Prowinch PWJTHF User manual

®
Reg. U.S. TM. O.
User’s Manual / Manual de usuario
Safety Warnings / Advertencias de seguridad
PWJTHF & PWJTHT Single phase models

This page intentionally left blank

Version 1.0
3Disclaimer
3
Prowinch® LLC declares that it has made all safety recommendations related to the purchased product
to the customer. As a result, it does not assume any responsibility for any damages or losses that the
client or third parties may suffer. These can be caused by or as a direct or indirect result of a breach or
omission of instructions or safety warnings in the User Manual and Security Warnings provided with the
unit purchased. Prowinch® LLC will not be liable for accidents and/or damages to persons and/or
property resulting from the negligent use of the product. In no case does Prowinch® LLC assume any
liability arising from using these voluntary recommendations and does not offer any guarantee
concerning them. These recommendations do not take precedence over the current safety regulations
of the plant. For purposes of enforcing the warranty of the product purchased, Prowinch® LLC, will only
be liable for any damage when proven the user has followed each one of the warnings contained in the
User Manual and Safety.
1. It is the sole responsibility of the Client / User to verify that the acquired equipment, products, and
accessories comply with the characteristics, capacities, requirements, components, accessories, and
other conditions for the use that the Client/user intends to give it.
2. It is also the sole responsibility of the Client / User to ensure that the equipment and products
purchased are operated and maintained with adequate safety standards and by personnel properly
trained in their use. The Client / User is also responsible for implementing all security measures
necessary to prevent accidents or damages to people or property and for following the indications and
warnings of the corresponding manual.
3. Any assistance provided by Prowinch® LLC in selecting the equipment, capacities, and characteristics
required by the client is delivered free of charge and based on the information about the application,
use, and requirements provided by the client. It is not the responsibility of Prowinch® LLC to verify the
accuracy of the given information. It is the sole and exclusive responsibility of the client -or who will use
the equipment and products acquired- to ensure that the specifications comply with the capabilities,
characteristics, up-to-date maintenance, and everything necessary for a correct and safe operation
about the intended use.
4. Prowinch® LLC recommends using winches with four brakes for personnel lifting. The use of winches
with three brakes or less, or operating with safety standards less than required for personnel lifting is
not recommended.
5. To guarantee the safety of the equipment's operators, it is necessary to conduct inspections and
maintenance of the equipment according to the recommended frequency of its work cycle. It is
mandatory to keep records and evidence, including written and photographic reports of: Maintenance, Start-
up, Load Tests, Training, Certifications, Inspections, and Reports of failures and accidents.
6. The reports mentioned above must be emailed to [email protected] within the first seven calendar
days after an event.
7. Compliance with timely implementation of mandatory activities described in points 6 and 7, in
addition to all the activities mentioned in the corresponding guidelines, are the user's sole responsibility.
Failure to comply with the preceding conditions releases Prowinch® LLC from any liability. The
information contained in this manual may contain technical errors or inaccuracies. Prowinch® LLC is not
responsible for errors, omissions, or incorrect information. This manual is subject to change without
prior notice. Download the latest version available at www.prowinch.com. Always check
www.prowinch.com for the latest information regarding this product. Please check our warranty policies on
our website www.prowinch.com/warranty.
PROPERTY REGISTRY Nº 189487
ANY REPRODUCTION IS FORBIDDEN
PROPERTY OF PROWINCH® 2022 - V8.0 ALL RIGHTS RESERVED
PROWINCH LLC COMPANY WITH QUALITY MANAGEMENT SYSTEM
PROWINCH® DISCLAIMER
V.07.22 [LA]

4
4
Hoists, Cranes, and other Lifting and material-movement-related equipment users must be
knowledgeable about the safe and proper use of this equipment and be aware of their responsibilities
as outlined in all applicable standards and regulations.
The ASME/ANSI B30 Standard contains provisions for the construction, installation, operation,
inspection, testing, maintenance, and use of cranes and other lifting and material-movement-related
equipment.
As OSHA’s, ASME, and ANSI standards state, a qualified person shall perform the installation, setup,
and operation of these units and equipment.
OSHA requires rated load tests for new and altered cranes. OSHA’s standard at 29 CFR 1910.179(k)
states:
Operational tests.
Before initial use, all new and altered cranes must be tested to ensure compliance with this section,
including the following functions:
Hoisting and lowering.
Trolley travel.
Bridge travel.
Limit switches, locking, and safety devices.
The trip setting of hoist limit switches shall be determined by tests with an empty hook traveling at
increasing speeds up to the maximum speed. The actuating mechanism of the limit switch must be
located so that it will trip the switch, under all conditions, in sufficient time to prevent contact of the
hook or hook block with any part of the trolley.
Rated load test. Test loads shall be at most 125 percent of the rated load unless otherwise
recommended by the manufacturer. Once you have performed a rated load test, paragraph
1910.179(k)(2) requires that test reports be placed on file where readily available to appropriate
personnel.”
To ensure safety and installation requirements, Prowinch requires a Load Test to be performed before
initial use for all Hoists, Winches, and Cranes, as well as other related components. Not fulfilling this
requirement is dangerous, could lead to equipment failure, and will automatically void the warranty.
The B30 Standard is intended to:
(a) Prevent or minimize worker injury and otherwise provide for protecting life, limb, and property
by prescribing safety requirements.
(b) Provide direction to manufacturers, owners, employers, users, and others responsible for proper
application.
Safety Bulletin

5
5
(c) Guide governments and other regulatory bodies in developing, communicating, and enforcing
appropriate safety directives. The equipment covered by the B30 Standard is subject to hazards that
cannot be reduced by mechanical means but only by the exercise of intelligence, care, and common
sense. It is essential to have personnel involved in the use and operation of equipment that is
competent, careful, physically, and mentally qualified, and trained in the proper operation of the
equipment and the handling of loads. Serious hazards include, but are not limited to, improper or
inadequate maintenance, overloading, dropping, or slipping of the load, obstructing the free passage of
the load, and using equipment for a purpose for which it was not intended or designed.
Failure to Read, understand and follow the corresponding ASME B30 Standard information for your
Hoist and Lifting equipment may result in severe INJURY or DEATH. It is YOUR RESPONSIBILITY
to consider all risk factors and follow all the equipment-related ASME B30 standard, which comprises
the following volumes:
B30.1 Jacks, Industrial Rollers, Air Casters, and Hydraulic Gantries.
B30.2 Overhead and Gantry Cranes (Top Running Bridge, Single or Multiple Girder, Top Running
Trolley Hoist).
B30.3 Tower Cranes.
B30.4 Portal and Pedestal Cranes.
B30.5 Mobile and Locomotive Cranes.
B30.6 Derricks.
B30.7 Winches.
B30.8 Floating Cranes and Floating Derricks.
B30.9 Slings.
B30.10 Hooks.
B30.11 Monorails and Underhung Cranes.
B30.12 Handling Loads Suspended From Rotorcraft.
B30.13 Storage/Retrieval (S/R) Machines and Associated Equipment.
B30.14 Side Boom Tractors.
B30.15 Mobile Hydraulic Cranes.
B30.16 Overhead Hoists (Underhung).
B30.17 Overhead and Gantry Cranes (Top Running Bridge, Single Girder, Underhung Hoist).
B30.18 Stacker Cranes (Top or Under Running Bridge, Multiple Girder With Top or Under Running
Trolley Hoist).
B30.19 Cableways.
B30.20 Below-the-Hook Lifting Devices.
B30.21 Lever Hoists.
B30.22 Articulating Boom Cranes.
B30.23 Personnel Lifting Systems.
B30.24 Container Cranes.
B30.25 Scrap and Material Handlers.
Safety Bulletin

6Safety Bulletin
6
DO NOT
DAILY CHECKLIST
1. DO NOT Operate, install, or repair the hoist unless trained and authorized.
2. DO NOT Operate the hoist unless you have first read the operator’s manual.
3. DO NOT Operate the hoist without appropriate PPE and without performing a pre-shift
inspection.
4. DO NOT Operate the hoist if not complying with all required OSHA regulations.
5. DO NOT Lift more than the rated load.
6. DO NOT Lift people or lift loads over people.
7. DO NOT Wrap the hoisting rope or chain around the load.
8. DO NOT Operate with the chain/rope not properly seated in the sprockets, drum, or sheave.
9. DO NOT Operate unless the direction of the hook travel agrees with the direction shown on the
control.
10. DO NOT Operate the hoist unless the hook travel limit devices function properly.(Test without
a load PRE-SHIFT )
11. DO NOT Operate the hoist with twisted, kinked, damaged, dirty, or unlubricated chain or
rope.
12. DO NOT Operate a damaged or malfunctioning hoist.
13. DO NOT Operate the hoist when the hook is not centered under the hoist
14. DO NOT Remove or obscure this tag or other WARNING & SAFETY LABELS.
B30.26 Rigging Hardware.
B30.27 Material Placement Systems. B30.28
Balance Lifting Units. B30.29 Self-Erecting
Tower Cranes. B30.30 Ropes.
TAGGED HOIST: Ensure the crane or hoist is not tagged out of order.
CONTROL DEVICES: Test Run. Ensure all motions agree with control device mark-ing.
BRAKES: Check all motions for excessive drift and abnormal stopping distances.
HOOK: Check for damage, cracks, nicks, gouges, deformations on throat opening, wear on saddle or
load-bearing point, and twist.
HOOK LATCH: Check for proper operations.

7
7
WIRE ROPE: Check for broken wires, broken strands, kinks, and deformation or damage to the
rope structure.
CHAIN: Check for corrosion, wear, elongation, twist, nicks, or gouges. Keep Chain/Wire Rope
Clean and Lubricated.
REEVING: Check the rope for proper reeving and that rope parts are not twisted.
LIMIT SWITCHES: Ensure that all limit devices stop lifting motion before the load block or chain/
rope stop strikes the hoist.
OIL LEAKAGE: Check for any signs of oil leakage on the crane/hoist and the floor. UNUSUAL
SOUNDS: Check for unusual sounds from the hoist while operating.
WARNING & SAFETY LABELS: Ensure that labels are not missing and they are legible.
Safety Bulletin

Version 1.0 Version 1.0
Index 8
8
Version 1.0
Disclaimer ................................................................................................................................................................................................ 3
Safetu bulletin......................................................................................................................................................................................... 4
Safety Precautions ................................................................................................................................................................................... 10
Hoist Safety Precautions ......................................................................................................................................................................... 11
Before Using the equipment ................................................................................................................11
During Operation ..................................................................................................................................12
Inspection, Maintenance and repairs ..................................................................................................12
Specications ........................................................................................................................................................................................... 15
Product Code .........................................................................................................................................15
Specication Chart ................................................................................................................................15
Load Level and Service Life ..................................................................................................................16
Fixed Hoist Specications .....................................................................................................................17
Trolley Hoist Specications ..................................................................................................................18
Hoists Dimensions .................................................................................................................................18
Oil & Lubricant Recommendations .......................................................................................................21
Installation ................................................................................................................................................................................................ 22
Installation .............................................................................................................................................22
Unpacking ..............................................................................................................................................22
Chain Bag Assembly ..............................................................................................................................23
Electrical Connections ...........................................................................................................................24
Install Trolley (models with trolley) ......................................................................................................26
Adjust Trolley Width (models with trolley) ..........................................................................................26
Install Trolley into Beam (models with trolley) ....................................................................................26
Supply Voltage .......................................................................................................................................26
Operation ................................................................................................................................................................................................... 27
Qualied Operator ................................................................................................................................27
Handling Precautions ...........................................................................................................................27
Recommended Operation ....................................................................................................................28
Parts ............................................................................................................................................................................................................ 30
Exploded view and parts list .................................................................................................................31
Motor and body assembly drawing ......................................................................................................31
Motor and body assembly parts list .....................................................................................................31
Trolley assembly drawing ......................................................................................................................33
Trolley assembly parts list .....................................................................................................................34
Inspection & Maintenance ........................................................................................................................................................................ 35
Operation ...............................................................................................................................................35
Periodic Inspection ...............................................................................................................................35
Troubleshooting ....................................................................................................................................................................................... 39
During operation ..................................................................................................................................39
Power Cable ...........................................................................................................................................41
Motor ......................................................................................................................................................41
Brake ......................................................................................................................................................42
Inside Wiring ..........................................................................................................................................42
Transformer ...........................................................................................................................................43
Contactor & Electric Reply ....................................................................................................................43
Limit switch ............................................................................................................................................44
Push Button switch ...............................................................................................................................44
Electric shock .........................................................................................................................................45
Hook .......................................................................................................................................................46
V.07.22 [LA]

Version 1.0
9Index
9
Load Chain .............................................................................................................................................46
Chain Wheel ...........................................................................................................................................47
Load pulley and empty pulley ..............................................................................................................47
Chain guide ............................................................................................................................................47
Chain wheel, junction part ...................................................................................................................47
Bearing ...................................................................................................................................................47
Trolley .....................................................................................................................................................48
Electric Trolley ........................................................................................................................................48
Manual Trolley ........................................................................................................................................44
Wiring Diagram .......................................................................................................................................................................................... 49
Conventional Hoist wiring diagram (PWJTHF-PWJTHT) .....................................................................49
V.07.22 [LA]

Version 1.0
10
Version 1.0
Safety Precautions 10
Thank you for purchasing our Prowinch® Electric Chain Hoist. This User Manual provides
important information for personnel involved with the installation, operation, and
maintenance of this product. Read this User Manual before installing, operating, or
maintaining the product.
1. SAFETY PRECAUTIONS
Mandatory use of:
Hard Hat Safety Glasses Safety Gloves Safety Shoes
Version 1.0
V.07.22 [LA]
•Prowinch® Electric Chain Hoist is designed for safe and reliable service if operated according to this
User Manual.
•Respect all warnings for personal and third-party safety. The inadequate operation of this equipment
may cause injuries or damage to the equipment.
•Read and understand this User Manual carefully before installation and commission of equipment.
•Always keep this User Manual in an accessible location.
•With compact structure, lightweight, and ease of use, PWJTHF and PWJTHT models are preferred
hoists for daily use in factories, mines, seaports, and warehouses.
•Hoists misused may harm users and result in wounds, injuries, or death. This User Manual highlights
symbols and notes for caution, warning, and danger. Attention to these areas ensures the safety of
the operator.

Version 1.0
Version 1.0
11 Safety Precautions
11
1.1. Hoist Safety Precautions
WARNING:
This symbol indicates a dangerous situation which if not avoided may cause minor or
moderate injury. It is also used for indicating unsafe practices.
DANGER:
This symbol indicates a potentially dangerous situation which if not avoided may
cause severe injuries or death
All operators and other users who are near the steel chain or its load must wear
required safety equipment: gloves, safety helmet / hard hat, safety shoes
and eye protection.
Before installing, removing, inspecting, or performing any maintenance on the
hoist, the unit must be unplugged, locked out, and tagged out.
Do not use this equipment in hazardous locations.
•Read and understand the instructions in this User Manual and labels associated with hoist before operating equipment.
•Wear appropriate clothing: Do not wear jewelry or loose clothes as they may attach to chain or hook.
•Wear leather gloves.
•Wear non-slip safety shoes, helmet, and eye protection.
•Perform full check of hoist. Check for damaged parts or unusual characteristics.
•Keep a safe distance: suggested distance is at least 1.5 times the length of hoist’s chain. Broken or loose chain may cause
injuries or death.
•Check hoist and chain are properly lubricated.
•Secure electric chain hoist to a suitable support.
•Visually inspect all electric chain hoists in addition to regular and maintenance inspections.
Read and understand the contents of this User Manual thoroughly before handling the product. Practicing correct and safe
operating procedures and implementing the recommended preventative maintenance will ensure a long, reliable, and safe
service.
After carefully reading and understanding this User Manual, store it for future reference.
1.2. Before using the Equipment:
V.07.22 [LA]

Version 1.0
Version 1.0
Safety Precautions 12
12
1.3. During Operation:
1.4. Inspection, Maintenance and Repairs:
ALWAYS:
•Refer to maximum load capacity displayed on ID plate of
hoist, not capacity of hook.
• Stop operation immediately if unauthorized personnel enter
working area.
• Check state of hoist: If engine overheats, stop hoist and let it
cool for a while.
••Stop, check, and secure load if hoist stops or loses
movement during operation.
• Focus on operation. Always pay attention and keep proper
balance.
• Unplug hoist after operation.
NEVER:
•Never exceed maximum load capacity.
•Never operate damaged or malfunctioning hoist.
•Never operate hoist if behaving unusually.
•Never lift, support, transport people, or lift or support loads over
people.
•Never walk over chain.
•Never operate electric chain hoist with twisted, kinked, damaged
or worn load chain.
•Never use load chain as a sling around load.
•Never operate a hoist if ID plate or safety labels are missing or
illegible.
•Never operate electric chain hoist when exposed to rain or water.
•Never use if operator is unwell or not completely attentive.
•Never leave the hoist unattended while energized or loaded.
•Never operate the hoist with a non-centered load.
•Never operate beyond the limits of the load chain or extend the
chain.
•Never use the load chain or hook as an electrical or welding
ground.
•Never remove the labels placed on the electric chain hoist.
•Never use the hoist to lift the load at an angle, nor pull or drag the
load.
ALWAYS:
•Check stability of electrical connections.
•Check chain and maintain lubrication.
•Prevent others from being beneath load.
•Regularly inspect and maintain hoist.
•Check correct installation of hoist before using.
•Avoid contact with explosive gases or materials.
NEVER:
•Never overload equipment
•Never transport people or animals.
•Never stand below load.
•Never use hoist if exposed to rain, snow, or electrical storm.
•Never leave load suspended for extended period. This may
cause component deformation an accident.
•Never leave loads suspended for an extended time. This
may cause damage to components or accidents.
•Never exceed the allowable operating temperatures stated
in this User Manual (depending on the model).
•Never expose equipment to water, sand, corrosive materials,
or other substances which may damage the equipment.
OVERLOAD
OVERLOAD
OVERLOAD
• Only trained and authorized personnel may perform repairs to the equipment.
• Use only original ProWinch® parts. The use of any other part immediately voids the warranty.
• Failure to use only original ProWinch® parts may create a dangerous condition for the operator.
Version 1.0
V.07.22 [LA]
DO NOT stand
under the load
NO ubicarse
bajo la carga
WARNING
ADVERTENCIA

Version 1.0
Version 1.0
13 Safety Precautions
13
1. Do not overload
.
4. Do not transport people or animals
with a hoist.
7. Inspect and maintain your hoist
regularly.
5. Do not step or walk under lifted load
and prevent others from doing so.
8. Always verify the correct hoist
installation before use.
6. Do not use the hoist if exposed to
rain,
snow or lightning.
2. Check the proper crimp of the
electrical connections.
- 3. Periodically check the chain and keep
it lubricated.
OVERLOAD
9. Do not leave the load lifted for long
periods of time. It may cause deformation
of the equipment and increase the risk
of an accident.
Oil
V.07.22 [LA]

Version 1.0
Version 1.0
Safety Precautions 14
14
Do not exceed the operating temperatures for
which the hoist is designed. This range is indicated in
this manual and may vary depending on the model.
Exposure to water, sand, a corrosive environment, or other potentially
harmful elements may damage the equipment.
Avoid contact with gases or explosive materials.
Warning:
V.07.22 [LA]

Version 1.0
15 Specications
15
2. SPECIFICATIONS
2.1. Product Code.
2.2. Specication Chart (For all models of Prowinch® Electric chain hoists).
Observations
Do not use Prowinch® Electric Chain Hoists when the temperature or humidity exceeds the range stated in the Specication
Chart.
Our hoists are designed to lift loads vertically under normal atmospheric and working conditions.
Item Specs
Operang temperature range (°C) -20° to ± 40°
Operang Humidity Range (%) < 85%
Protecon Class Hoist IP55
Buon Switch IP55
Power 1 Phase, 120V @ 50/60Hz
Noise Level (db) Single Speed Hoist 81db
Double Speed Hoist 81db
V.07.22 [LA]

Version 1.0 Version 1.0
Specications 16
16
2.3. Load Level and Service Life
Hoist
Duty
Class
Typical Areas of Applicaon
Operaonal Time Rangs at K = 0.65
Uniformly Distributed
Work Periods
Infrequent Work
Periods
Max. On
Time,
min/hr
Max. No.
Starts/hs
Max.
No. Time
From Cold
Start
Max. No.
of Starts
H1
Powerhouse and utilities with infrequent handling. Using
hoists primarily to install and service heavy
equipment, where loads frequently approach rated load
and where the hoist is idle for a 1 to 6-month
period between operations.
7.5
(12.5%) 75 15 100
H2
Light machine shop, fabricating service, and maintenance
use. Loads and utilization are distributed
randomly. Rated loads are infrequently handled—total
running time is less than 12.5% of the work period.
7.5
(12.5%) 75 15 100
H3
General machine shop, fabricating, assembly, storage,
and warehousing. Loads and utilization are
randomly distributed. Total running time is at most 25%
of the work period.
15 (25%) 150 30 200
H4
High-volume handling of heavy loads: frequently near
rated loads such as steel warehousing, machine
and fabricating shops, mills, and foundries, with a total
running time of not more than 50% of the work
period. Manual or automatic cycling of lighter loads with
rated loads infrequently handled, such as in heat
treating and plating operations, with total running time
frequently 50% of the work period.
30 (50%) 300 30 300
H5
Bulk handling of material in combination with buckets,
magnets, or other heavy attachments. Equipment
is often cab operated. Duty cycles approaching continuous
operation are frequently necessary. The user
must specify the exact details of the process, including the
weight of the attachments.
60 (100%) 600 N/A N/A
V.07.22 [LA]

Version 1.0
17 Specications
17
2.4. Fixed Hoist Specications
Working Condions Load Time
Maintenance
Interval
(Months)
Expected Life [Working Hours]
800 1600 3200 6300 12500
Light 6 - 12 H1 H2 H3 H4 H5
Normal < 65% < 25% 6 - 12 H2 H3 H4 H5
Heavy
Mechanisms are usually subjected to heavy
loads and frequently to the maximum load. > 65% > 25% 3 - 6 H3 H4 H5
Severe
Abnormal condions Envi-
ronmental, Geographical,
etc <100% < Duty Cycle
Limit
1 - 3 H4 H5
Specicaons Model
PWJTHF300 PWJTHF500 PWJTHF800
Capacity (lb) 300 500 800
Liing Speed (/min) 14 7 7
Motor Power (W) 160 160 200
Insulaon Grade IP55
Power Supply 120VAC
Control Voltage 120VAC
No. Chain falls 122
Spec. of Load Chain 5x15 5x15 5x15
Net Weight (lb) 28 40 40
Basic Dimensions
(in)
H5.4 5.4 5.7
A15 16 16.7
B14 14 14.0
D4.3 4.3 4.3
E2.8 2.8 2.8
V.07.22 [LA]
Mechanisms are regularly subjected to
the maximum load.
Mechanisms are generally subjected to moderate
loads and frequently to the maximum load.
Light mechanisms are typically subjected to light
loads and rarely to the maximum load.

Version 1.0 Version 1.0
Specications 18
18
2.5. Trolley Hoist Specications
2.6. Hoists Dimensions
Specicaons Model
PWJTHT300 PWJTHF500 PWJTHT800
Capacity (lb) 300 500 800
Liing Speed (/min) 14 7 7
Motor Power (W) 160 160 200
Insulaon Grade IP55
Power Supply 120VAC
Control Voltage 120VAC
No. Chain falls 122
Spec. of Load Chain 5x15 5x15 5x15
Net Weight (lb) 28 40 40
Basic Dimensions
(in)
H5.4 5.4 5.7
A15 16 16.7
B14 14 14.0
D4.3 4.3 4.3
E2.8 2.8 2.8
Model Dimension (in)
A B C D E F GH L KMN
PWJTHF300 14.5 14.1 6 4.3 2.8 7.9 3.0 5.5 1.4 / 0.91 1.0
PWJTHF500 16.0 14.1 6 4.3 2.8 7.9 3.0 5.5 1.4 / 0.91 1.0
PWJTHF800 16.7 14.1 6 4.3 2.8 7.9 3.0 5.7 1.5 / 0.98 1.1
PWJTHT300 14.5 14.1 6 4.3 2.8 7.9 3.0 5.5 1.4 / 0.91 1.0
PWJTHT500 16.0 14.1 6 4.3 2.8 7.9 3.0 5.5 1.4 / 0.91 1.0
PWJTHT800 16.7 14.1 6 4.3 2.8 7.9 3.0 5.7 1.5 / 0.98 1.1
V.07.22 [LA]

Version 1.0
19 Specications
19
V.07.22 [LA]

Version 1.0 Version 1.0
Specications 20
20
V.07.22 [LA]
