Prorack K137 Operation and installation manual

K137
Fitting Kit
EN Fitting Instructions for Basic Carrier
x 2 x 2 x 4 x 4
x 4 x 4
Revision No: 6F 1

Fitting Kit K137
MAX kgs (lbs)
W/P WHD
Nissan
Almera, 4dr Sedan 00-06 ZA 60 kgs (132 lbs) 60 kgs (132 lbs)
Almera, 4dr Sedan 00-06 EU 60 kgs (132 lbs) 60 kgs (132 lbs)
Pulsar N16, 4dr Sedan Jun 00-Jan 06 AU 60 kgs (132 lbs) 60 kgs (132 lbs)
Pulsar, 4dr Sedan 00-06 NZ 60 kgs (132 lbs) 60 kgs (132 lbs)
Sunny, 4dr Sedan 98-07 NZ 60 kgs (132 lbs) 60 kgs (132 lbs)
Sunny, 4dr Sedan 99-07 EU 60 kgs (132 lbs) 60 kgs (132 lbs)
2

Fitting Kit K137
X
A B C 1 2 3
Almera, 4dr Sedan 00-06 (ZA) - - - - - -
- - - - - -
Almera, 4dr Sedan 00-06 (EU) - - - - - -
- - - - - -
Pulsar N16, 4dr Sedan Jun 00-Jan 06 (AU) - - - - - -
- - - - - -
Pulsar, 4dr Sedan 00-06 (NZ) - - - - - -
- - - - - -
Sunny, 4dr Sedan 98-07 (NZ) -300mm 300mm - 740mm 706mm -
-11 -13/16ths" 11 13/16ths" - 29 1/8ths" 27 13/16ths" -
Sunny, 4dr Sedan 99-07 (EU) -300mm 300mm - 740mm 706mm -
-11 -13/16ths" 11 13/16ths" - 29 1/8ths" 27 13/16ths" -
3

Fitting Kit EN
K137
First Time Installation
●Remove parts from inside the package and
check. Contact your dealer if any parts are
missing or damaged.
●This kit fits type A, B, C and D.
●These instructions show type A crossbar
fitted. They also apply to type B, C and D.
NOTE: Clamp images in these instructions may
not be representative of the clamps in this kit
4

Fitting Kit EN
K137
●Use keys to remove covers.
●Use hex screwdriver to reverse adjusting
screw 10 turns.
●Press adjusting screw and pull crossbar
legs out. Refer to the crossbar instructions
for crossbar adjustment method.
●Ensure each end of the crossbar is
adjusted equally.
5

Fitting Kit EN
K137
●Remove locking screw.
●Apply protective strip as shown.
Trim if required.
●A = Clear
B = Grey
C = Black
●Letters refer to the part numbers stamped
on clamps.
●Clamp Part Number:
A = 341A
B = 342A
6

Fitting Kit EN
K137
●Attach clamp to each leg. NOTE; clamps
may have labels showing their positions on
the vehicle (For example; "Front Right").
●Refit locking screw so that it goes through
the hole in the clamp. Do not begin to
tighten the locking screw.
●Fit rubber pads (supplied with fitting kit) to
foot.
7

Fitting Kit EN
K137
●Make sure the pad fits into the holes
underneath the foot.
Fitment
●Place crossbar on vehicle. Minimum
recommended spacing between the bars is
700mm (27 1/2") (unless otherwise stated).
●Clamps over rubber door frame mouldings.
●Please check the front of this manual for
information relating specifically to your
vehicle.
●Adjust the legs on the crossbar so that they
are positioned equally from the ends of the
crossbar, and the clamps engage firmly on
the body work of the vehicle.
8

Fitting Kit EN
K137
●Tighten adjusting screw to 5 Nm (3.7 ft lb)
hand tight.
●Tighten locking screw on both legs evenly.
●Check crossbar is securely attached to the
vehicle.
9

Fitting Kit EN
K137
●Use keys to fit and lock covers
CAUTION: Recheck all fasteners immediately after
a load is applied to the crossbars.
Regularly check screws are tight.
