Progressive FLT-02 User manual

Model: FLT-02 User Guide
Contents
Caution
Specifications
Dimensional Drawing
Components
Assembly
Reset Procedure
Operation
Troubleshooting
Scan for video assembly!
1
2
3
4
5-7
8
8
9

Ensure no obstacles are in the desk's path. Ensure the
tabletop is not touching any walls. Ensure all cords are
appropriate length to accommodate the change in height.
Warning
Pinch Point
Keep hands and
fingers clear.
Keep children away from electric height-adjustable desks, control units, and handsets. There is a
risk of injury and electric shock.
During the Reset Procedure, the desk will retract 7mm below the lowest normal
operating height. Ensure no obstacles impede this motion of travel.
Keep all electrical components away from liquids.
Do not sit or stand on the desk frame. Do not crawl or lie under the desk frame.
Do not place any objects taller than 20" underneath the desk.
01 Caution

02 Specifications
Input Voltage
Output Voltage
Stroke (movement)
Height Range (without tabletop)
Base Width
Minimum Tabletop Size
Weight Capacity (load)
No Load Speed
Full Load Speed
Duty Cycle
Operating Noise
Frame Material
Finish
Leveling
Low Power Mode
Certification
Feature Description
Soft Start & Stop The desk frame will accelerate to maximum speed and decelerate to a stop to
ensure smooth travel.
Memory Presets
The smart remote has the ability to save preset height locations for convenience.
Set the numbered buttons on the smart remote for quick and seamless
adjustment.
Collision-Detection
The collision-detection feature will help protect the desk frame against obstacles
which impede the motion of travel. There are three force settings which can be
detected during travel: 22lbs, 33lbs, and 44lbs. This feature can be disabled by the
user.
120VAC, 60 Hz
24VDC
25.5"
23.6” - 49.1”
39.6" minimum - 74" maximum
45" x 25"
270 lbs (135 lbs per leg)
1.57"/s
1.18"/s
10% (2 minutes on, 18 minutes off)
< 50 dB
SPCC/ SPHC Steel
Powder Coat - White, Black, Grey
Adjustable Leveling Feet
Standby < 0.1W
UL, cUL, and BIFMA,

Retracted - 23.6"
22.6"
2"
27.5"
Maximum Width - 72.4"
Minimum Width - 43"
8.2"
10" 10"
17.7"
0.3"
*Feet and column style may vary slightly
03Dimensional Drawing
Extended - 49.1"

04Components
Included Allen Wrench (A) Phillips Head Screwdriver
and/or Power Drill Tape Measure
21
1 2
1 1
18
4
Attention: The drawings below are for reference only and may be slightly different from the physical
product. Please contact customer service if you are missing any components.
2
10
Leg Frame End
Frame End CB Center Rails Side Brackets
Control Box Remote Power Cord
Extension Cable
M6x10
Machine Screw
M6x14
Machine Screw
M6x35
Machine Screw
S5x20
Wood Screw
Cable Clips
S5x16
Wood Screw
2
1
2
16
7
2
5
8
11
14
3
6
9
12
15
1
4
7
10
13
16
Foot
(Pre-Installed Glides)
Progressive Desk Tabletop
Included Hardware
17M6x13
Machine Screw
7
If you purchased a Progressive Desk tabletop,
use the machine screws included in the tabletop
packaging (#17) instead of the wood screws (#14).
Progressive Desk tabletops will have pre-drilled
threaded holes for installation.
Tools You
Will Need

05Assembly
STEP 1
STEP 2
STEP 3
Expand frame to separate components
Use the Allen wrench to partially install each machine screw (12) until all screws are inserted
before fully tightening. Repeat for the second leg.
Ensure the frame end (4) is positioned as shown.
Use the Allen wrench to install 2 machine screws (13) into the side bracket (6). Repeat for the
second leg.
Attach legs to frame ends
Separate control box (7), center rails (5), and frame ends (3,4).
Install side brackets to frame ends

06Assembly
Place desk frame onto tabletop
Connect both frame ends using the center rails
STEP 4
STEP 5
STEP 6
Install foot with pre-installed glides
Ensure the gap is facing inward
and is closer to the top edge.
Extend the desk frame to align with the pre-drilled holes in the
tabletop. If you are using your own tabletop, allow the tabletop
to extend 1.5" beyond the side brackets.
Insert center rails (5) to join frame ends (3,4) together. Do not insert
or tighten machine screws until Step 8.
Use Allen wrench to install foot (2) using 4 machine screws (11). Repeat for the second leg.

07Assembly
Install control box & connect all peripherals
Secure center rails
STEP 7
STEP 8
STEP 9
Secure desk frame & remote to tabletop
If you have your own tabletop, position the desk
frame so that the tabletop extends 1.5" beyond
the side brackets (6). Use a power drill to install 7
wood screws (14) into the hole positions.
It is required to complete the reset procedure
in the next section prior to operating your
standing desk.
Progressive Desk Tabletop
If you have a Progressive Desk tabletop, use the
machine screws (18) included in the tabletop
packaging. Line up the desk frame with the pre-
drilled holes on the underside of the tabletop and
insert all machine screw before using the Allen
wrench to tighten each machine screw (18).
Third-Party Tabletop
M2
FHS
Use the Allen wrench to secure both center
rails (5) using 8 machine screws (11). The
machine screws should be tightened
against the center rails.
AC M1
•Plug in remote (8) to HS.
•Plug in nearest leg (1) to M2.
Use extension cord (10) if
needed.
•Plug in power cord (9) to AC.
•Plug in nearest leg (1) to M1.
Use extension cord (10) if
needed.
Attach power cord (9) to control box (7).
Use the included self-adhesive cable ties (16)
to secure loose wires to the underside of your
tabletop.
We recommend having two people for this
step. Flip the fully assembled desk by the legs
(not by the tabletop). Adjust the pre-
installed glides on the feet (2) as needed.
Attach both legs (1) to the control box (7). Use
the included extension cable (10) if necessary.
Slide the control box (7) into frame end CB (4).
Attach remote (8) to control box (7).
Line up the remote (8) with the tabletop
edge and install it to the tabletop using
a power drill and 2 wood screws (15).

08
Operation
Setting the LED display
Using the wired smart remote, retract the table lift to the lowest position. Press
and hold the 'Down' button again until the LED display flashes "RST".
Press and hold the 'M' button until the LED display flashes the starting height (if
the display returns to "RST" before the next step, repeat this step).
To change the value of the starting height, use the 'Up', 'Down' to increase and
decrease by 0.1. Use the '1', '2' to increase and decrease by 1s. Use the '3', and
'4' buttons to increase or decrease by 10s.
Once the correct value is displayed, wait 5 seconds until the LED display
flashes "RST". Follow the Reset Procedure outlined in the above section to save
the new starting height.
Note: the LED display has a tolerance of ±0.1.
WARNING: During the Reset Procedure, the table lift will retract 7mm below the lowest normal operating height.
Please ensure that no obstacles impede this motion of travel.
1. Move the desk frame to the lowest position. (If there is "RST" displayed on the remote,
continue to step 3).
2. To initiate the Reset Procedure, press and hold the down button on the remote until "RST" is
displayed. Release the down button.
3. Press and hold the down button on the remote, the desk frame will begin to retract 7mm lower
than the lowest normal operating height. Continue to hold the down button until the frame rises
slightly and comes to a stop at the normal lowest position. To stop motion at any time, release
the down button.
4. Once the desk frame has completed the Reset Procedure, the desk height will be displayed
on the remote.
Reset Procedure
●
●
●
●
●
●
Up button, adjust the desk upwards. Press and hold to continue travel.
Down button, adjust the desk downwards. Press and hold to continue travel.
Position 1, user’s first stored height position. Press once and desk will travel to the saved position.
Position 2, user’s second stored height position. Press once and desk will travel to the saved position.
Position 3, user’s third stored height position. Press once and desk will travel to saved position.
Position 4, user’s fourth stored height position. Press once and desk will travel to the saved position.
"▲"
"▼"
"1"
"2"
"3"
"4"
●Memory set position key. Press once followed by pressing 1, 2, 3, or 4 to save current height position.
"M"

09Troubleshooting
Problem Possible Cause Corrective Action
Low power mode
activated Press any button on the remote and LED will activate.
Connection issue Disconnect and reconnect the RJ-45 remote connector. Ensure connection is
secure and cable is not damaged.
Limit switch reached
Follow "Setting Limit Switches" instructions to remove the programmed limit. If
maximum or minimum height limit has been reached, please move the system
in the opposite direction.
Connection issue Disconnect and reconnect the Lifting Columns, Control Box, AC Power, and
Remote.
Table lift travels at a
significantly slower
speed than rated
specification.
Weight issue Ensure weight capacity has not exceeded the maximum load rating.
Unusual noise during
travel. Weight issue Ensure weight capacity has not exceeded the maximum load rating.
Table lift stops abruptly
during travel. Obstacle Ensure there are no obstacles in the path of the table lift. If the movement continues to fail, initiate the Reset Procedure.
Table lift is not level. Out of sync Disconnect and reconnect all cables (Lifting Column, Control Box, AC Power,
and Remote), then initiate the Reset Procedure.
Troubleshooting Guide
Remote LED is off.
Table lift does not
move when motion
control buttons are
pressed.
Error Code Error Summary Description
E01 M1 overcurrent protection
E02 M2 overcurrent protection
E03 M3 overcurrent protection
E04 M4 overcurrent protection
E07 M1 hall error
E08 M2 hall error
E09 M3 hall error
E10 M4 hall error
H01 Over heat /duty cycle
protection
All columns stop moving, remote displays H01 (if LED screen available). Allow
the system to rest for 16 minutes, use normally. Follow the Duty Cycle rating to
ensure no issues arise from overheating.
Error Codes (remotes with LED display)
All columns stop moving and remote displays E01-E04. Ensure that the total
weight capacity of the table lift has not been exceeded and that no obstacles
obstruct the movement. Press any key and remote will display
RST, initiate the Reset Procedure. If the issue persists, disconnect and
reconnect all of the lifting columns, including the main power. Repeat the Reset
Procedure.
All columns stop moving and remote displays E07-E10. Ensure that all columns
are still properly connected to the control box. Check to see if any cables have
been damaged. Press any key and remote will display RST, initiate the Reset
Procedure. If the issue persists, disconnect and reconnect all of the lifting
columns, including the main power. Repeat the Reset Procedure.
Have any queries? Our expert engineers are here to help!
Progressivedesk.com [email protected]1-800-828-9414
