protech QC8718 User manual

Inspection
Camera
with Record/Snapshot Function
User Manual
QC8718
TECHNICIAN

1
INTRODUCTION:
ATTENTION:
PACKAGE CONTENTS:
1. Inspection Camera Carry Case
2. Inspection Camera Unit
3. Camera Attachments
• Mirror • Single Hook • Magnet
1. Please pay attention to the camera lens. Excessive force or vibration may
damage the lens and the camera itself.
2. The camera tube is waterproof while the receiver is not. Please protect it
from water and moisture.
3. When the product is not in use, remove the battery.
This Inspection Camera is suitable for the inspection of pipelines, narrow
spaces, installation of equipment or xtures, vehicle maintenance and or any
other narrow space with limited visibility.
Notice
Prior to the rst use of this product, please carefully read this manual to avoid
any damage caused by error or improper use.
1. 2. 3.

2
FEATURES:
• 4.3” LCD screen.
• High resolution 1280 by 720 pixels CMOS sensor.
• Video snapshot and recording.
• 50° optical lens.
• Mini 5.2mm waterproof camera.
• IP67 rated camera & cable.
• 90cm exible camera cable.
• Camera head attachments including magnetic tip, mirror tip and hook.
PRODUCT STRUCTURE:
Micro SD Card Slot
Playback/Delete
90cm Flexible
Extended Tube
4.3” LCD screen
Power On/O
Screen
Brightness
Adjustment
USB Interface
Snapshot/Record
Zoom/Switch
from Colour to
Black & White
LED Brightness
Adjustment
Mini 5.2mm
Waterproof Camera

3
PREPARING THE UNIT FOR FIRST USE:
CAMERA ACCESSORY INSTALLATION:
POWERING THE UNIT ON/OFF:
Rear Battery
Compartment
Cover
1. Open the back cover of the battery compartment
2. Insert the 4x AA Batteries (Not included).
3. Close the back cover.
4. Pull out the cable to the required length.
5. Press and hold the Power Button to turn it on.
1. Power On: Press and hold the power button until the screen lights up.
2. Shutdown: Press and hold the power button until screen has turned o.
Slide an attachment over the base of the camera and gently squeeze the
black mounting module at the bottom of the attachment until hooked.

4
SNAPSHOT & RECORDING
VIEWING PHOTOS AND PLAYBACK VIDEOS
1. Snapshot: Quick press of the Snapshot/Record button.
2. Record: Press & hold the Snapshot/Record button until it begins recording.
1. View photos or videos: Quick press of the Playback/Delete Button.
2. Scroll through Gallery: In the Album Mode, use the Snapshot/Record
Button as “Up” and LED Brightness Adjustment Button as “Down”.
3. Playback Videos: Quick press of the Screen Brightness Adjustment Button
Snapshot/Record
Snapshot/Record
Note:
Before recording,
please format your
Micro SD Card on your
computer.
When formatting your
card, set the cluster
size to 64KB. The
maximum guaranteed
supported SD card size
is 32GB. The product
can work with higher
capacity high quality
SD cards.
Note:
To delete photos or
videos, Press & hold the
Playback/Delete button.
Playback/Delete
Screen
Brightness
Adjustment
LED Brightness
Adjustment

5
ZOOM & COLOUR MODES:
FLIP & MIRROR:
1. Zoom: Quick press of the Zoom/Colour Switch button.
Each press toggles through 1x, 1.5x, 2x zoom modes.
2. Colour Modes: Press & hold the Zoom/Colour Switch button and it will
change to display in “black/white”. To switch back to “colour” Press & hold
the Zoom/Colour Switch button again.
The Flip & Mirror option allows you to rotate and ip the video.
Press & hold the Screen Brightness Adjustment Button to toggle through 4 modes.
Screen
Brightness
Adjustment
Zoom/Switch
from Colour to
Black & White
Normal Mirror Normal
Upside Down
Mirror
Upside Down

6
SPECIFICATIONS:
* Can work with larger capacity High Quality SD Cards.
Camera
Diameter Of Camera Head Ø 5.2mm
Image Sensor CMOS
Eective Pixel 1280 x 720 pixels
Waterproof Level IP67
Monitor
Display Size 4.3" TFT LCD monitor
Screen Resolution 480 x 272 pixels (RGB)
Micro SD card support capacity 2 ~ 32GB*
Image Zoom 2x variable digital zoom
Photo Format .JPG
Video Format .AVI
Interface Micro USB
Power Supply 4x AA Batteries (Not included)
Power Consumption 360mA (MAX)
Operation Temperature -10 ~ +50"C
Storage Temperature -20 ~ +60"C
Operation Humidity 15% ~ 85%RH

Distributed by:
Electus Distribution Pty. Ltd.
320 Victoria Rd, Rydalmere
NSW 2116 Australia
www.electusdistribution.com.au
Made in China
