PACKAGE CONTENTS

This side back splash ce cote vers le murThis side back splash ce cote vers le mur

DESCRIPTION

Vessel Sink

Template

PART QUANTITY

SAFETY INFORMATION

Please read and understand this entire manual before attempting to assemble, operate or install the product.

• Shut o󰀨 water supply.

• Water should be completely drained from the main location water valve of faucet.

WARNING

• Handle with care.

• Improper care may cause the warranty to become invalid.

CAUTION

• Do not overtighten nuts.

PREPARATION

Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and

hardware contents list. If any part is missing or damaged, do not attempt to assemble the product.

Make sure the water supply valve is shut o󰀨 before installation.

Clean any old wax, putty, etc. from base area (if replacing an existing sink).

Estimated Assembly Time: 60 minutes

Tools Required for Assembly (not included): Pipe Wrench, Drill, Hacksaw, Jig Saw, Measuring Tape, Pencil, Putty

Knife, Sealant, Adjustable Wrench

Note: If you have a marble or stone counter top that does not have a cut-out to t the sink, it is recommended this

be done by a professional.

1. Locate the proper place on the vanity top that the vessel

sink will be installed. Make sure that there is enough room

under the vanity top for the faucet, water supply lines and

drain assembly (not included). The space on the back of

the vessel sink to the backsplash of the vanity should have

enough distance to accommodate desired faucet.

2. Please refer to template. Trace the cut-out line from the

template onto the vanity (this will be the cut-out line). Make

sure that the cut-out line is positioned properly on the

vanity.

3. Conﬁrm that the template mark on the vanity lines up with

the vessel sink. Then, make a clearance hole anywhere

near the cut-out line on the inside and then cut out the

portion within the cut-out line.

ASSEMBLY INSTRUCTIONS

4. Place the vessel sink into place. Check to make sure that

the vessel sink is positioned properly on the vanity.

5. Apply silicone or plumber’s putty to the underside outer

rim of the vessel sink. Then, secure vessel ﬁrmly down

and tighten drain assembly under the vanity top. Trim any

excess silicone or plumber’s putty o󰀨.

Note: Depending on the faucet, you may choose to

install it rst before you secure the vessel sink down.

6. Connect the water supply lines to the faucet and the P-trap

to the drain assembly (both not included) as required.

• Wipe the vessel sink with a non-abrasive cleaner and a soft towel. Make sure that the complete surface is cleaned and

dried.

CARE AND MAINTENANCE

WARRANTY

Printed in China

The manufacturer warrants this sink to be free from defects in workmanship and material present at time of shipment

from the factory for a limited lifetime from the date of purchase. This warranty applies only to the original purchaser. The

manufacturer agrees to correct such defects at no charge or, at our option, replace the sink with a comparable or superior

model. To obtain warranty service, call our customer service department at 1-866-389-8827 8 a.m. - 8 p.m., EST, Monday

- Sunday for return authorization and shipping instructions. You may be required to present a copy of your sales receipt

as proof of purchase. All cost of removal and reinstallation are the expressed responsibility of the purchaser. Any damage

to the sink by accident, misuse or improper installation, or by a󰀩xing accessories not produced by the manufacturer, are

the purchaser’s responsibility. The manufacturer assumes no responsibility whatsoever for faucet installation during the

warranty period. There is no further expressed warranty. The manufacturer disclaims any and all implied warranties. The

manufacturer shall not be liable for incidental, consequential or special damages arising at or in connection with product

use or performance except as may otherwise be accorded by law. This warranty gives you speciﬁc legal rights, and you

may also have other rights which vary from province to province. This warranty supersedes all prior warranties.
