PROEL FLASH12HDA User manual

FLASH12HDA
acve processed loudspeaker
USER MANUAL
MANUALE D'USO

FCC COMPLIANCE NOTICE
This device complies with part 15 of the FCC rules. Operaon is subject to the following two condions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operaon.
CAUTION: Changes or modificaons not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protecon against harmful interference in
a residenal installaon. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instrucon manual, may cause harmful interference to radio communicaons.
However, there is no guarantee that interference will not occur in a parcular installaon. If this equipment does
cause harmful interference to radio or television recepon, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separaon between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of
its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this
from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users should
contact either the retailer where they purchased this product, or their local government office, for details of where and how they can
take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and condions of the
purchase contract. This product should not be mixed with other commercial wastes for disposal.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure, that may be of sufficient magnitude to constute a risk of electric shock to persons.
The exclamaon point within an equilateral triangle is intended to alert the user to the presence of important operang and maintenance
(servicing) instrucons in the literature accompanying the appliance.
The informaon contained in this publicaon has been carefully prepared and checked. However no responsibility will be taken for any errors. All
rights are reserved and this document cannot be copied, photocopied or reproduced in part or completely without wrien consent being obtained
in advance from PROEL. PROEL reserves the right to make any aesthec, funconal or design modificaon to any of its products without any prior
noce. PROEL assumes no responsibility for the use or applicaon of the products or circuits described herein.
Il marchio riportato sul prodoo o sulla documentazione indica che il prodoo non deve essere smalto con altri rifiudomesci al
termine del ciclo di vita. Per evitare eventuali danni all’ambiente si invita l’utente a separare questo prodoo da altri pi di rifiue di
riciclarlo in maniera responsabile per favorire il riulizzo sostenibile delle risorse materiali. Gli utendomesci sono invitaa contaare
il rivenditore presso il quale è stato acquistato il prodoo o l’ufficio locale preposto per tue le informazioni relave alla raccolta
differenziata e al riciclaggio per questo po di prodoo. Gli uten
aziendali sono invitaa contaare il proprio fornitore e verificare i
termini e le condizioni del contrao di acquisto. Questo prodoo non deve essere smalto unitamente ad altri rifiucommerciali.
Il simbolo del lampo con freccia in un triangolo equilatero intende avverre l'ulizzatore per la presenza di "tensioni pericolose" non isolate
all'interno dell'involucro del prodoo, che possono avere una intensità sufficiente a costuire rischio di scossa elerica alle persone.
Il punto esclamavo in un triangolo equilatero intende avverre l'ulizzatore per la presenza di importanistruzioni per l'ulizzo e la
manutenzione nella documentazione che accompagna il prodoo.
Le informazioni contenute in questo documento sono state aentamente redae e controllate. Tuavia non è assunta alcuna responsabilità per
eventuali inesaezze. Tui dirisono riservae questo documento non può essere copiato, fotocopiato, riprodoo per intero o in parte senza
previo consenso scrio della PROEL. PROEL si riserva il dirio di apportare senza preavviso cambiamene modifiche esteche, funzionali o di
design a ciascun proprio prodoo. PROEL non assume alcuna responsabilità sull’uso o sul l’applicazione dei prodoo dei circuiqui descri.

3
INDEX
FCC COMPLIANCE NOTICE . . . . . . . . . . . . . . . . . . . 2
TECHNICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . 3
FREQUENCY RESPONSE . . . . . . . . . . . . . . . . . . . . . 4
DIMENSIONS AND FLYING POINTS. . . . . . . . . . . . . 4
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
CONTROL PANEL (FIG.1). . . . . . . . . . . . . . . . . . . . . 6
CONNECTIONS (FIG.2) . . . . . . . . . . . . . . . . . . . . . . 6
CONFIGURATION EXAMPLES (FIG.3) . . . . . . . . . . . 7
SAFETY AND PRECAUTIONS . . . . . . . . . . . . . . . . . . 8
IN CASE OF FAULT . . . . . . . . . . . . . . . . . . . . . . . . . . 8
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . 8
CE CONFORMITY. . . . . . . . . . . . . . . . . . . . . . . . . . . 9
PACKAGING, SHIPPING AND COMPLAINT . . . . . . . 9
WARRANTY AND PRODUCTS RETURN . . . . . . . . . . 9
INSTALLATION AND DISCLAIMER . . . . . . . . . . . . . . 9
POWER SUPPLY AND MAINTENANCE . . . . . . . . . . 9
GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . 10
INPUT AND CONTROL INSTRUCTIONS (FIG.1/2/3)10
INDICE
SPECIFICHE TECNICHE . . . . . . . . . . . . . . . . . . . . . . 3
RISPOSTA IN FREQUENZA. . . . . . . . . . . . . . . . . . . . 4
DIMENSIONI E PUNTI DI SOSPENSIONE. . . . . . . . . 4
ACCESSORI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
PANNELLO DI CONTROLLO (FIG.1) . . . . . . . . . . . . . 6
CONNESSIONI (FIG.2) . . . . . . . . . . . . . . . . . . . . . . . 6
ESEMPI CONFIGURAZIONI (FIG.3) . . . . . . . . . . . . . 7
AVVERTENZE PER LA SICUREZZA . . . . . . . . . . . . . 12
IN CASO DI GUASTO . . . . . . . . . . . . . . . . . . . . . . . 12
PROBLEMATICHE COMUNI. . . . . . . . . . . . . . . . . . 12
CONFORMITÀ CE. . . . . . . . . . . . . . . . . . . . . . . . . . 13
IMBALLAGGIO, TRASPORTO E RECLAMI . . . . . . . 13
GARANZIE E RESI . . . . . . . . . . . . . . . . . . . . . . . . . 13
INSTALLAZIONE E LIMITAZIONI D’USO. . . . . . . . . 13
ALIMENTAZIONE E MANUTENZIONE . . . . . . . . . . 13
INFORMAZIONI GENERALI . . . . . . . . . . . . . . . . . . 14
ISTRUZIONI INGRESSI E CONTROLLI (FIG.1/2/3) . 14
MODEL FLASH12HDA MODELLO FLASH12HDA
System type 2-way vented Sistema 2 vie bass-reflex
Low Frequency Device 12” CELESTION woofer with 3"VC Altoparlante bassi woofer 12" CELESTION - 3" VC
High Frequency Device 1” CELESTION compression driver with 1.75"VC Altoparlante aldriver a compressione 1" CELESTION - 1.75" VC
Angular Coverage 90° H x 60° V Copertura angolare 90° H x 60° V
Frequency response 50 Hz - 20 kHz Risposta in Frequenza 50 Hz - 20 kHz
Max SPL at 1mt (peak) 128 dBspl SPL massima a 1m (picco) 128 dBspl
Amplifier Connuous
Power
HF: 100 W Class AB
LF: 500 W Class D with SMPS
Potenza Connua
Amplificatore
Al: 100 W Classe AB
Bassi: 500 W Classe D con SMPS
Processing 96 KHz, 40 bit floang point CORE DSP Processore DSP 96 KHz, 40 bit floang point CORE DSP
Input Impedance 30 kohm balanced / 15 kohm unbalanced Impedenza ingresso 30 kohm sbilanciato / 15 kohm bilanciato
Input Sensivity LINE: +4 dBu / MIC: +34 dBu Sensibilità nom. ingresso LINE: +4 dBu / MIC: +34 dBu
Controls LEVEL, MIC/LINE selector, PRESET selector (FLAT,
DJ, SPEECH, MONITOR), GND li
Controlli LEVEL, seleore MIC/LINE, seleore PRESET (FLAT,
DJ, SPEECH, MONITOR), GND li
Connectors INPUT: COMBO (XLR-F/JACK)
LINK: XLR-M
Conneori INPUT: COMBO (XLR-F/JACK)
LINK: XLR-M
Power Supply 230 VAC or 120 VAC - 50/60 Hz Tensione alim. di rete 230 VAC o 120 VAC - 50/60 Hz
Maximum Consumpon 650 VA Consumo massimo 650 VA
Rated Consumpon* 200 VA Consumo nominale* 200 VA
Construcon Reinforced hi density Polypropylene Costruzione Polipropilene
Cabinet Colour Black Colore Nero
Flying System 4 x M10 Sistema di sospensione 4 x M10
Pole Adapter 1 x boom Flangia per suppor1 x soo
Handles 2 x sides, 1 x top Maniglie 2 x ai la, 1 x sopra
Monitor taper 42° Inclinazione monitor 42°
Weight 19.4 Kg (47.7 lb) Peso 19.4 Kg
Dimensions (W x H x D) 390 x 630 x 360 mm Dimensioni (LxAxP) 390 x 630 x 360 mm
* Rated consumpon is measured with pink noise with a crest factor of 12 dB,
this can be considered a standard music program.
* Il consumo nominale è misurato con un rumore rosa con un faore di cresta
di 12 dB, considerato come un programma standard di musica.
TECHNICAL SPECIFICATIONS SPECIFICHE TECNICHE

4
FREQUENCY RESPONSE RISPOSTA IN FREQUENZA
DIMENSIONS AND FLYING POINTS DIMENSIONI E PUNTI DI SOSPENSIONE
63 cm
24.8"
39 cm
15.4"
36 cm
14.2"
Pole Adapter
M10 Flying Point
M10 Flying Point
42°
10k5k2k1k500200100
50
40 20kHz
120.0
dBSPL
110.0
100.0
90.0
80.0
70.0
0
-6
-12
-18
-24
-30
dB
30°
60°
90° -90°
-60°
-30°
2000 Hz
4000 Hz
8000 Hz
16000 Hz
HORIZONTAL
HORN POLAR PLOT
Q = 5.3 DI = 7.3
0
-6
-12 -18 -24 -30
dB 30°
60°
90°
-90°
-60°
-30°
2000 Hz
4000 Hz
8000 Hz
16000 Hz
VERTICAL
HORN POLAR PLOT
Q = 7.0 DI = 8.5

5
ACCESSORIES
KP210
Adjustable speaker pole for speaker-subwoofer separaon
with terminal pieces Ø 35 mm. Supplied with a bolt
locking mechanism incorporang a steel pin for extra
safety. Adjustment: 825 - 1320 mm.
FRE300BK
Professional aluminium floor-stand for speaker with
terminal pieces Ø 35mm. Supplied with a screw locking
system, a steel safety pin and “Aircushioned” air-damped
release device to grant a flexible, fast and easy adjustment.
Adjustment: 1470-2180 mm.
AC169
Black galvanized steel eyebolt MA10 for flying mount.
KPTFL12
C-shape metal bracket for wall mount with 4 step of 15°
combined with 2 step of 40°.
KPTNX04
Horizontal and Vercal adjustable metal bracket for wall
mount, bar length 25 cm, 12.5° 4 step vert. aiming, 10°
7 step hor. aiming, must be used in conjunction with
KPTFL12.
PLH300
Single aluminium coupler with M12 bolt, always use two
couplers with the KPTL12 for each speaker.
COVERFL12
Heavy duty cover for carrying.
ACCESSORI
KP210
Supporto distanziatore cassa-subwoofer regolabile in
acciaio con terminali Ø 35mm. Dotato di meccanismo di
chiusura a vite con pin di sicurezza in acciaio. Regolazione:
825 - 1320 mm.
FRE300BK
Supporto professionale in alluminio da pavimento con
terminali Ø 35mm. Con sistema di blocco a vite, pin di
sicurezza in acciaio e disposivo di smorzamento ad aria
per la massima velocità e facilità di regolazione.
Regolazione: 1470-2180 mm.
AC169
Golfare in acciaio zincato nero MA10 per sospensione.
KPTFL12
Supporto in metallo a C per montaggio a muro con 4 passi
da 15° combinabili con 2 passi a 40°.
KPTNX04
Staffa in metallo regolabile in orizzontale e vercale per
montaggio a muro, lunghezza barra 25 cm, 4 passi a 12.5°
in vercale e 7 passi a 10° in orizzontale, deve essere usata
con l'accessorio KPTFL12.
PLH300
Accoppiatore per truss in alluminio con bullone M12,
usarne sempre due insieme all'accessorio KPTFL12.
COVERFL12
Copertura di protezione per il trasporto.
COVERFL12
FRE300BK
PLH300
AC169 KPTNX04
KPTFL12
KP210

6
CONTROL PANEL (FIG.1) PANNELLO DI CONTROLLO (FIG.1)
CONNECTIONS (FIG.2) CONNESSIONI (FIG.2)
INPUT (ingresso)
Jack (bilanciato)
INPUT
Jack (balanced)
sleeve - ground
tip - hot
ring - cold
INPUT (ingresso)
XLR bilanciato maschio
INPUT
Balanced male XLR
ground
hot
cold
INPUT (ingresso)
Jack (sbilanciato)
INPUT
Jack (unbalanced)
ground
tip - hot
cold
*nota: connettere insieme cold e ground
per cavi da bilanciato a sbilanciato
*note: connect both cold and ground
to make cable from balanced to unbalanced
LINK (uscita)
XLR bilanciato femmina
LINK (output)
Balanced female XLR
ground
hot
cold

7
CONFIGURATION EXAMPLES (FIG.3) ESEMPI CONFIGURAZIONI (FIG.3)
PROEL suggested
equipment:
M-series mixer
dynamic
microphone
PROEL suggested
types:
DM580 - DM586 - DM226
DM220 - DM800
or
WM wireless mic
LEFT
FLASH12HDA (sat)
+ SW115HA (sub)
RIGHT
FLASH12HDA (sat)
+ SW115HA (sub)
RIGHT
FLASH12HDA
LEFT
FLASH12HDA
basic system
2x FLASH12HDA
600W x2 (1200W)
FLASH12HDA
(mic in)
single voice system
FLASH12HDA
(mic in)
single voice system
minimal
conference
system
SUB+SAT system
2x SW115HA
+
2x FLASH12HDA
500W x2 + 600W x2
(2200W)
SET THE EQ PRESET ON “SPEECH”
AND LINE/MIC ON “MIC”
L
R
L
R
L

8
SAFETY AND PRECAUTIONS
• CAUTION: before using this product read carefully the following safety instrucons. Take a look of this manual enrely and preserve it for
future reference.
When using any electric product, basic precauons should always be taken, including the following:
– To reduce the risk, close supervision is necessary when the product is used near children.
– Protect the apparatus from atmospheric agents and keep it away from water, rain and high humidity places.
– This product should be site away from heat sources such as radiators, lamps and any other device that generate heat.
– This product should be located so that its locaon or posion does not interfere with its proper venlaon and heang dissipaon.
– Care should be taken so that objects and liquids do not go inside the product.
– The product should be connected to a power supply mains line only of the type described on the operang instrucons or as marked on the
product. Connect the apparatus to a power supply using only power cord included making always sure it is in good condions.
– WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable.
– Do not cancel the safety feature assured by means of a polarized line plug (one blade wider than the other) or with a earth connecon.
– Make sure that power supply mains line has a proper earth connecon.
– Power supply cord should be unplugged from the outlet during strong thunderstorm or when leunused for a long period of me.
– Do not place objects on the product’s power cord or place it in a posion where anyone could trip over, walk on or roll anything over it. Do not
allow the product to rest on or to be installed over power cords of any type. Improper installaons of this type create the possibility of fire hazard
and/or personal injury.
– This product may be capable of producing sound levels that could cause
permanent hearing loss. Exposure to extremely high noise levels may cause
permanent hearing loss. Individuals vary considerably in suscepbility to noise-
induced hearing loss, but nearly everyone will lose some hearing if exposed
to sufficiently intense noise for a period of time. The U.S. Government’s
Occupational Safety and Health Administration (OSHA) has specified the
permissible noise level exposures shown in the following chart. According to
OSHA, any exposure in excess of these permissible limits could result in some
hearing loss. To ensure against potenally dangerous exposure to high sound
pressure levels, it is recommended that all persons exposed to equipment
capable of producing high sound pressure levels use hearing protectors while
the equipment is in operaon. Ear plugs or protectors in the ear canals or over
the ears must be worn when operang the equipment in order to prevent
permanent hearing loss if exposure is in excess of the limits set forth here. Keep
your's aenon that children and pets are more suscepble to excessive noise
levels.
IN CASE OF FAULT
• In case of fault or maintenance this product should be inspected only by qualified service personnel when:
– There is a flaw either in the connecons or in the supplied connecng cables.
– Liquids have spilled inside the product.
– The product has fallen and been damaged.
– The product does not appear to operate normally or exhibits a marked change in performance.
– The product has been lost liquids or gases or the enclosure is damaged.
• Do not operate on the product, it has no user-serviceable parts inside, refer servicing to an authorized maintenance centre.
TROUBLESHOOTING
No Power • The loudspeaker's "POWER" switch is off.
• Make sure the mains AC outlet is live (check with a tester or a lamp).
• Make sure the mains plug is securely plugged into mains AC outlet.
No Sound • Is the input LEVEL control for the channel turned up?
• Is the SIGNAL LED illuminated? If not check if your signal level is too low or check the signal cable, mixer and other
equipment seng and cabling.
• Are you sure your signal cables works properly? check it using a cable tester or replacing with a new one.
• Is the SPEAKON cable connector correctly inserted? turn it clockwise unl it clicks.
• Are you sure your power cable works properly? check it using a cable tester or replacing with a new one.
Distorted Sound • Input signal level is too high. Turn down your level controls.
NOTE: The loudspeakers should never be operated at a level which causes the amplifier Clip LEDs to illuminate
constantly.
Different channel
level
• Check if are using a balanced cable for one channel and an unbalanced one for the other, as this would cause a
considerable difference in channel levels.
• Be sure that your loudspeaker system is fully connected and both loudspeakers have the same impedance.
Noise / Hum • Enable GND LIFT buon on rear panel, if the problem persist press all GND LIFT buons for all system's amplifiers.
• Whenever possible, preferably use only balanced cables. Unbalanced lines may also be used but may result in noise
over long cable runs.
• Somemes it helps to plug all audio equipment into the same AC circuit so they share a common ground.
Duraon Per Day
In Hours
Sound Level dBA
Slow Response
Typical
Example
8 90 Duo in small club
692
4 95 Subway Train
397
2 100 Very loud classical music
1.5 102
1 105 Traffic noise
0.5 110
0.25 or less 115 Loudest parts at a rock concert

9
CE CONFORMITY
• Proel products comply with direcve 2004/108/EC (EMC), as stated in EN 55103-1 and EN 55103-2 standards and with direcve 2006/95/CE
(LVD), as stated in EN 60065 standard.
• Under the EM disturbance, the rao of signal-noise will be changed above 10dB.
PACKAGING, SHIPPING AND COMPLAINT
• This unit package has been submied to ISTA 1A integrity tests. We suggest you control the unit condions immediately aer unpacking it.
• If any damage is found, immediately advise the dealer. Keep all unit packaging parts to allow inspecon.
• Proel is not responsible for any damage that occurs during shipment.
• Products are sold “delivered ex warehouse” and shipment is at charge and risk of the buyer.
• Possible damages to unit should be immediately nofied to forwarder. Each complaint for package tampered with should be done within eight
days from product receipt.
WARRANTY AND PRODUCTS RETURN
• Proel products have operang warranty and comply their specificaons, as stated by manufacturer.
• Proel warrants all materials, workmanship and proper operaon of this product for a period of two years from the original date of purchase. If
any defects are found in the materials or workmanship or if the product fails to funcon properly during the applicable warranty period, the owner
should inform about these defects the dealer or the distributor, providing receipt or invoice of date of purchase and defect detailed descripon.
This warranty does not extend to damage resulng from improper installaon, misuse, neglect or abuse. Proel S.p.A. will verify damage on returned
units, and when the unit has been properly used and warranty is sll valid, then the unit will be replaced or repaired. Proel S.p.A. is not responsible
for any "direct damage" or "indirect damage" caused by product defecveness.
INSTALLATION AND DISCLAIMER
• Proel products have been expressly designed for audio applicaon, with signals in audio range (20Hz to 20kHz). Proel has no liability for damages
caused in case of lack of maintenance, modificaons, improper use or improper installaon non-applying safety instrucons.
• The installaon of these speakers is provided for indoors, in case of use outdoors be sure that the speakers are installed correctly in a safe
locaon protected from wind, rain and humidity. To avoid performance deterioraon of mechanical, acouscs and electrical parts is not advisable
to leave these speakers exposed outdoors for a long period of me, so we suggest a temporary installaon for the limited sound events.
• The installaon of these speakers is provided for floor or by means of specific stands able to support their weight. Therefore avoid installaon
on unstable elements such as: furniture, chairs and vibrant surfaces as stages or other speakers without appropriate fix point specifically designed
to avoid speaker movement. Then avoid the use of inadequate supports, we suggest to use PROEL stands and accessories only.
• In case of the speakers are provided of rigging points: DO NOT SUSPEND THE SPEAKERS FROM THE HANDLES, use exclusively these rigging points.
Consult professional rigger or structural engineers prior to suspending loudspeakers from a structure not intended for that use. Always know the
working load limit of the structure supporng the loudspeakers. Always make sure that the rigging hardware minimum rang is at least five mes
the actual load, speakers and rigging hardware.
• In case of suspended installaons of acve loudspeakers where is not possible to turn on and offthe speakers from their appropriate switches,
we recommend to install switches on the mains lines, for this purpose consult an expert electrician for the exact dimension of wiring.
• Locate the speakers as far away as possible from radio or television receivers or other sensive equipment. These speakers have a strong
magnec field which can induce hum and noise into unshielded devices that are located nearby with consequent deterioraon of recepon of
image and sound.
• Proel S.p.A. reserves the right to change these specificaons at any me without noce.
• Proel S.p.A. declines any liability for damages to objects or persons caused by lacks of maintenance, improper use, installaon not performed
with safety precauons and at the state of the art.
POWER SUPPLY AND MAINTENANCE
• Clean only with dry cloth.
• Check periodically that the slots for its proper venlaon and heang dissipaon are not obstructed by dust, remove the dust using a dry brush
or a compressed air gun.
• The amplified loudspeakers of Proel have been designed with CLASS I construcon and must be connected always to a mains socket outlet with
a protecve earth connecon (the third grounding prong).
• Before connecng the product to the mains outlet make certain that the mains line voltage matches that shown on the rear of the product, a
tolerance of up to ±10% is acceptable.
• Inside the amplified loudspeakers are present special safety devices such as:
9Transformer and amplifier over-heang protecon.
9Protecon against excessive power applied at each speaker.
• THE REPLACEMENT OF FUSES INSIDE THE APPARATUS MUST BE MADE ONLY BY QUALIFIED PERSONNEL.
• CHECK THE CONDITION OF THE PROTECTION FUSE, ACCESSIBLE OUTWARD, ONLY WITH THE APPARATUS SWITCHED OFF AND DISCONNECTED
FROM THE MAINS LINE OUTLET.
• REPLACE THE PROTECTION FUSE ONLY WITH SAME TYPE AS SHOWN ON THE PRODUCT.
• IF AFTER THE SUBSTITUTION, THE FUSE INTERRUPTS AGAIN THE APPARATUS WORKING, DO NOT TRY AGAIN THEN CONTACT THE PROEL
SERVICE CENTRE.

10
GENERAL INFORMATION
Thank you for having chosen a PROEL product.
FLASH12HDA is an acve full-range 2-way system featuring high-grade CELESTION transducers and a DSP-controlled
lightweight amplifier module in a sturdy polypropylene cabinet. The transducers employed include a 1” compression
driver with a 1.75" voice coil on a wide constant coverage horn, designed for providing an extended response and low
distoron levels, and a high-power 12” woofer with a 3” voice coil.
The profile of the cabinet allows the use of the enclosure also as a stage monitor, whereas four M10 suspension points
are provided for installaon in a variety of posions using the oponal accessories available. Two convenient aluminium
handles, plus a third on top of the cabinet, make for easy handling and transportaon.
The amplifier module includes a 100 W CLASS AB amplifier for the HF secon and a 500 W CLASS D amplifier with SMPS
for the LF secon. A built-in DSP secon features state-of-the-art signal processing with 40 bit floang point resoluon
and 24 bit AD/DA converters, for a superior sonic performance. Advanced funcons include full parametric EQ for the
system fine tuning, delay lines for speaker alignment, up to 48 dB/oct. crossover filters, three bands of dynamic EQ,
compressors/limiters for protecng the transducers against distoron and power overloads. 4 different PRESETS (FLAT,
DJ, SPEECH, MONITOR) opmized for using the system in different applicaons are also available.
INPUT AND CONTROL INSTRUCTIONS (FIG. 1 / 2 / 3)
1. LINE/MIC IN (combo XLR-JACK input)
This is a female combo connector, which accepts a XLR or a JACK plug from almost any type of equipment with a
balanced or unbalanced outputs. The XLR input is wired as follows:
Pin 1 = shield or ground
Pin 2 = + posive or "hot"
Pin 3 = - negave or "cold"
The JACK input is wired as follows:
Tip = + posive or "hot"
Ring = - negave or "cold"
Sleeve = shield or ground
When connecng an unbalanced signal, wire them as follows:
Pin2 / Tip = + posive or "hot"
Pin 1-3 / Sleeve = shield or ground
NOTE: whenever possible, use always balanced cables. Unbalanced lines may also be used but may result in noise over
long cable runs. In any case, avoid using a balanced cable for one channel and an unbalanced one for the other.
2. LINK (XLR output)
This is a male XLR connector, it is connected in parallel with the respecve LINE IN input, so the LINK is wired as LINE IN
input. Connect these to the inputs of other powered speakers to make an array.
3. GND LIFT switch
This switch lithe ground of the balanced audio inputs from the earth-ground of the amplifier. If you have HUM noise
problem on one or more loudspeaker try to change the posion of these switches (oen all up or all down for all the
amplifiers in the system). Please note that to have an effect all cables must be balanced.
4. MIC / LINE switch
This switch adjusts the gain of the LINE/MIC input varying the sensivity between MIC, suited to connect a microphone,
and LINE, suited to connect a device with high level output like a MIXER, a CD player etc.
NOTE: do not use the MIC sensivity to "pump up" the volume with the LINE level equipment, in order to avoid the AD
converter saturaon that could produce very annoying distoron.
5. LEVEL control
Rotary level control: it aenuates the level of the signal sent to the LINE input. The aenuaon ranges from “0” fully
closed (the signal is completely aenuated) to “10” fully open, nominal level (the signal is not aenuated in any way,
so is fed to the internal amplifier at the same level at which it arrives on input).
