Operations Manual
Model: CSD1515
Digitally Controlled
Clam Shell Grill

Operation Instructions
Please read carefully before attempting to use this appliance.
Step 1. Carefully unpack and clean grill plates with mild soap then sponge clean
with cold water.
Step. 2. Place in location where it will be used allowing for clearances per the
dimensions indicated.
WARNING! Allow 2” minimum clearance between adjacent equipment and/or
wall areas.
Do not touch hot surfaces.
Step 3. Plug into proper 3 prong wall outlet. If other appliances are connected
to the same circuit make sure the total load does not exceed maximum
ampacity of the circuit. Electrical information is as follows:
120V/60Hz/1 phase/2200W/18.3 Amps
208V/60Hz/1 phase/2800W/13.5 Amps
Step 4: Warm-up
Energize by turning on the power switch which will illuminate when turned
on. The display flashes and shows left preset timer during warm-up. Pre-
heat temperature time will be 40-50 minutes. When the set point is
reached, the display stops flashing and beeps 3 times.
Step 4: Operation
Simply place product on grill, close lid and press the
desired pre-set time cycle (ex: 10 seconds). After the time cycle is
finished press it again to reset the time cycle.
Cleaning Instructions
NOTE! Always turn off power and allow to cool down before attempting to clean.
Never submerge grill in water or other liquid nor use mineral spirits
or other flammable material to clean this appliance.
!Never use ice to cool down grill, warranty will be void!
Clean stainless steel and griddle surfaces with soap and water using a
soft, clean cloth periodically as required, but at least once daily. Never
use harsh abrasives. Use only non-abrasive scouring pads when required.

Clean Cycle
275°F is the factory default temp for the CLEAN cycle. To change the CLEAN cycle temp, simultaneously
hold down the TEMP and CLEAN buttons for 15 seconds.
Using the up or down arrows to adjust to the desired temp.
To start a clean cycle, push CLEAN button once so the CLEAN LED light is turned on. All preset LED’s are
turned off, and the temperature set point is changed to the clean set point of 275°F. This also initiates
the cool down to clean set point condition as well the display starts flashing until the clean set point is
reached.
To stop the clean cycle, simply press the CLEAN button once to deactivate the clean cycle. The CLEAN
LED is turned off, the preset LED’s are restored, the temperature set point is changed to the main set
point. Again, the warm-up condition is initiated and the display flashes until the cook set point is
reached.

CSD1515 Operating Instructions:
1. Press desired time to start the time cycle. After the cycle is finished, press it again to
reset the time cycle
2. If for any reason the timer has to be reset in the middle of a cycle, you must press and hold
the corresponding timer button for 3 seconds.
HOW TO FIND TEMPERATURE
1. To find the temperature of the UPPER PLATEN: Press the TEMPERATURE
button and the ARROW UP button at the same time.
2. To find the temperature of the LOWER PLATEN: Press the TEMPERATURE
button and the ARROW DOWN button at the same time
* 275° is the factory default temp for the CLEAN cycle. To change the CLEAN cycle temp,
simultaneously hold down the TEMP and CLEAN buttons for 15 seconds. The current temp setting will
display on the right digital display only. Using the up or down arrows to adjust to the desired temp.

Instruction’s for Adjusting the Temperature
PRESS and hold the TEMP and
ARROW up
buttons simultaneously for 15
seconds.
The current temperature setting
will display on the right
digital display only.
Using the ARROW buttons, you
may now adjust the temperature
to your
desired setting.
Once you have set your desired
temperature simply push
the TEMP button. The digital
displays will now read the
preset times.
Instruction’s for Adjusting the Set-Time
Press the TEMP button first and then the
desired timer button and continue to hold
both for 5 seconds.
The digital displays will now read their preset
times as shown here. Each side is capable of
having up to 4 different settings, making a total
of 8 set-times.
Now using the ARROW buttons you
can set your desired time.
Once you have set the desired time simply press the
TEMP button, the unit will display the new set-time.
*IMPORTANT NOTE: When adjusting the time settings, The RIGHT SIDE time buttons
control the left side, so the same time you set on the right will automatically be set to
the left side accordingly. If you desire an additional set of times you can adjust the left
side AFTER you have adjusted the right side without effecting the right side settings.

55
2X
2X
54
2X
2X 2
1
28
4X 42
4X
40
71
70
4X
3
75
16X
6
52
4X
76
78
74 2X
73 2X
46
45 2X
A2P
79
CSD1515
A2
2X
89
A1
73
A1P
EXPCSD1515 RC 061317 CUSTOMER MANUAL
SHEET 1 OF 2

33
16
51
6X
83
82
2X
19
2X 63
2X
86
15
3X
80 3X
17
3X
44
77
4X
32
41
36
49
2X 37
2X 17
2X
34
35
70
71 6
81
48
2X
22
2X 21
2X 20
2X
5
2X 62X
66
14
4X
53
4X
31
4X
64
4X 72
3X
68
69 10
30
85
8X
65
10
3X
13
2X
9
4X
4
35
34
39
2X
48
2X 17
2X
37
19
44
18
2X
87 63
3X
80
3X
17
77 3X
36
4X
41
32 49
2X
15
12X 24
2X 26
23
2X
25
29
2X
58
61
27
59
61
60
59
61
59
60
4X
10
2X
38
47
4X
31
4X
62
50
11
53
2X
43
12
57
2X
7
67
56
8
EXPCSD1515 RC 061317 CUSTOMER MANUAL
SHEET 2 OF 2
A4P
A4
A5
A6
CSD1515
2X
88
2X 90
2X 84
2X
A3
84
A3P

PARTS LIST FOR THE CSD1515/CSD1515P
MODEL MODEL MODEL
CSD1515A/
CSD1515PA CSD1515CEC/ CSD1515PCEC CSD1515E/ CSD1515PE
120 V 220V 208 V
1 LOWER WRAP AROUND SHROUD ASSEMBLY 110115501 110115501 110115501 1
2 GREEN INSULATION WASHER C4401 C4401 C4401 2
3 HEX NUT 3/8-16 NH3816 NH3816 NH3816 4
4 STRAIN RELIEF 1106546468 1106546468 1106546468 1
5 SCREW, SET 3/8-16 x 1 SST38161 SST38161 SST38161 2
6 SCREW, SET 3/8-16 x 1/2 SST381612 SST381612 SST381612 4
7 FUSE HOLDER 1 AMP MPPF708 MPPF708 MPPF708 1
8 FUSE BUSS 1 AMP MPPF701R MPPF701R MPPF701R 1
9 SOLID STATE RELAY PL2425 PL2425 PL2425 2
10 SCREW, PAN HEAD PHILLIPS 8-32 x 3/8 STAINLESS STEEL SP83238S SP83238S SP83238S 15
11 5 STAGE TERMINAL BLOCK 6015 6015 6015 1
12 TRANSFORMER 11096975 11096975 11096975 1
13 SINK, HEAT, ALUMINUM PAD 11057322 11057322 11057322 3
14 GROMMET INSULATION 7/8 O.D. X3/8 I.D, Thickness 5/16 110115554 110115554 110115554 2
15 E-CLIP, RETAINING RING LCC3478 LCC3478 LCC3478 4
16 HANDLE LEFT ASSEMBLY 110115522 110115522 110115522 1
17 WASHER, SPLIT LOCK 5/16 WL516 WL516 WL516 10
18 HANDLE RIGHT ASSEMBLY 110115521 110115521 110115521 1
19 HANDLE GRIP 110901168 110901168 110901168 2
20 TUBING PAD 110115531 110115531 110115531 2
21 SPRING, DETENT 1-1/2 LONG 110115555 110115555 110115555 2
22 PLUNGER ASSEMBLY 110115544 110115544 110115544 2
23 HANDLE SPRING ADJUSTING COLLAR 110115528 110115528 110115528 2
24 SCREW SET KNURLED CUP POINT 5/16-18 X 3/8 SST5161838KN SST5161838KN SST5161838KN 12
25 COUNTER BALANCE SPRING RIGHT HAND 1101023154R 1101023154R 1101023154R 1
26 COUNTER BALANCE SPRING LEFT HAND 1101023154L 1101023154L 1101023154L 1
27 COLLAR HOLDER 110115530 110115530 110115530 2
28 FEET, RUBBER 3/4 11016546469 11016546469 11016546469 4
29 BUSHING TEFLON 3/4 LONG 110113441 110113441 110113441 2
30 GREASE TRAY 110115505 110115505 110115505 1
31 NUT, HEX 6-32 NH632 NH632 NH632 8
32 TOP LINK 110115508 110115508 110115508 2
33 WIRE HARNESS CSD1515R 11018636050 11018636050 11018636050 1
34 UPPER LEVELING BRACKET 110115510 110115510 110115510 2
35 UPPERLEVELING SHIM 110115557 110115557 110115557 2
36 PIN, PIVOT FRONT 11017088865 11017088865 11017088865 2
37 BOLT, HEX 5/16-18 X 1 STAINLESS STEEL BH516181S BH516181S BH516181S 4
38 BACK COVER 110115562 110115562 110115562 1
39 POWER CORD 1101591174 MPPW202 1101009176 1
40 SHIM, LOWER PLATEN 11060420 11060420 11060420 1
41 PIN PIVOT BACK 11017088866 11017088866 11017088866 2
42 WASHER, SPLIT LOCK 3/8 WL38 WL38 WL38 4
43 TRANSFORMER INSULATION 1101159180 1101159180 1101159180 1
44 SHIM, CLEVIS 11060421 11060421 11060421 2
45 BOLT, HEX 1/4-20 X 1 BH14201 BH14201 BH14201 2
46 NUT, HEX 1/4-20 NH1420 NH1420 NH1420 2
47 SCREW, PAN HEAD, PHILLIPS 8-32 x 1-1/2 STAINLESS STEEL SP832112S SP832112S SP832112S 2
48 WASHER, INTERNAL TOOTH LOCK 5/16 WLIT516 WLIT516 WLIT516 4
49 RETAINING RING 11017088867 11017088867 11017088867 8
50 MARKER STRIP, #5 MS6015 MS6015 MS6015 1
51 SCREW, PAN HEAD PHILLIPS 2-56 X 1/4 SP25614 SP25614 SP25614 1
52 WASHER, SAE 3/8 WSAE38 WSAE38 WSAE38 16
53 WASHER, INTERNAL TOOTH LOCK #6 WLIT6 WLIT6 WLIT6 8
54 WASHER, SAE 1/4 WSAE14 WSAE14 WSAE14 2
55 WASHER, SPLIT LOCK 1/4 WL14 WL14 WL14 2
56 SCREW, PAN HEAD PHILLIPS 6-32 x 3/8 SP63238 SP63238 SP63238 2
57 SCREW, PAN HEAD PHILLIPS 6-32 x 5/8 SP63258 SP63258 SP63258 2
58 SCREW, PAN HEAD PHILLIPS 8-32 X 1 SP8321 SP8321 SP8321 1
59 NUT, HEX 8-32 NH832 NH832 NH832 3
60 WASHER, SAE #8 WSAE8 WSAE8 WSAE8 4
61 WASHER, INTERNAL TOOTH LOCK #8 WLIT8 WLIT8 WLIT8 3
62 MOUNTING BRACKET ASSEMBLY 110115559 110115559 110115559 1
ITEM # DESCRIPTION QTY.
PLCSD1515 RC 061317 CUSTOMER MANUAL

PARTS LIST FOR THE CSD1515/CSD1515P
MODEL MODEL MODEL
CSD1515A/
CSD1515PA CSD1515CEC/ CSD1515PCEC CSD1515E/ CSD1515PE
120 V 220V 208 V
ITEM # DESCRIPTION QTY.
63 BUSHING, TEFLON, 3/4 ID x.875 x 1 LONG 110115541 110115541 110115541 4
64 WASHER, STEEL 311150019 311150019 311150019 4
65 BOTTOM COVER ASSEMBLY 110115570 110115570 110115570 1
66 DIGITAL CONTROL 110171433052 110171433052 110171433052 1
67 SCREW, PAN HEAD PHILLIPS 8-32 x 1/2 SP83212 SP83212 SP83212 4
68 INSTRUMENT HOUSING ASSEMBLY 11017636011 11017636011 11017636011 1
69 OVERLAY OCSD1515RA OCSD1515RA OCSD1515RA 1
70 WASHER, SAE #6 WSAE6 WSAE6 WSAE6 2
71 SCREW, PAN HD 6-32 x1/4, NICKEL PLATE SP63214 SP63214 SP63214 2
72 NYLON SPACER 1/4 x.141 x 9/32 11090109 11090109 11090109 4
73 FLANGED BUSHING TEFLON 1/2 LONG 110115563 110115563 110115563 4
74 STOP, HEX PIN 11018344037 11018344037 11018344037 2
75 RTD SENSOR 2000 OHM, BOTTOM 1108881102 1108881102 1108881102 1
76 SCREW, SET 3/8-16 X 1-1/2 SST3816112 SST3816112 SST3816112 4
77 WASHER, CUT 5/16 WC516 WC516 WC516 6
78 LOWER PLATEN INSULATION 110115542 110115542 110115542 1
79 COVER, LOWER PLATEN ASSEMBLY 110115506 110115506 110115506 1
80 SCREW, SOCKET HEAD 5/16-18 x3/4 SSH5161834 SSH5161834 SSH5161834 6
81 RTD, TOP SENSOR 1108881101 1108881101 1108881101 1
82 SCREW, PAN HEAD PHILLIPS 10-24 X 3/8 STAINLESS STEEL SP102438S SP102438S SP102438S 6
83 UPPER SHROUD 110121721 110121721 110121721 1
84 SCREW, PAN HEAD PHILLIPS 8-32 x 3/8 SP83238 SP83238 SP83238 4
85 INSULATION UPPER PLATEN 110888251 110888251 110888251 2
86 CLEVIS ASSEMBLY LEFT HAND 110115503 110115503 110115503 1
87 CLEVIS ASSEMBLY RIGHT HAND 110115504 110115504 110115504 1
88 SPACER 11013283 11013283 11013283 2
89 GROMMET, RUBBER 110103919 110103919 110103919 1
90 CLAMP, CABLE 5/16" BUNDLE CC516 CC516 CC516 2
91 MANUAL CSD1515 MCSD1515 MCSD1515 MCSD1515 1
A1 LOWER PLATEN WITH WIRING 1101155207 1101155208 1101155209 1
A1P LOWER PLATEN PANINI WITH WIRING 1101155207P 1101155208P 1101155209P 1
A2 LOWER PLATEN ASSEMBLY 1101155116 1101155117 1101155118 1
A2P LOWER PLATEN PANINI ASSEMBLY 1101155116P 1101155117P 1101155118P 1
A3 UPPER PLATEN WITH WIRING 1101217201 1101217203 1101217202 1
A3P UPPER PLATEN PANINI WITH WIRING 1101217201P 1101217203P 1101217202P 1
A4 UPPER PLATEN ASSEMBLY 1101217101 1101217103 1101217102 1
A4P UPPER PLATEN PANINI ASSEMBLY 1101217101P 1101217103P 1101217102P 1
A5 KITTED, CONTROLLER TEMPERATURE, WITH INSTRUCTIONS 110171433052K 110171433052K 110171433052K 1
A6 KITTED, CONTROLLER TEMPERATURE ASSEMBLY 11017143352K 11017143352K 11017143352K 1
PLCSD1515 RC 061317 CUSTOMER MANUAL

Warranty & Return Policy
Proluxe warrants all products manufactured by it against defects in workmanship or materials from the date of purchase for a period of
(1) year on parts and labor. This warranty applies to only equipment purchased and used in the United States. Warranty period
shall begin when equipment ships. Warranty travel shall only be covered for 60 miles. Limited lifetime warranty on heating
elements.
ALL WARRANTY SERVICE CALLS MUST BE APPROVED BY PROLUXE. IF THIS PROCEDURE IS NOT FOLLOWED,
WARRANTY SERVICE WILL NOT BE COVERED. WARRANTY SERVICE WILL BE PAID ON STRAIGHT TIME, OVERTIME WILL
NOT BE COVERED.
Exclusions:
1. WOOD / GAS FIRED OVENS: PROLUXE warranty applies to the main body of the oven being steel / refractory and insulation shall
be free from defects in materials and workmanship for a period of four years from the date of purchase. The gas equipment shall be
free from defects in materials and workmanship for a period of one (1) year
from the date of purchase. Lifetime warranty against cracks on oven floor.
2. Air compressors are excluded from this warranty, but PROLUXE may act as a warranty expeditor in certain instances regarding
these compressors. The air compressor manufacturer provides a limited warranty
and a copy of this warranty is furnished with all compressors sold by PROLUXE. For prompt handling of compressor warranty claims
the instructions of the compressor manufacturer must be adhered to.
3. Equipment built to special order as well as accessories cannot be canceled and are not returnable unless defective within the
terms of this warranty.
4. In no event shall PROLUXE be liable for consequential damages arising out of the failure of any of its products if operated
improperly or caused by normal wear or damage by operator abuse.
5. BC2325 pedestal warranty disclaimer: Pedestals shall only be covered under warranty if they have been cleaned using the factory
approved cleaning method. cracked or damaged pedestals must be inspected by the factory before warranty is authorized.
6. Limited lifetime warranty on heating elements: If replacement is needed, Proluxe will send the new part at no charge but labor will
not be covered unless the unit is still under the 1 year manufacture warranty.
Returned Merchandise Policy:
Should it become necessary to return any of the company’s products, the following instructions must be adhered to: First,
contact our customer service department for approval and a return authorization number. Please have the serial number
of your item available at that time. All merchandise must be shipped freight prepaid by customer or service agency.
Subject to the inspection of the product by the company, a restocking charge of 20% of the Net purchased price paid to
PROLUXE will be assessed. Merchandise may not be returned for credit without prior written approval of PROLUXE. Collect shipments
will not be accepted. No returns after 60 days of original shipment date on machines. Purchased parts may not be returned after 30
days.
If upon inspection by PROLUXE or its authorized agent it is determined the equipment has not been used in an appropriate manner,
has been modified, or has not been properly maintained, or has been subject to misuse,
misapplication, neglect, abuse, accident, unauthorized modification, damage during transit, delivery, fire, flood, act or war,
riot or act of God, then this warranty shall be deemed null and void.
Terms & Conditions:
1. Prices indicated in the PRICE LIST are suggested retail prices and are shown in U.S. DOLLARS.
2. Terms of Payment: 1% 10 days, NET 30 days.
3. NEW ACCOUNTS: Satisfactory credit information must be provided before open account status can be extended.
Unless agreed otherwise, all shipments will be made C.O.D., CASH IN ADVANCE.
4. PRICING: Prices, specifications, model numbers, capacities and accessories are subject to change without notice.
5. FREIGHT / ROUTING: Method of shipment will be determined by PROLUXE unless otherwise
advised by PURCHASER.
6. DAMAGED CLAIMS: All merchandise shipped at purchaser’s risk. Inspection must be made by purchaser at time
goods are received. If goods are damaged, the PURCHASER shall request that the agent of the transportation
company make a written notation on the proper shipping documents immediately and then file a claim for damage.
GOODS DAMAGED IN SHIPMENT ARE NOT RETURNABLE.
7. RETURNS: Machines may not be returned after 60 days. Purchased parts may not be returned after 30 days. A
restocking fee of 20% will be assessed on non-warranty returns.
8. TAXES: Prices indicated herein DO NOT include State, Federal, Local or foreign taxes or duties, nor do they include
fees, permits, insurance or other levies, all of which are the responsibility of the purchaser.
9. All orders are subject to acceptance by PROLUXE.
10. Possession of this price list shall not be considered an offer to sell.
Rev 12916
