PROGRESSIVE DESK FLT-07 User manual

Contents
Caution
Specifications
Dimensional Drawing
Components/Setup
Operation/Reset Procedure
Troubleshooting
Model: FLT-07 User Guide
1
2
3
4
5
6

Ensure no obstacles are in the column's path. Ensure the
columns are not touching any walls. Ensure all cords
are appropriate length to accommodate the change in
height.
Warning
Pinch Point
Keep hands and
fingers clear.
Keep children away from electric height-adjustable lifting columns, control units, and handsets.
There is a risk of injury and electric shock.
During the Reset Procedure, the columns will retract 7mm below the lowest normal
operating height, ensure no obstacles impede this motion of travel.
Keep all electrical components away from liquids.
Do not sit or stand on the lifting columns. Do not crawl or lie under the lifting columns.
Do not place any objects taller than 20" underneath the lifting columns.
01 Caution

02Specifications
Duty Cycle 10% Max. 2 mins on, 18 mins off
Height Range 24"- 56" (without table top)
Weight Capacity 880 lbs (440lbs Per Leg)
Input Voltage 120 VAC, 60 Hz
Output Voltage 24 VDC
Stroke 32"
Speed 0.5"/sec
Material Aluminum Alloy
Feature Description
Soft Start and Stop The tablelift will accelerate to maximum speed and
deccelerate to a stop to ensure smooth travel.
Memory Presets The Smart Remote has the ability to save preset height locations for convenience. Set the numbered buttons on the Smart Remote
for quick and seamless adjustment.
*When using the FLT-07 with the included control box, the stroke size will be 31" due to the safety feature built into the
control box.

3.8"
3.3"
4.4"
6.7"
Ø0.5"
Ø0.2"
2.5"
2.5"
24.0"
0.5"
0.5"
7.9"
4.4"
1.4"
3.2"
1.6"
7.9"
4.4"
1.9"
0.8"
3.9"
1.6"
0.3"
0.3"
Legs
Remote
M
34
2
1
˄˅
5.7"
3.3"
2.0"
3.4"
2.2"
1.4" 0.2"
Control Box
AC
F HS M2
10.1"
0.1"
0.3"
3.5"
1.6"
3.5"
0.7"
AC
M2
F
HS
M1
M1
03Dimensional Drawing

FLT-07
CONTROL BOX
F
HS
M2AC
M1
110/240VAC
WIRED REMOTE
FLT-07
LIFTING COLUMN [M1]
FLT-07
LIFTING COLUMN [M2]
Lifting Columns x 2 Control Box and Remote
AC Power Cord
04Components
04
Setup
M
34
2
1
˄˅M
34
2
1
˄˅M
34
2
1
˄˅

WARNING: During the Reset Procedure, the table lift will retract 7mm below the lowest normal operating height,
please ensure that no obstacles impede this motion of travel.
1. Move the table lift to the lowest position. (If there is an 'RSt' displayed on the remote, continue
to step 3.)
2. To initiate the Reset Procedure, press and hold the down button on the remote until "ASr" is
displayed. Release the down button.
3. Press and hold the down button on the remote, the table lift will begin to retract 7mm lower
than the lowest normal operating height. To stop motion at any time, let go of the down button.
4. Once the table lift has completed the Reset Procedure, height will be displayed on the remote.
05Operation
Using the wired smart remote, retract the table lift to the lowest position. Press and
hold the 'Down' button again until the LED display flashes "RST".
Press and hold the 'M' button until the LED display flashes the starting height (if
the display returns to "RSt" before the next step, repeat this step).
To change the value of the starting height, use the 'Up', 'Down' to increase and
decrease by 0.1. Use the '1', '2' to increase and decrease by 1s. Use the '3', and '4'
buttons to increase or decrease by 10s.
Once the correct value is displayed, wait 5 seconds until the LED display flashes
"RSt". Follow the Reset Procedure outlined in the next section to save the new
starting height.
Note: the LED display has a tolerance of ±0.1.
Normal Operation
Using the wired remote, press and hold the 'Up' button to raise the table lift. To lower the table lift, press and hold
the 'Down' button. The 'Up' and 'Down' buttons are momentary controlled, when they are released, the table lift will
stop immediately.
To set a preset location, move the table lift to the desired height. Press the 'M' button followed by a numbered
button. The LED display will flash an 'S', followed by an 'S - Number'. This will indicate that the preset has been saved.
To use a preset, press any of the numbered buttons and the table lift will begin to move to the preset position. It is
important to ensure that no obstacles impede the motion of travel. To stop the table lift, press any button.
If the table lift does not function as intended or the LED display flashes "RSt", please follow the Reset Procedure
outlined in the next section.
Setting the LED Display
Reset Procedure

06Troubleshooting
Problem Possible Cause Corrective Action
Low power mode
activated Press any button on the remote and LED will activate.
Connection issue Disconnect and reconnect the RJ-45 remote connector. Ensure connection is
secure and cable is not damaged.
Limit switch reached
Follow "Setting Limit Switches" instructions to remove the programmed limit. If
maximum or minimum height limit has been reached, please move the system
in the opposite direction.
Connection issue Disconnect and reconnect the Lifting Columns, Control Box, AC Power, and
Remote.
Table lift travels at a
significantly slower
speed than rated
specification.
Weight issue Ensure weight capacity has not exceeded the maximum load rating.
Unusual noise during
travel. Weight issue Ensure weight capacity has not exceeded the maximum load rating.
Table lift stops abruptly
during travel. Obstacle Ensure there are no obstacles in the path of the table lift. If the movement continues to fail, initiate the Reset Procedure.
Table lift is not level. Out of sync Disconnect and reconnect all cables (Lifting Column, Control Box, AC Power,
and Remote), then initiate the Reset Procedure.
Troubleshooting Guide
Remote LED is off.
Table lift does not
move when motion
control buttons are
pressed.
Error Code Error Summary Description
E01 M1 overcurrent protection
E02 M2 overcurrent protection
E03 M3 overcurrent protection
E04 M4 overcurrent protection
E07 M1 hall error
E08 M2 hall error
E09 M3 hall error
E10 M4 hall error
H01 Over heat /duty cycle
protection
All columns stop moving, remote displays H01 (if LED screen available). Allow
the system to rest for 16 minutes, use normally. Follow the Duty Cycle rating to
ensure no issues arise from overheating.
Error Codes (remotes with LED display)
All columns stop moving and remote displays E01-E04. Ensure that the total
weight capacity of the table lift has not been exceeded and that no obstacles
obstruct the movement. Press any key and remote will display
RST, initiate the Reset Procedure. If the issue persists, disconnect and
reconnect all of the lifting columns, including the main power. Repeat the Reset
Procedure.
All columns stop moving and remote displays E07-E10. Ensure that all columns
are still properly connected to the control box. Check to see if any cables have
been damaged. Press any key and remote will display RST, initiate the Reset
Procedure. If the issue persists, disconnect and reconnect all of the lifting
columns, including the main power. Repeat the Reset Procedure.
