Progressive FLT-04 User manual

Contents
Caution
Specifications
Dimensional Drawing
Components
Assembly
Setup
Operation/Reset Procedure
Troubleshooting
Model: FLT-04 User Guide
1
2
3,4
5
6
7
8
9

Ensure no obstacles are in the column's path. Ensure the
columns are not touching any walls. Ensure all cords
are appropriate length to accommodate the change in
height.
Warning
Pinch Point
Keep hands and
fingers clear.
Keep children away from electric height-adjustable lifting columns, control units, and handsets.
There is a risk of injury and electric shock.
During the Reset Procedure, the columns will retract 7mm below the lowest normal
operating height, ensure no obstacles impede this motion of travel.
Keep all electrical components away from liquids.
Do not sit or stand on the lifting columns. Do not crawl or lie under the lifting columns.
Do not place any objects taller than 20" underneath the desk.
01 Caution

Duty Cycle 10% Max. 2 mins on, 18 mins off
Height Range 23.5” - 49” (without table top)
Minimum Table Top Size 43"x 24”
Weight Capacity 700lbs (175 lbs Per Leg)
Input Voltage 120 VAC, 60 Hz
Output Voltage 24 VDC
Stroke 25.5"
Speed 1.50"/sec
Material Steel
Certification UL
Feature Description
Soft Start and Stop The tablelift will accelerate to maximum speed and
deccelerate to a stop to ensure smooth travel.
Memory Presets The Smart Remote has the ability to save preset height locations for convenience. Set the numbered buttons on the Smart Remote
for quick and seamless adjustment.
02 Specifications

1.9"
1.4" 0.8"
0.6"
2.8" 1.6"
Ø1.8"
Ø0.4"
0.4"
0.2"
1.3"
2.8" 2.4"
0.6"
3.5"
7.1" 6.5"
0.8"
3.4"
6.3"
0.6" 6.4"
5.1"
1.0"
6.1"
7.1"
0.1"
0.1"
Ø0.25"
Ø0.20"
1.9"
0.1"
Legs
Brackets
Stand-Offs
22.0"
3.8"
1.7"
0.5"
6.5"
7.0"
2.0" 3.2"
0.5"
1.0"
M6X10
03Dimensional Drawing

Control Box
Wired Remote
AC
HS M1 M2 M3
1.8"
5.8"
0.6"
0.5"
AC
M4
M1 M2 M3 M4
HS
10.1"
5.8"
Ø0.2
0.6000
M
34
2
1
˄˅
5.7"
3.3"
2.0"
3.4"
2.2"
1.4" 0.2"
04
Dimensional Drawing

Leg Stand-Off
Wood Screw
M5x20
Wood Screw
M5x16
Control Box Remote Power Cable LC Cable (59") Cable Clip
Glide
(Pre-installed)
Machine Screw
M6x14
VT Bracket
Noise Attenuation
Pad x16
x4 x4
x24 x4
x1
x32
x4
x15
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
Qty
4
4
4
4
16
1
1
1
4
15
32
24
4
Description
Leg
Stand-Off
Glide (Pre-installed)
VT Bracket
Noise Attenuation Pad
Control Box
Remote
Power Cable
LC-Cable (59")
Cable Clip
Wood Screw: M5x20
Machine Screw: M6x14
Wood Screw: M5x16
x1 x1 x4
x4
05
Components

STEP 6
Now that everything’s in place we can start connecting it
all together. Connect the remote (P7) to the Control Box
(P6). Use the 4x LC Cables (P9) to connect each Leg
(P1) to the Control Box (P6). Finally take the Power
Cable (P8) and connect each one to the control box.
Use the included adhesive-backed Cable Clips (P10) to
secure all the wires for cable organization.
STEP 7
Once you have everything connected and secure,
carefully turn your surface right-side-up. We recommend
using at least 2 people to do this. Adjust the pre-installed
Glides (P3) as needed.
STEP 8
Plug the Power Cable (P8) from the Control Box (P6)
into an outlet.
IMPORTANT
You MUST reset the table lift prior to use. See Reset
Procedure on page 7.
STEP 3
Place the 4 Legs (P1) into the 4 VT Brackets (P4) as shown.
Using the supplied Allen Wrench, loosely thread the M6X14
Machine Screws (P12) into the remaining holes on each of the
VT Brackets (P4) to secure the 4 legs (P1). Once all screws are in
place, fully tighten all four screws.
STEP 4
Now that the Legs (P1) are secure you can attach the 4 Stand-
Offs (P2) and 4x Glides (P3) to the bottom of each leg as shown.
Secure the Stand-Offs (P2) and Glides (P3) with the remaining
M6X14 Machine Screws (P12), 4 per leg.
STEP 5
Attach the Control Box (P6) to the underside of your surface
using 2x of the M5X16 Screws (P13). Make sure you leave
enough room for cable connections into the wire ports
on the box. Next find a suitable area to place your Remote (P7),
we recommend somewhere on the end of your surface along the
front edge. Once you are satisfied with its position you can attach
it using 2x M5X16 Screws.
STEP 1
Lay out all the included components and hardware
to ensure you have everything listed on the parts page.
Take four of the self-adhesive Noise Attenuation Pads
(P5) and place them on the VT Brackets (P4) as shown.
STEP 2
Place the VT Brackets (P4) on the underside of the
surface you will be lifting. Use the included 24x Wood
Screws (P11) to attach the Brackets in place, using six
screws per bracket.
Caution: Double-check that the wood screws
(P13) are short enough that they won’t puncture a
hole in your surface when screwed in completely
If your surface is not pre-drilled we recommend
you pre-drill any holes needed for the VT Brackets
(P4). Never use countersunk screws
As stated earlier make sure the screws are short
enough that they don’t puncture a hole in your
surface when screwed in completely. Do not
overtighten the screws here, overtightening may
cause damage to the components.
Ensure the box and remote are placed so
the wires can reach between all components
06
Assembly

FLT-04
CONTROL BOX
HS
M4
M3
WIRED REMOTE
FLT-04 Leg
[M1,M3]
FLT-04 Leg
[M2,M4]
M2
M1
110VAC AC
07
Setup

WARNING: During the Reset Procedure, the table lift will retract 7mm below the lowest normal operating height,
please ensure that no obstacles impede this motion of travel.
1. Move the table lift to the lowest position. (If there is an 'RSt' displayed on the remote, continue
to step 3.)
2. To initiate the Reset Procedure, press and hold the down button on the remote until "ASr" is
displayed. Release the down button.
3. Press and hold the down button on the remote, the table lift will begin to retract 7mm lower
than the lowest normal operating height. To stop motion at any time, let go of the down button.
4. Once the table lift has completed the Reset Procedure, height will be displayed on the remote.
08
Operation
Using the wired smart remote, retract the table lift to the lowest position. Press and
hold the 'Down' button again until the LED display flashes "RST".
Press and hold the 'M' button until the LED display flashes the starting height (if
the display returns to "RSt" before the next step, repeat this step).
To change the value of the starting height, use the 'Up', 'Down' to increase and
decrease by 0.1. Use the '1', '2' to increase and decrease by 1s. Use the '3', and '4'
buttons to increase or decrease by 10s.
Once the correct value is displayed, wait 5 seconds until the LED display flashes
"RSt". Follow the Reset Procedure outlined in the next section to save the new
starting height.
Note: the LED display has a tolerance of ±0.1.
Normal Operation
Using the wired remote, press and hold the 'Up' button to raise the table lift. To lower the table lift, press and hold
the 'Down' button. The 'Up' and 'Down' buttons are momentary controlled, when they are released, the table lift will
stop immediately.
To set a preset location, move the table lift to the desired height. Press the 'M' button followed by a numbered
button. The LED display will flash an 'S', followed by an 'S - Number'. This will indicate that the preset has been saved.
To use a preset, press any of the numbered buttons and the table lift will begin to move to the preset position. It is
important to ensure that no obstacles impede the motion of travel. To stop the table lift, press any button.
If the table lift does not function as intended or the LED display flashes "RSt", please follow the Reset Procedure
outlined in the next section.
Setting the LED Display
Reset Procedure

09
Troubleshooting
Problem Possible Cause Corrective Action
Low power mode
activated Press any button on the remote and LED will activate.
Connection issue Disconnect and reconnect the RJ-45 remote connector. Ensure connection is
secure and cable is not damaged.
Limit switch reached Follow "Setting Limit Switches" instructions to remove the programmed limit. If maximum or minimum height limit has been reached, please move the system
in the opposite direction.
Connection issue Disconnect and reconnect the Lifting Columns, Control Box, AC Power, and
Remote.
Table lift travels at a
significantly slower
speed than rated
specification.
Weight issue Ensure weight capacity has not exceeded the maximum load rating.
Unusual noise during
travel. Weight issue Ensure weight capacity has not exceeded the maximum load rating.
Table lift stops abruptly
during travel. Obstacle Ensure there are no obstacles in the path of the table lift. If the movement continues to fail, initiate the Reset Procedure.
Table lift is not level. Out of sync Disconnect and reconnect all cables (Lifting Column, Control Box, AC Power,
and Remote), then initiate the Reset Procedure.
Troubleshooting Guide
Remote LED is off.
Table lift does not
move when motion
control buttons are
pressed.
Error Code Error Summary Description
E01 M1 overcurrent protection
E02 M2 overcurrent protection
E03 M3 overcurrent protection
E04 M4 overcurrent protection
E07 M1 hall error
E08 M2 hall error
E09 M3 hall error
E10 M4 hall error
H01 Over heat /duty cycle
protection
All columns stop moving, remote displays H01 (if LED screen available). Allow
the system to rest for 16 minutes, use normally. Follow the Duty Cycle rating to
ensure no issues arise from overheating.
Error Codes (remotes with LED display)
All columns stop moving and remote displays E01-E04. Ensure that the total
weight capacity of the table lift has not been exceeded and that no obstacles
obstruct the movement. Press any key and remote will display
RST, initiate the Reset Procedure. If the issue persists, disconnect and
reconnect all of the lifting columns, including the main power. Repeat the Reset
Procedure.
All columns stop moving and remote displays E07-E10. Ensure that all columns
are still properly connected to the control box. Check to see if any cables have
been damaged. Press any key and remote will display RST, initiate the Reset
Procedure. If the issue persists, disconnect and reconnect all of the lifting
columns, including the main power. Repeat the Reset Procedure.
