Pullman A-031b User manual

15L WET & DRY JANITOR
VACUUM CLEANER
1000W
IDEAL FOR:
Restaurants
Cafes
Motels & Hotels
School
A- 0 31b

Always switch off the cleaner and remove the plug from the electricity power supply before cleaning
your appliance, when not in use or attempting any maintenance task. The cleaner must only be
connected to an AC power supply at the voltage shown on the rating label. This cleaner should only be
used for its intended purpose as described in this instruction manual.
Never operate the vacuum cleaner without filters.
SAFETY PRECAUTIONS AND WARNING:
IMPORTANT
WHEN USING YOUR VACUUM CLEANER, BASIC PRECAUTIONS SHOULD ALWAYS
BE OBSERVED, INCLUDING THE FOLLOWINGS;
1. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
2. Children should be supervised to ensure that
they do not play with the appliance.
3. To prevent electrical shock, do not immerse
the top cover of the appliance, power cord or
power plug into water or other liquids.
4. To prevent electrical shock, do not use the
vacuum cleaner outdoors.
5. Always check the power cord before use, the
power cord and the plug should be in a good
condition and must not be damaged. If the
power supply cord is damaged or defective,
it must be replaced by the manufacturer, its
service agent or similarly qualified persons in
order to avoid a hazard.
6. Do not unplug by pulling on the power cord.
To unplug, grasp the plug not the power cord.
Use only Australian and New Zealand electrical
safety approved extension cords.
7. Do not pull or carry the appliance by the power
cable, use the power cable as a handle or
pull the power cable around shaft edges or
corners. Avoid running the appliance over the
power cable.
8. Ensure the appliance is switched off before
unplugging.
9. Do not handle or operate the appliance
with wet hands and follow electrical safety
precautions at all times.
10. Extreme caution should be exercised when
using the appliance on stairs.
11. Do not attempt to change the attachments
while the appliance is plugged in to Mains
power supply. Switch off and remove plug from
Mains power supply. Use only manufacturer’s
recommended accessories.
12. Do not operate the vacuum cleaner too
close to the heaters, radiators and other hot
surfaces.
13. Do not use the appliance to pick up flammable
items or combustible liquids (i.e. gasoline, hot
ashes cigarettes, matches, explosive materials
or anything burning) or use in areas where such
substances and items may be present.
14. Do not use the appliance to pick up toxic
materials (i.e. chlorine bleach, ammonia).
15. Ensure the appliance is disconnected from the
Mains power supply before connecting the
hose to the unit.
16. Before vacuuming, remove any large or shaft
objects from the floor or cleaning surface in
order to prevent damage to the filter.
2

1. Do not operate the vacuum cleaner too close to heaters, radiators, and other
hot surfaces.
2. Before inserting the plug into the wall, make sure your hand is dry.
3. Before turning on the vacuum cleaner, remove any large or sharp objects from
the floor or cleaning surface in order to prevent damage to the filter.
4. When you want to pull the plug from the wall, do not use the power cable, gently
pull the plug from the power socket.
5. If the hose inlet or telescopic chrome tube are blocked, you should switch off the
cleaner straight away and remove from mains power. Clear the blockage before
attempting to start the vacuum cleaner again.
BEFORE YOU BEGIN
This machine is equipped with a cord and plug. In the event that either of these parts get
damaged, it must be repaired by a qualified technician.
17. If the air inlet, floor head or the telescopic tube
is blocked, switch off the cleaner straight away
and remove from the Mains power. First clear
the blocked object before attempting to start
the cleaner vacuum again.
18. Do not leave the appliance unattended when it
is connected to a Mains power supply.
19. Before carry out any maintenance service
or cleaning the filters, always switch off the
vacuum cleaner and disconnect the plug from
power supply
20. Keep ends of the hose, telescopic tube and
other openings away from your face and body.
21. Do not use the vacuum cleaner if it is damaged
or breaks down. Check the electrical regularly
for defects. If connection cables, electrical
hoses, electrical contacts and electric tubes
are damaged, have them replace immediately.
22. Never clean any of the electrical parts,
especially the electrical connections with water
or liquid cleaners.
23. Never attempt to make any modifications
electrically to the vacuum cleaner.
24. Always store the appliance indoors in a cool
and dry place.
25. For indoors and domestic use only
26. Damage caused by improper use or by not
observing the instructions in this manual will
void warranty.
3PULLMAN 15L WET & DRY JANITOR A-031b

KNOW YOUR PRODUCT
11. 14.
1. Handle
2. 2 Piece Metal Tube
3. Hose
4. Lid Handle
5. On/Off Switch
6. Lid
7. Latches
8. Hose Inlet
9. Tank
10. Wet Pick Up Floor Tool
11. Combination Floor Tool
12. Dusting Brush
13. Crevice Tool
14. Upholstery Nozzle
Technical Information
Model: A-031b
220-240V~ 50Hz
1000W
2.
3.
5.
6.
7.
8.
9.
4.
10.
1.
12. 13.
4

ASSEMBLY (WITH HOSE)
3. Connect the tube to the desired cleaning
accessory.
4. Connect the hose to the Pullman A-031b.
1. Connect the 2-piece metal tube together.
Part 1
2. Connect the handle on the hose to the tube.
5PULLMAN 15L WET & DRY JANITOR A-031b

ACCESSORIES
Fitting dusting brush and crevice tool
To fit the accessories to the 2 piece metal tube,
gently insert the tube into the top of the dusting
brush or crevice tool.
Dusting Brush – ideal for cleaning furniture, curtains
and upholstery
Crevice Tool – ideal for cleaning in tight spaces
Upholstery Nozzle – For vacuuming furniture and
upholstery.
Crevice Tool Dusting Brush
Upholstery Nozzle
Wet Pick Up Floor Tool
The wet pick-up tool is ideal for wet applications.
Combination Floor Tool
The Combination Floor Tool is ideal for vacuuming
hard floors and carpets.
6

OPERATION
Fit in Place
2. Ensure the cloth filter bag is always installed before
dry use.
3. Turn the switch of the vacuum cleaner to position “I”.
4. Empty the dust tank or dust bag when it’s full or after
each use.
5. The cloth filter also needs to be cleaned accordingly.
IMPORTANT: DISCONNECT THE CLEANER BEFORE CHANGING ACCESSORIES OR TO
EMPTY THE CLEANER.
Dry Vacuum Cleaning
1. Release the latches to remove the canister lid.
7PULLMAN 15L WET & DRY JANITOR A-031b

1. Ensure the cloth filter is removed before the cleaner is
used.
2. Turn the switch of the vacuum cleaner to position “I”.
IMPORTANT: Empty the tank after each use.
Wet Vacuum Cleaning
OPERATION
Remove
8

MAINTENANCE
Recommend to change the filter every 6
months to maintain the good air flow.
1. Release the latches to remove the canister lid.
2. Remove the cloth filter.
3. The cloth filter bag can be washed under luke
warm water.
4. Dry by airing for at least 24 hours.
ATTENTION: DISCONNECT FROM MAINS POWER SUPPLY BEFORE DOING ANY
MAINTENANCE WORK. IF PROPER CARE IS TAKEN TO MAINTAIN YOUR CLEANER,
MOTOR MAINTENANCE IS UNNECESSARY. HOWEVER WE RECOMMEND THAT
YOUR CLEANER IS SERVICED ONCE A YEAR.
9PULLMAN 15L WET & DRY JANITOR A-031b

SPECIFICATIONS
TROUBLESHOOTING
TROUBLE POSSIBLE CAUSE REMEDY
Suction weakens or
cleaner runs hot
Clogged filter Brush dirt from filter. If condition
continues, change filter.
Air leak Check all fittings for tight fit (floor tool,
hoses, etc.). Check that tank cover is
sealed properly.
Obstruction in hose
or floor tool
Check floor tool, hose, etc. for
obstructions, and remove if present.
Watts: 1000W
Capacity: 15L
Power Cable Length: 7m
Net Weight: 8.5Kg
10

CUSTOMER CARE
For customer service or product enquiries please contact 1800 815 270 (AU) or 0800 282 288 (NZ)
PRODUCT NUMBER PRODUCT DESCRIPTION
33500314 Small Castor Wheels
33200523 On/Off Switch
31110013 Combination Floor Tool
31110127 Hard Floor Squeegee Tool
31220268 Hose Assembly
31300393 Chrome Tube
31130 0 62 Dusting Brush
3112 0 071 Crevice Tool
33701473 Float Cage
33400148 Cloth Filter
31140059 Upholstery Tool
33701474 Latch
11PULLMAN 15L WET & DRY JANITOR A-031b

Electrical Home-Aids Pty. Ltd.
ABN 62 007 539 577
Ground Level, Building 3, Brandon Business Park
530 Springvale Road, Glen Waverley, Victoria 3150
Pullman is a registered trademark.
Contact Electrical Home-Aids Pty. Ltd. for your nearest authorised
service centre on 1800 815 270 (AU) or 0800 282 288 (NZ).
[email protected]
V1 0117
Your Pullman cleaner has a
one year parts and labour
warranty against product
defects and failures when the
product is used in accordance
with the terms and conditions
of this warranty statement.
The cleaner must be operated in accordance with
these instructions. This cleaner is not designed for
the collection of vitreous building material including
particle board, construction products and similar
products such as wood/fibres, cement, fillers,
fibre glass etc or excessive or frequent sand. The
infrequent pick-up of these materials in these
circumstances may be harmful to your cleaner
and may void the manufacturer’s warranty.
Accessories and consumables including dust
bags and filters, unless defective in manufacture,
are not subject to this warranty. In order to prolong
the life of accessories and consumables, regular
care and maintenance is recommended.
When properly used and cared for, your cleaner
will render excellent service; refer to the instruction
manual for further details, as misuse or failure to
follow the instructions makes this warranty void.
In the event of service or advice being needed,
please contact Electrical Home-Aids Pty Ltd, ABN
62 007 539 577, Ground Level, Building 3 Brandon
Business Park, 530 Springvale Rd, Glen Waverley,
VIC 3150. Customer Care: 1800 815 270.
The decision to repair or replace the cleaner is at
the sole discretion of Electrical Home-Aids Pty Ltd.
If International Cleaning Solutions Pty Ltd decide
to repair or replace the cleaner, it will do so at its
own cost.
Electrical Home-Aids Pty Ltd is unable to accept
responsibility under this warranty for any repair
work not carried out by an authorised Electrical
Home-Aids Service Agent or from the use of
non-genuine parts. If any part is no longer
available or manufactured, International Cleaning
Solutions will replace it with a genuine functional
replacement part. This warranty does not apply
to the cost of replacing any parts of the product
due to normal wear and tear, alterations, improper
installation, physical abuse, misuse or accidental
damage. Any transportation costs involved in the
repair of defective parts shall be borne by the
claimant.
If proof of purchase cannot be provided at the time
of a warranty claim or service, any work carried
out on the cleaner is chargeable. The repair or
replacement of the cleaner under this warranty
does not extend the original period of warranty.
The benefits conferred by this warranty are in
addition to all other rights and remedies in respect of
the product as outlined under the Competition and
Consumer Act and other State and Territory laws.
“Our goods come with guarantees that cannot
be excluded in the Australian Consumer Law.
You are entitled to a replacement or refund for a
major failure and for compensation for any other
reasonably foreseeable loss or damage. You are
also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.”
Conditions of warranty
