PROGRESSIVE DESK FLT-09 User manual

V 1.05
Scan for video assembly!
FLT-09
User Manual

Caution 3
Specifications 4
Dimensional Drawing 5
Components
6
Assembly 7
Operations 9
Troubleshooting 12
P a g e | 2
Table of Contents
Have any queries? Our expert engineers are here to help!
[email protected] progressivedesk.com
1-800-828-9414

Warning
Pinch Point
Keep hands and
fingers clear.
Caution
Ensure no obstacles are in the desk's path. Ensure the
tabletop is not touching any walls. Ensure all cords are
appropriate length to accommodate the change in height.
Keep children away from electric height-adjustable desks, control units, and handsets. There is a
risk of injury and electric shock.
During the Reset Procedure, the desk will retract 7mm below the lowest normal
operating height. Ensure no obstacles impede this motion of travel.
Keep all electrical components away from liquids.
Do not sit or stand on the desk frame. Do not crawl or lie under the desk frame.
Do not place any objects taller than 20" underneath the desk.
P a g e | 3

Specifications
P a g e | 4
Input Voltage
Specification Description
120 VAC, 60 Hz
24 VDC
25.5"
23.6" - 49.1"
330 lbs (110 lbs per leg)
1.57"/s
1.18"/s
10% (2 minutes on, 18 minutes off)
< 50 dB
Steel
Powder Coat - White, Black, Grey
Adjustable Leveling Feet
Standby < 0.1W
IP51 Legs and IP20 Controller
Output Voltage
Stroke (Movement)
Height Range (without tabletop)
Weight Capacity (load)
No Load Speed
Full Load Speed
Duty Cycle
Operating Noise
Frame Material
Finish
Leveling
Low Power Mode
Protection Class
UL (Customizable)
Certification
Soft Start and Stop
Feature Description
The tablelift will accelerate to maximum speed and deccelerate to a stop to ensure
smooth travel.
The Anti-Collision feature will help protect the tablelift against obstacles which impede
the motion of travel. There are 3 force settings which can be detected during travel,
22lbs, 33lbs, and 44lbs.
The Smart Remote has the ability to save preset height locations for convenience.
Set the numbered buttons on the Smart Remote for quick and seamless adjustment.
Memory Presets
Anti-Collision

Dimensional Drawing
*Feet and column style may vary slightly
P a g e | 5

4mm Allen Wrench (included) Phillips Head Screwdriver
and/or Power Drill
Tape Measure
9
9
2
1
3
10
10
8
6
4
7
P a g e | 6
Components
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Qty
3
3
2
1
1
4
1
1
16
28
16
2
1
1
1
Description
Feet
Leg
Side Bracket
Frame 1
Frame 2
Center Rail
120° Frame 1
120° Frame 2
M6x14 Machine Screw
M6x10 Machine Screw
M5x20 Wood Screw
M5x16 Wood Screw
Remote
Extension Cable
Control Box

Assembly
P a g e | 7
STEP 1
Attach the 120° Frames (7,8) to one of the Legs (2) as
shown in the picture below. Line up the holes on the
Leg with the holes on the Frames.
Use the supplied Allen Wrench to insert four M6x10
Machine Screws (10) through the holes on the Frame
(7,8) going into the Leg (2). Rotate each screw just a
few turns until all four are inserted, then tighten them.
STEP 3
Slide the Side Brackets (3) into both Frames (4,5).
Attach the brackets using two M6x14 Machine Screws
(9).
STEP 4
Slide the Center Rails (6) into the 120° Frames (7,8)
and attach them into position using sixteen of the
M6x10 Machine Screws (10).
STEP 5
Attach each Foot (1) to each Leg (2) with four M6x14
Machine Screws (9) and tighten them.
STEP 2
Place one of the Legs (2) into one of the Frames (4,5)
and line up the holes.
Use the supplied Allen Wrench to insert four M6x10
Machine Screws (10) through the holes on the Frame
(4,5) going into the Leg (2). Rotate each screw just a
few turns until all four are inserted, then tighten them.
Repeat the process for the other Leg and Frame.

Assembly
P a g e | 8
STEP 6
Place the assembled three-leg frame onto the
underside of your tabletop. Adjust the width of the
frame to fit your tabletop by sliding the two halves
apart.
We recommend leaving at least 1.25" of the tabletop
extending beyond the assembled frame. Make sure to
center the Side Brackets (3).
STEP 9
Connect the cable from each Leg (2) directly into the
control box. Use cable extenders when necessary.
Then connect the hand remote cable to the control
box. Use the adhesive-backed cable clips to secure
the cables so they are not loose and in the way.
STEP 10
We recommend having two people for this step. Flip
the fully assembled desk by the legs (not by the
tabletop).
IMPORTANT
Prior to normal operation, please complete a Reset
Procedure outlined in the next section.
STEP 7
If your tabletop has pre-drilled holes, skip ahead to
Step 8. If not, lock the position of the Center Rails
using eight of the M6x10 Machine Screws (10). Make
sure the screws make contact with the Center Rails (6)
by sliding them as needed.
STEP 8
Ensure that the wood screws are not too long for
your tabletop.
If you have a Progressive Desk tabletop, please use
the provided machine screws included with the
abletop. Attach the frame to the tabletop using seven
of the M5x20 Wood Screws (12).
Attach the included Hand Remote so the front of the
remote is lined up with the tabletop edge. Place the
remote anywhere along the edge so that you'll have
easy access to it. Use two of the M5x16 Wood Screws
(11) to attach and secure the remote to the tabletop.
Do not over-tighten the screws as this could cause
damage to the components.

1234 M
1
2
3
4
M
P a g e | 9
Operations
REMOTE BUTTONS
RESET PROCEDURE
HEIGHT CALIBRATION
MEMORY PRESET PROGRAMMING
Height Display
UP - Hold to move table lift up
DOWN - Hold to move table lift down
Memory Preset 1
Memory Preset 5
Memory Preset 3
Memory Preset 4
Memory Preset programming button
WARNING: During the Reset Procedure, the table lift will retract 0.28 inches below the lowest normal operating
position. Ensure there are not obstructions in the path of the table lift. Release the DOWN button to stop motion at any
time.
1. Use the UP or DOWN button to bring the desk to
the desired height.
2. Press M button once, followed by the desired
Memory Preset button.
1. If remote height display shows "ASr", skip to step 4.
2. Move the table lift to the lowest position using DOWN button.
3. Once at the lowest position, press and hold the DOWN button on the remote until
height display shows "ASr". Release the DOWN button.
4. Press and hold the DOWN button, the table lift will move down 0.28 inches below the
lowest normal operating position. Continue to hold the DOWN button until the table lift
moves back up to the lowest normal operating position. Release the DOWN button.
5. The table lift height will be displayed on the remote height display and is now ready
for use.
Calibrate the Remote height display to match actual height of desk which may differ depending on feet height or table top
thickness.
1. Move the table lift to the lowest position using the DOWN button. Measure the height from the floor to surface of table
top. If measured height does not match the height on the remote height display, continue with the following steps.
2. Press and hold the DOWN button until height display shows "ASr". Release the DOWN button.
3. Press and hold the M button until the height display flashes.
4. Use the UP and DOWN buttons to match the height display with your measured height.
5. Once the correct value is displayed, do not touch the remote until the height display flashes "ASr". Hold the DOWN
button until the table lift slightly lowers, then slightly rises back up. Release when the table lift height is displayed on the
remote.

P a g e | 10
Operations
REMOTE CONTROL LOCK
To Lock
Press and hold the M button. The remote height display will show "S-", then it will show the table lift height, and finally
it will display "LOC". The remote control buttons are now locked.
To Unlock
Press and hold the M button until the height display shows the table lift height.
HEIGHT DISPLAY UNITS (inch or centimeter)
1. Move the table lift to the lowest position using the DOWN button.
2. Press and hold the DOWN button until the display shows "ASr". Release the DOWN button.
3. Hold the 2 button to select through the options. Release once the display shows the code corresponding to the desired
setting.
"10.3" - centimeters
"10.4" - inches
Once the selection is made, "ASr" will show up on the display.
4. Hold the DOWN button until the table lift slightly lowers, then slightly rises back up. Release when the table lift height is
displayed on the remote.
COLLISION DETECTION SENSITIVITY
1. Move the table lift to the lowest position using the DOWN button.
2. Press and hold the DOWN button until the display shows "ASr". Release the DOWN button.
3. Hold the UP button to select through the options. Release once the display shows the code corresponding to the desired
setting.
"10.5" - 22lbs
"10.6" - 33lbs
"10.7" - 55lbs
Once the selection is made, "ASr" will show up on the display.
4. Hold the DOWN button until the table lift slightly lowers, then slightly rises back up. Release when the table lift height is
displayed on the remote.

P a g e | 11
Operations
MEMORY PRESET ONE-TOUCH and CONSTANT-TOUCH MODE
One-Touch mode is the default setting. The memory preset button may be pressed once without holding and the table lift
will move to the desired height. Any button may be pressed to stop movement.
Constant-Touch mode requires you to hold the memory preset button until the desired height is reached. Releasing the
memory preset button earlier will make the table lift stop immediately.
MINIMUM AND MAXIMUM HEIGHT LIMIT
Resetting to Default Minimum and Maximum Height Limit
1. Press the M button once and wait for the display to show "S-".
2. Hold the M button until the display shows "555" and then release.
Setting Maximum Height Limit
1. Use the UP or DOWN button to bring the desk to the desired maximum height limit.
2. Press the M button once. "S-" will appear on the display screen. Press the UP button once, the "S-" will flash once.
3. Hold the M button until the display shows "999". Release the M button.
Setting Minimum Height Limit
1. Use the UP or DOWN button to bring the desk to the desired minimum height limit.
2. Press the M button once. "S-" will appear on the display screen. Press the DOWN button once, the "S-" will flash once.
3. Hold the M button until the display shows "000". Release the M button.
1. Move the table lift to the lowest position using the DOWN button.
2. Press and hold the DOWN button until the display shows "ASr". Release the DOWN button.
3. Hold the 1 button to select through the options. Release once the display shows the code corresponding to the desired
setting.
"10.1" - One-Touch
"10.2" - Constant-Touch
Once the selection is made, "ASr" will show up on the display.
4. Hold the DOWN button until the table lift slightly lowers, then slightly rises back up. Release when the table lift height is
displayed on the remote.

Code
E01 - E04
E07
E08
E09
E10
H01
Power issue
or
Firmware issue
M1 - Connection issue or
Legs are uneven
M2 - Connection issue or
Legs are uneven
M3 - Connection issue or
Legs are uneven
M4 - Connection issue or
Legs are uneven
Over heat / Duty
Cycle protection
Ensure AC outlet is not faulty.
Ensure all parts in the table lift are authentic and compatible.
Initiate Reset Procedure to clear the error.
Allow the system to rest for 18 minutes, then it may be used
normally. Follow the Duty Cycle rating listed in Specifications
to prevent overheating.
Ensure all Legs are securely connected to the Control Box and
cables are free of damage.
Ensure there are no obstructions affecting the table lift travel path.
Ensure weight on table lift is evenly distributed and does not exceed
table lift limits. Initiate Reset Procedure to clear the error.
Description Solution
Problem
Table lift is
not level
Remote
height is off
Table lift
unresponsive
Significantly
slow movement
Unusual noise
during travel
Table lift stops
abruptly
Connection issue Disconnect and reconnect all cables (Lifting Column, Control Box, AC
Power, and Remote), then initiate the Reset Procedure.
Ensure weight on table lift is evenly distributed and does not exceed
table lift limits, then initiate the Reset Procedure.
Press any button on the Remote.
Ensure Remote and Power Cord connection to
Control Box is secure and free of damage.
Please refer to Setting Minimum and Maximum Height Limit.
Disconnect and reconnect all cables connected to Control Box.
Ensure all cables are secure and free of damage.
Ensure weight on table lift is evenly distributed and
does not exceed table lift limits.
Ensure weight on table lift is evenly distributed and
does not exceed table lift limits.
Ensure there are no obstructions affecting the table lift travel path.
Weight issue
Weight issue
Weight issue
Obstruction
Low Power
Mode active
Connection issue
Connection issue
Travel limits
reached
Description Solution
P a g e | 12
Troubleshooting
Have any queries? Our expert engineers are here to help!
[email protected] progressivedesk.com
1-800-828-9414
