PROGRESSIVE DESK FLT-01 User manual

V 1.03
FLT-01
User Manual

P a g e | 2
Table of Contents
Have any queries? Our expert engineers are here to help!
[email protected] progressivedesk.com
1-800-828-9414
Caution 3
Specifications 4
Dimensional Drawing 5
Components 6
Assembly 7
Operations 10
Troubleshooting 11

Warning
Pinch Point
Keep hands and
fingers clear.
Caution
Ensure no obstacles are in the desk's path. Ensure the
tabletop is not touching any walls. Ensure all cords are
appropriate length to accommodate the change in height.
Keep children away from electric height-adjustable desks, control units, and handsets. There is a
risk of injury and electric shock.
During the Reset Procedure, the desk will retract 7mm below the lowest normal operating height.
Ensure no obstacles impede this motion.
Keep all electrical components away from liquids.
Do not sit or stand on the desk frame. Do not crawl or lie under the desk frame.
Do not place any objects taller than 20" underneath the desk.
P a g e | 3

Specifications
P a g e | 4
Input Voltage
Specification Description
120 VAC, 60 Hz
24VDC
25.5"
23.1" - 48.6"
180 lbs
1.57"/s
1.18"/s
10% (2 minutes on, 18 minutes off)
< 50 dB
Steel
Powder Coat - White, Black, Grey
Adjustable Leveling Feet
Output Voltage
Stroke (movement)
Height Range (without tabletop)
Weight Capacity (load)
No Load Speed
Full Load Speed
Duty Cycle
Operating Noise
Frame Material
Finish
Leveling
Standby < 0.1W (Activated by Default)
Low Power Mode
Soft Start and Stop
Features Description
The table lift will accelerate to maximum speed and decelerate to a stop to ensure
smooth travel.
The Anti-Collision feature will help protect the table lift against obstacles which
impede the motion of travel. There are 3 force settings which can be detected
during travel, 22lbs, 33lbs, and 44lbs.
The Smart Remote has the ability to save preset height locations for convenience.
Set the numbered buttons on the Smart Remote for quick and seamless adjustment.
Memory Presets
Anti-Collision

5x 0.30"
6.40"
1.30"
7.78"
7.88"
23.1"
22.7"
17.40"
1.50"
2.76"
48.6"
19.60"
Dimensional Drawing
P a g e | 5

P a g e | 6
Components
Important: The drawings below are for reference only and may be slightly different from the physical product.
Please contact us if you have missing or damaged components.
Included Allen Wrench (B4) Phillips Head Screwdriver
and/or Electric Driver
Tape Measure
Tools You
Will Need
No. Part Qty.
Bracket
A1
Remote
A4 1
1
Control Box
A5 1
Leg
A2 1
Power Cord
A6 1
A6 1
Base Plate
A3 1
Extension Cable
No. Part Qty.No. Part Qty.
Allen Wrench
B3 4
M6x16 Countersunk
Machine Screws
B4 1
S5x16 Wood Screws
B1 9
M6x10 Machine Screws
B2 4

Assembly
STEP 1: Attach the Bracket to the Tabletop
P a g e | 7
Method A: Progressive Desk tabletop
Line up the Bracket (A1) with the predrilled holes on the underside of the tabletop and insert the M6x18 machine screws
and washers included with your tabletop. Use the Allen Wrench included with your tabletop to tighten each machine screw
to secure the bracket to the tabletop.
Method B: Third-Party Tabletop
Position the Bracket (A1) so that the wider flange side is 2.87” further from the edge than the narrow side to center the
bracket on the tabletop. Mark all five holes’ location. Use a power drill with a 5/32” drill bit to drill a hole 0.5” deep at each
location. Install 5x S5x20 Wood Screws (B1).
A1
M6 Washer
M6x18

Insert the Leg (A2) into the Bracket and align the holes. Secure with 4x M6x10 Machine Screws (B2) using Allen Wrench
(B4).
Assembly
STEP 2: Install the Leg to the Bracket
Place the Remote (A4) and Control Box (A5) at the desired location and mark all four holes’ locations.
Use a power drill with a 5/32” drill bit to drill a hole 0.5” deep at each location.
Use 4x S5x16 Wood Screws (B1) to secure the Remote (A4) and Control Box (A5).
STEP 3: Secure and connect the Remote and Control Box
P a g e | 8
B1
B1
B2
A2
A4
A5

B3
A3
Assembly
STEP 4: Connect Cables
P a g e | 9
Connect the Remote (A4) to the HS port of the Control Box (A5).
Connect the Power Cord (A6) to the Control Box (A5).
Connect the Cable from the Leg (A2) to the M1 Port of the Control Box (A5). Connect the Extension Cable (A7) to the Leg
cable if the Leg Cable is not long enough to reach the Control Box (A5).
Secure and organize cables as desired.
STEP 5: Install the Base Plate to the Leg
Place the Base Plate (A3), with the feet facing upwards, onto the leg and secure using 4x M6x16 Counter Sunk Machine
Screws (B3). Tighten screws with Allen Wrench (B4) and ensure the screws are flush with the surface of the base plate.
STEP 6: Flip the Table Lift Upright and Initiate the Reset Procedure
After flipping the table life upright, adjust the leveling feet to level the table. Proceed to the reset procedure after leveling. It
is critical that the reset procedure is completed before using the table lift.

P a g e | 10
Operations
Normal Operation
Using the wired remote, press and hold the 'Up' button to raise the table lift. To lower the table lift, press and hold the
'Down' button. The 'Up' and 'Down' buttons are momentary controlled, when they are released, the table lift will stop
immediately.
To set a preset location, move the table lift to the desired height. Press the 'M' button followed by a numbered button. The
LED display will flash an 'S', followed by an 'S - Number'. This will indicate that the preset has been saved.
To use a preset, press any of the numbered buttons and the table lift will begin to move to the preset position. It is
important to ensure that no obstacles impede the motion of travel. To stop the table lift, press any button.
If the table lift does not function as intended or the LED display flashes "RSt", please follow the Reset Procedure outlined
in the next section.
Using the wired smart remote, retract the table lift to the lowest position. Press
and hold the 'Down' button again until the LED display flashes "RST".
Press and hold the 'M' button until the LED display flashes the starting height (if
the display returns to "RST" before the next step, repeat this step).
To change the value of the starting height, use the 'Up', 'Down' to increase and
decrease by 0.1. Use the '1', '2' to increase and decrease by 1s. Use the '3', and
'4' buttons to increase or decrease by 10s.
Once the correct value is displayed, wait 5 seconds until the LED display
flashes "RST". Follow the Reset Procedure outlined in the above section to save
the new starting height.
Note: the LED display has a tolerance of ±0.1.
1
3
M
M
Setting the LED Display
Reset Procedure
WARNING: During the Reset Procedure, the table lift will retract 7mm below the lowest normal operating height.
Please ensure that no obstacles impede this motion of travel.
1. Move the desk frame to the lowest position. (If there is "RST" displayed on the
remote, continue to step 3).
2. To initiate the Reset Procedure, press and hold the down button on the remote until
"RST" is displayed. Release the down button.
3. Press and hold the down button on the remote, the desk frame will begin to retract
7mm lower than the lowest normal operating height. Continue to hold the down button
until the frame rises slightly and comes to a stop at the normal lowest position. To stop
motion at any time, release the down button.
4. Once the desk frame has completed the Reset Procedure, the desk height will be
displayed on the remote.

Error Code
E01
E02
E03
E04
E07
E08
E10
E09
H01
M1 overcurrent protection
M2 overcurrent protection
M3 overcurrent protection
M4 overcurrent protection
M1 hall error
M2 hall error
M3 hall error
M4 hall error
Over heat / Duty
Cycle protection
All columns stop moving and remote displays E01-E04. Ensure that the total weight
capacity of the table lift has not been exceeded and that no obstacles obstruct the
movement. Press any key and remote will display RST, initiate the Reset Procedure. If the
issue persists, disconnect and reconnect all of the lifting columns, including the main
power. Repeat the Reset Procedure.
All columns stop moving, remote displays H01 (if LED screen available). Allow the system
to rest for 18 minutes, then it may be used normally. Follow the Duty Cycle rating to
ensure no issues arise from overheating.
All columns stop moving and remote displays E07-E10. Ensure that all columns are still
properly connected to the control box. Check to see if any cables have been damaged.
Press any key and remote will display RST, initiate the Reset Procedure. If the issue
persists, disconnect and reconnect all of the lifting columns, including the main power.
Repeat the Reset Procedure.
Error Summary Description
Error Codes (remotes with LED display)
Problem
Remote LED
is off.
Table lift does not
move when motion
control buttons are
pressed.
Table lift travels at
a significantly
slower speed than
rate specification.
Unusual noise
during travel.
Table lift stops
abruptly during
travel.
Table lift is
not level.
Low power mode activated Press any button on the remote and LED will activate.
Disconnect and reconnect the RJ-45 remote connector.
Ensure connection is secure and cable is not damaged.
Follow "Setting Limit Switches" instructions to remove the programmed limit. If maximum or
minimum height limit has been reached, please move the system in the opposite direction.
Disconnect and reconnect the Lifting Columns, Control Box, AC Power, and Remote.
Ensure weight capacity has not exceeded the maximum load rating.
Ensure weight capacity has not exceeded the maximum load rating.
Ensure there are no obstacles in the path of the table lift. If the movement contin-
ues to fail, initiate the Reset Procedure.
Disconnect and reconnect all cables (Lifting Column, Control Box, AC Power,
and Remote), then initiate the Reset Procedure.
Connection issue
Weight issue
Obstacle
Out of sync
Limit switch reached
Connection issue
Weight issue
Possible Cause Corrective Action
Troubleshooting Guide
Have any queries? Our expert engineers are here to help!
[email protected] progressivedesk.com
1-800-828-9414
P a g e | 11
Troubleshooting
