ProMinent Duodos 10 User manual

Duodos 10
Air-driven double diaphragm pump
Assembly and operating instructions
A1136
EN
Original Operating Instructions (2006/42/EC)Part number 985472 BA DUO 011 09/16 EN
Please carefully read these operating instructions before use. · Do not discard.
The operator shall be liable for any damage caused by installation or operating errors.
The latest version of the operating instructions are available on our homepage.

In order to make it easier to read, this document uses the male
form in grammatical structures but with an implied neutral sense. It
is aimed equally at both men and women. We kindly ask female
readers for their understanding in this simplification of the text.
Please read the supplementary information in its entirety.
Information
This provides important information relating to the cor‐
rect operation of the unit or is intended to make your
work easier.
Warning information
Warning information includes detailed descriptions of the haz‐
ardous situation, see
Ä Chapter 2.1 ‘Labelling of Warning Informa‐
tion’ on page 5 .
The following symbols are used to highlight instructions, links, lists,
results and other elements in this document:
More symbols
Symbol Description
Action, step by step.
⇨Outcome of an action.
Links to elements or sections of these instructions or other applicable documents.
nList without set order.
[Button] Display element (e.g. indicators).
Operating element (e.g. button, switch).
‘Display /GUI’ Screen elements (e.g. buttons, assignment of function keys).
CODE Presentation of software elements and/or texts.
General non-discriminatory approach
Supplementary information
Supplemental instructions
2

Table of contents
1 Function and identification.................................................... 4
1.1 Function........................................................................ 4
1.2 Identification.................................................................. 4
2 Safety and Responsibility...................................................... 5
2.1 Labelling of Warning Information.................................. 5
2.2 Users' qualifications...................................................... 6
2.3 Intended use................................................................. 7
2.4 Duodos general safety notes........................................ 7
3 Transport and storage......................................................... 10
3.1 Transport.................................................................... 10
3.2 Storage....................................................................... 10
4 Assembly............................................................................ 11
4.1 Installation surroundings............................................. 11
4.1.1 Securing the double diaphragm pump..................... 12
4.2 Ambient conditions..................................................... 13
4.3 Layout of the suction side........................................... 13
4.4 Compressed air supply............................................... 14
5 Operation of the double diaphragm pump.......................... 15
6 Commissioning................................................................... 16
6.1 Checks prior to commissioning................................... 16
6.2 Priming........................................................................ 17
6.3 Interrupting operation.................................................. 17
7 Checking Tightening Torque Prior to Commissioning......... 18
8 Maintenance of the double diaphragm pump...................... 19
8.1 Troubleshooting.......................................................... 19
8.2 Air valve maintenance................................................ 20
8.3 Maintenance of the pilot valve.................................... 23
8.4 Maintenance of the ball valves................................... 24
8.5 Maintenance of the diaphragms................................. 25
9 Disposal of Used Parts....................................................... 27
10 Technical Drawing – Duodos 10......................................... 28
10.1 Exploded drawings and parts lists............................ 29
11 Spare Parts kits................................................................... 33
12 Technical data..................................................................... 34
12.1 Performance curves.................................................. 36
13 Declaration of Conformity................................................... 37
14 Index................................................................................... 38
Table of contents
3

1 Function and identification
1.1 Function
The Duodos is an air-driven double diaphragm pump.
The Duodos is run-dry safe and self-priming.
The pump capacity of the double diaphragm pump can be con‐
trolled by changing the pressure in the air supply. The air control is
designed for oil-free operation. The Duodos is optimally suited to
the transport of liquid chemicals.
The Duodos double diaphragm pump transports liquids to a dis‐
charge lift of 70 m. As the pump capacity depends greatly on the
back pressure, the performance curve must always be observed.
At the same time, the differential pressure between the hydraulic
and pneumatic sides must not exceed 2 bar. Higher values reduce
the service life of the double diaphragm pump.
When selecting the double diaphragm pump you must check its
material compatibility. In addition, the density, viscosity, solids con‐
tent and temperature of the liquid being transported must be con‐
sidered.
Permissible values for the medium
Temperature of the medium
– PP version: 5 ... 65 °C
– PVDF version: -13 ... 93 °C
Viscosity of the medium max. 200 mPas
Solids content: none
1.2 Identification
Type Housing Diaphragm Feed rate l/h Order numbers
Duodos 10 PP Santoprene®0 ... 900 1010793
Duodos 10 PVDF Teflon®0 ... 900 1010797
Function and identification
4

2 Safety and Responsibility
2.1 Labelling of Warning Information
These operating instructions provide information on the technical
data and functions of the product. These operating instructions pro‐
vide detailed warning information and are provided as clear step-
by-step instructions.
The warning information and notes are categorised according to
the following scheme. A number of different symbols are used to
denote different situations. The symbols shown here serve only as
examples.
DANGER!
Nature and source of the danger
Consequence: Fatal or very serious injuries.
Measure to be taken to avoid this danger.
Description of hazard
– Denotes an immediate threatening danger. If the
situation is disregarded, it will result in fatal or very
serious injuries.
WARNING!
Nature and source of the danger
Possible consequence: Fatal or very serious injuries.
Measure to be taken to avoid this danger.
– Denotes a possibly hazardous situation. If the sit‐
uation is disregarded, it could result in fatal or very
serious injuries.
CAUTION!
Nature and source of the danger
Possible consequence: Slight or minor injuries. Mate‐
rial damage.
Measure to be taken to avoid this danger.
– Denotes a possibly hazardous situation. If the sit‐
uation is disregarded, it could result in slight or
minor injuries. May also be used as a warning
about material damage.
NOTICE!
Nature and source of the danger
Damage to the product or its surroundings.
Measure to be taken to avoid this danger.
– Denotes a possibly damaging situation. If the situa‐
tion is disregarded, the product or an object in its
vicinity could be damaged.
Introduction
Safety and Responsibility
5

Type of information
Hints on use and additional information.
Source of the information. Additional measures.
– Denotes hints on use and other useful information.
It does not indicate a hazardous or damaging sit‐
uation.
2.2 Users' qualifications
WARNING!
Danger of injury with inadequately qualified personnel!
The operator of the plant / device is responsible for
ensuring that the qualifications are fulfilled.
If inadequately qualified personnel work on the unit or
loiter in the hazard zone of the unit, this could result in
dangers that could cause serious injuries and material
damage.
– All work on the unit should therefore only be con‐
ducted by qualified personnel.
– Unqualified personnel should be kept away from
the hazard zone
Training Definition
Instructed personnel An instructed person is deemed to be a person who has been instructed and,
if required, trained in the tasks assigned to him/her and possible dangers that
could result from improper behaviour, as well as having been instructed in the
required protective equipment and protective measures.
Trained user A trained user is a person who fulfils the requirements made of an instructed
person and who has also received additional training specific to the system
from ProMinent or another authorised distribution partner.
Trained qualified per‐
sonnel
A qualified employee is deemed to be a person who is able to assess the
tasks assigned to him and recognize possible hazards based on his/her
training, knowledge and experience, as well as knowledge of pertinent regula‐
tions. The assessment of a person's technical training can also be based on
several years of work in the relevant field.
Electrician Electricians are deemed to be people, who are able to complete work on elec‐
trical systems and recognize and avoid possible hazards independently based
on his/her technical training and experience, as well as knowledge of pertinent
standards and regulations.
Electricians should be specifically trained for the working environment in
which the are employed and know the relevant standards and regulations.
Electricians must comply with the provisions of the applicable statutory direc‐
tives on accident prevention.
Customer Service depart‐
ment
Customer Service department refers to service technicians, who have
received proven training and have been authorised by ProMinent to work on
the system.
Safety and Responsibility
6

Note for the system operator
The pertinent accident prevention regulations, as well
as all other generally acknowledged safety regulations,
must be adhered to!
2.3 Intended use
CAUTION!
Intended use
Possible consequences if the instructions are not
observed: Minor injuries and material damage
– The pump is intended for liquids transport
– The pump is not intended for the transport of gas‐
eous or solid media
– Only use the pump in accordance with the tech‐
nical data and specifications outlined in the oper‐
ating instructions.
– The pump is not designed for use in areas at risk
from explosion
– Only switch the device on if it has been properly
fastened to the ground or its holding fixture.
2.4 Duodos general safety notes
WARNING!
Danger from hazardous substances!
Possible consequence: Fatal or very serious injuries.
Please ensure when handling hazardous substances
that you have read the latest safety data sheets pro‐
vided by the manufacture of the hazardous substance.
The actions required are described in the safety data
sheet. Check the safety data sheet regularly and
replace, if necessary, as the hazard potential of a sub‐
stance can be re-evaluated at any time based on new
findings.
The system operator is responsible for ensuring that
these safety data sheets are available and that they
are kept up to date, as well as for producing an associ‐
ated hazard assessment for the workstations affected.
Safety and Responsibility
7

WARNING!
Hazardous media / contamination of persons and
equipment
Possible consequence: Fatal or very serious injuries.
material damage
– Ensure the device is resistant to the media being
conveyed
– Always observe the safety data sheets for the
media to be conveyed. The system operator must
ensure that these safety data sheets are available
and that they are kept up-to-date
– The safety data sheets for the media being con‐
veyed are always decisive for initiating counter
measures in the event of leakage to the media
being conveyed
– Observe the general restrictions in relation to vis‐
cosity limits, chemical resistance and density
WARNING!
Service life of the diaphragm
Possible consequence: Fatal or very serious injuries
The service life of the diaphragm cannot be precisely
specified. For this reason, the possibility of fracture
and subsequent leakage of liquids must be taken into
account.
In addition, you must prevent particles from the defec‐
tive diaphragm reaching the media being conveyed.
This can be achieved e.g. by filtration, a hose rupture
alarm or other means suitable for the respective
process.
CAUTION!
Compressed air
Before working on the double diaphragm pump, close
the compressed air lines and vent the double dia‐
phragm pump.
Before undertaking any maintenance and repair work,
close off the compressed air supply, discharge the
compressed air and detach the air supply line from the
double diaphragm pump. The line to the discharge
side of the double diaphragm pump may be under
pressure and must likewise be vented.
CAUTION!
Hot surface
When conveying hot liquids, the pump can likewise
become hot. Hot surfaces may then be present on the
pump. Bear this in mind and take suitable measures to
reduce any hazards.
Safety and Responsibility
8

Maximum pump sound pressure level 91 dB
Depending on the operating conditions, the maximum
sound pressure level of the device can reach 88 dB ±
3 dB. Bear this in mind and take suitable measures to
reduce any impact caused by this sound pressure
level. The type and implementation of suitable meas‐
ures depends on the local circumstances and is the
responsibility of the system operator.
Check the fastening elements are correctly seated.
Before commissioning the double diaphragm pump,
you must check that all fastening elements with sealing
rings are correctly seated. The seals may ‘creep’ , so
that the fastening elements come loose over time.
In the event of a diaphragm rupture
In the event of a diaphragm rupture, the pumped
medium can enter the air system of the double dia‐
phragm pump and from there into the atmosphere. If
the pumped medium is a dangerous, harmful or toxic
substance, the air outlet must be routed to a suitable
area where safe disposal is possible.
Operation in the open air and outdoors
– Take suitable measures to protect the device from
environmental influences when operating outside
such as:
– UV rays
– Humidity
– Frost, etc.
Safety and Responsibility
9

3 Transport and storage
nUser qualification, transport and storage: trained user, see
Ä Chapter 2.2 ‘Users' qualifications’ on page 6
WARNING!
Danger from hazardous substances!
Possible consequence: Fatal or very serious injuries.
Please ensure when handling hazardous substances
that you have read the latest safety data sheets pro‐
vided by the manufacture of the hazardous substance.
The actions required are described in the safety data
sheet. Check the safety data sheet regularly and
replace, if necessary, as the hazard potential of a sub‐
stance can be re-evaluated at any time based on new
findings.
The system operator is responsible for ensuring that
these safety data sheets are available and that they
are kept up to date, as well as for producing an associ‐
ated hazard assessment for the workstations affected.
3.1 Transport
Transport
nThe pump is protected by means of cardboard packaging
nThe packaging materials can be recycled
nConsider the ambient conditions
3.2 Storage
The device must be completely drained before storage.
Permissible storage conditions:
All versions: + 5 °C ... 60 °C
All versions: < 95% relative air humidity (non-condensing)
Permissible operating conditions:
All versions: - 10 °C ... 40 °C
All versions: < 95% relative air humidity (non-condensing)
Transport and storage
10

4 Assembly
nUser qualification, installation: trained qualified personnel, see
Ä Chapter 2.2 ‘Users' qualifications’ on page 6
CAUTION!
Possible consequence: Slight or minor injuries. Mate‐
rial damage.
Observe the permissible ambient conditions.
4.1 Installation surroundings
Upright installation
Install the double diaphragm pump upright and plumb.
The valves of the double diaphragm pump operate
when loaded by gravity. The valve balls are pressed by
gravity into the valve seat and seal it off. Installation
outside the vertical axis impairs the function of the
valves.
Nominal width of the pipework
The threaded connectors must not reduce the nominal
width of the pipework or the double diaphragm pump.
The hydraulic connectors have internal and external
threads. Do not screw threaded fittings on to the
internal thread as this would lead to a reduction of the
nominal width.
Keep the suction line short and the number of pipe valves small.
Do not reduce the diameter of the suction line. If a rigid pipework
system is used, short flexible hose pieces should be inserted
between the double diaphragm pump and pipework to protect the
double diaphragm pump against vibration and tensile and com‐
pressive forces. The installation of a pulsation damper is recom‐
mended to reduce pulsations in the pumped medium.
Assembly
11

A1142
1.
2. 3. 4. 5. 6.
7.
8. 9. 10. 11. 12.
13.
14. 16. 17. 18.
19.
15.
Fig. 1: Installation surroundings
1. Pulsation damper
2. Flexible connection
3. Pipe connection
4. Manometer
5. Shut-off valve
6. Discharge side
7. Outlet valve
8. Flexible connection
9. Filter/controller module
10. Air dryer (option)
11. Shut-off valve
12. Compressed air connection
13. Outlet valve
14. Suction side
15. Shut-off valve
16. Manometer
17. Pipe connection
18. Flexible connection
19. Air outlet
4.1.1 Securing the double diaphragm pump
Correct securing of the device
Only switch the device on if it has been properly fas‐
tened to the ground or its holding fixture. The system
operator is responsible for ensuring that the ground
and the fittings can hold the device safely and under all
operating conditions.
Assembly
12

4.2 Ambient conditions
NOTICE!
Ambient conditions
Possible consequence: Property damage and
increased wear and tear
Assembly is to be carried out in the following order. If
the pump has to be installed outdoors, then it is to be
equipped with protection against sunlight and weather
influences.
When positioning the pump, ensure that sufficient
room for access is provided for all types of mainte‐
nance work.
4.3 Layout of the suction side
Nominal width of the pipework
The threaded connectors must not reduce the nominal
width of the pipework or the double diaphragm pump.
The hydraulic connectors have internal and external
threads. Do not screw threaded fittings on to the
internal thread as this would lead to a reduction of the
nominal width.
Dimensioning of the suction side
Layout the suction side with generous dimensions. The
supply of the double diaphragm pump with the liquid to
be pumped must be ensured under all load and oper‐
ating statutes. Ensure that the inside diameters of the
suction lines are generously sized.
To ensure a maximum service life of the diaphragm, the double
diaphragm pump should be installed as close as possible to the
pumped medium. If there is a positive priming pressure on the suc‐
tion side of more than 3.0 m water column, the fitting of a back
pressure valve in the air outlet of the double diaphragm pump is
recommended in order to protect the diaphragm. The minimum air
pressure to operate the double diaphragm pump is approximately 1
bar.
Assembly
13

4.4 Compressed air supply
Compressed air supply
The double diaphragm pump must be connected to a
compressed air supply in accordance with the current
state of the art (ISO 8573-1). We require unoiled,
residual oil-free (residual oil from the compressors of
maximum 0.1 mg/m³ for HEES-liquids, bio-oils or max.
5mg/m³ permitted for mineral oils) and appropriately
dried compressed air (ISO 8573-1, class 4 with 3 °C
PDP).
Our recommendation is that the pressure dew point
must be at least 10 °C below the ambient temperature.
Suitable compressed air supply
The system operator is responsible for the provision of
a suitable compressed air supply. In doing so, observe
ISO 8573.
Layout the compressed air supply with generous dimensions. Your
compressed air supply must be able to supply the double dia‐
phragm pump with sufficient compressed air at any time and under
all operating statutes. In this respect also consider the air con‐
sumption of other devices and machinery connected to the same
compressed air supply. Considerable pressure fluctuations can
occur in the compressed air supply when switching compressed air
consumers on and off.
The air pressure of the supplied air must not exceed 7 bar (100
psi). Connect the air inlet of the double diaphragm pump to a com‐
pressed air supply, which is designed to provide the required pump
capacity in terms of air quantity and pressure. To guarantee the
supply pressure remains within the specified values, a control
valve should be connected upstream of the double diaphragm
pump.
In there is a rigid air supply line insert a short piece of flexible hose
between the double diaphragm pump and the pipework.
The weight of the air supply line, control valve, and filters must not
weigh upon the air connection fitting of the double diaphragm
pump, rather it must be supported in a suitable manner. Otherwise
the double diaphragm pump can be damaged.
Based on their design, the air valve and the pilot valve do not
require any lubrication and indeed must not be lubricated.
Water in the compressed air can lead to the exhaust air freezing or
the double diaphragm pump icing up. The possible consequences
are malfunctions or failure of the double diaphragm pump. It is rec‐
ommended that an air dryer is fitted. This extracts the water from
the compressed air and protects against icing up.
Lubrication of the air valves
Moisture in the air line
Assembly
14

5 Operation of the double diaphragm pump
nUser qualification: operation instructed personnel, see
Ä Chapter 2.2 ‘Users' qualifications’ on page 6
The double diaphragm pump is fully integrated into the customer
provided system and is then controlled from this system. It is not
possible to operate the double diaphragm pump directly.
Operation of the double diaphragm pump
15

6 Commissioning
nUser qualification, commissioning: trained user, see Ä Chapter
2.2 ‘Users' qualifications’ on page 6
Check the fastening elements are correctly seated.
Before commissioning the double diaphragm pump,
you must check that all fastening elements with sealing
rings are correctly seated. The seals may ‘creep’ , so
that the fastening elements come loose over time.
6.1 Checks prior to commissioning
WARNING!
Danger from hazardous substances!
Possible consequence: Fatal or very serious injuries.
Please ensure when handling hazardous substances
that you have read the latest safety data sheets pro‐
vided by the manufacture of the hazardous substance.
The actions required are described in the safety data
sheet. Check the safety data sheet regularly and
replace, if necessary, as the hazard potential of a sub‐
stance can be re-evaluated at any time based on new
findings.
The system operator is responsible for ensuring that
these safety data sheets are available and that they
are kept up to date, as well as for producing an associ‐
ated hazard assessment for the workstations affected.
The following checks are to be carried out:
nEnsure that the device has not been damaged during transpor‐
tation or storage. Immediately report any damage to the sup‐
plier
nCheck that the air pressure is suitable for the device.
nEnsure that the device is suitable for the liquid to be conveyed
and that it will not be attacked.
nMake sure that the temperature of the liquid does not exceed
the recommended temperature range
nInstall a manometer in the discharge line if the back pressure
value is unknown
nUnder the operating conditions, check the values for flow, pres‐
sure, etc.
nInstall a pressure relief valve in the discharge line in order to
protect the pump in the event that a valve is unintentionally
closed off or the line is blocked in another way.
Commissioning
16

6.2 Priming
1. To start the double diaphragm pump, open the air value by
approximately 1/2 to 3/4 of a turn
2.
Cavitation
If opening of the air valve causes the stroke rate
of the double diaphragm pump to increase, but
not however the flow volume passing through the
double diaphragm pump, then cavitation is the
cause. Slightly turn back the air valve so that the
air consumption and feed rate of the double dia‐
phragm pump are set in an optimum ratio.
Once the double diaphragm pump is filled with water, open
the air valve further to set the required air flow.
6.3 Interrupting operation
WARNING!
Danger from hazardous substances!
Possible consequence: Fatal or very serious injuries.
Please ensure when handling hazardous substances
that you have read the latest safety data sheets pro‐
vided by the manufacture of the hazardous substance.
The actions required are described in the safety data
sheet. Check the safety data sheet regularly and
replace, if necessary, as the hazard potential of a sub‐
stance can be re-evaluated at any time based on new
findings.
The system operator is responsible for ensuring that
these safety data sheets are available and that they
are kept up to date, as well as for producing an associ‐
ated hazard assessment for the workstations affected.
Rinse through the double diaphragm pump after every use if liquids
are used which when stationary have a tendency to form deposits
or to solidify. This avoids damage to the double diaphragm pump.
Liquid residues remaining in the double diaphragm pump may dry
out and form deposits. When restarting the double diaphragm
pump, this can lead to problems at the diaphragms and the ball
valves. At temperatures below 0 °C the double diaphragm pump
must always be completely drained.
Commissioning
17

7 Checking Tightening Torque Prior to Commissioning
Lasting tightness
Check that the threaded connectors have the correct
torque during commissioning.
We also recommend checking these threaded connec‐
tors for correct torque at least once a year because the
pump material yields and the tightening torque is then
reduced.
A2249
3,4 Nm
2,2 Nm
2,2 Nm
2,2 Nm
2,2 Nm
I.
Fig. 2: Checking tightening torque prior to commissioning.
1. Tighten all screws (37) to 2.2 Nm.
2. Tighten the screw (11) to 3.4 Nm.
3. Tighten the nut (25) at position I by instinct as there is no
torque specified for this nut.
Checking Tightening Torque Prior to Commissioning
18

8 Maintenance of the double diaphragm pump
nUser qualification, wait: instructed personnel, see Ä Chapter
2.2 ‘Users' qualifications’ on page 6
WARNING!
Danger from hazardous substances!
Possible consequence: Fatal or very serious injuries.
Please ensure when handling hazardous substances
that you have read the latest safety data sheets pro‐
vided by the manufacture of the hazardous substance.
The actions required are described in the safety data
sheet. Check the safety data sheet regularly and
replace, if necessary, as the hazard potential of a sub‐
stance can be re-evaluated at any time based on new
findings.
The system operator is responsible for ensuring that
these safety data sheets are available and that they
are kept up to date, as well as for producing an associ‐
ated hazard assessment for the workstations affected.
Before all work
Before all work on the double diaphragm pump, dis‐
connect the double diaphragm pump from the com‐
pressed air supply and the feed and discharge lines,
vent and decontaminate. Always observe the safety
data sheet for the chemicals to be conveyed.
8.1 Troubleshooting
Possible symptoms
nDouble diaphragm pump does not cycle
nDouble diaphragm pump cycles, but does not pump
nDouble diaphragm pump cycles, but insufficient feed rate
nDouble diaphragm pump cycles irregularly
nDouble diaphragm pump vibrates strongly
Cause: Measure:
Suction lift of the system too high For suction lifts above 6 metres, priming of the pump can in most
cases be induced by pre-filling the pump chambers
Too high priming pressure on the
suction side of the system
If there is a priming pressure of more than 3 metres water column, pro‐
vide a back pressure valve in the air outlet of the double diaphragm
pump
Back pressure of the medium
higher than the air pressure
Increase the air inlet pressure to the double diaphragm pump
Compressed air pressure higher
than the back pressure of the
medium
Adjust the feed air pressure according to the performance curve of the
double diaphragm pump. At high stroke rates, cavitation in the medium
may occur
Suction line of too small nominal
width
Observe the recommendations of the dimensioned drawing for the
cross-section of the suction line
Maintenance of the double diaphragm pump
19

Cause: Measure:
Air line of too small nominal width Observe the recommendations for dimensioning of the air inlet line in
the operating instructions of the double diaphragm pump
Air distribution system of the
double diaphragm pump
Dismantle and examine the air valve, pilot valve and control pins
Rigid pipe connections at the
pump
Use flexible connections and a pulsation damper
Exhaust air silencer blocked Remove the silencer. Then clean or de-ice and refit.
Pumped medium in the exhaust
air silencer
Dismantle pump chambers and determine whether a diaphragm is
broken or a diaphragm flange is loose
Ball valve blocked Dismantle the liquid end of the double diaphragm pump and clear the
blockage
Ball valve or valve seat worn or
distorted
Check the ball valves and valve seats for wear and correct seating
Replace as necessary
Suction line blocked Clear blockage or check and clean suction line
Discharge line blocked Check for blockage. Valves in the discharge line may be closed
Pump chamber blocked Dismantle the liquid end and inspect the diaphragm chambers of the
double diaphragm pump
8.2 Air valve maintenance
To carry out maintenance on the air valve first discon‐
nect the compressed air supply, vent the double dia‐
phragm pump and remove the air supply line from the
double diaphragm pump.
Maintenance of the double diaphragm pump
20
