UNIVERSAL TV EXPLORER
TV EXPLORER®II / II+
1
1GENERAL
1.1 Description
The television explorer TV EXPLORER II / II+ represents an evolutionary step with
respect to the traditional field strength meters. The continuous PROMAX innovation
process in the sector of field strength meter yields an instrument that changes the way to
take and understand television signals measurements.
This equipment incorporates important advances in the functional aspects as
well as in the ergonomics to allow the installers to make their work with maximum
comfort and speed. Simultaneously the instrument is reliable for any possible problem
at the input signal, at the distribution components or the receiver equipment.
The TV EXPLORER II / II+ has been designed to satisfy all the necessities of
measurement during the transition from the analogue transmissions to digital in
terrestrial, satellites and cable systems. Allowing measurements of analogue signals
as well as digital ones. When pressing the auto identification key, it searches and
identifies the signal under test. First it recognises whether the signal is an analogue
channel or a digital one. If the channel is analogue, it determines the television standard
of the signal. When the signal is digital (DVB), it analyses for each modulation type QAM
/ QPSK / 8PSK / COFDM all the associated parameters such as the modulation system:
carriers 2k-8k, symbol rate, code rate, etc. and determines the value of the signals
under test.
The range of frequencies covered makes this instrument an excellent tool for FM
radio, terrestrial TV, mobile TV, satellite TV and cable TV (where the subband tuning
margin, from 5 to 45 MHz, enables the user to carry out tests on the return channel).
TV EXPLORER®is a registered trademark PROMAX Electronica S.A.
1Trademark of the DVB - Digital Video Broadcasting Project (4661/4662).

USER’S MANUAL. TV EXPLORER II/II+
Page 2 12/2013
The TV EXPLORER II/II+ includes the main TV standards: M, N, B, G, I, D, Kand
L, adopting, apart from the characteristic parameters of the standard, the correcting
automatic system to obtain in all the cases an accurate measuring of the input signal
level. It accepts any TV system (PAL, SECAM and NTSC) and allows the user to work
directly with digital TV signals decoding them, so that the television image may be
viewed, and directly measuring the power, carrier/noise ratio (C/N), the bit error rate
(BER) and the modulation error ratio (MER), as well for DVB-T/H (COFDM) as DVB-
S/S2 (QPSK/8PSK) and DVB-C (QAM) signals. This instrument allows to obtain a
graphical representation of the Constellation Diagram for DVB-C (QAM), DVB-T/H
(COFDM) and DVB-S/S2 (QPSK/8PSK) signals.
Being a multistandard instrument, it can be efficiently used in any country of the
world.
Includes a symbol-based keyboard that allows the direct access to the various
functions that are displayed simultaneously on screen.
The TV EXPLORER II / II+ makes a dynamic exploration of the spectrum,
detecting all the channels in the explored band, this applies for the terrestrial and the
satellite television bands. The meter locates all the channels in the spectrum with no
need of any previous information about the number of channels, the type of signals
transmitted or their characteristics. With the data collected after each exploration, it
creates a register that contains tables of channels that can be independent for each
system or installation. At any time, the measurement sessions using only the pretuned
channels can be repeated. In this way it is possible to optimise the measurement
process.
Shown on the frontal panel is the type of measurement that is being carried
(Terrestrial-Satellite/Analogue-Digital) and the data are presented on a hi-res 6.5" colour
graphic TFT transflective display with panoramic aspect ratio (16:9). The equipment
incorporates a light sensor that activates the contrast and luminosity of the display
according to the environmental conditions.
Furthermore the TV EXPLORER II+ comes with a conector for CAM modules
(PC-Card) that allows the insertion of subscriber conditional access cards.
The EXPLORER is an ideal size to hold with a hand. The instrument can be held
to the body with the carrying bag or transport belt, which at the same time protects it
from the rain. Because it is designed for outdoor use, it includes an anti-shock protector
that completely covers the instrument, and is supplied with a strong transport case. As
well, the front panel does not have any keys nor gaps to avoid accidental water ingress.

USER’S MANUAL. TV EXPLORER II/II+
12/2013 Page 3
English
The TV EXPLORER II / II+ is designed to integrate measurements that require
different operating configurations. In this way it incorporates a specific function to
facilitate the alignment of antennas. When activating the alignment function the
instrument is set automatically to offer a fast spectrum sweep and a high sensitivity
graphical bar that allows fine adjust for the maximum signal. In addition it includes a
module for the powering of LNBs and DVB-T antennas to 5V, and the commands for
the programming of DiSEqC 1.2 and SatCR devices.
The EXPLORER can be updated to new software versions that extend the available
functions in the future. That means it can incorporate new benefits without additional
cost. For example, in the test of satellite signals distribution networks, using
combined with an IF generator permits to carry out an easy verification of the
installations before commissionning.
The spectrum analyser features with high accuracy, resolution, sensitivity and
sweep speed allows the instrument to be very useful for applications as the installation
of antennas or the detection of complex impulsional noise events. It presents an
innovative control system based on four arrows, that makes the use of the spectrum
analyser very intuitive. The arrows allow adjusting the reference level by steps of 10 or
5 dB and the frequency margin span on screen.
To enhance its convenience of use, it includes memories to store automatically
the different data acquisitions, i.e.: acquisition name, test points, frequency, channel
plan, etc.,. Moreover, the DATALOGGER function makes it much easier to test systems
in which a large number of measurements have to be made, and enables further
processing of all the information acquired using a computer system. The equipment is
able to generate automatic measurement reports and to update itself through Internet by
means of PkTools provided software.
The TV EXPLORER II+ in addition, allows to record and to play a TS
corresponding to services from a digital channel. For it, the equipment uses an internal
memory of up to 1 GB.
Also, this meter incorporates a DiSEqC2command generator and permits to
supply different voltages to the external unit (5 V / 13 V / 15 V / 18 V / 24 V) and includes
an EUROCONNECTOR, or Scart connector, for audio/video input/output.
The TV EXPLORER II / II+ is powered by rechargeable battery or connected to
the mains through the supplied external DC power charger.
It incorporates a USB port, which enables the communication with a PC and to
download dataloggers and channel plans.
2DiSEqCTM is a trademark of EUTELSAT.

USER’S MANUAL. TV EXPLORER II/II+
Page 4 12/2013
This instrument due to its extreme-compact design, technical specifications and
low cost becomes the industry standard for the installer.
1.2 Specifications
CONFIGURATION FOR MEASURING LEVEL AND POWER
TUNING Digital frequency synthesis. Continuous tuning from
5 to 1000 MHz (3) and from 950 to 2150 MHz.
Tuning modes Chanel or frequency (IF or downlink at satellite
band).
Channel plan configurable on demand.
Resolution 5-1000 MHz: 50 kHz.
950-2150 MHz: < 200 kHz (span FULL-500-200-
100-50-32-16 MHz).
Automatic search (Explorer) Threshold level selectable. DVB-T/H, DVB-C and
DVB-S/S2 selection.
Signal identification Analogue and digital. Automatic.
RF INPUT
Impedance 75 Ω.
Connector Universal, with BNC or F adapter.
Maximum signal 130 dBμV.
Maximum input voltage
DC to 100 Hz 50 Vrms (powered by the AL-103 power charger).
30 Vrms (not powered by the AL-103 power
charger).
5 MHz to 2150 MHz 130 dBμV.
DIGITAL SIGNALS MEASUREMENT
POWER RANGE
COFDM: 45 dBμV to 100 dBμV.
QAM: 45 dBμV to 110 dBμV.
QPSK/8PSK: 44 dBμV to 114 dBμV.
MEASUREMENTS
DVB-T/H (COFDM): Power, CBER, VBER, MER, C/N and Noise margin.
Presentation: Numeric and level bar.
3Continuous tunning from 45 to 865 MHz for TV EXPLORER II.

USER’S MANUAL. TV EXPLORER II/II+
12/2013 Page 5
English
DVB-C (QAM): Power, BER, MER, C/N and Noise margin.
Presentation: Numeric and level bar.
DVB-S (QPSK): Power, CBER, VBER, MER, C/N and Noise margin.
Presentation: Numeric and level bar.
DVB-S2 (QPSK/8PSK): Power, CBER, LBER, MER, C/N and wrong packets.
Presentation: Numeric and level bar.
CONSTELLATION DIAGRAM
Type of signal DVB-T/H, DVB-C, DVB-S and DVB-S2.
Presentation I-Q graph.
DVB-H SIGNAL PARAMETERS
Carriers 2k / 4k/ 8k (Selected by the user).
Guard Interval 1/4, 1/8, 1/16, 1/32 (Selected by the user).
Code Rate 1/2, 2/3, 3/4, 5/6, 7/8.
Modulation QPSK, 16-QAM, 64-QAM.
Spectral inversion Selectable: ON, OFF.
Hierarchy Indicates hierarchy mode.
Cell ID Transmitter station.
TPS signalling Time slicing, symbol interleaver and MPE-FEC.
DVB-C SIGNAL PARAMETERS
Demodulation 16/32/64/128/256 QAM.
Symbol rate 1000 to 7000 kbauds.
Roll-off (α) factor
of Nyquist filter 0.15.
Spectral inversion Selectable: ON, OFF.
DVB-S SIGNAL PARAMETERS
Symbol rate 2 to 45 Mbauds.
Roll-off (α) factor
of Nyquist filter 0.35.
Code Rate 1/2, 2/3, 3/4, 5/6, 7/8 and AUTO.
Spectral inversion Selectable: ON, OFF.
DVB-S2 SIGNAL PARAMETERS
Symbol rate (QPSK) 2 to 33 Mbauds.
Symbol rate (8PSK) 2 to 30 Mbauds.
Roll-off (α) factor
of Nyquist filter 0.20, 0.25 and 0.35.
Code Rate (QPSK) 1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 and AUTO.
Code Rate (8PSK) 3/5, 2/3, 3/4, 5/6, 8/9, 9/10 and AUTO.
Spectral inversion Selectable: ON, OFF.
Pilots Indication if are present.

USER’S MANUAL. TV EXPLORER II/II+
Page 6 12/2013
VIDEO
Format DVB: MPEG-2 (MP@ML).
MPEG-4 AVC H.264 (free or scrambled)4.
Services decoding Service list and PIDs.
ANALOGUE SIGNALS MEASUREMENT
LEVEL MEASUREMENT
Measurement range
Terrestrial TV & FM bands 10 dBμV to 130 dBμV (3.16 μV to 3,16 V).
Satellite TV band 30 dBμV to 130 dBμV (31.6 μV to 3,16 V).
Reading Auto-range, reading is displayed on an OSD
window.
Digital Absolute value calibrated in dBμV, dBmV or dBm.
Analogue Relative value through an analogue bar on the
screen.
Measurement bandwidth 230 kHz (Terrestrial band) +4 MHz (Satellite band)
According to span (maximum band ripple 1 dB).
Audible indicator LV audio. A tone with pitch proportional to signal
strength.
Accuracy
Subband ±1,5 dB (30-120 dBμV, 5-45 MHz) (22 °C±5 °C).
Terrestrial bands ±1.5 dB (30-120 dBμV, 45-1000 MHz) (22 °C±5 °C).
Satellite band ±2.5 dB (40-100 dBμV, 950-2050 MHz) (22 °C ± 5 °C).
Overrange indication ↑,↓.
MEASUREMENTS MODE
Terrestrial bands
Analogue channels Level, Video-Audio ratio, Carrier-Noise ratio and FM
deviation and demodulation.
Digital channels Channel power, Carrier-Noise ratio and Channel
identification.
Satellite band
Analogue channels Level and Carrier-Noise ratio.
Digital channels Channel power and Carrier-Noise ratio.
DATALOGGER function5Measurements automatic acquisition and storage.
Analogue channels Level, C/N and V/A ratios.
Digital channels Frequency offset, MPEG-2 / MPEG-4 detection,
power, C/N, MER, CBER, VBER, LBER and noise
margin.
4If the service is compatible with transcoding modules MPEG-4 to MPEG-2 in CAM format (or consult availability)
(only TV EXPLORER II+).
5Using PkTools software application with a PC.

USER’S MANUAL. TV EXPLORER II/II+
12/2013 Page 7
English
SAT IF TEST Function6IF distribution network response for satellite band.
ATTENUATION TEST Function7Signal distribution network response for terrestrial
band.
SPECTRUM ANALYSER MODE
Satellite band 30 dBμV to 130 dBμV (31.6 μV to 3.16 V).
Terrestrial bands 10 dBμV to 130 dBμV (3.16 μV to 3.16 V).
Measurement bandwidth According to span.
Terrestrial 230 kHz, 1 MHz.
Satellite 4 MHz, 1 MHz.
Span
Terrestrial Full span (full band) - 500 - 200 - 100 - 50 - 32 - 16 -
8 MHz selectable.
Satellite Full span (full band) - 500 - 200 - 100 - 50 - 32 - 16
MHz selectable.
Markers 1 with Frequency and level or C/N indications.
Vertical range Adjustable in steps of 5 or 10 dB.
Measurements
Terrestrial bands
Analogue channels Level.
Digital channels Channel power.
Satellite band
Analogue channels Level.
Digital channels Channel power.
ECHOES ANALYSER MODE
Measurement range
Delay 0.1 μs to 224 μs.
Distance 0.3 km to 67.2 km.
Power range 0 dBc to —30 dBc.
MONITOR DISPLAY
Monitor TFT colour 6.5 inches. Transflective LCD.
Aspect ratio 16:9, 4:3.
Colour system PAL, SECAM and NTSC.
TV standard M, N, B, G, I, D, K and L.
Spectrum mode Variable span, dynamic range and reference level by
means of arrow cursors.
Sensibility 40 dBμV for correct synchronism.
6Function to be used with RP-250 or RP-050 IF signal simulator.
7Function to be used with RP-250 or RP-080 pilot signals simulator.

USER’S MANUAL. TV EXPLORER II/II+
Page 8 12/2013
BASE BAND SIGNAL
VIDEO
Format DVB: MPEG-2 (MP@ML).
MPEG-4 AVC H.264 (freeorscrambled )8.
Conditional access types Common Interface, according to available user CAM.
External video input Scart.
Sensibility 1 Vpp (75 Ω) positive video.
Video output Scart (75 Ω).
SOUND
Input Scart
Outputs Built in speaker, Scart.
Demodulation TV PAL, SECAM, NTSC system according to
DVB-T/H, DVB-C, DVB-S/S2 and MPEG standards.
De-emphasis 50 μs, 75 μs (NTSC).
Subcarrier Digital frequency synthesis according to the TV
standard.
USB INTERFACE For datalogger and channel plans transfer.
EXTERNAL UNITS POWER
SUPPLY Through the RF input connector.
Terrestrial and Satellite External or 5/13/15/18/24 V.
22 kHz signal Selectable in satellite band.
Voltage 0.65 V ± 0.25 V.
Frequency 22 kHz ± 4 kHz.
Maximum power 5 W.
DiSEqC9GENERATOR According to DiSEqC 1.2 standard.
POWER SUPPLY
Internal
Batteries 7.2 V 12 Ah Li-Ion battery.
Autonomy > 4.5 hours in continuous mode.
Recharging time 3 hours up to 80% (instrument off).
External
Voltage 12 V.
Consumption 40 W.
Auto power off Programmable. After the selected amount of
minutes without operating on any control.
Deactivable.
8If the service is compatible with transcoding modules MPEG-4 to MPEG-2 in CAM format (or consult availability)
(only TV EXPLORER II+).
9DiSEqCTM is a trademark of EUTELSAT

USER’S MANUAL. TV EXPLORER II/II+
12/2013 Page 9
English
OPERATING ENVIRONMENTAL CONDITIONS
Altitude Up to 2000 m.
Temperature range From 5 to 40 °C (Automatic disconnection by excess
of temperature).
Max. relative humidity 80 % (up to 31°C),
decreasing lineally up to 50% at 40 °C.
MECHANICAL FEATURES
Dimensions 230 (W) x 161 (H) x 76 (D) mm.
(Total size: 2.814 cm3).
Weight 2.2 kg (without holster).
INCLUDED ACCESSORIES.
1x CB-077 Rechargeable Li+ battery 7,2 V 12 Ah.
1x AT-010 10 dB attenuator.
1x AD-055 "F"/F-BNC/F adapter.
1x AD-056 "F"/F-"DIN"/F adapter.
1x AD-057 "F"/F-"F"/F adapter.
1x AL-103 External DC charger.
1x DC-229 Transport suitcase.
1x DC-267 Carrying bag.
1x DC-289 Transport belt.
1x AA-103 Car lighter charger.
1x CC-040 Cable Connection USB.
1x CA-005 Mains cord.
1x USB Memory.
OPTIONAL ACCESSORIES
DC-266 Protective bag.
RECOMMENDATIONS ABOUT THE PACKING
It is recommended to keep all the packing material in order to return the
equipment, if necessary, to the Technical Service.

USER’S MANUAL. TV EXPLORER II/II+
Page 10 12/2013

USER’S MANUAL. TV EXPLORER II/II+
12/2013 Page 11
English
2SAFETY RULES
2.1 General safety rules
*The safety could not be assured if the instructions for use are not closely
followed.
*Use this equipment connected only to systems with their negative of
measurement connected to ground potential.
*The AL-103 external DC charger is a Class I equipment, for safety reasons plug it
to a supply line with the corresponding ground terminal.
*This equipment can be used in Overvoltage Category I installations and
Pollution Degree 2 environments.
External DC charger can be used in Overvoltage Category II, installation and
Pollution Degree 1 environments.
*When using some of the following accessories use only the specified ones to
ensure safety.
Rechargeable battery
External DC charger
Car lighter charger cable
Power cord
*Observe all specified ratings both of supply and measurement.
*Remember that voltages higher than 70 V DC or 33 V AC rms are dangerous.
*Use this instrument under the specified environmental conditions.
*When using the power adaptor, the negative of measurement is at ground
potential.
*Do not obstruct the ventilation system of the instrument.
*Use for the signal inputs/outputs, specially when working with high levels,
appropriate low radiation cables.
*Follow the cleaning instructions described in the Maintenance paragraph.

USER’S MANUAL. TV EXPLORER II/II+
Page 12 12/2013
*Symbols related with safety:
2.2 Descriptive Examples of Over-Voltage Categories
Cat I Low voltage installations isolated from the mains
Cat II Portable domestic installations
Cat III Fixed domestic installations
Cat IV Industrial installations

USER’S MANUAL. TV EXPLORER II/II+
12/2013 Page 13
English
3INSTALLATION
3.1 Power Supply
The TV EXPLORER II / II+ is a portable instrument powered by one 7.2 V Li-Ion
battery. There is also an external DC charger provided for mains connection and battery
charging.
3.1.1 Operation using the External DC Charger
Connect the external DC charger to EXT. SUPPLY [32] on the
TV EXPLORER II / II+ side panel. Connect the DC charger to the mains. Then, press the
rotary selector [1] for more than two seconds. The level meter is now in operation and
the battery is slowly charged. When the instrument is connected to the mains, the
CHARGER indicator [4] remains lit. This indicator changes of colour according to the
battery charge status:
BATTERY CHARGE STATUS
OFF ON
RED < 50 % < 90 %
YELLOW > 50 % > 90 %
GREEN 100 % 100 %
Table 1.- Indication of the battery charge status (CHARGER).
3.1.2 Operation using the Battery
For the device to operate on the battery, disconnect the power cable and press the
rotary selector [1] for more than two seconds. The fully charged battery can power the
equipment for more than 4.5 hours non-stop.
If battery is very weak, the battery cut-off circuit will prevent the device from
functioning. In such a situation battery must be recharged immediately.
Before taking any measurements, you have to check the charge status of the
battery by checking the battery charge level indicator that appears when activating the
measurement mode pressing key [12]. These are the indicators on screen:

USER’S MANUAL. TV EXPLORER II/II+
Page 14 12/2013
BATTERY CHARGE LEVEL INDICATORS
COLOUR SYMBOL CHARGE LEVEL
GREEN 75 % ∼100 %
GREEN 30 % ∼75 %
GREEN 10 % ∼30 %
Empty battery.
Recharge in progress.
Table 2.- Indication of the battery charge level on screen.
3.1.2.1 Battery Charging
To fully charge the battery, connect the instrument to the external DC charger
without activating the power on process. The length of time it takes to recharge it
depends on the condition of the battery. When the instrument is in operation the
recharging process is slower. If they are very low the recharging period is about
5 hours. The CHARGER [4] indicator should remain lit.
When the battery charging process is completed with the instrument off, the fan
stops.
IMPORTANT
The instrument battery needs to be kept charged between 30% and 50% of its
capacity when not in use. The battery needs to be fully charged for best results. A
fully charged battery suffers temperature-related discharge. For example, at a room
temperature of 20 ° C, it can lose up to 10% of its charge over 12 months.
3.2 Installation and Start-up
The TV EXPLORER II / II+ level meter is designed for use as a portable device.
Therefore does not require installation
When the rotary selector [1] is pressed for more than two seconds, the instrument
is started up in the automatic power-off mode; that is, the device is automatically
disconnected after the selected minutes if no key has been pressed. When the device is
operating, it is also possible to select the auto power-off mode by means of the
Preferences menu [22] and to select the time out until the automatic power-off.
When the equipment is going to be moved, activate the Transport mode by
means of the Preferences menu [22] to disable the power on process until one specific
key from main keyboard is pressed [8] as is it indicated on screen.

USER’S MANUAL. TV EXPLORER II/II+
12/2013 Page 15
English
4QUICK USER GUIDE
STEP 1.- Battery charging
1. Connect the DC external charger to the equipment through connector [32] located on
the lateral panel.
2. Connect the DC charger to the mains.
3. When the equipment is connected to the mains, the CHARGER led [4] remains
lighted.
DC IN
Figure 1.- Battery charging
STEP 2.- Power on and signal connection
1. Hold the rotary selector [1] pressed until the equipment is powered on.
2. Connect the RF signal source in the input connector [30].
Figure 2.- Power on and signal connection.

USER’S MANUAL. TV EXPLORER II/II+
Page 16 12/2013
STEP 3.- To carry out a complete channel band exploration
1. Select the frequency band to explore [14] (terrestrial or satellite).
2. Activate the exploration process by holding [25] key pressed.
3. Press [10] key to visualise the channels detected and [6] to change
between channels from detected channels list.
STEP 4.- To carry out the tuned channel identification
1. Select the frequency band to explore [14] (terrestrial or satellite).
2. Activate the identification process pressing once on [25] key.
3. Press [10] key to visualise the signal detected from channel or frequency
identified or [13] to monitor the corresponding spectrum.
NOTE: In the case that is desired to explore or identify DVB-C signals it is
necessary to select previously DVB-C standard as digital signal identifier
through [22] PREFERENCES menu.
STEP 5.- Making measurements
1. Select the channel or frequency [24] to measure by means of the rotary selector
[1].
2. Press [12] key to select the type of measurement until on screen appears the
corresponding measurement.

USER’S MANUAL. TV EXPLORER II/II+
12/2013 Page 17
English
STEP 6.- Frequency spectrum monitoring
1. Select the frequency band to graph [14] (terrestrial or satellite).
2. Press [13] key to activate the signal sweeping.
3. Press [6] to modify the reference level in the vertical axis.
4. Press [6] to modify span in the horizontal axis.
STEP 7.- Video signal monitoring
1. Select the terrestrial frequency band [14].
2. Tune the channel or frequency [24] that is desired to visualize on screen.
3. Verify that the equipment receives an appropriate signal level [12].
4. Press [10] key to visualise the TV image, if the channel is digital press [6]
and place the cursor on the Service Identifier field and press the rotary selector [1] to
obtain the available list of services.
