Peristaltic metering pump DULCO flex Control,
DFYa
DULCOnvert
Installation and configuration manual
A3507
These operating instructions are only valid in conjunction with the operating instructions for the pump.
EN
Part no. 999564 Version: BA DX 042 02/22 EN
Please carefully read these operating instructions before use. · Do not discard.
The operator shall be liable for any damage caused by installation or operating errors.
The latest version of the operating instructions are available on our homepage.

Table of contents
1Requirements.................................................................................. 3
2 Setting up the pump........................................................................ 4
2.1 General................................................................................... 4
2.2 Setting the slave address........................................................ 4
2.3 Switching PROFIBUS® to active/inactive................................ 4
3PROFINET® settings....................................................................... 5
4Special features in active PROFIBUS® mode................................. 6
4.1 General................................................................................... 6
4.2 Displays................................................................................... 6
4.3 LEDs on the PROFIBUS® module.......................................... 6
5 Assembly and electrical installation................................................. 7
6 Operation......................................................................................... 8
6.1 General................................................................................... 8
6.2 GSD file................................................................................... 8
6.3 Description of the data objects................................................ 8
7 Technical data on DULCOnvert..................................................... 12
8 Disposal......................................................................................... 13
Table of contents
2

1 Requirements
You can enhance the pump with PROFIBUS® functionality with a plug-in
module. Simply insert the plug-in module into the front of the pump. The
menu item
‘Fieldbus’ then appears in the operating menu and the PRO‐
FIBUS® symbol appears in the status bar of the display.
The pump can then be extended with PROFINET® functionality using the
DULCOnvert converter.
Requirements
3

2 Setting up the pump
2.1 General
Familiarise yourself with the process: We describe here how to set up the
pump for PROFIBUS® mode. You will later meet the pump's
PROFINET® protocol via the DULCOnvert in the master control system.
For this reason, "PROFIBUS®" is interchangeable with "PROFINET®" at
many points.
You can set up a pump with PROFIBUS® module in the same way as the
standard pump, with the addition of bus functionality.
The pump interrupts the set-up process in the event of a pause longer
than 60 seconds.
2.2 Setting the slave address
The address is pre-set to "125". There is no need to manually set the slave
address if a master in the PROFIBUS® segment assigns the slave
addresses.
1. Press the
[Menu] key.
2. Turn the
[Clickwheel] to ‘Fieldbus’ and press the [Clickwheel] .
3. Turn the
[Clickwheel] to ‘BUS address’ and press the [Clickwheel] .
INFORMATION!: Always set the 3-digit PROFIBUS® address to "002".
1. Set the 1st digit with the
[Clickwheel] and press the [Priming] key.
ðThe 2nd digit of the address is highlighted.
2. Set the 2nd digit with the
[Clickwheel] and press the [Priming]
key.
ðThe 3rd digit of the address is highlighted.
3. Set the 3rd digit with the
[Clickwheel] and press the [Clickwheel] .
ðThe address has now been fully entered.
2.3 Switching PROFIBUS® to active/inactive
Set the
‘Fieldbus’ to ‘active’ in the operating menu for the pump to be
controlled by the PROFIBUS®.
1. Press the
[Menu] key.
2. Turn the
[Clickwheel] to ‘Bus active’ and press the [Clickwheel] .
3. Turn the
[Clickwheel] to ‘Active’ or ‘Inactive’ and press the
[Clickwheel] . You’re done!
All external inputs of the pump, such as level monitoring, dosing monitor
and external control (pause, contact input, analogue input), will continue to
function while the PROFIBUS® is
‘active’ . The external inputs lead to the
expected reactions as is the case with a pump without PROFIBUS®
module. The pump transmits relevant information via the PROFIBUS® to
the master (PLC, PC etc.).
If the PROFIBUS® is set to
‘inactive’ , the settings for the operating mode
previously selected will be reloaded.
If the pump is switched to another operating mode, then the pump will stop
and can only be restarted using the
[Stop/Start] key.
Setting up the pump
4

3 PROFINET® settings
1. Connect the DULCOnvert to its supply voltage.
2. Connect the DULCOnvert to the PROFINET® network - see “Instal‐
lation” chapter.
3. Select
‘Update accessible devices’ in the TIA portal under ‘Online
access’ .
Fig. 1: ‘Update accessible devices’
ðThe default name is
‘nl51ndpl’ .
4. Assign a new name via
‘Online & diagnostics’ .
Fig. 2: Assign name
5. Continue configuring as usual. Description of the available objects -
refer to "Operation".
PROFINET® settings
5

4 Special features in active PROFIBUS® mode
4.1 General
INFORMATION!: The pump cannot be manually set or programmed in
PROFIBUS® mode. To do so, switch the PROFIBUS® to
‘inactive’ .
nYou can move between the continuous displays at any time, as in the
other operating modes. This does not affect the operation of the
pump.
nThe settings from other operating modes are carried over when
switching over to PROFIBUS® mode. By contrast, the settings made
via the PROFIBUS® are not saved.
INFORMATION!: The settings only apply as long as the pump is con‐
nected to the PROFIBUS®.
Only the total speed and the total number of litres continue to be
counted and saved.
nIf the pump is switched to PROFIBUS® mode, the pump will stop and
can only be restarted using the PROFIBUS®.
4.2 Displays
There are additional identifiers in the operating display when PROFIBUS®
mode is running.
Stop PROFIBUS®: the pump has been stopped using PROFIBUS®.
The master has sent the pump a corresponding telegram.
Connection error: if the pump loses its connection to the PROFIBUS®
(for instance as soon as the PROFIBUS® is stopped), then the error
symbol and the symbol flash on the main display.
4.3 LEDs on the PROFIBUS® module
LEDs Cause
Flashing red and green at a
slow rhythm
Connection between the PROFIBUS® module and pump has been disrupted;
the hardware or software version of the pump may not be suitable for PROFIBUS®
Lit red No connection to the PROFIBUS®
Lit green Pump in cyclic operation
Operating display
Status display
Main display
Special features in active PROFIBUS® mode
6

5 Assembly and electrical installation
Please follow this order:
A. - Install the housing
B. - Install the PROFIBUS® cable
C. - Connect the DULCOnvert to the mains voltage
D. - Install the PROFINET® cable
E. - Properly close the housing
1. Flap open the two flaps on the left and right of the housing cover.
2. Use appropriate screws to screw the housing to a vertical base sur‐
face close to the pump using the 4 deep drill holes. Take into
account the length of the PROFIBUS® cable and the plug-in power
unit.
CAUTION!
When installed, the top should be pointing
upwards otherwise the specific IP degree of pro‐
tection will not be achieved.
Connect the PROFIBUS® cable of the DULCOnvert to the PROFIBUS®
terminal of the pump. There is no need for terminal resistors.
Connect the plug-in power unit of the DULCOnvert to the supply
voltage.
1. Unscrew the housing screws and open the cover.
2. Screw the clamping screw of the large threaded connector on the
left of the housing and remove the rubber insert.
3. Correctly thread the clamping screw the right way round onto the
PROFINET® cable.
4. Guide the PROFINET® cable into the housing and insert it into the
terminal on the converter until the cable snaps into place.
5. Place the rubber insert around the cable and press into the
threaded connector.
6. Screw the clamping screw onto the threaded connector until the
threaded connector is moisture-tight.
1. Check whether the sealing surfaces of the housing cover and the
black seal of the lower part of the housing are free of dirt.
2. Replace the housing cover onto the lower part of the housing and
fasten in place with the screws.
3. Close the two flaps on the left and right of the housing cover.
A. Installing the housing
B. Installing the PROFIBUS® cable
C. Connecting the DULCOnvert to the
supply voltage
D. Installing the PROFINET® cable
E. Properly closing the housing
Carefully close the housing otherwise the
specified IP degree of protection will not
be achieved.
Assembly and electrical installation
7

6 Operation
6.1 General
The DULCOnvert now makes the pump a subscriber in the PROFINET®.
The usage data is thus transmitted cyclically and acyclically.
6.2 GSD file
Use the GSDML file to configure the master. The GSDML file describes all
the features of the pump in PROFINET® mode, such as keywords, diag‐
nostics, modules and slots. The GSDML file can be downloaded from the
PROFINET® website and from the ProMinent website. The file name is
unique: GSDML-V2.2-Prominent-DFYa-DPL-20210929-115936.xml
6.3 Description of the data objects
INFORMATION!: The initial parameters must be transmitted from the
master so that the pump can engage in cyclic data transmission. Only
standard parametrisation is needed for this as there are no application-
specific parameters.
INFORMATION!: Please note: data is stored according to the "Big-Endian"
principle. This means that the byte with the highest-value bits is stored
first, meaning that this byte is at the lowest storage address. Refer to the
section below for an example based on "Status":
The pump status is stored as UINT32 type at the offset addresses +0 to
+3. Bytes are stored in this sequence:
Tab. 1: Pump status
Name Type Offset Byte Bits
Status UINT32 +0 0 24 ... 31
+1 1 16 ... 23
+2 2 8 … 15
+3 3 0 … 7
Description of the data objects
Operation
8

All the data objects that can be cyclically transmitted are described below.
Tab. 2: All data objects
Name No. Type Description
Device identifier 0 UINT32 Byte 0+1 = 0x1180 Identification number
Byte 2 = 0x50 ProMinent identifier for pump
product group
Byte 3 = 8 "DULCO flex Control" pump family
Status 1 UINT32 bit Name Function
0 Motor 0 – Motor idle 1 – Motor run‐
ning
1 - -
2 Mode 00 – halt 03 – contact
3 01 – manual 04 - analog
4 02 – batch
5 Error There are errors, see "Errors"
6 Warnings There are warnings, see "Warn‐
ings"
7 Manual stop Pump has been stopped manually
8 Stop Pump has stopped
9 Priming Pump is in priming mode (higher-
level function)
10 Auxiliary Pump is in auxiliary mode (higher-
level function)
11 Pause Pump has been switched to pause
(higher-level function)
12 Module Fieldbus mode active
13 Hose change Hose is being changed
14 Batch Mem. Batch memory is activated
15 Calibrated Pump is calibrated
16 Relay 1 Relay 1 physically exists
17 Relay 2 Relay 2 physically exists
18 AnalogOut Module physically exists
19 Hose rupture Hose rupture sensor is installed
20 Actual direction
of rotation
0 = clockwise
1 = counter-clockwise
The user should stop the pump
and wait for the release to change
the direction of rotation (Bit #21 in
the status). Only then can the
direction of rotation be reversed.
21 Direction of
rotation
Release for change of direction of
rotation
22 - -
24 - -
27 - -
Operation
9

Name No. Type Description
Start-Stop 2 BYTE Corresponds to Start-Stop switch; if Start-Stop = 0, then the pump is
stopped.
Reset 3 BYTE If the “Reset” value is switched from 1 to 0, the internal pump memory
is deleted (e.g. with batch metering) and - as far as possible - pending
errors are cleared.
Mode 4, 5 BYTE Value Name Description
0 Halt Pump is ready but not metering.
1 Manual Pump is metering continuously at
the set frequency.
2 Batch When triggered, the pump meters
the number of revolutions set in
batch pre-selection.
3 Contact Pump meters the number of revo‐
lutions calculated from the product
of "Number of triggers * External
factor".
4 Analog Pump meters according to the ana‐
logue signal and the
‘Analog’
operating mode set on the pump.
Dosing rate 6, 7 UINT16 Dosing rate set in litres / hour ("Minimum" .. "Maximum dosing rate").
Actual dosing rate 8 UINT16 Actual dosing rate in litres / hour (0.. "Maximum dosing rate").
Maximum dosing
rate
9 UINT16 Maximum dosing rate in litres / hour
Batch pre-selection 10, 11 UINT32 Number of half revolutions in batch mode per trigger. (12 … Maximum
= 999.999 litres / trigger).
Batch start 12 BYTE If the value changes from 1 to 0, batch metering is activated in batch
operation. Batches can also be activated via the contact input.
Batch memory 13 BYTE If the batch memory is activated and a new batch is triggered during
batch metering already in progress, then the remaining revolutions are
increased by the number of the new batch.
If the memory is not activated, the remaining revolutions of the batch
not yet processed are cleared and the new batch is processed.
Remaining revolu‐
tions
14 UINT32 The remaining revolutions still to be processed with batch metering
External factor 15, 16 UINT16 Factor by which the incoming pulses are multiplied. The factor is given
as a hundredth. Value range is 2…19998 - the factor is then 0.01…
99.99 revolutions.
External memory 17 BYTE As with batch metering, once again here high factors are added
together or the remaining revolutions are cleared.
Direction of rotation 19 UINT16 Target direction of rotation 0 = clockwise and 1 = counter-clockwise
Hose service life 20 UINT32 Hose service life - revolutions since the last hose change
Error 21 UINT16 bit Name Function
0 Minimum Metering liquid level too low
1 Batch Too many revolutions > 100000
2 Analog < 4mA Analogue current is less than 4 mA
3 Analog > 23mA Analogue current is greater than 23
mA
4 Temperature
error
Temperature too high
5 Hose rupture Metering hose damaged
Operation
10

Name No. Type Description
6 - -
7 - -
8 - -
9 - -
11 - -
13 Bus error Bus error reported by the module
14 System error System components faulty - see
LCD screen
15 Module error Error in module handling
Warnings 22 UINT16 bit Name Function
0 Minimum Metering liquid level too low
1 Calibration -
2 - -
3 - -
4 - -
5 - -
6 - -
7 - -
8 - -
Revolution counter 23 UINT32 Counts the number of revolutions since the last reset
Reset revolution
counter
24 UINT8 If the value changes from 1 to 0, the revolution counter is reset
Volume counter 25 FLOAT32 Volume counter
Litres per revolu‐
tion
26 FLOAT32 Litres per revolution
Clear volume
counter
27 UINT8 If the value changes from 1 to 0, the volume counter is cleared
Identity code 28 STRING32 Pump identity code (pump specification)
Serial number 29 STRING16 Pump serial number
Name 30 STRING32 Pump name, freely selectable (max. 32 characters)
Installation site 31 STRING32 Installation site, freely selectable. (max. 32 characters)
Operation
11

7 Technical data on DULCOnvert
Supply voltage: 230 V AC
Degree of protection: IP66 *
* with professional installation
PROFIBUS cable, length: 2 m
Plug-in power unit, length: 1.5 m
Housing, HxWxD: 140x110x60 mm *
* without threaded connectors
Electrical data
Degree of protection
Dimensions
Technical data on DULCOnvert
12

8 Disposal
In accordance with the European Directive 2012/19/EU on waste electrical
and electronic equipment, this device features the symbol showing a
waste bin with a line through it. The device must not be disposed of along
with domestic waste. To return the device, use the return and collection
systems available and observe the local legal requirements.
Sign indicating EU collection system
Disposal
13

14

15

999564, 1, en_GB
© 2022
ProMinent GmbH
Im Schuhmachergewann 5 - 11
69123 Heidelberg
Germany
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Internet: www.prominent.com
