ProMinent OZONFILT OZMa 1 A User manual

Ozone Generation System
OZONFILT® Type OZMa 1 - 6 A/O
Operating instructions
P_PMA_OF_0010_SW3
EN
Original Operating Instructions (2006/42/EC)Part no. 986323 BA OF 035 03/21 EN
Please carefully read these operating instructions before use. · Do not discard.
The operator shall be liable for any damage caused by installation or operating errors.
The latest version of the operating instructions are available on our homepage.

Read the following supplementary information in its entirety!
Should you already know this information, you will benefit more
from referring to the operating instructions.
The following are highlighted separately in the document:
nEnumerated lists
Operating guidelines
Keys:
[UP] key
Software interface text: ‘Software interface text’ .
Menu sequences:
‘Main menu è Configure è ...’
Information
This provides important information relating to the
correct operation of the unit or is intended to make
your work easier.
Safety notes
Safety notes are identified by pictograms - see "Safety Chapter".
Note for the system operator
This document includes notes and quotes from German guidelines
relating to the system operator's scope of responsibility. This infor‐
mation does not discharge the operator from his responsibility as
an operator and is intended only to remind him or make him aware
of specific problem areas. This information does not lay claim to
being complete, nor applicable to every country and every type of
application, nor to being unconditionally up-to-date.
Supplementary information
Supplemental directives
2

Table of contents
1About the Product................................................................. 6
2 Identity code.......................................................................... 7
3 Safety.................................................................................... 9
3.1 Identification of safety notes......................................... 9
3.2 Warning symbols denoting different types of danger.... 9
3.3 Intended use................................................................. 9
3.4 Personnel qualification................................................ 10
3.5 General Safety Requirements.................................... 10
3.6 Safety equipment........................................................ 11
3.7 Notes for the System Operator................................... 11
4 Components of the System and Their Role........................ 13
4.1 Overview of OZONFILT® OZMa 1-6 A/O.................... 13
4.2 Description of the Ozone Generation System OZON‐
FILT® OZMa................................................................ 21
4.2.1 Air-conditioning System (air-conditioning unit,
optional)................................................................... 21
4.2.2 The OZONFILT® OZMa 1-6 A Drying Unit............... 21
4.2.3 The OZONFILT® OZMa 1-6 O Gas Supply............. 22
4.2.4 The OZONFILT® OZMa 1-6 O Gas System............ 22
4.2.5 The Ozone Generator.............................................. 23
4.2.6 The Ozone Gas Transfer Equipment....................... 23
4.2.7 Mixing Equipment (Accessory)................................ 23
4.2.8 Cooling Water System............................................. 24
4.2.9 Electrical System Components................................ 24
4.3 Safety equipment........................................................ 25
4.3.1 Flow Detector (Accessory)....................................... 25
4.3.2 Door Safety Switch.................................................. 25
4.3.3 Emergency Stop Switch in the Operating Room of
the Ozone Generation Systems (Accessory)........... 26
4.3.4 Main Switch on the System..................................... 26
4.3.5 Pressure Control Valves.......................................... 26
4.3.6 Non-return Valves.................................................... 26
4.3.7 Ozone Warning Device (Accessory)........................ 26
5Operation of the OZONFILT® OZMa................................... 28
5.1 Electric power............................................................. 28
5.2 Operating Gas Flow.................................................... 28
5.3 Cooling Water Flow.................................................... 29
5.4 Raw Water Flow......................................................... 29
5.5 Schematic diagram of water treatment using the
OZONFILT® OZMa 1-6 A (with air as the
operating gas)............................................................. 30
5.6 Schematic diagram of water treatment using the
OZONFILT® OZMa 1-6 O (with oxygen as the oper‐
ating gas).................................................................... 31
6 Scope of Delivery, Storage and Transport.......................... 32
6.1 Scope of Delivery........................................................ 32
6.2 Storage....................................................................... 32
6.3 Transport.................................................................... 33
7 Assembly and installation................................................... 34
7.1 Safety Guidelines and General Requirements........... 34
Table of contents
3

7.2 Requirements Relating to the System Installation
Place........................................................................... 34
7.3 Requirements Relating to System Components......... 36
7.3.1 Mixing Modules (Accessory).................................... 36
7.3.2 Ozone Removal from Filters and Reaction Sec‐
tion........................................................................... 37
7.4 Assembly.................................................................... 38
7.4.1 Raw Water Piping.................................................... 38
7.4.2 Oxygen Supply System........................................... 39
7.4.3 Ozone Gas System.................................................. 39
7.4.4 Cooling Water System............................................. 40
7.4.5 Air-conditioning System (air-conditioning unit,
optional)................................................................... 40
8 Electrical Installation........................................................... 41
8.1 Information Relating to Electrical Connections........... 41
8.2 System Electrical Inputs and Outputs......................... 41
9 Commissioning................................................................... 44
9.1 Adjusting the Initial Gas Pressure............................... 47
9.2 Adjusting the Process Gas Flow................................. 47
9.3 Adjusting the Cooling Water Flow Rate...................... 48
10 Operation............................................................................ 49
10.1 Touch panel.............................................................. 49
10.2 Operating Principles................................................. 49
10.3 Operation of the Control for System Calibration....... 50
10.3.1 Operating Keys and Control Information............... 51
10.3.2 Process Flowchart Displays................................... 52
10.4 Authorisation Scheme............................................... 53
10.4.1 OPERATOR User.................................................. 54
10.4.2 EXPERT User........................................................ 55
10.5 Operating Modes and Settings................................. 56
10.5.1 Operating modes................................................... 56
10.5.2 Ozone Sensor (only with Ozone Sensor).............. 62
10.5.3 Ozone Sensor Limit Values (only with Ozone
Sensor).................................................................. 64
10.5.4 Dewpoint sensor (option)....................................... 64
10.5.5 Control parameter.................................................. 65
10.5.6 Gas Flow mode (optional)...................................... 67
10.5.7 Protocol Output...................................................... 70
10.5.8 System................................................................... 71
10.5.9 Keyboard lock........................................................ 71
10.5.10 Info....................................................................... 72
10.5.11 Login - Logout...................................................... 72
10.6 Functional Process................................................... 72
10.7 Important System Statuses....................................... 72
10.7.1 "Start with Ozone Generation" Operating Status... 72
10.7.2 "Start without Ozone Generation" Operating
Status..................................................................... 73
10.7.3 "Fault" Operating Status........................................ 73
10.7.4 "Process Water Flow Rate Too Low" Operating
Status..................................................................... 73
10.7.5 "Stop" Operating Status......................................... 74
10.7.6 "Pause" Operating Status...................................... 74
Table of contents
4

10.7.7 Behaviour Upon Switching on Power.................... 74
10.8 Display...................................................................... 75
10.8.1 Complete System.................................................. 75
10.9 Display Values on the Touch Panel.......................... 75
10.9.1 Control Variable in "Internal" Operating Mode....... 75
10.9.2 Setpoint in "External" Operating Mode (Option).... 75
10.9.3 Ozone Output........................................................ 75
10.9.4 Gas flow rate.......................................................... 75
10.9.5 Ozone generator pressure..................................... 76
10.9.6 Cooling water......................................................... 76
10.9.7 Primary current...................................................... 76
10.9.8 Primary voltage...................................................... 76
10.9.9 Status Page........................................................... 76
10.9.10 Control range....................................................... 76
10.9.11 Ozone reduction in%........................................... 77
10.9.12 "Internal" / "External" Operating Mode................. 77
10.9.13 0/4-20 mA............................................................ 77
10.9.14 Language............................................................. 77
11 Maintenance....................................................................... 78
11.1 Safety Guidelines for Maintenance and Repair........ 78
11.2 Routine Inspection.................................................... 78
11.3 Regular Maintenance................................................ 79
12 Troubleshooting.................................................................. 82
13 Technical Data.................................................................... 87
13.1 Complete System .................................................... 87
13.2 OZMa Electrical Inputs and Outputs......................... 93
13.3 Supplementary information for modified designs...... 96
14 Accessories......................................................................... 97
14.1 Classification............................................................. 97
14.2 Description................................................................ 97
15 Dimensional Drawings...................................................... 101
16 Operating Report.............................................................. 107
17 Wiring Diagram................................................................. 108
18 EC Declaration of Conformity........................................... 109
19 Information on the legally compliant use of ozone............ 110
20 Index................................................................................. 111
Table of contents
5

1 About the Product
OZONFILT® OZMa ozone generator systems are designed as
pressurised systems, in which an operating gas - either air (OZMa
1-6 A) or oxygen (OZMa 1-6 O) - is fed into the ozone generator
under pressure.
The ozone is generated using medium-frequency high voltage and
is primary current controlled. The introduction of the electronic
power unit, developed in-house by ProMinent, provides extensive
protection for the electrical components (high voltage transformer
and power stage) and also permits the correct digital display of the
ozone output in "grams/hour".
As a result, any required ozone output between 3 and 100 % of the
nominal capacity can be set reproducibly, and largely independ‐
ently of voltage and pressure fluctuations.
The use of an integrated pressure swing dryer and a dielectric with
optimum thermal conductivity makes the system extremely com‐
pact.
The novel design of the generator ensures outstanding cooling per‐
formance with low cooling water consumption and removes the
heat produced quickly before the ozone produced can decompose
due to excessive heat. Operation under pressure means that the
ozone generated can be introduced directly into water systems
with back pressures of up to 2 bar.
Additional booster pumps and injectors can therefore be dispensed
with in many applications.
A DULCOTEST® OZE ozone sensor can be connected directly to
the PID control (optional) integrated in the controller. This ensures
that the systems are especially useful for measured value
dependent and measured value controlled operation.
The ozone concentration is maintained constant using the "control
valve" option, independent from the required ozone output insofar
as this is possible. Consequently the solubility of the ozone, which
is essentially dependent on the ozone concentration, remains con‐
stant even with low setpoints. Moreover, the gas quantity injected
into the raw water is reduced and consequently the system's gas
consumption also.
The integrated data logger (option) writes data to an SD card. The
screen recorder can be used to visualise the measured values
(optional).
About the Product
6

2 Identity code
Ozone generation system type OZONFILT® OZMa
OZMa Type
*
Air Oxygen * of the ozone generator
01 70 g/h 105 g/h
02 105 g/h 150 g/h
03 140 g/h 210 g/h
04 210 g/h 320 g/h
05 280 g/h 420 g/h
06 420 g/h 630 g/h
Operating gas
A Operating gas - air
O Operating gas - oxygen
Design
P ProMaqua
S Special version
C ProMaqua with air-conditioning
Mechanical design
0 Standard (packaging for transport by HGV)
1 Standard (packaging for sea/air freight)
2 In stainless steel cabinet (packaging for transport by commercial vehicle)
3 In stainless steel cabinet (packaging for sea/air freight)
M Modified *order-related design. Unit properties, see order documentation
Operating voltage
A Single phase 230 V ± 10 %, 50/60 Hz (only types 01-03)
S Single phase 230/400 V ± 10 %, 50/60 Hz (only types 04-06)
Gas treatment
0 Gas treatment not integrated (operating gas - oxygen design)
1 Gas treatment integrated without filter package (operating gas - air
design)
2 Gas treatment integrated with filter package (operating gas - air
design)
3 Gas treatment not integrated (operating gas - oxygen design),
includes gas control valve
4 Gas treatment integrated, without filter package (operating gas - air
design), includes gas control valve
5 Gas treatment integrated, with filter package (operating gas - air
design), includes gas control valve
Pre-set language
DE German
EN English
Identity code
7

Ozone generation system type OZONFILT® OZMa
FR French
IT Italian
ES Spanish
Control
0 Basic version with digital input to control two adjustable
power stages
1 External power control via 0/4-20 mA input, data logger
2 External power control, ozone measurement and visuali‐
sation via screen recorder, 2 freely configurable 0/40-20
mA inputs, 1 freely configurable 0/4-20 mA output
3 As 2 with additionally integrated PID controller for control
of the ozone concentration independent of measured
value and flow
Communication interfaces
0 None
4PROFIBUS® DP interface
Additional options
0 None
1 Dewpoint sensor
Certifications
01 CE mark
Hardware
0 Standard
Software
0 Standard
Tab. 1: Explanation of the identity code:
Mechanical design: With designs 0 and 1, the system is installed in a standard control
cabinet made of powder-coated steel.
Gas treatment: Without filter package for oil-free generated or de-oiled com‐
pressed air.
With filter package for compressed air with residual oil content.
Identity code
8

3 Safety
Please read this chapter carefully before operating the system and
keep this instruction manual easily accessible in the vicinity of the
system.
3.1 Identification of safety notes
The following signal words are used in these operating instructions
to denote different levels of danger:
Signal word Meaning
DANGER! This combination of symbol and
signal word indicates an imme‐
diate dangerous situation that
will result in death or serious
injury if it is not avoided.
WARNING! This combination of symbol and
signal word indicates a possible
dangerous situation that can
result in death or serious injury
if it is not avoided.
CAUTION! This combination of symbol and
signal word indicates a possible
dangerous situation that can
result in minor injury if it is not
avoided.
3.2 Warning symbols denoting different types of danger
The following warning symbols are used in these operating instruc‐
tions to denote different types of danger:
Warning signs Type of danger
Warning – high-voltage.
Warning – toxic substances.
Warning – danger zone.
3.3 Intended use
nThe OZONFILT® OZMa is intended solely to generate and
meter an ozoniferous gas mixture from compressed air or
oxygen.
nAll other uses or a modification of the system are only per‐
mitted with the written authorisation of ProMinent GmbH, Hei‐
delberg.
nThe system may not be operated in conditions other than those
described in this document.
Identification of safety notes
Warning symbols denoting different
types of danger
Safety
9

nThe system is not intended for operation outside.
nThe system is not intended for portable operation.
nThe correct and proper operation of the system cannot be
guaranteed if non-genuine parts or third party accessories are
used.
nThe OZMa ozone generation system may only be operated by
qualified personnel (refer to the following table).
nObserve the information contained in the operating instructions
at the different phases of the device's service life.
nPlease observe the relevant national regulations and guide‐
lines throughout every phase of the system's service life.
3.4 Personnel qualification
Action Qualification
Assembly / installation Service technicians
Initial commissioning Service technicians
Start up Technical experts
Operation Instructed personnel
Maintenance / Repair Service technicians
Decommissioning Service technicians
Troubleshooting by operator Instructed personnel
Troubleshooting by experts Service technicians
Technical experts
A technical expert is deemed to be a person who is able to assess
the tasks assigned to him and recognize possible hazards based
on his/her technical training and experience, as well as knowledge
of applicable regulations.
Instructed person
An instructed person is deemed to be a person who has been
instructed and, if required, trained in the tasks assigned to him/her
and possible dangers that could result from improper behaviour, as
well as having been instructed in the required protective equipment
and protective measures.
Service technicians
The Service department refers to service technicians, who have
received proven training and have been authorised by ProMinent®
to work on the system.
3.5 General Safety Requirements
nTo ensure maximum safety, all persons, who are involved in
working with the ozone generation system, must be familiar
with the safety regulations and operation of the ozone genera‐
tion system.
nThe ozone generation system must be used in compliance with
all relevant regulations. The use of the system for a purpose
other than the purpose intended by the manufacturer will incur
unforeseeable risks.
Explanation of the table
Safety
10

nAll guarantee and liability claims on the part of the system
operator will not be admitted following interference by unau‐
thorised personnel.
nPlease observe all locally applicable
–laws
– health and safety regulations
– environmental regulations
nImmediately report any malfunctions or risks, which you, as the
user, notice to the operator of the system or to your supervi‐
sors.
nAs a matter of principle no protective or safety equipment may
be removed while the system is in operation. Never attempt to
bypass the safety equipment.
nIf protective or safety equipment has to be removed to set up
or service the plant or to carry out repairs, switch off the
system beforehand and ensure that it cannot be reconnected.
Prior to switching the system on, refit the safety and protective
equipment and ensure that it is complete, securely fitted and
that it can perform its task properly.
nWork on technical equipment (such as work on the pneumatic,
hydraulic or electrical equipment) may only be done by appro‐
priately qualified technical personnel.
nAll safety and warning signs on the plant must be visible at all
times.
3.6 Safety equipment
The safety equipment is described in the chapter "Assembly and
Installation".
Further safety equipment is described in the chapter "Components
of the System and Their Role" - "Safety Equipment".
3.7 Notes for the System Operator
Prior to commissioning the system, the operator is obliged to:
nObtain current safety-related information on oxygen (if rele‐
vant), ozone and ozoniferous water.
The operator should create the legal framework for safe operation
of the system, based on the information provided in the data
sheets concerning health and safety, water and environmental pro‐
tection and taking into consideration the actual operating environ‐
ment on site.
The operator is also obliged to produce operating instructions
(including information on danger prevention and an alarm plan) on
"Handling Ozone" and (only with system type "O") "Handling
Oxygen".
The OZONFILT® OZMa 1-6 O ozone generation systems generate
ozone from pure oxygen with a concentration of over 90 volume
percent. For this reason the guidelines relating to the handling of
oxygen should also be noted.
In addition to the operating instructions, the following German reg‐
ulations issued by the Federation of Commercial Professional
Associations (HVGB) and the Professional Association of the
Chemical Industry (BG Chemie) should also be included as infor‐
mation:
Safety
11

a) - ZH 1/474 "Guidelines on the Use of Ozone in Water Treat‐
ment"
b) - ZH 1/262 "Bulletin 052 Ozone"
c) - Accident Prevention and Insurance Association regulation
BGV UVV Oxygen
d) - Accident prevention regulation "Occupational Health and
Safety Labelling" (BGV A 8)
Safety
12

4 Components of the System and Their Role
4.1 Overview of OZONFILT® OZMa 1-6 A/O
A
B
470
5
6
78910 11 12 13
14
16
17
18
19
20
21
22
1
2
4
23
24
25
26
27
47
23
54
53
P_PMA_OF_0012_SW_2
Fig. 1: Ozone generation system OZONFILT® OZMa 1-3 A - without air-conditioning and without door
Components of the System and Their Role
13

P_PM_OF_0026_SW_2
5
678910 11 12 13
14
16
17
18
19
20
21
22
1
2
3
4
25
27
47
23
54
53
Fig. 2: Ozone generation system OZONFILT® OZMa 1-6 O - without air-conditioning and without door
No. Component Function
1 Pressure regulating valve with pres‐
sure sensor
Unit for adjusting and displaying the priming pressure of
the system.
2 Ozone generator A portion of the oxygen in the operating gas is converted
into ozone in the water-cooled ozone generator.
3 Ozone outlet non-return valve The non-return valve prevents the backflow of process
water into the ozone generator (only with OZMa 4-6).
4 Adjustable operating gas throttle
valve
The flow of operating gas for ozone generation can be
adjusted using the throttle valve.
5 Ozone outlet diaphragm valve The diaphragm valve protects each ozone generator
against the backflow of process water
6 Operating pressure sensor The pressure sensor displays and monitors the oper‐
ating pressure in the ozone generator.
7 Ozone outlet -
Components of the System and Their Role
14

No. Component Function
8 Ozone generator pressure relief
valve
The pressure relief valve limits the operating pressure in
the ozone generator.
9 Flow meter with minimum contact Used to display and monitor the cooling water flow rate
through the ozone generator.
10 Cooling water outlet -
11 Gas flow meter The gas flow meter provides a measured value and
monitors the operating gas flow rate for ozone genera‐
tion.
12 Control (PLC Programmable Logic
Controller)
The control (PLC Programmable Logic Controller) is
used to control and monitor the entire system.
13 Door switch The door switch stops the generation of ozone as soon
as the control cabinet door is opened.
14 Communication circuit board The communication circuit board provides the link from
the internal and external electrical components to the
electronic control.
16 Internal power supply 24 Volt -
17 Fan control The fan control is used to actuate the control cabinet fan
according to the temperature.
18 Control cabinet temperature monitor The temperature monitor is used to monitor the tempera‐
ture in the control cabinet.
19 Main switch The main switch connects or disconnects the system
from the mains voltage or from the mains/power supply.
20 Power unit for HV transformer Supplies the primary side of the high-voltage transformer
with electrical signals for ozone generation.
21 HV transformer (High-voltage trans‐
former)
The high-voltage transformer converts the electrical sig‐
nals supplied by the power unit into the high-voltage sig‐
nals required for ozone generation.
22 Choke coils The choke coils are used to adjust the profile of the elec‐
trical signals on the primary side of the high-voltage
transformer.
23 Solenoid valve block - drying unit Used to control the gas flows in the system's drying unit,
if one is integrated.
24 Cooling water inlet angle valve The cooling water flow rate through the ozone generator
can be adjusted using the angle valve.
25 Cooling water inlet -
26 Storage tank for drying unit The storage tanks accommodate the molecular sieves
for the drying unit.
27 Pressure regulating valve The pressure for the drying unit of the system can be
adjusted using the pressure regulating valve.
28 Operating gas inlet -
29 Touch panel (display and operating
unit)
The touch panel (display and operating unit) acts as an
interface between the system and the operating per‐
sonnel.
30 Water mixed with ozone -
31 Mixing section (accessory) Mixes the ozoniferous gas with the process water.
32 Point of injection non-return valve Should be fitted vertically pointing downwards.
Components of the System and Their Role
15

No. Component Function
33 Point of injection non-return valve The non-return valve prevents the backflow of process
water into the pipework at the ozone outlet of the
system.
34 Ozone entry -
35 Raw water -
36 Bypass opening for gas flow meter The bypass opening adjusts the gas flow through the
gas flow meter
37 Opening for regeneration air The opening adjusts the gas flow for regeneration on
systems with an integral drying unit.
38 Drying unit non-return valves The non-return valves prevent the backflow of operating
gas into the regeneration gas duct.
39 Solenoid valve block - drying unit -
40 Cooling water inlet solenoid valve The solenoid valve on the cooling water inlet stops the
flow of cooling water when the system is idle.
41 Compressor unit (accessory) The compressor unit provides the compressed ambient
air required for the drying unit.
42 Cooling water outlet temperature
gauge
The temperature gauge is used to display and monitor
the temperature of the cooling water at the system's
cooling water outlet.
43 Drying unit operating pressure sensor The pressure sensor is used to display and monitor the
pressure at the outlet of the drying unit as well as to con‐
trol it.
44 Silencer for regeneration gas The silencer provides controlled pressure relief for the
drying unit storage tanks.
45 Filter unit (optional accessory) The filter unit filters particles and separates oil and water
from the compressed ambient air.
47 Ozone outlet non-return valve -
51 Regeneration air outlet (Only OZMa 1-6 A)
53 Ozone generation safety cut-out Switches off ozone generation when the power con‐
sumption is too high.
54 Control safety cut-out Switches off all control components and low voltage con‐
sumers in the system when the power consumption is
too high.
55 Oxygen inlet solenoid valve -
Components of the System and Their Role
16

19
P_PMA_OF_0013_SW
27
1
25
51 (44)
a) b)
Fig. 3: Ozone generation system OZMa - without air-conditioning; top view of the right and left side
1 Pressure regulating valve with pressure sensor
19 Main switch
25 Cooling water inlet
27 Pressure regulating valve
44 Silencer for regeneration gas (only OZMa 1-6 A)
51 Regeneration air output (only OZMa 1-6 A)
Components of the System and Their Role
17

29
10
7
28
25
35 34 31 30
33
32
P_PMA_OF_0015_SW
Fig. 4: Ozone generation system OZMa with mixing equipment - without air-conditioning
7 Ozone outlet
10 Cooling water outlet
25 Cooling water inlet
28 Operating gas inlet
29 Display and operating unit
30 Water mixed with ozone
31 Mixing section (accessory)
32 Should be fitted vertically pointing downwards.
34 Ozone entry
35 Raw water
40 Cooling water inlet solenoid valve
Components of the System and Their Role
18

5: Membranventil mit Pilotventil Ozonausgang
T
PI
PI
PI
FI
PI
5
2
9
42
52
40
41
1
39
36
11
4
26
37
38
6
8
38
26
45
43
44
33
51
27
50
725
10
35 30
31
52
56
2
56
2
56
56 56 56
57
24
56 56 56
58
2424
P_PMA_OF_0030_SW_2
Fig. 5: Schematic pneumatic and hydraulic flow in the ozone gen‐
eration systems OZMa 1-6 A with drying unit for use with air as an
operating gas
1 Pressure regulating valve with pressure sensor
2 Ozone generator #
3 Ozone outlet non-return valve
4 Adjustable operating gas throttle valve
5 Diaphragm valve with ozone outlet pilot valve
6 Operating pressure sensor on ozone generator
7 Ozone outlet
8 Ozone generator pressure relief valve
9 Flow meter with minimum contact
10 Cooling water outlet
11 Gas flow meter
24 Cooling water inlet angle valve
25 Cooling water inlet
26 Storage tank for drying unit
27 Pressure regulating valve
30 Raw water outlet
31 Mixing section (accessory)
33 Point of injection non-return valve
35 Raw water inlet
36 Bypass opening for gas flow meter
37 Opening for regeneration air
38 Drying unit non-return valve
39 Solenoid valve block - drying unit
40 Cooling water inlet solenoid valve
41 Compressor unit (accessory)
42 Cooling water outlet temperature gauge
43 Drying unit operating pressure sensor
44 Silencer for regeneration gas
45 Filter unit (optional accessory)
50 Compressed air inlet
51 Regeneration air outlet
52 Raw water pressure sensor (accessory)
56 Stopcock (only with OZMa 4-6)
57 Ozone collector (only with OZMa 4-6)
58 Control valve (optional)
# 2 Ozone generator with OZMa 4 A and OZMa 5 A
3 Ozone generator with OZMa 6 A
Components of the System and Their Role
19

5
3
2
9
42
52
40
T
36
11
4
38
6
8
PI
FI
33
PI
725
10
35 30
31
52
56
2
56
2
56
56 56 56
57
56 56 56
58
1
PI
27
55
O2
242424
P_PMA_OF_0031_SW_2
Fig. 6: Schematic pneumatic and hydraulic flow in the ozone gen‐
eration systems OZMa 1-6 O with drying unit for use with oxygen
as an operating gas
1 Pressure regulating valve with pressure sensor
2 Ozone generator #
3 Ozone outlet non-return valve
4 Adjustable operating gas throttle valve
5 Ozone outlet solenoid valve
6 Operating pressure sensor on ozone generator
7 Ozone outlet
8 Ozone generator pressure relief valve
9 Flow meter with minimum contact
10 Cooling water outlet
11 Gas flow meter
24 Cooling water inlet angle valve
25 Cooling water inlet
27 Pressure regulating valve
30 Raw water outlet
31 Mixing section (accessory)
33 Point of injection non-return valve
35 Raw water inlet
36 Bypass opening for gas flow meter
40 Cooling water inlet solenoid valve
42 Cooling water outlet temperature gauge
50 Compressed air inlet
52 Raw water pressure sensor (accessory)
55 Oxygen inlet solenoid valve
56 Stopcock (only with OZMa 4-6)
57 Ozone collector (only with OZMa 4-6)
58 Control valve (optional)
# 2 Ozone generator with OZMa 4 O and OZMa 5 O
3 Ozone generator with OZMa 6 O
Components of the System and Their Role
20
