Promate Twister User manual

Twister
Portable Bluetooth™ Speaker for Audio & Call Streaming with in-built
Microphone
User Guide

Introduction
The Twister is an elegantly designed twisted speaker system. Connects to any Bluetooth™
enabled device such as iPhones, iPads and any other mobile device, the Twister automatically
routes all audio sounds to a powerful speaker system, allowing you to listen to music and hear
incoming and outgoing calls. The Twister has a powerful in-built microphone, a working range
of up to ten meters, and an in-built 1200mAH lithium battery with an average life of 7-8 hours
and is lightweight and easily portable.
Inside the box
Twister BluetoothTM speaker
Mini USB charge cable
3.5 mm Audio cable
Warranty Card
User manual
(The contents of the box are subject to changes intended to improve product performance
without prior notice)
Product specifications
Bluetooth™: Version 2.1 + EDR
Input power: 5V, 500mA
Output power: 3W x 2
Impedance: 4 Ohms
Speaker frequency: 20-20Khz
Signal-to-noise ratio: 85dB
Charging time: 2 hours
Playing time: 7-8hours
Component Identification

BluetoothTM connectivity button Volume +
Volume - Answer phone call Play/Pause Microphone
On/Off Mini-USB 3.5 mm Audio cable
charging port
Charging

Turn off Twister before charging
Connect the Twister using the supplied USB cable to a power source such as PC or USB
charging devices
Red indicator light is ON during charging, turns OFF after fully charged.
If the red indicator blinks it shows a low battery power, it is time for charging.
Powering on/off the Twister
After the device is fully charged, turn ON/OFF sliding switch (on back side of the unit) to
“ON”
Switch-on: hold down the Power/Mode button for five seconds until red LED appears.
The red & blue LED will blink quickly. Now the Twister is in standby-mode for pairing.
Switch-off: again, hold down the Power/Mode button until red LED appears. The red LED
will blink off after switch-off.
Turn ON/OFF sliding switch to “OFF”
Note: If you hold down Power/Mode to switch off before turn ON/OFF sliding switch to “OFF”,
Twister will remember paired device and pair automatically next time.
LED indicator Settings
OFF: Power off
Blue/Red: Pairing mode
Solid Blue: power on with Bluetooth™Mode (successfully paired via Bluetooth™)
Solid Green: power on with AUX-in mode
Pairing Twister with mobiles (BluetoothTM enabled) and Tablets.
Please keep the speaker and mobile within 1 meter distance
Turn on Twister until the blue & red LED blinks. Now the unit is standby for pairing.
Start the BluetoothTM function of mobile and search the Bluetooth™devices. After
searching, select “Twister” in the BluetoothTM device list.
If required, enter password or PIN N0: “0000”, and press “Yes” or “Confirm” key. Some
mobiles don’t need a password, and it will vary depending on your Bluetooth™settings
and version.
After successful pairing, select “Twister” in the BluetoothTM device list, and press
“connect”
LED turns to solid blue, indicating Twister is paired with devices via Bluetooth.
Note: 1: If the pairing is not successful, please turn off speaker first, and then re-pair again.

2: After pairing is successful, paired devices will remember each other. Unless pairing
information is deleted because of a new pairing, there is no need to pair when using it the next
time. If you want to pair the speaker with other devices, please turn off BluetoothTM function of
existing source device, and pair Twister with the new device according to steps 1-6 mentioned
above.
Pairing Twister with iPhone, iPad, iPad mini
Keep Twister and iPhone (iPad, iPad mini within a 1 meter range when pairing
Turn on Twister, and when the blue & red LED blinks quickly, the unit is in standby, ready
for pairing.
In iPhone (iPad), go to General, then to Bluetooth, then tap on the BluetoothTM function,
search the BluetoothTM devices and identify Twister.
Select Twister to complete pairing.
The LED will turn to solid blue indicating Twister is paired with iPhone (iPad, iPad mini)
via Bluetooth™.
Pairing Twister with BluetoothTM enabled PC or notebook
Please keep Twister and PC within a 1 meter range when pairing.
Turn on Twister, and when the blue & red LED blinks quickly, the unit is in standby, ready
for pairing.
Activate BluetoothTM connectivity on your PC and begin SEARCH NEW DEVICE function.
After a short scanning period, PC will indicate that your Twister speaker has been
discovered and is ready for connecting/pairing.
If you are requested to enter a pin-code, use the code “0000”
Click to pair Twister and PC.
The LED will turn to solid blue indicating Twister is paired with PC via Bluetooth.
Pairing Twister with Mac OS X 10 or above
Please keep Twister and Mac within a 1 meter range when pairing
Turn on Twister, and when the blue & red LED blinks quickly, the unit is in standby, ready
for pairing.
Pair it with Mac –choose setup BluetoothTM device from the BluetoothTM status menu in
the menu bar, and follow the onscreen instructions to pair with the speaker. If the
BluetoothTM status menu is not available, open BluetoothTM preferences and select the
“Show BluetoothTM status in the menu bar” checkbox. As per of the pairing process, you
may need to enter a passkey (0000)
Open System Preferences and click Sound
Click Output and select the BluetoothTM speaker

Click Input and select your speaker. Adjust the Input and Output volume.
LED turns to solid blue indicating Twister is paired with devices via Bluetooth.
Note: Some applications, including iChat AV, allow you to select the audio device from within
the application (independently of the default audio input and output selected on the Sound
pane of System Preferences). To use a BluetoothTM speaker with iChat AV, select the BluetoothTM
speaker for audio input and output on the Video pane of iChat preferences.
Re-connecting to a paired device
Each time Twister is turned on, it will attempt to connect to the last device it was paired
with automatically (the source device must be turned on). Twister will do as below 2
options
Connect to last connected devices automatically, then just start music playback.
It will be listed on the screen of devices as an output channel, then please select Twister
as output channel and play music.
Note: in some cases, the speaker may need to be manually selected from your operating system
sound or hardware output list.
HFP device exception
When Twister is in standby mode, it will not be able to connect to any HFP device. To “wake” the
speaker and re-connect to the previously used HFP device, press the POWER/MODE twice to re-
connect automatically.
Hand-free: Answer the phone call via Twister
When have an incoming call, press “Answer phone call” button 1 time to answer via
speaker.
Press it again to end a call.
When there is no incoming call, the “answer phone call” button will work as “Play/Pause”
to control music. Press it to start music, press again to pause.
Note: Twister will not work as loudspeaker if answering the phone calls by mobile itself.
AUX port
You can connect AUX port to any music devices via the AUX cable included.
Short press Power/Mode button to change the mode between AUX and Bluetooth™.
LED turns to solid green in AUX mode.
Keeping the device out of the reach of small children:

The packing products and the plastic bags for the accessories are not toys.
The bag itself and those small fittings inside can cause suffocation. Do not attempt to
disassemble the device. No parts embedded can be replaced or repaired by users.
Only authorized dealers or maintenance centers can disassemble this product. For issues
with any parts including normal wear, break, or damages, please contact your dealer.
Keep the product away from rain or other liquids.
Do not use your headset in areas with flammable gases, as this could cause fires.
