Project Source FV05-094-3 User manual

ITEM #0510209
0527988
4-LIGHT VANITY BAR
MODEL #FV05-094-2
FV05-094-3
Français p. 8
Español p. 15
ATTACH YOUR RECEIPT HERE
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-866-389-8827, 8 a.m. - 6 p.m., EST, Monday - Thursday, 8 a.m. -
5 p.m., EST, Friday.
1
AB13506
Serial Number Purchase Date
Project Source®is a registered trademark
of LF, LLC. All rights reserved.
Lowes.com

23
PACKAGE CONTENTS
B
A
B
B
B
B
D
C
Wire nut
Qty. 3
Machine
screw
Qty. 2
Outlet box
screw
Qty. 2 Plastic
wall
anchor
Qty. 2
SAFETY INFORMATION
WARNING
CAUTION
PREPARATION
HARDWARE CONTENTS (shown actual size)
B
AA B
BB BB
CC DD
Please read and understand this entire manual before attempting to assemble, operate or install
the product.
• TURN OFF ELECTRICITY at main fuse box (or circuit breaker box) before beginning
installation by removing fuse (or switching off circuit breaker).
• MINIMUM 90°C SUPPLY CONDUCTORS.
• CONSULT A QUALIFIED ELECTRICIAN TO ENSURE CORRECT BRANCH CIRCUIT
CONDUCTOR.
• If in doubt about electrical installation, consult a licensed electrician.
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents list. If any part is missing or damaged, do not attempt
to assemble the product.
Estimated Assembly Time: 25 minutes
Tools Required for Assembly (not included): Flathead screwdriver, Phillips screwdriver, Pliers,
Electrical tape, Wire cutters, Safety glasses.
Helpful Tools (not included): Wire strippers.
PART DESCRIPTION QUANTITY
A Mounting bracket (preassembled to Front plate (B)) 1
B Front plate 1
C Socket cover (preassembled to Front plate (B)) 4
D Green screw (preassembled to Mounting bracket (A)) 1
Lowes.com Lowes.com

5
4
ASSEMBLY INSTRUCTIONS
Hardware Used
Hardware Used
Hardware Used
1
2 5
6
x 2
x 2
x 2
x 3
Plastic wall anchor
Machine screw
Outlet box screw
Wire nut
B
B
B
B
DD
AA
BB
CC
CC
A
C
B
ASSEMBLY INSTRUCTIONS
5. Attach wire nuts (CC). Tape wire nuts (CC)
and wires together.
B
C
AA
BB
A
A
DD
3
4
1. Remove the socket covers (C) from the sockets on
mounting bracket (A). Then separate the mounting
bracket (A) from the front plate (B). The mounting
bracket (A) is supplied with keyhole slots for
additional attachment to the mounting face. Hold
the mounting bracket (A) against the wall with the
outlet box (not included) and mark the position of the
keyhole slots on the mounting surface; make sure
the xture will be level and mounted to a secure
surface.
2. Drill the holes at the marks on the mounting
surface, then insert the plastic wall anchors (DD)
into the holes.
3. Attach the mounting bracket (A) to the outlet box
using the two outlet box screws (BB). Attach the
mounting bracket (A) to the mounting surface using
machine screws (AA). Note: Make sure the narrow
ends of the keyhole slots face up.
4. Strip 3/4 in. of insulation from wire ends.
Twist stripped ends together with pliers (not
included), black to black (power) and white to
white (neutral). Attach copper wire to ground
wire. Helpful hint: If necessary, attach copper
ground wire to grounded outlet box.
6. Attach front plate (B) to mounting plate (A) by
aligning holes on front plate (B) with sockets on
mounting plate (A). Push socket covers (C) onto
sockets.
Lowes.com Lowes.com

7
6
CARE AND MAINTENANCE
• Shut off main power supply before wiping product with damp cloth or window cleaner. Do not
use abrasives.
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Bulb won’t light. 1. Bulb is burned out.
2. Power is off.
3. Faulty wire connection.
4. Faulty switch.
1. Replace light bulb.
2. Make sure power supply is on.
3. Check wiring.
4. Test or replace switch.
Fuse blows or circuit
breaker trips when
light is turned on.
Crossed wires or power wire is
grounding out.
Check wire connections.
WARRANTY
The manufacturer warrants all of its lighting xtures against defects in materials and workmanship
for one (1) year from the date of purchase. If within this period the product is found to be defective
in material or workmanship, the product must be returned, with a copy of the original sales receipt
as proof of purchase in the original carton, to the place of purchase. The manufacturer will, at its
option, repair, replace or refund the original purchase price to the consumer. This warranty does
not cover xtures becoming defective due to misuse, accidental damage, improper handling and/or
installation and specically excludes liability for direct, incidental or consequential damages. As
some states do not allow exclusions or limitations on an implied warranty, the above exclusions
and limitations may not apply to you. This warranty gives you specic legal rights, and you may
have other rights that vary from state to state.
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-866-389-8827, 8 a.m. - 6 p.m.,
EST, Monday - Thursday, 8 a.m. - 5 p.m., EST, Friday.
PART DESCRIPTION PART #
AA Machine screw 109-352600
BB Outlet box screw 109-042600
CC Wire nut 375-022000
DD Plastic wall anchor 407-039000
7
ASSEMBLY INSTRUCTIONS
B
AA B
BB BB
CC DD
7. Install light bulbs (not included). Use four
60-watt max. standard-base bulbs or four
13-watt standard-base CFL bulbs.
or
Lowes.com
Printed in China
