSTRUCTIONS ( FIG. 1 / 2 ) .................20
DSP SETTINGS ( FIG.3 ) .....................22

9
FRE300BK ESO1500LU10 COVER SESSION6
ACCESSORI FORNITI
• PALO ESTENSIBILE, lunghezza = 60-90 cm
• CAVO SPEAKON 4 FILI lunghezza = 2 m
• COVER per TOPS
OPTIONAL ACCESSORIES
FRE300BK
Professional aluminium floor-stand for speaker with
terminal pieces Ø 35mm. Adjustment: 147-218 cm.
ESO1500LU10
Professional SPEAKON cable (2 x 4 mm2), length: 10 m.
COVERSESSION6
Protecon cover for the subwoofer.
ACCESSORI OPZIONALI
FRE300BK
Supporto professionale in alluminio da pavimento con
terminali Ø 35mm. Regolazione: 147-218 cm.
ESO1500LU10
Cavo SPEAKON professionale (2 x 4 mm2), lungh.: 10 m.
COVERSESSION6
Copertura di protezione per il subwoofer.
SUPPLIED ACCESSORIES
• EXPANDABLE POLE, length = 60-90 cm
• 4 WIRES SPEAKON CABLE length = 2 m
• COVER for TOPS

10
CONNECTIONS (FIG.1) CONNESSIONI (FIG.1)
INGRESSO MIC/LINE
Jack (bilanciato)
MIC/LINE IN
Jack (balanced)
sleeve - ground
ring - cold
LINE
XLR bilanciato maschio
LINE IN
Balanced male XLR
ground
hot
cold
INGRESSO MIC/LINE
Jack (sbilanciato)
MIC/LINE IN
Jack (unbalanced)
ground
cold
ground per cavi da bilanciato
a sbilanciato.
*Note: connect both cold and ground
to make cable from balanced to
unbalanced.
TOP OUTPUTS (speaker outputs)
Speakon Cable Connector
2- 1+
2+ 1-
n.c. 1+
1-
n.c.
STEREO & DUAL modes
LEFT TOP & RIGHT TOP outputs
4-WIRE CABLE (supplied)
MONO & DOUBLE modes
LEFT TOP output only
2- 1+
2+ 1-
1+
1-
2-
2+
LINK (uscita)
XLR bilanciato femmina
LINK (output)
Balanced female XLR
*note: for the best mike cabling we suggest to connect the GND shield wire to pin 1 and to the connector shell at each side
of the cable.
*nota: per un miglior cablaggio microfono, si consiglia di collegare lo schermo GND sia al pin 1 che all’involucro del
conne�ore su ogni lato.
ground
hot
cold
1
1
3
3
21
3
2
1
3
2
2
CAVO MICROFONO
Bilanciato
MIC CABLE
Balanced
ground
hot
cold
1
3
2
*
ground
hot
cold
1
3
2
*

11
SILK PRINT ON THE REAR OF THE PLEXIGLASS
1 COLOR: BLACK
SILK PRINT ON THE REAR OF THE PLEXIGLASS
1 COLOR: BLACK
SILK PRINT ON THE REAR OF THE PLEXIGLASS
1 COLOR: BLACK
SILK PRINT ON THE REAR OF THE PLEXIGLASS
1 COLOR: BLACK
SILK PRINT ON THE REAR OF THE PLEXIGLASS
1 COLOR: BLACK
SILK PRINT ON THE REAR OF THE PLEXIGLASS
1 COLOR: BLACK
CONTROL PANEL (FIG.2) PANNELLO DI CONTROLLO (FIG.2)

12
DSP OPERATIONS (FIG.3) FUNZIONI DSP (FIG.3)
VOLUME: 0dB
...
VOLUME: MUTE
TREBLE = +6dB
TREBLE = -6dB
BASS = +6dB
BASS = -6dB
1-MUSIC
2-LIVE
3-DJ
4-SPEECH
SUB: 0dB
...
SUB: MUTE
CONTRAST: 9
...
CONTRAST: 0
OFF
ON
STEREO 1-MUSIC
VOLUME: 0dB
CH1:LINE CH2:LINE
PUSH TO EDIT
SETUP PAGE 1/8
STEREO
PUSH TO EDIT
2
1
SETUP PAGE 1/9
DUAL
PUSH TO EDIT
+
SETUP PAGE 1/9
MONO
PUSH TO EDIT
+
1
SETUP PAGE 1/8
DOUBLE
PUSH TO EDIT
IN LEVEL PAGE 2/9
GAIN 1:
LEVEL1:
GAIN 2:
LEVEL2:
LINE
0dB
LINE
0dB
PUSH TO SELECT
EQ PAGE 2/8
BASS : 0dB
TREBLE: 0dB
PUSH TO SELECT
GAINx : LINE
MIC
MIC-20
LEVELx : 0dB
...
MUTE
PRESET PAGE 3/8
1-MUSIC
PUSH TO EDIT
SUB LEVEL PAGE 4/8
SUB: 0dB
PUSH TO EDIT
BLUETOOTH PAGE 5/8
OFF
PUSH TO EDIT
LCD PAGE 6/8
CONTRAST=5
PUSH TO EDIT
EXIT PAGE 8/8
EXIT
PUSH AND RETURN
TO MAIN PAGE
INFO PAGE 7/8
CORE LT DSP
Model: SESSION6
FWR rel: 1.0
PROEL

13
VOLUME: 0dB
...
VOLUME: MUTE
TREBLE = +6dB
TREBLE = -6dB
BASS = +6dB
BASS = -6dB
1-MUSIC
2-LIVE
3-DJ
4-SPEECH
SUB: 0dB
...
SUB: MUTE
CONTRAST: 9
...
CONTRAST: 0
OFF
ON
STEREO 1-MUSIC
VOLUME: 0dB
CH1:LINE CH2:LINE
PUSH TO EDIT
SETUP PAGE 1/8
STEREO
PUSH TO EDIT
2
1
SETUP PAGE 1/9
DUAL
PUSH TO EDIT
+
SETUP PAGE 1/9
MONO
PUSH TO EDIT
+
1
SETUP PAGE 1/8
DOUBLE
PUSH TO EDIT
IN LEVEL PAGE 2/9
GAIN 1:
LEVEL1:
GAIN 2:
LEVEL2:
LINE
0dB
LINE
0dB
PUSH TO SELECT
EQ PAGE 2/8
BASS : 0dB
TREBLE: 0dB
PUSH TO SELECT
GAINx : LINE
MIC
MIC-20
LEVELx : 0dB
...
MUTE
PRESET PAGE 3/8
1-MUSIC
PUSH TO EDIT
SUB LEVEL PAGE 4/8
SUB: 0dB
PUSH TO EDIT
BLUETOOTH PAGE 5/8
OFF
PUSH TO EDIT
LCD PAGE 6/8
CONTRAST=5
PUSH TO EDIT
EXIT PAGE 8/8
EXIT
PUSH AND RETURN
TO MAIN PAGE
INFO PAGE 7/8
CORE LT DSP
Model: SESSION6
FWR rel: 1.0
PROEL

14
STEREO & DUAL MODE CONNECTION CONNESSIONE MODO STEREO & DUAL
MONO & DOUBLE MODE TOP LINKING COLLEGAMENTO TOP MODO MONO & DOUBLE
A
B
A
B
A
B
A
B
LOCK UNLOCK
Note: in this configuraon the system works properly also if
TOPS A and B are inverted. You can use equally the supplied
4-wire cable + one oponal 2-wire cable or two oponal
2-wire cables.
Nota: in questa configurazione il sistema funziona correamente
anche se i TOPS A e B sono inver. Potete ulizzare il cavo a
4 fili fornito + un cavo opzionale a 2 fili oppure due cavi
opzionali a 2 fili.
4 WIRES SPEAKON CABLE lenght = 2 m
(SUPPLIED WITH THE PRODUCT)
or
2 WIRES SPEAKON CABLE lenght: 10 m
(OPTIONAL, CODE: ESO1500LU10)
CAVO SPEAKON 4 FILI lunghezza = 2 m
(FORNITO CON IL PRODOTTO)
o
CAVO SPEAKON 2 FILI lunghezza 10 m
(OPZIONALE, CODICE ESO1500LU10)
2 WIRES SPEAKON CABLE lenght: 10 m
(OPTIONAL, CODE: ESO1500LU10)
CAVO SPEAKON 2 FILI lunghezza 10 m
(OPZIONALE, CODICE ESO1500LU10)

15
must NEVER be inverted and the supplied 4-wires
SPEAKON cable must ALWAYS
with the subwoofer.
IMPORTANTE: quando si collegano i due TOPS, la posizione
di A & B non deve MAI SEMPRE
per la connessione con il subwoofer.
4 WIRES SPEAKON CABLE lenght = 2 m
(SUPPLIED WITH THE PRODUCT)
CAVO SPEAKON 4 FILI lunghezza = 2 m
(FORNITO CON IL PRODOTTO)

16
SYSTEM
System type Portable Powered 2.1 System with Two Line Array Tops and One Subwoofer
Maximum SPL Output 128 dB peak system output (pink noise)
Frequency Response (-10dB) 38Hz – 20kHz
SPEAKERS
LF Driver 2 x 10” (254mm) woofer in Bass-Reex conguraon
HF Driver 12 x 3.25” (82mm) neodymium drivers (6 for each TOP)
Coverage Paern 120° x 60°
AMPLIFIER
Type Class D with SMPS
System Power Rang 600 Was LF, 2x300 Was HF Connuous, 2400W Peak
Channels 2 MIC/LINE selectable inputs
Connectors 2 x COMBO (INPUTS), 2 x XLR-M (LINK), 2 x SPEAKON (POWER OUTPUTS)
Controls 1 x LCD with Data Encoder
Processing 24bit / 48KHz CORE DSP: 2-band EQ, Selectable CONFIGURATION and EQ PRESETS, Digital Liming
Wireless Audio Bluetooth built-in receiver
GENERAL SPECIFICATIONS
Cabinet Material Plywood
Finishing High-strength polyurethane black paint
Grille Powder coated perforated steel with an-dust screen
Handles 2 x sides (SUB)
Pole Socket 1 x top M20 (SUB), 1 x boom 35mm (TOP)
Included Accessories M20 / 35mm telescopic pole, 4-wire SPEAKON/SPEAKON cable, 2 x SAT cover
Dimensions (W x H x D) TOP: 112x616x132 mm
SUB: 420x580x490 mm
Weight TOP: 4.5 kg (9.9 lbs) (2x)
SUB: 26.5 kg (58.4 lbs)
SYSTEM: 35.5 kg (78.2 lbs)
Power Supply 230 V~ or 120 V~ - 50/60 Hz with LINE VOLTAGE selector
Rated Consumpon 480 W
TECHNICAL SPECIFICATIONS SPECIFICHE TECNICHE

17
DIMENSIONS DIMENSIONI
58 cm
22.8"
49 cm
19.3"
42 cm
16.5"
M20 pole adaptor
11.2 cm
4.4"
13.2 cm
5.2"
61.6 cm
24.3"
ø35mm Pole Adaptor
A - B connecon and interlocking
(used with MONO setup only)
B A

18
SAFETY AND PRECAUTIONS
• CAUTION: before using this product read carefully the following safety instrucons. Take a look of this manual enrely and preserve it for
future reference.
When using any electric product, basic precauons should always be taken, including the following:
– To reduce the risk, close supervision is necessary when the product is used near children.
– Protect the apparatus from atmospheric agents and keep it away from water, rain and high humidity places.
– This product should be site away from heat sources such as radiators, lamps and any other device that generate heat.
– This product should be located so that its locaon or posion does not interfere with its proper venlaon and heang dissipaon.
– Care should be taken so that objects and liquids do not go inside the product.
– The product should be connected to a power supply mains line only of the type described on the operang instrucons or as marked on the
product. Connect the apparatus to a power supply using only power cord included making always sure it is in good condions.
– WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable.
– Do not cancel the safety feature assured by means of a polarized line plug (one blade wider than the other) or with a earth connecon.
– Make sure that power supply mains line has a proper earth connecon.
– Power supply cord should be unplugged from the outlet during strong thunderstorm or when le unused for a long period of me.
– Do not place objects on the product’s power cord or place it in a posion where anyone could trip over, walk on or roll anything over it. Do not
allow the product to rest on or to be installed over power cords of any type. Improper installaons of this type create the possibility of re hazard
and/or personal injury.
– This product may be capable of producing sound levels that could cause
permanent hearing loss. Exposure to extremely high noise levels may cause
permanent hearing loss. Individuals vary considerably in suscepbility to noise-
induced hearing loss, but nearly everyone will lose some hearing if exposed
to sufficiently intense noise for a period of time. The U.S. Government’s
Occupational Safety and Health Administration (OSHA) has specified the
permissible noise level exposures shown in the following chart. According to
OSHA, any exposure in excess of these permissible limits could result in some
hearing loss. To ensure against potenally dangerous exposure to high sound
pressure levels, it is recommended that all persons exposed to equipment
capable of producing high sound pressure levels use hearing protectors while
the equipment is in operaon. Ear plugs or protectors in the ear canals or over
the ears must be worn when operang the equipment in order to prevent
permanent hearing loss if exposure is in excess of the limits set forth here. Keep
your aenon that children and pets are more suscepble to excessive noise
levels.
IN CASE OF FAULT
• In case of fault or maintenance this product should be inspected only by qualied service personnel when:
– There is a aw either in the connecons or in the supplied connecng cables.
– Liquids have spilled inside the product.
– The product has fallen and been damaged.
– The product does not appear to operate normally or exhibits a marked change in performance.
– The product has been lost liquids or gases or the enclosure is damaged.
• Do not operate on the product, it has no user-serviceable parts inside, refer servicing to an authorized maintenance centre.
TROUBLESHOOTING
No Power • The loudspeaker's "POWER" switch is o.
• Make sure the mains AC outlet is live (check with a tester or a lamp).
• Make sure the mains plug is securely plugged into mains AC outlet.
No Sound • Is the input LEVEL control for the channel turned up?
• The IN LEVEL meter on the display shows a signal? If not check if your signal level is too low or check the signal cable,
mixer and other equipment seng and cabling.
• Are you sure your signal cables works properly? check it using a cable tester or replacing with a new one.
Distorted Sound • Input signal level is too high. Turn down your level controls.
NOTE: The loudspeakers should never be operated at a level which causes the amplier Clip to illuminate constantly.
Dierent channel
level
• Check if are using a balanced cable for one channel and an unbalanced one for the other, as this would cause a
considerable dierence in channel levels.
Noise / Hum • Whenever possible, preferably use only balanced cables. Unbalanced lines may also be used but may result in noise
over long cable runs.
• Somemes it helps to plug all audio equipment into the same AC circuit so they share a common ground.
CE CONFORMITY
• Proel products comply with direcve 2014/30/CE (EMC), as stated in EN 55103-1 and EN 55103-2 standards and with direcve 2014/35/CE
(LVD), as stated in EN 60065 standard.
• Under the EM disturbance, the rao of signal-noise will be changed above 10dB.
Duraon Per Day
In Hours
Sound Level dBA
Slow Response
Typical
Example
890 Duo in small club
692
495 Subway Train
397
2100 Very loud classical music
1.5 102
1105 Trac noise
0.5 110
0.25 or less 115 Loudest parts at a rock concert

19
PACKAGING, SHIPPING AND COMPLAINT
• This unit package has been submied to ISTA 1A integrity tests. We suggest you control the unit condions immediately aer unpacking it.
• If any damage is found, immediately advise the dealer. Keep all unit packaging parts to allow inspecon.
• Proel is not responsible for any damage that occurs during shipment.
• Products are sold “delivered ex warehouse” and shipment is at charge and risk of the buyer.
• Possible damages to unit should be immediately noed to forwarder. Each complaint for package tampered with should be done within eight
days from product receipt.
WARRANTY AND PRODUCTS RETURN
• Proel products have operang warranty and comply their specicaons, as stated by manufacturer.
• Proel warrants all materials, workmanship and proper operaon of this product for a period of two years from the original date of purchase. If
any defects are found in the materials or workmanship or if the product fails to funcon properly during the applicable warranty period, the owner
should inform about these defects the dealer or the distributor, providing receipt or invoice of date of purchase and defect detailed descripon.
This warranty does not extend to damage resulng from improper installaon, misuse, neglect or abuse. Proel S.p.A. will verify damage on returned
units, and when the unit has been properly used and warranty is sll valid, then the unit will be replaced or repaired. Proel S.p.A. is not responsible
for any "direct damage" or "indirect damage" caused by product defecveness.
INSTALLATION AND DISCLAIMER
• Proel products have been expressly designed for audio applicaon, with signals in audio range (20Hz to 20kHz). Proel has no liability for damages
caused in case of lack of maintenance, modicaons, improper use or improper installaon non-applying safety instrucons.
• The installaon of these speakers is provided for indoors, in case of use outdoors be sure that the speakers are installed correctly in a safe
locaon protected from wind, rain and humidity. To avoid performance deterioraon of mechanical, acouscs and electrical parts is not advisable
to leave these speakers exposed outdoors for a long period of me, so we suggest a temporary installaon for the limited sound events.
• The installaon of these speakers is provided for oor or by means of specic stands able to support their weight. Therefore avoid installaon
on unstable elements such as: furniture, chairs and vibrant surfaces as stages or other speakers without appropriate x point specically designed
to avoid speaker movement. Then avoid the use of inadequate supports, we suggest to use PROEL stands and accessories only.
• In case of the speakers are provided of rigging points: DO NOT SUSPEND THE SPEAKERS FROM THE HANDLES, use exclusively these rigging points.
Consult professional rigger or structural engineers prior to suspending loudspeakers from a structure not intended for that use. Always know the
working load limit of the structure supporng the loudspeakers. Always make sure that the rigging hardware minimum rang is at least ve mes
the actual load, speakers and rigging hardware.
• In case of suspended installaons of acve loudspeakers where is not possible to turn on and o the speakers from their appropriate switches,
we recommend to install switches on the mains lines, for this purpose consult an expert electrician for the exact dimension of wiring.
• Locate the speakers as far away as possible from radio or television receivers or other sensive equipment. These speakers have a strong
magnec eld which can induce hum and noise into unshielded devices that are located nearby with consequent deterioraon of recepon of
image and sound.
• Proel S.p.A. reserves the right to change these specicaons at any me without noce.
• Proel S.p.A. declines any liability for damages to objects or persons caused by lacks of maintenance, improper use, installaon not performed
with safety precauons and at the state of the art.
POWER SUPPLY AND MAINTENANCE
• Clean only with dry cloth.
• Check periodically that the slots for its proper venlaon and heang dissipaon are not obstructed by dust, remove the dust using a dry brush
or a compressed air gun.
• The amplied loudspeakers of Proel have been designed with CLASS I construcon and must be connected always to a mains socket outlet with
a protecve earth connecon (the third grounding prong).
• Before connecng the product to the mains outlet make certain that the mains line voltage matches that shown on the rear of the product, a
tolerance of up to ±10% is acceptable.
• Inside the amplied loudspeakers are present special safety devices such as:
ü Amplier over-heang protecon.
ü Protecon against excessive power applied at each speaker.
• THE REPLACEMENT OF FUSES INSIDE THE APPARATUS MUST BE MADE ONLY BY QUALIFIED PERSONNEL.
• CHECK THE CONDITION OF THE PROTECTION FUSE, ACCESSIBLE OUTWARD, ONLY WITH THE APPARATUS SWITCHED OFF AND DISCONNECTED
FROM THE MAINS LINE OUTLET.
• REPLACE THE PROTECTION FUSE ONLY WITH SAME TYPE AS SHOWN ON THE PRODUCT.
• IF AFTER THE SUBSTITUTION, THE FUSE INTERRUPTS AGAIN THE APPARATUS WORKING, DO NOT TRY AGAIN THEN CONTACT THE PROEL
SERVICE CENTRE.

20
INTRODUCTION
Thank you for having chosen a PROEL product.
SESSION6, the top-of-the-range model of the series, is a compact high-power portable array system in an acve 2.1
conguraon, including two tops and one subwoofer. Designed for indoor and outdoor use in live concerts, mobile DJ
setups and corporate applicaons, the SESSION6 combines exibility, portability and performance with a professional
design and a sturdy plywood construcon.
Each top includes six 3.25” neodymium drivers in vercal array conguraon with progressive down lt, for increasing
the vercal coverage. A custom-designed phase plug provides an ultra-wide 120° horizontal coverage and guarantees
perfect voice intelligibility and accurate sound in any part of the listening area. The sub features two 10” high-excursion
woofers with 2.5” voice coil, able to provide very ‘punchy’ and dynamic basses, together with an extended low frequency
response and an impressive SPL.
The system is powered by a 3-channel 2400W Class D amplier and it’s controlled by the powerful PROEL CORE LT
DSP, able to deliver an outstanding sound denion. The signal processing includes a sophiscated Dynamic EQ and 4
EQ PRESETS (MUSIC, LIVE, DJ, SPEECH) to adapt the speakers to any kind of applicaon. The intuive control interface
features a single knob and a large LCD display, for controlling not only the DSP parameters but also the two MIC/LINE
selectable inputs, the system’s conguraon and the built-in BLUETOOTH audio interface.
Thanks to the innovave die-cast fast linking system with integrated connecons, the two tops can be combined
together, forming a longer 12-driver column and allowing the system to be used not only in STEREO mode, but also in
MONO or DOUBLE mode, for an extreme exibility.
A dedicated padded bag is included for storing and transporng the two columns and the provided pole and speaker
cable, for the maximum portability.
INSTRUCTIONS ( FIG. 1 / 2 )
1. LEFT / CH1 - MIC / LINE IN (combo XLR-JACK input)
This is a female combo connector, which accepts a XLR or a JACK plug from almost any type of equipment with a
balanced or unbalanced outputs. The XLR input is wired as follows:
Pin 1 = shield or ground
Pin 2 = + posive or "hot"
Pin 3 = - negave or "cold"
The JACK input is wired as follows:
Tip = + posive or "hot"
Ring = - negave or "cold"
Sleeve = shield or ground
When connecng an unbalanced signal, wire them as follows:
Pin 2 / Tip = + posive or "hot"
Pin 1-3 / Sleeve = shield or ground
NOTE: whenever possible, use always balanced cables. Unbalanced lines may also be used but may result in noise over
long cable runs. In any case, avoid using a balanced cable for one channel and an unbalanced one for the other.
In STEREO mode it works as the LINE input of the system's LEFT CHANNEL.
In DUAL and MONO mode it works as CH1 input, that is summed to CH2 input and sent to both amplier's channels.
In DUAL and MONO modes only, the input sensivity can be selected from the DSP display (page 2/9) as LINE, MIC or
MIC-20. The system's overall level can also be adjusted using the LEVEL control in the DSP main page.
In DOUBLE mode it works as the only LINE input for the system.
2. RIGHT / CH2 - MIC / LINE IN (combo XLR-JACK input)
Same as previous with the following dierences:
In STEREO mode it works as LINE input of RIGHT CHANNEL.
In DOUBLE mode it is DISABLED.
3. LEFT / CH1 LINK (XLR output balanced)
This is a male XLR connector connected in parallel with the LEFT /CH1 input, so it is wired as the input.
In STEREO and DOUBLE modes it can be connected to the inputs of other powered speakers to obtain a more powerful
system.
We recommend to not use this connector in DUAL and MONO modes with MIC and MIC-20 input sensivity.
4. RIGHT / CH2 LINK (XLR output balanced)
Same as above, connected in parallel with the RIGHT / CH2 input.
