Progressive FLT-20 User manual

Ex8
A
5x5
x4
F
1 2 3
4 5 6
7 8 9
21 1
1
2
1 2
1 1
1
2
3
E
A
104
2
1
3
4
5
6
7
9
8
10
A
4
F
3
2
A
M6x16
5x5 2.5x2.5 M8x50
ST4.2x19
M4x6
4x4
111
11
M6x30
12113
131
12
A
4
4x4
A
5x5
Power cable
Switch cord
Insert M6 (C) to attach supporting plates (6)
to each column (2,3). Do not fully tighten until
attaching desk frame to tabletop (see step 6).
Use 5*5 wrench (A) to tighten screws (C).
Install supporting beam on the column (2)
(3), tighten screw (F) with wrench 5x5 (A)
Adjust the support beam size(4)
according to table top size.
Extend
Loose
FLT-20
Duty Cycle
Operational Temperature
Number of stages
Rated Load
No Load Speed
Input Voltage
Lowest Position
Highest Position
Wrench
X4X1 X4 X4X14 X1
X8
16
Cx4
A
5x5
6
C
A3
2
Loose
Loosen screws on (4) with wrench 4x4(A),
then extend supporting beam.
C
STEP 1
STEP 2
STEP 3
14
Install Pedestal (1)
Install Supporting beam (4)
Install Pedestal (1) & Columns (2, 3) together. Use 5*5 wrench (A) to tighten the screws (E)
Insert gaskets (14) onto supporting beam (4)
and supporting plates (6) locations.
14
Install Supporting plate (6)
Attention: The drawings below are for reference only which may be slightly different from the physical product. Please contact customer service if you
are missing any components.
Technical Data
Parts List
Remote
B C D E F G
Recommended
Tabletop Size
Number of motors
15
Remote screw
3
Supporting plate
Column
Adaptor holder
Column
Gasket
Baffle
Transmission rod
Cable tie
Adapter
Supporting beam
Pedestal
Have any queries?
Our expert engineers are here to help!
Progressivedesk.com
[email protected]
1-800-828-9414
Frame Material
155 lbs
1.00"/sec
27.9"
47.6"
L: 39.3" to 62.9"
W: 19.6" to 31.4"
2
10% (2 minutes on, 18 minutes off)
1
Steel
100VAC to 240VAC
0°C to 40°C

9
7
Bx4
A
2.5x2.5
A
8
B
4
7
11
1
13
Connect the switch cord to the DC
port Connect the motor cord to the M1
port
2
2
1
Secure supporting beam, install baffle and power adaptor
Install the baffle (8) to the supporting beam (4)
using screws (B), and then lock with 2.5*2.5 wrench
(A).
Insert
Connect all cables to the adaptor (7)
Tighten screws on supporting beam with
wrench 4x4 (A) and supporting plate with
wrench 5x5 (A)
Tighten
4x4
2.5x2.5
A
A
1 2
G
3
G
STEP 5
STEP 6
STEP 7
10
Use cable tie to attach all cables
onto the table top.
Tear off Manage cables Attach them
Install transmission rod
Install transmission rod (5) to columns (2,3). Use 2.5*2.5 wrench (A) to tighten (G).
Connect the power after the
wiring is complete.
A
Tighten
Attention
The transmission rod is un-enclosed. Use
caution in this area as objects may get
and lubrication may be exposed.
STEP 4 Install the power adapter, tabletop and remote
Attach the desk frame to the tabletop
with screws (D). If you purchased a
Progressive Desk tabletop, use the
hardware included with the tabletop
and attach to threaded holes.
D x8
15 x3
D
15 D
Self-prepare
11
412
4
Securely attach the remote
directly to tabletop with screws
(15)to ensure features work
correctly. For remote positioning,
see graphic below.
Install the adaptor holder (11) to
the supporting beam(4).
The margins on the two
sides need to be no
larger than 7.87".
Remote must be positioned on the same side as
the motor. To attach remote to desired position,
attach desk frame to tabletop as shown below.
Please note the motor position and tabletop
grommet location when installing.

●
●
●
●
●
●
●
How to use Remote
LED screen
Key button
Up button, adjust the desk upwards
Down button, adjust the desk downwards
Position 1, user’s first stored height position
Position 2, user’s second stored height position
Position 3, user’s third stored height position
Position 4, user’s fourth stored height position
Operation Instruction
Adjust Height :
1. Press the "▲" button, the desk rises, press and hold to continue raising the desk
height. Press once to rise the height by 0.1cm
2. Press the "▼" button, the desk descends, press and hold to continue to descend.
Press once to descend the height by 0.1cm
Memory Preset Height:
1. When the desktop is stationary, press and hold the "1" button for 5 seconds. The
remote will beep and the display will show "S-1", indicating the saved position. Adjust
the desk to any height and return the desk back to the saved position by pressing the
"1" button.
2. Buttons "2", "3", and "4" all have the same memory height function as Button "1".
Repeat the steps above to set additional saved positions.
Reset Operation:
1. When the height of the device is incorrect or an error code appears, the device needs
to be reset and corrected. Press and hold the "3" button and the "4" button simultaneously
for 5 seconds to enter this function.
2. After entering the reset function, the display will show "RST". Press and hold the "▼"
button to reset the device. When the desk descends to the lowest position, it will raise
slightly and run until the screen displays "bot". At that point, the reset has completed.
Adjust the Collision Detection Sensitivity:
1. Press and hold the "▲" button and the "▼" button simultaneously for 5 seconds to
change the sensitivity. One gear will change each time this function is activated. There are
4 available gear options; A-0, A-1, A-2, A-3.
2. When the display shows “A-0”, the desk turns off the collision detection function; "A-3"
for high sensitivity; "A-2" for middle sensitivity; "A-1" for low sensitivity.
3. When the desk rises or descends, it will rebound immediately when it encounters an
obstacle to protect.
●
●
●
●
Attention
Common fault treatment
1. The transmission rod is un-enclosed. Use caution with cable management in this area. Do not
relocate desk while in motion.
2. Power supply: AC100V-240V,50/60HZ
3. Service Environment: 0°C to 40°C
4. Unplug the power plug before cleaning, wipe the dust on surface with slight wet dishcloth when
cleaning, be careful not to let the drops into the internal parts, do not loose the connector.
5. The electric box contains electronic components, metals, plastics, wires etc., so dispose of it in
accordance with each country's environmental legislation, not with the general household waste.
6. Check carefully to ensure correct and complete assembly before using.
7. Be familiar with all functions and program settings of the product before first use.
8. Slight noise caused by the V-ribbed belt or brake system due to structure will not have any
effect on the use of the equipment.
9. Corrosive or abrasive materials shouldn't be used to clean the equipment. Must ensure that the
cleaner used will not pollute the environment.
10. This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
11. Cleaning and user maintenance shall not be done by children without supervision.
12. If the supply cord is damaged, it must be replaced by the manufacturer.
13. Please make sure there is no hazardous sources in your operating environment. e.g., do not
leave the tools around. Always be careful to keep the packaging materials in order to avoid any
possible danger, e.g. plastic bag may lead to choking hazard to children.
14. Keep the original package of the equipment in case of future use in transportation. Always be
careful to keep the packaging materials in order to avoid any possible danger, e.g. plastic bag may
lead to choking hazard to children.
15. Keep the original package of the equipment in case of future use in transportation.
This marking indicates that this product
should not be disposed with other
household wastes. To prevent possible
harm to the environment or human health
from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable
reuse of material resources. To return your
used device, please use the return and
collection systems or contact the retailer
where the product was purchased. They
can take this product for environmental safe
recycling.
Wastedisposal
Troubleshooting:
1. Reset: When the LED shows "RST", press "▼" button until the desk descends to the lowest position. When the desk descends to
the lowest position, it will raise slightly and run until the screen displays "bot". At that point, the reset has completed.
2. If the lift doesn't work and the LED shows "E01" or "E02", please retry 18 minutes later.
3. If the "▼" button doesn't work, please check the cable connection and then cut off the power for at least 10 seconds. Reconnect to
the power and press "▼" button to start the reset process when it shows the "RST".
4. If the above process doesn't work, please contact our customer service.
●Child Lock Operation:
1. Press and hole the "1" button and the "2" button simultaneously for 5 seconds to enter
this function.
2. After entering the child lock function, the desk will no longer be responsive.
3. Press and hold the "1" button and the "2" button simultaneously for 5 seconds to exit this
function.
Corrective Action
1.Check if all the cables are connected well
1.Check if all the cables are connected well
2.Contact your supplier or dealer
2.Contact your supplier or dealer
1.Check if overloaded, max loading: 70kg;
1.Check if overloaded, max loading: 70kg;
1.Check if overloaded, max loading: 70kg;
2.Contact your supplier or dealer
2.Contact your supplier or dealer
2.Contact your supplier or dealer
1. Contact your supplier or dealer
1.Reset
2.Contact your supplier or dealer
1.Wait 18 minutes, then perform reset procedure.
2.Contact your supplier or dealer;
2.Contact your supplier or dealer.
1.Perform a reset operation;
1. Overworked. Wait 18 minutes and try again.
1. Check if overloaded. If yes, lessen the load then
press ▼ for reset until there is BOT letters on
screen. If not, press ▼ for reset.
1. Motor Error. Press ▼ for reset. If no response,
remove power and wait 10 seconds, then
reconnect and wait for "RST on screen. Long
press▼ for RESET.
1. Sensor Error. Try all above solutions. If no success,
contact supplier or dealer
Problem
No response while pressing
up arrow/ down arrow after
connected to a power supply
Rising at a low speed
The motor doesn't move as instructed
Lowers but does not raise
Drifting downwards
Frequently Reposition
Overworked
(Duty cycle:Max 2min on/18min
OFF）
Cannot reach full height range
No response while long
pressing down arrow after
connected to a power supply
E01 & E02 Error on remote
E03 or E04 Error on remote
E20 Error on remote
E30 Error on remote
"▲"
"▼"
"1"
"2"
"3"
"4"
34.4" - 53.7"
2.8"
39.0" - 58.3"
37.8" - 57"
1.4"
14.6"
17.7"
10.1"
8.2"
8.8"
28" - 47.6"
18.9"
23.6"
Dimensional Drawing
