Promag AG19 Installation manual

Any part of the contents of this document, without the express written GIGA-TMS
permission, shall not in any documents, electronic, mechanical form of remakes or
spread. File contents are subject to change without notice.
Revisions
Revision Date Description
01 Jul 13, 2020 Preliminary draft
Copyright© 2020
GIGA-TMS INC.
Printed in Taiwan

EMC EN55032 / EN55024
EMI Part 15 B
EMI VCCI-CISPR 32

Warning
Federal Communication Commission (FCC) Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
. Reorient or relocate the receiving antenna.
. Increase the separation between the equipment and receiver.
. Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
. Consult the dealer or an experienced radio/TV technician for help.

LIMITED WARRANTY
Giga-Tms warrants that the products sold pursuant to this Agreement will perform in
accordance with Giga-Tms’s published specifications. This warranty shall be provided
only for a period of one year from the date of the shipment of the product from Giga-
Tms (the “Warranty Period”). This warranty shall apply only to the “Buyer” (the original
purchaser, unless that entity resells the product as authorized by Giga-Tms, in which
event this warranty shall apply only to the first re-purchaser).
During the Warranty Period, should this product fail to conform to Giga-Tms’s
specifications, Giga-Tms will, at its option, repair or replace this product at no
additional charge except as set forth below. Repair parts and replacement products
will be furnished on an exchange basis and will be either reconditioned or new. All
replaced parts and products become the property of Giga-Tms. This limited warranty
does not include service to repair damage to the product resulting from accident,
disaster, unreasonable use, misuse, abuse, negligence, or modification of the product
not authorized by Giga-Tms. Giga-Tms reserves the right to examine the alleged
defective goods to determine whether the warranty is applicable.
Without limiting the generality of the foregoing, Giga-Tms specifically disclaims any
liability or warranty for goods resold in other than Giga-Tms’s original packages, and
for goods modified, altered, or treated without authorization by Giga-Tms.
Service may be obtained by delivering the product during the warranty period to Giga-
Tms (8F No. 31 Lane 169, Kang Ning Street, Hsi Chih Dist New Taipei City, Taiwan).
If this product is delivered by mail or by an equivalent shipping carrier, the customer
agrees to insure the product or assume the risk of loss or damage in transit, to prepay
shipping charges to the warranty service location, and to use the original shipping
container or equivalent. Giga-Tms will return the product, prepaid, via a three (3) day
shipping service. A Return Material Authorization (“RMA”) number must accompany
all returns. Buyers may obtain an RMA number by contacting with
[e-mail]
EACH BUYER UNDERSTANDS THAT THIS GIGA-TMS PRODUCT IS OFFERED
AS IS. GIGA-TMS MAKES NO OTHER WARRANTY, EXPRESS OR IMPLIED, AND
GIGA-TMS DISCLAIMS ANY WARRANTY OF ANY OTHER KIND, INCLUDING
ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE.
IF THIS PRODUCT DOES NOT CONFORM TO GIGA-TMS’S SPECIFICATIONS,

THE SOLE REMEDY SHALL BE REPAIR OR REPLACEMENT AS PROVIDED
ABOVE. GIGA-TMS’S LIABILITY, IF ANY, SHALL IN NO EVENT EXCEED THE
TOTAL AMOUNT PAID TO GIGA-TMS UNDER THIS AGREEMENT. IN NO EVENT
WILL GIGA-TMS BE LIABLE TO THE BUYER FOR ANY DAMAGES, INCLUDING
ANY LOST PROFITS, LOST SAVINGS, OR OTHER INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF, OR INABILITY TO
USE, SUCH PRODUCT, EVEN IF GIGA-TMS HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES, OR FOR ANY CLAIM BY ANY OTHER PARTY.
LIMITATION ON LIABILITY
EXCEPT AS PROVIDED IN THE SECTIONS RELATING TO GIGA-TMS’S LIMITED
WARRANTY, GIGA-TMS’S LIABILITY UNDER THIS AGREEMENT IS LIMITED TO
THE CONTRACT PRICE OF THIS PRODUCT.
GIGA-TMS MAKES NO OTHER WARRANTIES WITH RESPECT TO THE
PRODUCT, EXPRESSED OR IMPLIED, EXCEPT AS MAY BE STATED IN THIS
AGREEMENT, AND GIGA-TMS DISCLAIMS ANY IMPLIED WARRANTY,
INCLUDING WITHOUT LIMITATION ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
GIGA-TMS SHALL NOT BE LIABLE FOR CONTINGENT, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES TO PERSONS OR PROPERTY. GIGA-TMS
FURTHER LIMITS ITS LIABILITY OF ANY KIND WITH RESPECT TO THE
PRODUCT, INCLUDING ANY NEGLIGENCE ON ITS PART, TO THE CONTRACT
PRICE FOR THE GOODS.
GIGA-TMS’S SOLE LIABILITY AND BUYER’S EXCLUSIVE REMEDIES ARE
STATED IN THIS SECTION AND IN THE SECTION RELATING TO GIGA-TMS’S
LIMITED WARRANTY.

Contents
Chapter 1 : Introduction...........................................................................7
Introduce...............................................................................................................7
Fitting....................................................................................................................7
Chapter 2：About AG19...........................................................................8
Specification.........................................................................................................8
Chapter 3：How to use AG19..................................................................9
Start to use AG19.................................................................................................9
LED Indication......................................................................................................9
DIP SW Setting...................................................................................................10
Pin Description...................................................................................................11
Connection.........................................................................................................12
Chapter 4：Troubleshooting.................................................................15
Contact Us...............................................................................................16

Chapter 1 : Introduction
Introduce
The AG19 series products integrate a high sensitivity alcohol sensor. The algorithm
developed exclusively provides quick and reliable identification of whether the hands
have been disinfected with alcohol. It can be installed at the entrance of the area that
you want to control. Further clean the hands of entering personnel detection and
control. To ensure a safe and clean place in the control area.
Before using the AG19 . We recommend that you should already read this user guide.
Fitting
Software or user guide download table

Chapter 2：About AG19
Specification
AG19 series
PART NO AG19-00
(Relay only)
AG19-10
(Reader only)
AG19-20
(Relay + Reader)
Standard
Interface Wire – RS232 / RS485 / Wiegand
Power Require AC / DC 9 – 12V ; 1A
Dimension L: 90mm / W: 85mm / H: 40mm
Physical Characteristics
Weight 110 g
Environment parameter
Temperature Operating : -10°C ~ +60°C
Storage : -15°C ~ +65°C
Humidity Operating : +0% ~ +90% (no coagulation)
Storage : MAX 90% (no coagulation)
Regulatory approvals
Authentication CE FCC VCCI
EN55032 Part 15 B VCCI-CISPR 32
EN55024
ESD Contact : 4kv , Air : 8kv

DIP SW Setting
DIP1 DIP2 Approval Period
OFF OFF 3 Seconds (Default)
ON OFF 5 Seconds
OFF ON 10 Seconds
ON ON 15 Sconds
DIP3 DIP4 Sensitivity of Alcohol Detection
OFF OFF Very High (Default)
ON OFF High
OFF ON Middle
ON ON Low

Pin Description
Pin Name Description
1 Vout Power Output to Reader (Reguralation 5V or Vin DC)
2 GND GND
3 RDA Connect to Reader Wiegand D0 / RS232 TX / RS485+
4 RDB Connect to Reader Wiegand D1 / RS232 RX / RS485-
5 HDB Connect to Host Wiegand D1 / RS232 RX / RS485-
6 HDA Connect to Host Wiegand D0 / RS232 TX / RS485+
7 DO Digital Output
8 DI Digital Input
9 Vin Power Input (AC / DC 9V-24V)
10 GND GND (AC 9-24V)
11 NO Relay NO
12 NC Relay NC
13 COM Relay COM

Connection
AG19-00 Relay onley

AG19-10 Reader only
Power Control

AG19-20 Relay + Reader

Chapter 4：Troubleshooting
1. AG19 doesn’t work?
Please check that the AG19 is actually connected to the power supply (AC / DC 9
– 12V ; 1A) . The red power light of AG19 is lighting
