ProMinent Beta b BT4b Series User manual

Solenoid Metering Pump
Beta b BT4b and BT5b
Operating instructions
Target group: Technical personnel
EN
Original operating instructions (2006/42/EC)Part no. 986356 Version: BA BE 036 04/22 EN
Please carefully read these operating instructions before use. · Do not discard.
The operator shall be liable for any damage caused by installation or operating errors.
The latest version of the operating instructions are available on our homepage.

Read the following supplementary information in its entirety! You
will benefit more from the operating instructions should you already
know this information.
The following are highlighted separately in the document:
nEnumerated lists
Instructions
ðOutcome of the instructions
Ä ‘State the identity code and serial number’ on page 2 : Links to
points in this chapter
- refer to ... : References to points in this document or another
document
[Keys]
Information
This provides important information relating to the
correct operation of the unit or is intended to make
your work easier.
Safety information
Safety information is identified by pictograms - see "Safety”
chapter.
These operating instructions conform to current EU regulations
applicable at the time of publication.
Please state the identity code and serial number, which you can
find on the nameplate, when you contact us or order spare parts.
This enables us to clearly identify the unit type and material ver‐
sions.
In order to make it easier to read, this document uses the male
form in grammatical structures but with an implied neutral sense. It
is aimed equally at both men and women. We kindly ask female
readers for their understanding in this simplification of the text.
Supplementary information
Fig. 1: Please read!
Validity
State the identity code and serial
number
General non-discriminatory approach
Supplemental directives
2

Table of contents
1Identity code.......................................................................... 5
2 About this pump.................................................................... 8
3 Safety chapter....................................................................... 9
4 Storage, Transport and Unpacking..................................... 14
5 Overview of Equipment and Control Elements................... 16
5.1 Overview of Equipment............................................... 16
5.2 Control Elements........................................................ 17
5.2.1 Pulse control switch................................................. 17
5.2.2 Stroke Length Adjustment Button............................ 17
5.2.3 Multifunctional Switch.............................................. 17
5.2.4 Functional and Fault Indicators................................ 18
5.2.5 "External control" terminal....................................... 18
5.2.6 "Level switch" terminal............................................. 18
6 Functional description......................................................... 19
6.1 Liquid End................................................................... 19
6.2 Drive Unit.................................................................... 19
6.3 Capacity...................................................................... 19
6.4 Self-Bleeding.............................................................. 19
6.5 Operating modes ....................................................... 19
6.6 Functions.................................................................... 20
6.7 Relay........................................................................... 20
6.8 Hierarchy of Operating Modes, Functions and Fault
Statuses...................................................................... 20
7 Assembly............................................................................ 21
8 Installation, hydraulic.......................................................... 22
8.1 Installing hose lines.................................................... 23
8.1.1 Installation with metering pumps without
degassing................................................................ 23
8.1.2 Installation with metering pumps with degassing..... 25
8.1.3 Installation with metering pumps with self-
degassing (SEK type).............................................. 26
8.1.4 Basic installation notes............................................ 27
9 Electrical installation........................................................... 29
9.1 Supply voltage connector........................................... 30
9.1.1 Supply voltage......................................................... 31
9.2 Supply voltage connector - low voltage...................... 31
9.3 Description of the Terminals....................................... 32
9.3.1 "External control" terminal....................................... 32
9.3.2 "Level switch" terminal............................................. 34
9.4 Relay........................................................................... 35
9.4.1 Relay functions........................................................ 35
9.4.2 “Fault indicating relay” output (identity code 1 + 3).. 36
9.4.3 “Fault indicating relay + Pacing relay” and/or
“Warning relay”, “Cut-off relay” output (identity code
4 + 5, A + B)............................................................. 36
10 Start up............................................................................... 38
11 Operation............................................................................ 41
11.1 Manual operation...................................................... 41
11.1.1 Capacity................................................................. 41
Table of contents
3

11.1.2 Functions............................................................... 41
11.1.3 External contact..................................................... 42
11.1.4 External analogue.................................................. 43
11.2 Remote operation..................................................... 43
12 Maintenance....................................................................... 44
13 Repair................................................................................. 46
13.1 Cleaning valves........................................................ 47
13.2 Replacing the diaphragm.......................................... 48
13.2.1 Replacing the vPTFE diaphragm........................... 50
14 Troubleshooting.................................................................. 51
14.1 Faults without error message................................... 51
14.2 Fault messages........................................................ 52
14.3 Warning messages................................................... 52
14.4 All other errors.......................................................... 52
15 Decommissioning and disposal.......................................... 53
15.1 Decommissioning..................................................... 53
15.2 Disposal.................................................................... 54
16 Technical data..................................................................... 55
16.1 Performance data..................................................... 55
16.1.1 Performance data with vPTFE diaphragm............. 57
16.2 Accuracy................................................................... 58
16.2.1 Standard Liquid End.............................................. 58
16.2.2 Self-Bleeding Liquid End....................................... 58
16.3 Viscosity.................................................................... 58
16.4 Material specifications.............................................. 59
16.5 Electrical data........................................................... 59
16.6 Temperatures........................................................... 61
16.7 Climate...................................................................... 62
16.8 Altitude of site .......................................................... 62
16.9 Degree of protection and safety requirements.......... 62
16.9.1 Degree of protection.............................................. 62
16.9.2 Safety requirements............................................... 62
16.9.3 Degree of pollution................................................. 62
16.10 Compatibility........................................................... 62
16.11 Sound pressure level.............................................. 63
16.12 Shipping weight...................................................... 63
17 Dimensional drawings......................................................... 64
18 Diagrams for setting the capacity........................................ 70
19 Exploded drawings and ordering information...................... 76
19.1 Exploded drawings................................................... 76
19.2 Ordering information............................................... 100
20 Declaration of Conformity for Machinery, Mains Voltage.. 101
21 Declaration of Conformity for Machinery, Low Voltage..... 102
22 UK Declaration of Conformity........................................... 103
23 UK Declaration of Conformity........................................... 104
24 Approvals.......................................................................... 105
25 Index................................................................................. 106
Table of contents
4

1 Identity code
Product identification
This identity code serves to identify the product.
Use the identity code from the Product Catalogue
for orders.
Product range Beta b
BT4
b
Type Output
bar l/h
1000 10 0.74
1601 16 1.10
1602 16 2.20
1604 16 3.60
0708 7 7.10
0413 4 12.30
0220 2 19.00
BT5
b
2504 25 2.90
1008 10 6.80
0713 7 11.00
0420 4 17.10
0232 2 32.00
Material of dosing head/valves
PP Polypropylene/PVDF. With the self-degassing design (SEK): Polypropylene/polypropy‐
lene
NP Clear acrylic/PVDF. With the self-degassing design (SEK): Clear acrylic/PVC
PV PVDF/PVDF
TT PTFE + 25% carbon /PTFE + 25%
SS Stainless steel 1.4401/1.4571
Material of seals/diaphragm
T PTFE/PTFE-coated
E EPDM/PTFE-coated, only with PP and NP self-degassing (SEK)
B FPM-B/PTFE-coated, only with PP and NP self-degassing (SEK)
S Diaphragm with additional FPM coating for media containing silicate
F FDA-compliant
Dosing head version
0 without degassing, without valve spring only for NP, TT, SS and type 0232
Identity code
5

Product range Beta b
1 without degassing, with valve spring only for NP, TT, SS and type 0232
2 with degassing, without valve spring only for PP, PV, NP, not for type 0232
3 with degassing, with valve spring only for PP, PV, NP, not for type 0232
4 design for higher-viscosity media only for PVT, type 1604, 2504, 0708, 1008,
0413, 0713, 0220, 0420
7 self-degassing (SER) only for PV/NP, not for types 1000, 1601 and 0232
9 self-degassing (SEK) only for PP/NP, not for types 1000 and 0232
Hydraulic connector
0 standard connector in line with technical data
5 connector for 12/6 hose, discharge side only
9 connector for 10/4 hose, discharge side only
Design
0 Standard
Logo
0 with ProMinent logo
Electrical connection
U 100 ... 230 V ± 10%, 50/60 Hz*
Cable and plug
A 2 m European
B 2 m Swiss
C 2 m Australian
D 2 m US American
F 2 m Japanese
G 2 m Brazilian
I 2 m Israeli
V 5 m US American 115 V
W 5 m US American 115 V
1 2 m open end
Relay
0 no relay
1 fault indicating relay NC, (change-over relay)
3 fault indicating relay NO, (change-over relay)
4 as 1 + pacing relay, (1x of each)
5 as 3 + pacing relay, (1x of each)
Accessories
0 no accessories
1 with foot and injection valve, 2 m PVC suc‐
tion line, 5 m PE dosing line
Identity code
6

Product range Beta b
Control type
0 no lock
1 with lock: manual operation locked
when external cable is plugged in
H external without PCS stop
Control version
0 Standard
A external analogue 0...20 mA /
4...20 mA
Options
00 no options
Identity code
7

2 About this pump
This solenoid metering pump Beta b is equipped with all adjust‐
ment and activation functions for modern water treatment and the
dosing of chemicals. It has pulse step-up and pulse step-down
compared with the preceding model. This enables it to adapt more
precisely to external signal generators. The result is the simpler
and more precise adjustment of chemical consumption to the
actual need. It also has a 10 percent increase in efficiency and
energy efficiency over the preceding model. The Beta b can be
simply adjusted during operation.
Properties of the device
About this pump
8

3 Safety chapter
The following signal words are used in these operating instructions
to denote different severities of danger:
Signal word Meaning
WARNING Denotes a possibly dangerous
situation. If this is disregarded,
you are in a life-threatening sit‐
uation and this can result in
serious injuries.
CAUTION Denotes a possibly dangerous
situation. If this is disregarded,
it could result in slight or minor
injuries or material damage.
The following warning signs are used in these operating instruc‐
tions to denote different types of danger:
Warning signs Type of danger
Warning – automatic start-up.
Warning – high-voltage.
Warning – danger zone.
NOTICE!
Wear caused by "Pump ON/OFF" using the mains
connection
Frequent switching of the pump on and off (>2
times each day) using the supply voltage leads to
increased wear in the pump. The pump is not tech‐
nically designed for this.
If necessary, use the "Pause" function to switch the
pump to standby mode. Do not switch the pump on
and off using the supply voltage to spare a pause
input.
nOnly use the pump to meter liquid feed chemicals.
nOnly use the pump once it has been correctly installed and
started up in accordance with the technical data and specifica‐
tions contained in the operating instructions.
nObserve the general limitations with regard to viscosity limits,
chemical resistance and density - see also the ProMinent
Resistance List in the product catalogue or at www.promi‐
nent.com.
nAll other uses or modifications are prohibited.
nThe pump is not designed to meter gaseous media and solids.
nThe pump is not intended to meter flammable media without
appropriate protective measures having been put in place.
Identification of safety notes
Warning signs denoting different
types of danger
Intended use
Safety chapter
9

nThe pump is not designed to meter explosive media.
nThe pump is not intended for operation in areas at risk from
explosion.
nThe pump is not designed for use outdoors, without appro‐
priate protective measures.
nOnly allow the pump to be operated by trained and authorised
personnel, see the following "Qualifications" table.
nYou have a duty to observe the information contained in the
operating instructions during the different phases of the unit's
service life.
WARNING!
Warning about personal and material damage
The pump can start to pump, as soon as it is con‐
nected to the mains voltage.
– Install an emergency cut-off switch in the pump
power supply line or integrate the pump in the
emergency cut-off management of the system.
WARNING!
Danger of electric shock
Supply voltage may be present inside the pump
housing.
– Safely and quickly disconnect the pump from
the mains/power supply if the pump housing
has been damaged.
Only return the pump to operation after an
authorised repair.
WARNING!
Fire danger
When pumping inflammable media the operator
must take suitable safety precautions.
WARNING!
Danger from hazardous substances!
Possible consequence: Fatal or very serious inju‐
ries.
Please ensure when handling hazardous sub‐
stances that you have read the latest safety data
sheets provided by the manufacture of the haz‐
ardous substance. The actions required are
described in the safety data sheet. Check the
safety data sheet regularly and replace, if neces‐
sary, as the hazard potential of a substance can be
re-evaluated at any time based on new findings.
The system operator is responsible for ensuring
that these safety data sheets are available and that
they are kept up to date, as well as for producing
an associated hazard assessment for the worksta‐
tions affected.
Safety information
Safety chapter
10

CAUTION!
Warning of feed chemical spraying around
Feed chemical may spray out of the hydraulic com‐
ponents if they are tampered with or opened due to
pressure in the liquid end and adjacent parts of the
system.
– Disconnect the pump from the mains power
supply and ensure that it cannot be switched
on again by unauthorised persons.
–Ensure that the system is at atmospheric pres‐
sure before commencing any work on hydraulic
parts of the system.
CAUTION!
Warning of feed chemical spraying around
The metering pump may generate a multiple of its
nominal pressure. Hydraulic parts can rupture if a
pressure line is blocked.
–Correctly install a relief valve in the pressure
line downstream of the metering pump.
CAUTION!
Warning of feed chemical spraying around
An unsuitable feed chemical can damage the parts
of the pump that come into contact with the chem‐
ical.
– Take into account the resistance of the wetted
materials and the ProMinent Resistance List
when selecting the feed chemical - see the
ProMinent Product Catalogue or visit ProMi‐
nent.
CAUTION!
Danger of injury to personnel and material damage
The use of untested third party components can
result in injury to personnel and material damage.
– Only fit parts to metering pumps that have
been tested and recommended by ProMinent.
CAUTION!
Danger from incorrectly operated or inadequately
maintained pumps
Danger can arise from a poorly accessible pump
due to incorrect operation and poor maintenance.
– Ensure that the pump is accessible at all times.
– Adhere to the maintenance intervals.
Safety chapter
11

CAUTION!
Danger from incorrect metering
Should a different liquid end size be fitted, this will
change the metering behaviour of the pump.
– Have the pump reprogrammed in the works.
nDosing head
nHousing
nHood (houses the control elements)
The dosing head may only be removed by the customer in accord‐
ance with the "Repair" chapter.
The housing and the hood may only be removed by ProMinent
customer service department.
In an emergency, either pull out the mains plug, turn the multifunc‐
tional switch to "Stop" or press the Emergency Stop switch
installed on the customer's side or disconnect the pump from the
mains power supply in line with the emergency shut-down man‐
agement guidelines for your system!
If feed chemical escapes, additionally ensure that the hydraulic
system around the pump is at atmospheric pressure. Adhere to the
safety data sheet for the feed chemical.
Task Qualification
Storage, transport, unpacking Instructed person
Assembly Technical personnel, service
Planning the hydraulic installa‐
tion
Qualified personnel who have a
thorough knowledge of
metering pumps
Hydraulic installation Technical personnel, service
Installation, electrical Electrical technician
Operation Instructed person
Maintenance, repair Technical personnel, service
Decommissioning, disposal Technical personnel, service
Troubleshooting Technical personnel, electrical
technician, instructed person,
service
Explanation of the table:
Qualified personnel
A qualified employee is deemed to be a person who is able to
assess the tasks assigned to him and recognise possible dangers
based on his/her technical training, knowledge and experience, as
well as knowledge of pertinent regulations.
Note:
A qualification of equal validity to a technical qualification can also
be gained by several years of employment in the relevant field of
work.
Fixed separating protective equipment
Information in the event of an emer‐
gency
Qualification of personnel
Safety chapter
12

Electrical technician
An electrical technician is able to complete work on electrical sys‐
tems and recognise and avoid possible dangers independently
based on his/her technical training and experience, as well as
knowledge of pertinent standards and regulations.
The electrical technician should be specifically trained for the
working environment in which he is employed and know the rele‐
vant standards and regulations.
An electrical technician must comply with the provisions of the
applicable statutory directives on accident prevention.
Instructed person
An instructed person is deemed to be a person who has been
instructed and, if required, trained in the tasks assigned to him/her
and possible dangers that could result from improper behaviour, as
well as having been instructed in the required protective equipment
and protective measures.
Service
The Service department refers to service technicians, who have
received proven training and have been authorised by ProMinent
to work on the system.
Sound pressure level LpA < 70 dB according to EN ISO 20361
at maximum stroke length, maximum stroke rate, maximum back
pressure (water)
Sound pressure level
Safety chapter
13

4 Storage, Transport and Unpacking
WARNING!
The transporting of pumps which have been used
with radioactive feed chemicals is forbidden!
They will also not be accepted by ProMinent!
WARNING!
Only return metering pumps for repair in a cleaned
state and with a flushed liquid end - refer to
"Decommissioning!
Only return metering pumps with a completed
Decontamination Declaration form. The Decon‐
tamination Declaration constitutes an integral part
of an inspection / repair order. A unit can only be
inspected or repaired when a Declaration of
Decontamination Form is submitted that has been
completed correctly and in full by an authorised
and qualified person on behalf of the pump oper‐
ator.
The "Decontamination Declaration Form" can be
found on our homepage.
CAUTION!
Danger of material damage
The device can be damaged by incorrect or
improper storage or transportation!
– The unit should only be stored or transported in
a well packaged state - preferably in its original
packaging.
–The packaged unit should also only be stored
or transported in accordance with the stipu‐
lated storage conditions.
– The packaged unit should be protected from
moisture and the ingress of chemicals.
Data Value Unit
Minimum storage and transport tem‐
perature
-20 °C
Maximum storage and transport tem‐
perature
+60 °C
Maximum air humidity * 95 % rel.
humidity
* non-condensing
Safety Information
Ambient conditions
Storage, Transport and Unpacking
14

Compare the delivery note with the scope of delivery:
nMetering pump with mains cable
nConnector kit for hose/pipe connection (optional)
nProduct-specific operating instructions with EC Declaration of
Conformity
nOptional accessories
Scope of delivery
Storage, Transport and Unpacking
15

5 Overview of Equipment and Control Elements
5.1 Overview of Equipment
1 2 3
P_BE_0013_SW
Fig. 2: Complete overview
1 Control unit
2 Drive unit
3 Liquid end
a
b
c
d
e
f
P_BE_0008_SW
Fig. 3: Overview of liquid end (PV)
a Discharge valve
b Backplate
c Dosing head
d Bleed valve
e Bypass hose sleeve
f Suction valve
Overview of Equipment and Control Elements
16

5.2 Control Elements
1
2
3
4
5
7
8
9
6
P_BE_0011_SW
Fig. 4
1 Pulse control switch
2 Stroke Length Adjustment Button
3 Fault indicator (red)
4 Warning indicator (yellow)
5 Operating indicator (green)
6 Multifunctional Switch
7 "External control" terminal
8 Relay connection (optional)
9 "Level switch" terminal
5.2.1 Pulse control switch
In "External Contact" operating mode, the pulse control switch
either triggers a series of strokes or steps down an incoming series
of contacts by a single contact (at the "external control" terminal).
In "External Analogue" operating mode, the stroke rate can be con‐
trolled by an mA signal via the pulse control switch. To do so, the
multifunctional switch has to be turned to "Extern".
5.2.2 Stroke Length Adjustment Button
The stroke length adjustment button can be used to adjust the
stroke length.
5.2.3 Multifunctional Switch
The multifunctional switch can be used to set the following func‐
tions, operating modes and stroke rate.
The operating modes that can be set are:
nTest (priming function)
nStop (optionally missing)
nExtern (Contact)
Overview of Equipment and Control Elements
17

nExternal (analogue, optional)
nManual (setting stroke rate in 10% increments)
5.2.4 Functional and Fault Indicators
The fault indicator lights up if the fluid level in the dosing tank falls
below the second switching point of the level switch (20 mm
residual filling level in the dosing tank).
The fault indicator lights up if the current falls below 3.8 mA (only
with 4...20 mA) or exceeds 23 mA in "External Analogue" operating
mode.
This LED flashes in the event of an undefined operating status.
The warning indicator lights up if the fluid level in the dosing tank
falls below the first switching point of the level switch.
The operating indicator lights up if the pump is ready for operation
and there are no fault or warning alerts. It goes out quickly as soon
as the pump has performed a stroke.
5.2.5 "External control" terminal
The "external control" terminal is a five-pole panel terminal.
It enables the following functions and operating modes to be used:
nPause
nExternal contact
nExternal Analogue (optional)
nAuxiliary frequency (external frequency changer)
The two- and four-pole cables used to date can
continue to be used. The "Auxiliary frequency"
function can, however, only be used with a five-
pole cable.
5.2.6 "Level switch" terminal
A 2-stage level switch with pre-warning and end switch-off can be
connected.
Fault indicator (red)
Warning indicator (yellow)
Operating indicator (green)
Overview of Equipment and Control Elements
18

6 Functional description
6.1 Liquid End
The dosing process is performed as follows: The diaphragm is
pressed into the dosing head; the pressure in the dosing head
closes the suction valve and the feed chemical flows through the
discharge valve out of the dosing head. The diaphragm is now
drawn out of the dosing head; the discharge valve closes due to
the negative pressure in the dosing head and fresh feed chemical
flows through the suction valve into the dosing head. One cycle is
completed.
6.2 Drive Unit
The diaphragm is driven by an electromagnet, which is controlled
by an electronic controller.
6.3 Capacity
The capacity is determined by the stroke length and the stroke
rate.
The stroke length is adjusted by the stroke length adjustment knob
within a range of 0 ... 100 %. A stroke length of between 30 ... 100
% (SEK type: 50 ... 100 %) is recommended to achieve the speci‐
fied reproducibility!
Data Value Unit
Recommended stroke length,
standard type
30 ... 100 %
Recommended stroke length, SEK
type
50 ... 100 %
The stroke rate can be set within a range of 10 ... 100 % using the
multifunctional switch.
6.4 Self-Bleeding
Self-bleeding liquid ends (SEK types) are capable of independent
priming when a discharge line is connected and diverting existent
air pockets via a bypass. During operation they are also capable of
conveying away gases which are produced, independently of the
operating pressure in the system. It is also possible to dose pre‐
cisely in a depressurised state due to the integral back pressure
valve.
6.5 Operating modes
The operating modes are selected by means of the multifunctional
switch.
As soon as the stroke rate has been set by the multifunctional
switch, the pump finds itself in "Manual" operating mode. 100%
corresponds to 180 strokes/min.
"Manual" operating mode
Functional description
19

The "External Contact" operating mode is described below in the
"Operation" and "Installation, Electrical" chapters.
The "External Analogue" operating mode is described below in the
"Operation" and "Installation, Electrical" chapters.
6.6 Functions
The functions are described below in the "Operation" chapter.
6.7 Relay
The pump has two connecting options.
The relay can switch a connected power circuit (e.g. for an alarm
horn) in the event of warnings or fault messages (e.g. warning
levels).
The relay can be retrofitted with the retrofit kit via a knock-out
opening in the pump foot - refer to "Retrofitting relays".
This combined relay can generate a contact with each stroke via its
pacing relay in addition to its function as a fault indicating relay.
The relay can be retrofitted with the retrofit kit via a knock-out
opening in the pump foot - refer to "Retrofitting relays".
6.8 Hierarchy of Operating Modes, Functions and Fault Statuses
The different operating modes, functions and fault statuses have a
different effect on if and how the pump reacts.
The following list shows the order:
1. - Test (priming)
2. - Fault, Stop, Pause
3. - Auxiliary frequency (external frequency changeover)
4. - Manual, Extern Contact
Comments:
re 1 - "Priming" can take place in any mode of the pump (pro‐
viding it is functioning).
re 2 - "Fault", "Stop" und "Pause" stop everything apart from "Pri‐
ming".
re 3 - The stroke rate of "Auxiliary frequency" always has priority
over the stroke rate specified by an operating mode in 4.
"External contact" operating mode
"External Analogue" operating mode
Fault indicating relay option
Fault indicating and pacing relay
option
Functional description
20
