Promise Pegasus2 R6 User manual

P EGASUS2
R6, R4, R8
Product Manual
Version 2.0

Copyright
© 2013 PROMISE Technology, Inc. All Rights Reserved. PROMISE, the PROMISE logo, VTrak, Pegasus, SmartStor,
SuperTrak, FastTrak, VessRAID, Vess, PerfectPATH, PerfectRAID, SATA150, ULTRA133, VTrak S3000, BackTrak, Hyper-
Cache, HyperCache-R, HyperCache-W, DeltaScan and GreenRAID are registered or pending trademarks of PROMISE
Technology, Inc. in the U.S. and other countries. All other trademarks are the property of their respective owners. Informa-
tion regarding products, services and offerings may be superseded by subsequent documents and are subject to change
without notice. For the latest information and specications regarding PROMISE Technology, Inc. and any of its offerings
or services, please contact your local PROMISE ofce or the corporate headquarters. Visit www.PROMISE.com for more
information on PROMISE products.
Important data protection information
You should back up all data before installing any drive controller or storage peripheral. PROMISE Technology is not re-
sponsible for any loss of data resulting from the use, disuse or misuse of this or any other PROMISE Technology product.
Notice
Although PROMISE Technology has attempted to ensure the accuracy of the content of this document; it is possible that
this document may contain technical inaccuracies, typographical, or other errors. PROMISE Technology assumes no
liability for any error in this publication, and for damages, whether direct, indirect, incidental, consequential or otherwise,
that may result from such error, including, but not limited to loss of data or prots.
PROMISE Technology provides this publication “as is” without warranty of any kind, either express or implied, including,
but not limited to implied warranties of merchantability or tness for a particular purpose. The published information in
the manual is subject to change without notice. PROMISE Technology reserves the right to make changes in the product
design, layout, and driver revisions without notication to its users. This version of this document supersedes all previous
versions.
Recommendations
In this Product Manual, the appearance of products made by other companies, including but not limited to software, serv-
ers, and disk drives, is for the purpose of illustration and explanation only. PROMISE Technology does not recommend,
endorse, prefer, or support any product made by another manufacturer.
ii
Pegasus2 R4/R6/R8 Product Manual

About this guide
This Product Manual describes how to setup, use, and maintain the Pegasus2 R8, R6 and R4 unit. It also describes how to use
the PROMISE Utility software that you install and run on your Macintosh computer.
Although this manual is written specically for the Pegasus2 models, many of the functions and descriptions can be applied to
the original release of Pegasus, Pegasus R4 and Pegasus R6. Pegasus2 is operationally compatible with the original release of
Pegasus. Material that applies only to the Pegasus2 will specify Pegasus2. Use of the term “Pegasus” implies that the material
applies to both versions.
This manual includes a full table of contents, chapter task lists, and numerous cross-references to help you nd the specic infor-
mation you are looking for.
Also included are four levels of notices:
WARNINGWARNING
iii
Promise Technologies

VCCI
KCC
FCC
iv
Pegasus2 R4/R6/R8 Product Manual

WARNINGWARNING
WARNINGWARNING
v
Promise Technologies

Pegasus2 R4/R6/R8 Product Manual Contents
Contents
About this guide iii
introduction to PegAsus2 1
Architecture 2
Protocol SuPPort 2
Key BenefitS 2
sPecificAtions 3
Hardware 4
instAllAtion And setuP 6
summAry of the setuP Procedure 7
Packing List 7
connect tHe Power cord 8
connect Pegasus2to your Mac 9
instAlling the softwAre10
Power modes on the PegAsus2 13
shutting down the PegAsus2 13
dAisy-chAining multiPle PegAsus/PegAsus2 units 14
unlocKing the ui 15
DiSPlAying MultiPle PegASuS/PegASuS2 unitS 15
tocreAte ADiSK ArrAy AnD logicAl Drive 16
mAnAge with Promise utility 17
accessing tHe ProMise utiLity 18
oPening 18
cloSing 18
unlocking the ui 19
Perusing the Promise utility interfAce 20
toolBAr iconS 21
cuStoMizing the toolBAr21
device menus 22
coMPonent liSt 22
PhySicAl Drive Menu 22
front view 23
BAcK view 24
Managing subsysteMs 25
viewing subsystem informAtion 25
mAking subsystem settings 26
cleAring stAtistics 26
restoring fActory defAult settings 27
sAving Aservice rePort27
uPdAting firmwAre 28
Managing tHe raid controLLer 29
viewing controller informAtion 29
viewing controller stAtistics 30
mAking controller settings 31
mAking buzzer settings 32
mAking fAn settings 32
Managing encLosures 33
viewing the enclosure informAtion 33
viewing temPerAture sensor informAtion 34
locAting An enclosure 35
Managing background activities 36
viewing current bAckground Activities 37
viewing scheduled bAckground Activities 37
Adding Ascheduled bAckground Activity 37
chAnging AbAckground Activity schedule39
enAbling or disAbling Ascheduled bAckground Activity
40
deleting Ascheduled bAckground Activity 40
mediA PAtrol 41
MAKing MeDiA PAtrol SettingS 41
redundAncy check 42
MAKing reDunDAncy checK SettingS 42
initiAlizAtion 42
MAKing initiAlizAtion SettingS 43
rebuild 43
MAKing reBuilD SettingS 44

Contents Promise Technologies
migrAtion 44
MAKing MigrAtion SettingS 44
Pdm 45
MAKing PDM SettingS 45
trAnsition 46
MAKing trAnSition SettingS 46
synchronizAtion 47
MAKing SynchronizAtion SettingS 47
Managing PHysicaL drives 48
viewing Alist of PhysicAl drives 48
viewing PhysicAl drive informAtion 49
viewing PhysicAl drive stAtistics 50
viewing PhysicAl drive smArt log informAtion 51
locAting APhysicAl drive 51
mAking globAl PhysicAl drive settings 52
mAking individuAl PhysicAl drive settings 52
mAking PhysicAl drive smArt log settings 53
cleAring AstAle or APfA condition 53
forcing APhysicAl drive offline 54
running MeDiA PAtrol on your PhySicAl DriveS 55
Managing disk arrays 56
viewing Alist of disk ArrAys 56
viewing disk ArrAy informAtion 57
creAting Adisk ArrAy mAnuAlly 58
creAting Adisk ArrAy And logicAl drive with the wizArd 59
chooSing AutoMAtic configurAtion 60
chooSing exPreSS configurAtion 61
chooSing ADvAnceD configurAtion 63
mAking disk ArrAy settings 65
locAting Adisk ArrAy 66
deleting Adisk ArrAy 67
PrePAring Adisk ArrAy for trAnsPort 67
rebuilding Adisk ArrAy 68
PerforMing AMAnuAl reBuilD 68
PAuSing AnD reSuMing AreBuilD 69
StoPPing AreBuilD 69
Managing LogicaL drives 70
viewing Alist of logicAl drives 71
viewing logicAl drive informAtion 71
viewing logicAl drive stAtistics 72
mAking logicAl drive settings 73
viewing logicAl drive check tAbles 74
creAting AlogicAl drive mAnuAlly 74
formAtting your logicAl drives 76
locAting AlogicAl drive 76
deleting AlogicAl drive 77
initiAlizing AlogicAl drive 77
PAuSing AnD reSuMing An initiAlizAtion 78
StoPPing An initiAlizAtion 78
redundAncy check on AlogicAl drive 78
PAuSing AnD reSuMing AreDunDAncy checK 79
StoPPing AreDunDAncy checK 79
migrAting AlogicAl drive 79
running Pdm on AlogicAl drive 81
PAuSing AnD reSuMing PDM 81
StoPPing PDM 81
Managing sPare drives 82
viewing Alist of sPAre drives 82
viewing sPAre drive informAtion 83
creAting AsPAre drive mAnuAlly 84
mAking sPAre drive settings 85
running sPAre check 85
deleting AsPAre drive 86
running AtrAnSition on ASPAre Drive 86
running AtrAnsition 87
PAuSing AnD reSuMing AtrAnSition 87
StoPPing, PAuSing or reSuMing AtrAnSition 87

Pegasus2 R4/R6/R8 Product Manual Contents
technology bAckground 88
disk arrays 89
mediA PAtrol 89
Pdm 90
LogicaL drives 91
rAid levels 91
rAiD 0 – StriPe 91
rAiD 1 – Mirror 93
rAiD 1e – enhAnceD Mirror 94
rAiD 5 – BlocK AnD PArity StriPe 95
rAiD 6 – BlocK AnD DouBle PArity StriPe 96
rAiD 10 – Mirror + StriPe 97
rAiD 50 – StriPing of DiStriButeD PArity 98
rAiD 60 – DouBle PArity + StriPe 100
rAid level migrAtion 101
MigrAtion requireMentS 101
Source AnD tArget rAiD levelS 101
striPe size 106
sector size 107
initiAlizAtion 107
ForMatting LogicaL drives 108
ProMiSe utility with DefAult SettingS 108
ProMiSe utility with cuStoM SettingS 109
DiSK utility 110
sPare drives 111
definition 111
oPtions 111
requirements 112
trAnsition 112
running AtrAnSition 112
raid controLLers 116
reAD cAche Policy 116
write cAche Policy 116
cAPAcity coercion 117
troubleshooting 118
resPonding to An Audible AlArm 118
cHecking Leds119
SuBSySteM leDS119
Drive cArrier leDS120
Promise utility 121
viewing the event logs 121
viewing runtiMe eventS 121
viewing nvrAM eventS 122
event Severity DeScriPtionS 122
PHysicaL drive ProbLeMs 123
diAgnosis using the Promise utility 123
locAting APhysicAl drive 124
rePlAcing APhysicAl drive 125
PhySicAl Drive wArning MeSSAge 128
disk array and LogicaL drive ProbLeMs 129
disk ArrAy degrAded/logicAl drive criticAl 129
disk ArrAy offline/logicAl drive offline 130
rePAiring An offline DiSK ArrAy or logicAl Drive 130
rebuilding Adisk ArrAy 131
incomPlete ArrAy 132
MigrAtion 132
trAnSPort 132
unreAdAble disk wArning 133
subsysteM ProbLeMs 134
diAgnosing Asubsystem Problem 134
overheAting 135
fAn fAilure 135
inADequAte Air circulAtion 136
Power suPPly 136
connection ProbLeMs 137
cAbles 137
dAisy-chAins 138
PerForMance Monitor 139

Contents Promise Technologies
contActing technicAl suPPort 140
limited wArrAnty 144
DiSclAiMer of other wArrAntieS 145
your reSPonSiBilitieS 146
returning the ProDuct for rePAir 146
aPPendix a 148
trAnsferring A PhysicAl hArd disk from mAc toPegAsus2 148
PASS-through DiSK ProceDure for MAc 148
aPPendix b 150
imPortAnt informAtion 150
hArD Drive coMPAtiBility 150
gnu generAl PuBlic licenSe 151

introduction to PegAsus2
This chapter covers the following topics:
• “Architecture”
• “Protocol Support”
• “KeyBenets”
• “Specications”
• “Hardware”
PROMISE Technology’s Pegasus2 R8, R6 and R4 are direct attached storage (DAS) solutions for
externalstoragetargetedforsmallandmediumbusiness(SMB)users,smallofce/homeofce
(SOHO) users, and digital Audio and Video production professionals.
Pegasus2 models (R4, R6, R8) are operationally compatible with the original release Pegasus R4 and
R6 models. Use the latest version of the PROMISE Utility to monitor the Pegasus2 status and perform
maintenance and management functions. The latest version of the PROMISE Utility can also be used
for the original release of Pegasus.
1
Promise Technologies

Architecture
The Pegasus2 architecture is based on a state-of-the-art PMC Sierra 8011
I/Oprocessorcoupledwith512MBofDDR2SDRAMmemoryandaworldclassenterprise-proven
RAID engine.
Protocol SuPPort
Pegasus2supportsThunderbolt2™technology,providingtwochannelswith20Gb/softhroughput
in both directions simultaneously. Thunderbolt 2 is compatible with the previous original version of
Thunderbolt.
Thunderbolt and Thunderbolt 2 support daisy-chaining up to six (6) high-speed peripheral devices,
including external disks, video capture devices, and a Mini DisplayPort monitor.
Pegasus2 has two Thunderbolt ports, as required for daisy-chaining.
Key BenefitS
• Thunderbolt20Gb/sdataconnection
• PMCSierra8011I/Oprocessor
• 512MBofDDR2SDRAMmemory
• PROMISE Utility management tool
• Compatible with Apple Time Machine
• R6,sixSATA3.5-inchharddiskdrives
• R4,fourSATA3.5-inchharddiskdrives
• R8,eightSATA3.5-incheharddiskdrives
• Additional storage using multiple daisy-chained Pegasus and Pegasus2 enclosures
• 250WFlex-ATAPowerwith80PlusBronze.
2
Pegasus2 R4/R6/R8 Product Manual

Storage Disks ThePegasus2isshippedwith3.5inchSATAHardDiskDrives(HDD)installedinthe
drive carriers and placed in the drive bays.
Userscanreplacethedriveswithanyofthesupporteddrivetypes.FormanyRAID
congurations,itisbesttoinstalldrivesthatareidenticalintypeandstoragecapacity.
The following storage disk types are supported on the Pegasus2:
• 2.5-inchand3.5-inchSATAharddiskdrives
• 2.5-inchSSD
• 2.5-inchand3.5-inchHybridHDD
Capacity The Pegasus2 is available in three form factors that differ in the number of drives that
canbeinstalled.TotalcapacitydependsonthesizeoftheHDDshippedwiththeunit.
• The Pegasus2 R4 is shipped with four HDD
• The Pegasus2 R6 is shipped with six HDD
• The Pegasus2 R8 is shipped with eight HDD
• In addition, Pegasus2 enclosures can be connected or “daisy-chained” to other
Pegasus2 or Pegasus units to scale up the available storage capacity.
Power supply 250WFlex-ATAPowerwith80PlusBronzewithPFC,100-230Vauto-ranging,
50-60HzAC
System Fan Pegasus2 R4/R6:Dimension:92(W)x92(H)x25(D)mm/Airow:70CFM
Pegasus2 R8:Dimension:120(W)x120(H)x25.8(D)mm/Airow:97CFM
RAID function RAIDlevelsupport:RAID0,1,1E,5,6,10,and
RAID50(Pegasus2R6/R8only)
RAID 60 (Pegasus2 R8 only)
OS Support MacOSX10.8orhigher.MacBookPro/iMac/MacBookAir/MacMini
Hardware
monitoring
Fan,Temperature,Power,Enclosure,Physicaldrives,Logicaldrives,RAIDcontroller
Temperature Operating:5°~35°C
Non-operating:-40°~70°C
Humidity Operating:10%~95%non-condensing
Storage:5%-95%non-condensing
Dimensions R8:315x187x235mm(12.6x7.4x9.3in)
R6:250x187x235mm(9.8x7.4x9.3in)
R4:195x187x235mm(7.7x7.4x9.3in)
Weight Asshippedwithall3.5”HDDinstalled:
R8: 6.4 kg
R6:5.25kg
R4: 4.3 kg
Certication Safety:UL/CSA/CE/TUVEMI:CB-EMC,FCC,CE-EMC,VCCI/PSE,BSMI,
C-tick/RCM
Environmental:EuPDirectiveN,ROHS,WEEESafety:CB,UL,cUL,CE-LVD,PSE,
BSMI, RCM
speCifiCAtions
3
Promise Technologies

hArdwAre
This section provides a brief introduction to the external hardware of the Pegasus2 R4. R6 and R8. The
R6andR8aretallersincetheyhavemoreharddiskcarriers.Forthepurposeofinstallationtheyare
nearly identical.
LED Description
System Status* TheSystemStatusLEDlocatedonthePowerbuttonlightsbluewhenthePegasus2
isoperatingnormally.Whenthesystemisbootingup,thislightsorangeandwilllight
bluewhenfullybootediftherearenoproblemsdetected.AredSystemStatusLED
indicates a serious problem such as an incomplete array or failed hard disk drive.
Thunderbolt Link These light blue when the Thunderbolt cable is connected, they remain dark when
there is no link.
Drive Status and
Activity*
TheDriveStatusLEDlightsbluewhenaphysicaldriveispresentandfunctioning
normally.AredDriveStatusLEDindicatesaproblemwiththephysicaldriveoran
array.TheDriveActivityLEDlightsbluewhenthephysicaldriveispresentandblinks
blue when there is activity on the drive.
* See “CheckingLEDs”onpage119formoredetailsaboutusingLEDindicatorsfortroubleshooting.
Thunderbolt
Link LEDs DriveStatus LED
Power Button
/ System Status
LED
Drive Activity LED
Drive Carrier
Pegasus2 R4 front view
4
Pegasus2 R4/R6/R8 Product Manual

Feature Description
Thunderbolt Ports Use a Thunderbolt cable to connect the Pegasus2 to a Thunderbolt ready computer.
This connection completes the physical link, it is the path through which the SATA
link is established.
Cooling Vents The cooling vents on the back should be clear and unobstructed to allow proper
airowfordiskandsystemcooling.Notethattheairintakeventslocatedonthefront
of the enclosure should also be unobstructed.
Power Receptacle Use only the power cord shipped with the device to connect the power. Insert one
end of the power cord into the power receptacle and insert the other end into a
suitable power source such as a wall outlet or a power strip.
Note
As far as the location of the Thunderbolt ports is concerned, the back of the R4, R6
and R8 are identical, i.e. near the top and left of center. The power connection is in
the lower right corner on both devices.
Power
Connection
Thunderbolt Ports
Pegasus2 R4 back view
5
Promise Technologies

instAllAtion And setuP
This chapter contains the following topics:
• “Packing List” on page 7
• “Connect the power cord” on page 8
• “Connect Pegasus2 to your Mac” on page 9
• “Installing the Software” on page 10
• “Power modes on the Pegasus2” on page 13
• “Shutting down the Pegasus2” on page 13
CAUTION
The electronic components within the Pegasus2 unit are sensitive to damage from
Electro-Static Discharge (ESD). Observe appropriate precautions at all times when
handling the Pegasus2 unit or its subassemblies.
WARNING
Thefancontainshazardousmovingparts.Keepngersandotherbody
parts away.
6
Pegasus2 R4/R6/R8 Product Manual

PAcking list
Check the shipping package to make sure you have the following items:
• Pegasus2 R4, Pegasus2 R6 or Pegasus2 R8
• Hard disk drives (four in R4, six in R6, eight in R8)
• Quick Start Guide
• Thunderboltcable
• Power cord
summAry of the setup proCedure
The setup procedure for the Pegasus2 is simple and easy. The device is shipped with hard disk drives
installedandaRAIDarraycongured,soitisjustnecessarytoplugitinandconnectthedevice.
However you should install the PROMISE Utility software used for monitoring and administration of the
system. Please follow the setup procedure here or in the Quick Start Guide.
Thesetupprocessissummarizedbelow.
1. Unpack the Pegasus2 shipping package
2. Connect the power cord and power on the Pegasus2 R4/R6/R8.
3. ConnectthePegasus2toyourMaccomputerwithaThunderboltcable.
4. Find the Pegasus2 Utility installation package located on the device (Pegasus2 is shipped with
RAID5conguration)andinstallthemanagementsoftwareutility.
7
Promise Technologies

connect the Power cord
To connect the power cord the Pegasus2 unit:
1. AttachthepowercordonthebackofthePegasus2unit.See“Thunderboltandpower
connections”below.
2. Plugtheotherendintoasuitablepowersource.
Thunderbolt and power connecons
Thunderbolt ports
Pegasus2 system
MacBook Pro
(shown as an example)
Thunderbolt port
To power source
Power cable
Thunderbolt cable
8
Pegasus2 R4/R6/R8 Product Manual

connect PegAsus2to your mAc
ToestablishtheThunderboltconnection:
1. ConnectaThunderboltcablefromoneoftheThunderboltportsonthebackofthePegasus2to
theThunderboltportonyourMaccomputer.See“Thunderboltandpowerconnections”onpage
8.
2. If the Pegasus2 is plugged into a power source and the Mac is running, the Pegasus2 will power
onandbegintobootup.See“Power modes on the Pegasus2” on page 13 for information on
powerupandshutdownbehavior.
You will notice the following:
• ThePowerButtonLEDlightsorangeatrst,thenblue.
• ThedrivecarrierPower/StatusLEDslightblue.
• TheThunderboltLinkLEDfortheportconnectedtotheMaclightsblue.
See “Pegasus2 R4 front view” on page 4 for illustration of the front of the device.
• The“PROMISERAID”storagedriveicon(seepicturebelow)appearsonyourdesktop.
This indicates the Pegasus2 is ready for use.
Note
If the Thunderbolt cable is connected to a Mac that is running, the Pegasus2 will
power up as soon as the power is connected. This is a new feature for the Pegasus2.
Note
When the device is powered on by connecting the Thunderbolt cable, or by pressing
the Power Button, the Power Button turns orange. It takes about 30 seconds to start
the Pegasus2 unit.
9
Promise Technologies

instAlling the softwAre
ThePegasus2unitshipsreadytousewithoutcongurationorset-up.Howeveritisagoodidea
to install the PROMISE Utility software even if you do not plan to make any changes to device
conguration.Theutilityisusefulformonitoringthesystemandgettingrmwareupdates.
TheutilityisnecessaryifyouplantochangethedefaultRAIDconguration(Pegasus2isshippedwith
a RAID 5) or if you will swap out any of the hard disks shipped with the device.
ThesoftwareutilityinstallationpackageislocatedonthePegasus2.Followtheinstructionsbelowto
install the utility.
To install the Pegasus2 Software Utility:
1. Double-clickonthePegasus2icononyourdesktoptoviewthedevicecontents.
See example to right.
2. Findthele“R_PROMISE_Utility_318000018.dmg”anddouble-clickonittomountthevirtual
drive containing the installation software package.*
3. Double-clickonthePROMISE_Utility_318000018.pkgletobeginthesoftwareinstallation.*
* Theversionnumberofthe.dmgleand.pkglewillchangeasitisupdated.Theversionnumberused
inthisexampleisjustforthepurposeofillustration.
10
Pegasus2 R4/R6/R8 Product Manual

TheWelcomemenuexplainsthatsoftwarewillbeinstalledontheMac.ClicktheContinue
buttontoproceedwithinstallation.
4. The Software License Agreement appears, please read the statement and click Continue to
proceed.
5. Click Agree if you agree to the terms of the license. To read the license, click Read License.
Choose Disagree if you do not agree the terms, in which case the installation procedure is
terminated.
6. If you clicked Agree in the previous menu, the software is now ready to install. Click Install to
begin.
11
Promise Technologies
