ProMinent CHLORINSITU IIa Operating and maintenance instructions

Chlorine electrolysis system
CHLORINSITU IIa 60 ... 300 g/h
Maintenance instructions
B1015
Target group: technical personnel.
The maintenance instructions are only valid in conjunction with the installation and operating instructions.
EN
Original operating instructions (2006/42/EC)981159 BA CI 026 10/23 EN
Please carefully read these operating instructions before use. · Do not discard.
The operator shall be liable for any damage caused by installation or operating errors.
The latest version of the operating instructions are available on our homepage.

Table of contents
1 Safety.................................................................................... 3
2 Maintenance of Chlorinsitu IIa 60 - 300 g/h.......................... 4
2.1 Warning information...................................................... 4
2.2 Recommendation for the weeks prior to mainte‐
nance............................................................................ 4
2.3 Maintenance intervals................................................... 4
2.4 Auxiliary equipment required for maintenance work..... 4
2.4.1 Protective clothing..................................................... 4
2.4.2 Contents of the capacity-specific “Maintenance
pack 1” (annual maintenance):.................................. 6
2.4.3 Contents of the capacity-specific “Maintenance
pack 3” (3-yearly maintenance):................................ 6
2.4.4 Contents of the spare parts kit................................... 6
3 Annual and 3-yearly maintenance steps with Maintenance
kit 1 and Maintenance kit 3................................................... 7
3.1 Check the status and condition of the system prior to
maintenance................................................................. 8
3.1.1 Maintenance check-list.............................................. 8
3.1.2 Checking the alarm history...................................... 11
3.1.3 Monitoring escaping liquid....................................... 11
3.1.4 Monitoring the hydrogen outlet................................ 11
3.1.5 Checking the room ventilation................................. 11
3.1.6 Is the water test kit still valid?.................................. 11
3.1.7 Measuring cell current............................................. 11
3.1.8 Cell voltage measurement....................................... 12
3.1.9 Checking the water flow rate................................... 12
3.1.10 Checking leak detection in the collection pan........ 12
3.1.11 Does production stop?........................................... 12
3.1.12 Is production running?........................................... 12
3.1.13 Stopping production............................................... 12
3.1.14 Checking whether the right salt is being used....... 12
3.2 Rinsing the system prior to maintenance.................... 12
3.3 Brine tank and brine pump.......................................... 14
3.4 Softener and water supply.......................................... 14
3.4.1 Maintenance on the softener: Softener head........... 15
3.4.2 Maintenance on the softener: Brine suction............ 15
3.5 Product tank................................................................ 16
3.6 System cabinet........................................................... 17
3.7 Control cabinet............................................................ 20
3.8 Electrolysis cell........................................................... 21
3.8.1 Acid cleaning of the electrolysis cells...................... 22
4 Restarting production.......................................................... 24
4.1 Switching on the power supply................................... 24
4.2 Calibration of the brine pump...................................... 24
Table of contents
2

1 Safety
WARNING!
Danger from hazardous substances!
Possible consequence: Fatal or very serious inju‐
ries.
Please ensure when handling hazardous sub‐
stances that you have read the latest safety data
sheets provided by the manufacture of the haz‐
ardous substance. The actions required are
described in the safety data sheet. Check the
safety data sheet regularly and replace, if neces‐
sary, as the hazard potential of a substance can be
re-evaluated at any time based on new findings.
The system operator is responsible for ensuring
that these safety data sheets are available and that
they are kept up to date, as well as for producing
an associated hazard assessment for the worksta‐
tions affected.
nMaintenance may only be carried out by authorised technical
personnel.
nThese maintenance instructions are only valid in conjunction
with the “Installation and operating instructions for the chlorine
electrolysis system CHLORINSITU® IIa”.
Safety
3

2 Maintenance of Chlorinsitu IIa 60 - 300 g/h
2.1 Warning information
WARNING!
Danger from hazardous substances!
Possible consequence: Fatal or very serious inju‐
ries.
Please ensure when handling hazardous sub‐
stances that you have read the latest safety data
sheets provided by the manufacture of the haz‐
ardous substance. The actions required are
described in the safety data sheet. Check the
safety data sheet regularly and replace, if neces‐
sary, as the hazard potential of a substance can be
re-evaluated at any time based on new findings.
The system operator is responsible for ensuring
that these safety data sheets are available and that
they are kept up to date, as well as for producing
an associated hazard assessment for the worksta‐
tions affected.
WARNING!
You are working with chemicals here:
– Sodium hypochlorite 0.9% (NaOCl)
– Hydrochloric acid 5% (HCI)
– Salt (NaCl)
Therefore:
– Never mix NaOCI with HCI as this produces
toxic gas.
– Pay attention to the material safety data
sheets.
– Wear effective personal protective equipment.
2.2 Recommendation for the weeks prior to maintenance
In the weeks leading up to maintenance, preferably fill only as
much salt into the brine tank as you will need in the time prior to
maintenance to keep the level as low as possible.
2.3 Maintenance intervals
nannually
ncarry out an additional maintenance every 3 years
2.4 Auxiliary equipment required for maintenance work
2.4.1 Protective clothing
Protective clothing:
nSafety goggles,
nGloves,
Maintenance of Chlorinsitu IIa 60 - 300 g/h
4

nAppropriate clothing and shoes,
nRefer to the material safety data sheets,
n10-litre bucket for water and brine,
nOnly with acid cleaning: 20-litre canister to dispose of the
diluted hydrochloric acid,
nService passwords (your sales partner will provide you with the
service password),
nOperating instructions for the CIIa 60 ... 300.
Depending on the installation version and system updates, the
images in this manual may differ from your installation. There are
various maintenance packages and spare parts packages avail‐
able to match your installation. We urgently recommend updating
the installation to the latest update. The following graphic shows an
overview of the installation versions and updates of the system.
Nur MP-1 Nur MP-1
CIIa Version V2.0
Installationen Baujahr
> 10.2022
Original Installationen
Installationen Baujahr
< 01.2021
Update 01.2021
Installationen Baujahr
> 01.2021 – 11.2022
Update 11.2021
Installationen Baujahr
> 11.2021 – 10.2022
Field Update
12.2020
(7200700)
Field Update
10.2021
(7200701)
MP-1
MP-3 CIIa … gr
SPP
MP-3 CIIa … gr
SPP update 10.2021
MP-3
SPP CIIa … gr V2.0
A3748
Fig. 1: Installation versions and updates of the system
Maintenance of Chlorinsitu IIa 60 - 300 g/h
5

2.4.2 Contents of the capacity-specific “Maintenance pack 1” (annual maintenance):
1 - Test kit for softened water < 0.1 °dH,
2 - Water filter,
3 - Filter mat for the fan,
4 - Spare parts kit: brine metering, complete,
5 - Foot valve
6 - Injection valve(s)
7 - MP sealing set CIIa
2.4.3 Contents of the capacity-specific “Maintenance pack 3” (3-yearly maintenance):
1 - Contents as per “Maintenance pack 1”, but in addition:
2 - Maintenance kit for the softener
3 - Resin cleaning concentrate
4 - Measuring cup
5 - Wrench, softener
6 - Rinsing kit, drain
7 - Rinsing kit, supply
8 - Solenoid valve
9 - Level switch float
10 - Level switch float
2.4.4 Contents of the spare parts kit
The spare parts kit contains replacement components that are
required to continue the process. The contents of the spare parts
kit vary depending on the version of the installation and the number
of updates.
nSpare electrical components, such as relays, fuses and fan(s)
nTemperature sensor (certain installation versions)
nHydraulic components, such as level switches, valves, seals,
brine pump
Maintenance of Chlorinsitu IIa 60 - 300 g/h
6

3 Annual and 3-yearly maintenance steps with Maintenance kit 1
and Maintenance kit 3
INFORMATION: Follow the instructions. This will avoid hazards
caused by the product.
A3749
Power and
water supply
Power but no
water supply
No power and
water supply
Check the system
Rinse the system
Maintenance: Brine tank & pump
Maintenance: Softener
& water supply
Maintenance: Production tank
Maintenance: hydraulic
Maintenance: electrical
Maintenance: Electrolysis cell
Acid cleaning: Electrolysis cell
Start-up and calibration
Ensure that the system has been
rinsed before commencing maintenance work
at these positions.
Fig. 2: System status during maintenance steps
Annual and 3-yearly maintenance steps with Maintenance kit 1 and Maintenance kit 3
7

Maintenance must be carried out in this order. If this sequence is
not adhered to, it is your responsibility to ensure that the machine
is in proper working order.
3.1 Check the status and condition of the system prior to maintenance
Complete the inspection list in the check-list. The check-list consti‐
tutes an integral part of the maintenance pack. Contact the supplier
if no check-list has been provided. Read off the production param‐
eters on the screen. Refer to the operating instructions for the
menu structure for all parameters.
3.1.1 Maintenance check-list
Serial number of the CIIa:
Capacity of the CIIa:
Commissioning date:
Maintenance interval: nannually
nevery 3 years
nevery 5 years
Performed by:
Date:
Remarks:
Annual and 3-yearly maintenance steps with Maintenance kit 1 and Maintenance kit 3
8

No. Subject OK
1 Pre-maintenance performance values:
Cell current [A]:
Cell voltage [V]:
Cell input temperature [°C]:
Cell output temperature [°C]:
Cell flow on [l/h]:
Cell flow off [l/h]:
Production hours [hours]:
Days until next maintenance [days]:
Water hardness < 0.05 °dH? [yes / no]:
2 Alarm messages to be noted?
3 Visual check and visual leaks to be noted?
4 Does the salt used comply with the specification?
5 Safety in relation to hydrogen:
Visual check of the extract air pipe for diluted hydrogen
Visual check of the drain for diluted hydrogen to the outside
Room air suction opening free (> 225 cm2)?
Does the unit stop after the cabinet door is opened?
6 Replace the water filter.
7 Change or clean the air intake filter.
8 At least every 3 years: Cleaning the cell(s) with acid is recommended but is not neces‐
sary in each case.
9 Maintain the brine metering pump.
10 Replace the brine injection valve.
11 Calibrate the brine metering pump.
12 If fitted: maintain the chlorine metering pump.
13 Annually: replace the foot valve in the internal chlorine tank – recommended.
Annual and 3-yearly maintenance steps with Maintenance kit 1 and Maintenance kit 3
9

No. Subject OK
14 Replace sealing rings in the three-part couplings:
Do not use any tools to tighten the three-part couplings.
nAt the inputs and outputs of the cells
nDownstream of the far right / last cell
n32 mm pipe on the internal chlorine tank
15 Replace around the outlet sensor:
nO-rings on the three-part coupling upstream and downstream of the sensor
nFlat seal upstream and downstream of the sensor. Manually tighten rotary sensor
16 Salt tank:
nCheck for hard salt crust on the base.
nCheck for dirt on the base.
nClean the tank if needed.
nReplace both foot valves.
17 Has the test kit for the water hardness not yet run out?
18 Every 3 years: replace the measuring turbine cartridge of the outlet sensor.
19 Every 3 years: replace the control valve for water metering.
20 Every 3 years: maintain the water softener.
Replace the piston, seals and washers and clean the nozzle.
21 Every 5 years: replace the housing fan.
22 Every 5 years: replace the cells - recommended.
23 Every 5 years: replace the float switch of the chlorine tank, recommended.
24 Reset the maintenance counter to 365 days.
25 Post-maintenance performance values:
Cell current [A]
Cell voltage [V]
Cell input temperature [°C]
Cell output temperature [°C]
Cell flow on [l/h]
Cell flow off [l/h]
Production hours [hours]
Days until next maintenance [days]
Water hardness < 0.05 °dH? [yes / no]
26 Check the orange screw cover of the internal storage tank. The screw cover must be
fully closed.
Annual and 3-yearly maintenance steps with Maintenance kit 1 and Maintenance kit 3
10

3.1.2 Checking the alarm history
Check the alarm history by pressing the
!
button on the screen. A
list is displayed. Try to avoid future alarms. Refer to the operating
instructions for an explanation of the alarms.
Chlorinsitu®-IIa
No external enable
Brine
Chlorine
H2O
H2
0.0 A
0.0 L/h
!
B1007
Fig. 3: The main menu of the user interface, standard control
Follow the instructions on the HMI of the system for a system with
a Siemens control.
3.1.3 Monitoring escaping liquid
Check whether there are any visible liquid leaks on the system. If
there are leaks, record them to eliminate them later.
3.1.4 Monitoring the hydrogen outlet
Check whether the hydrogen pipework to the room is leaking.
Check that there are no obstructions in the lines or outside the
lines. Eliminate the cause if a leak or obstruction is found.
3.1.5 Checking the room ventilation
Check visually and by touch whether the room ventilation system is
blocked.
3.1.6 Is the water test kit still valid?
Check the expiry date to determine whether the water test kit can
still be used.
3.1.7 Measuring cell current
Use a current clamp to measure the cell current. Check whether
the current is 75 ±2 A.
Annual and 3-yearly maintenance steps with Maintenance kit 1 and Maintenance kit 3
11

3.1.8 Cell voltage measurement
Use a multimeter to measure the voltage of each individual cell.
The cell voltage must lie between 3.0 and 3.7 V DC per cell. Refer
to the ‘Fault reporting’ chapter in the operating instructions if the
voltage is higher.
3.1.9 Checking the water flow rate
Check whether the product is flowing into the storage tank.
3.1.10 Checking leak detection in the collection pan
Connect the two plugs together: the system must stop pro‐
ducing chlorine. The solenoid valve (water inlet) must close.
Press the float: the system must stop producing chlorine. The
solenoid valve (water inlet) must close.
3.1.11 Does production stop?
Does production stop when the door is opened?
3.1.12 Is production running?
Does production continue even though the door is open?
3.1.13 Stopping production
See the next chapter.
3.1.14 Checking whether the right salt is being used
Refer to the data sheet.
3.2 Rinsing the system prior to maintenance
1. Use the [START/STOP] button in the main menu to stop the
system.
2. Use the product pump to drain the product tank. Store the
product that comes out of the product tank in a suitable tank.
1. Route the outlet hose of the product pump into the suitable
tank.
2. Turn the rotary switch of the product pump from
“EXTERNAL” to “100%” operating mode to pump the product
out of the product tank.
3. When the product tank is empty, turn the rotary switch of
the product pump back to “EXTERNAL”.
With systems produced before
10/2022
With systems produced after 10/2022
Annual and 3-yearly maintenance steps with Maintenance kit 1 and Maintenance kit 3
12

3. Fill the product tank with water:
1. Connect the outlet of the product pump to the drain.
2. Use a hose to connect the sampling valve of the softener
to the product tank and open the orange cover.
3. Open the sampling valve of the softener to start the filling
process.
4. Level: between the lower and upper level switches.
5. Close the sampling valve of the softener.
6. Remove the hose from the product tank
ðThe product tank is now filled with water. It is possible
that the product pump pumps water while filling the
product tank. When the product pump starts pumping the
water, close the softener sampling valve and remove the
hose.
4. Rinsing the brine suction side:
1. Remove both foot valves on the brine tank.
2. Insert both suction hoses into a 10-litre bucket filled with
water and rinse the suction hoses by hand.
3. Clean the filters of both foot valves.
4. Re-assemble the foot valves.
5. Replace both foot valves in the bucket.
6. Turn the rotary switch of the brine pump from
“EXTERNAL” to “100%” to rinse the brine out of the system
for a few minutes.
7. If required, bleed the brine pump.
5. Refill the bucket if you need to.
Capacity: Water required:
60 g/h 2 litres
120 g/h 3 litres
180 g/h 4 litres
240 g/h 5 litres
300 g/h 6 litres
6. 1. Select “External” on the brine pump.
2. If available, select “External” on the product pump.
3. Call up the Maintenance menu on your control.
Standard control: in the Maintenance menu, press the right
arrow key and select “Rinse”.
Siemens control: in the Maintenance menu, press “Rinse
cells for 10 minutes”.
ðThe cell is now rinsed with water for 10 minutes: no
product is produced and no brine is metered.
7. 1. Turn the rotary switch of the brine pump to STOP.
2. Turn the rotary switch of the product pump to STOP.
8. Switch off the external power supply as soon as cell rinsing
has ended.
ðThe cell(s), lines, sensors etc. are now filled with water
instead of with brine or product.
Annual and 3-yearly maintenance steps with Maintenance kit 1 and Maintenance kit 3
13

B1189
Fig. 4: Disconnecting the water supply
9. 1. Disconnect the water supply
2. Open and close the sampling valve of the water softener to
bring the system to atmospheric pressure.
3.3 Brine tank and brine pump
1. Check whether the brine tank is leaking. If so, eliminate the
leakage.
2. Check whether salt crusts have formed in the brine tank. You
will need to clean the brine tank if the brine tank is seriously
dirty or if a hard salt layer of ≧ 5 cm has formed on the base,
which is impermeable to water.
3. Remove all crusting and other contaminants.
4. Read the brine pump manual for the correct instructions for
maintenance of the brine pump.
3.4 Softener and water supply
INFORMATION: Read the operating instructions for the water soft‐
ener system, e.g. on the Ehrle manufacturer's website, model:
Clack WS1CI.
B1111
Fig. 5: Water filter
1. Replace the water filter.
2. Every 3 years: replace the water inlet valve and make sure
that the arrow on the valve points in the direction of flow.
Annual and 3-yearly maintenance steps with Maintenance kit 1 and Maintenance kit 3
14

3. If the water inlet valve is still the “white valve”, then replace it
with a BÜRKERT® valve.
Date of manufacture of the system Required updates
Prior to 01-2021 Update 12-2020 and update 10-2021
From 01-2021 to 11-2021 Update 10-2021
B1190
Fig. 6: Annually: clean the venturi pipe at the top.
4. Softener maintenance.
Annually: clean the venturi pipe at the top.
Every 3 years:
nReplace the piston spacer ring.
nReplace the O-rings.
nReplace the injector.
nReplace the injector filter mesh.
3.4.1 Maintenance on the softener: Softener head
1. Unlock the click system to remove the plastic cover of the
control unit (see Fig. 6, the component on the left of the
image):
2. Disconnect the plugs.
3. Press the retaining bracket up and remove the control unit
with display.
4. Use the special wrench to loosen the power end cap.
5. Remove the piston downwards out of the softener head.
6. Remove the piston spacer ring from the housing.
7. Use the special wrench to unscrew the injector cover to gain
access to the injector and the injector cap.
8. Use a screwdriver to dismantle the injector.
9. Use a screwdriver to dismantle the injector cap.
3.4.2 Maintenance on the softener: Brine suction
1. Remove the retaining clip.
2. Loosen the brine suction connector.
3. Dismantle the top-up lock from the brine suction connector.
4. Remove the retaining clip of the angle piece.
Annual and 3-yearly maintenance steps with Maintenance kit 1 and Maintenance kit 3
15

5. Loosen the angle piece.
6. Remove the retaining bracket of the other angle piece.
7. Use the special wrench to loosen the cap to gain access to
the flow meter.
8. During maintenance, replace the parts from the maintenance
pack. Make sure that all O-rings are slightly lubricated before
fitting them.
9. Replace the injector filter mesh and all O-rings.
10. Dismantle the softener head.
11. Replace the O-rings under the softener head.
12. Re-fit the softener head on the softener.
13. Re-install the injector and injector cap in the housing. Make
sure that you do not confuse the two components.
Resin in litres 5.6 l
(6x18 bottle)
12.5 l
(8x22 bottle)
18 l
(8x35 bottle)
40 l
(10x44 bottle)
75 l
(13x54 bottle)
Injector colour Black Blue Blue Blue Green
14. Use the special wrench to secure the injector cap.
15. Refit both angle pieces.
16. Refit the retaining clips of both angle pieces.
17. Re-install all new and cleaned/lubricated parts into the
housing.
18. Use the special wrench to secure the power end cap.
19. Guide the cables through the guides.
20. Fit the bracket of the control unit with display.
21. Securely lock the cables in the guides.
22. Insert both plugs back into the sockets.
23. Replace the plastic cover and make sure that the time and all
settings are correct.
3.5 Product tank
1. Check whether there is a leak and eliminate the leak.
2. Check the cover and the seal of the product tank for damage.
3. Every 3 years: replace the level switch of the product tank.
4. Replace the O-ring in the foot valve annually.
5. Annually: clean the filter in the foot valve.
Every 3 years: replace the complete foot valve.
6. Every 3 years: maintain the product pump in accordance with
the product pump maintenance manual.
7. Ensure that the product metering hose is at atmospheric
pressure.
8. You can remove the product metering pump from the supply
tank to work more easily on the liquid side.
9. Carry out maintenance as per the operating instructions for
the metering pump. Replace the diaphragm, valves etc.
Monitoring leak-tightness
Monitoring the cover
Replacing the level switch
Replacing O-rings
Cleaning the foot valve
Maintaining the product pump
Maintaining the optional product
metering pump
Annual and 3-yearly maintenance steps with Maintenance kit 1 and Maintenance kit 3
16

3.6 System cabinet
1. Rectify any leaks if any were found during the initial inspec‐
tion.
B1110
Fig. 7: Filter mat
2. Replace the filter mat
3. While replacing the filter mat, check that the fan rotates prop‐
erly by manually rotating the fan. Any stuttering, jolting etc. is
a sign that the fan will soon need to be replaced.
A3750
Fig. 8: Replacing the seals of the product lines
4. Replace all seals of the chlorine line. There are different
numbers of seals that need to be replaced on the different
versions. All seals downstream of the cells through which the
product flows must be replaced. For systems from year of
construction 10-2022 onwards refer to the figure:
Filter mat
Checking the fan
Replacing the seals of the product
lines
Annual and 3-yearly maintenance steps with Maintenance kit 1 and Maintenance kit 3
17

A3751
Fig. 9: Water injection valve
5. Every 3 years: replace the complete valve. Pay attention to
the direction arrow on the valve.
B1114
Fig. 10: Electric valve
6. Every 3 years: if the system still has an electric water regu‐
lating valve, replace this water regulating valve every 3 years
by simply disconnecting the hoses (clip system). Pay atten‐
tion to the direction of the flow meter:
The system requires an update if the water regulating valve
is no longer available: 10-2021. This update includes a soft‐
ware update.
Replacing the water injection valve
Replacing the electric valve
Annual and 3-yearly maintenance steps with Maintenance kit 1 and Maintenance kit 3
18

A3752
Fig. 11: Flow meter
7. Replace the flow meter. You can reuse the hose and pipe
couplings. Use PTFE thread sealing tape to tighten the cou‐
plings in the flow meter. Check the arrow of the flow meter
before assembly: the arrow must point in the direction of flow.
8. Replace the entire injector in the brine metering pipe.
9. Depending on the system and the revision status of the
system, the “injector in the water softening line” must also be
replaced.
10. Replace the internal parts of the injector.
Remove the first part to detach the internal parts.
Replace all internal parts of the injector.
11. Replace the internal parts of the injector, except for the
spring. You will need to reuse this spring.
Remove the first part to detach the internal parts.
Replace all internal parts of the injector, except for the spring.
You will need to reuse this spring.
ðNewer versions of the system are designed without these
injectors and do not require the injector.
B1193
Fig. 12: Cartridge flow meter
12. Only for systems with a flow meter connected downstream of
the cells.
Every 3 years: replace the cartridge.
We urgently recommend updating the system with at least
“Update 12-2020”. It is even better to update the system with
update 10-2021.
Note that a hardware update also requires a software update.
Replacing the flow meter
Annually: replace the injector for brine
metering
Every 3 years: replace the injector
upstream of the electrolysis cell
Systems without flow limiter
Systems with flow limiter
Replacing the cartridge flow meter
Annual and 3-yearly maintenance steps with Maintenance kit 1 and Maintenance kit 3
19

B1113
Fig. 13: Flow sensor
13. Open both threaded connectors of the flow sensor at the
outlet.
nPay attention to the flow sensor’s measuring cartridge, as
it can fall out.
nA direction arrow is located on the flow sensor. The direc‐
tion arrow must point upwards.
nFundamentally do not use any tools to tighten the 3-part
couplings or hexagonal head screws. It is enough to
tighten them hand-tight.
1 - Loosen the pipework between the cells and the flow
sensor (left part in the image Fig. 12) and remove this
pipework. The temperature sensor must remain in the
line.
2 - Replace all O-rings in the 3-part couplings.
3 - Remove the 2 hexagonal head screws from the sensor,
and replace the 2 flat seals above and below the flow
sensor, see figure Fig. 13.
CAUTION! Pay attention to the flow sensor’s measuring
cartridge, as it can fall out.
Replace the measuring cartridge in the sensor every 3
years.
4 - Replace the 2 hexagonal head screws of the sensor, but
do not yet fit the sensor.
14. Only for systems from 10-2022. Check whether the level
switch is working properly. If not, replace the level switch.
3.7 Control cabinet
1. Check them for corrosion and replace if necessary.
2. Check that all cables are properly connected and secure any
cables that are not properly secured.
3. If fitted: replace the filter mat of the ventilation system.
4. Check that the fan is rotating properly by manually rotating
the fan. Any jamming or snagging is a sign that the fan will
soon need to be replaced.
Checking the level switch in the col‐
lection pan
Checking the relays
Checking for loose cables
Filter mat
Checking the fan
Annual and 3-yearly maintenance steps with Maintenance kit 1 and Maintenance kit 3
20
