Pullman CB60 User manual

60L WET & DRY
VACUUM CLEANER
2000W
IDEAL FOR:
Shops
Garages
Motels & Hotels
Restaurants & Cafes
CB60

Always switch off the cleaner and remove the plug from the electricity power supply before cleaning
your appliance, when not in use, or attempting any maintenance task. The cleaner must only be
connected to an AC power supply at the voltage shown on the rating label. This cleaner should only
be used for its intended purpose as described in this instruction manual.
1. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge
unless they have been given supervision
or instruction concerning the use of the
appliance by a person responsible for their
safety.
2. Children should be supervised to ensure that
they do not play with the appliance.
3. To prevent electrical shock do not immerse
the appliance, power cord or power plug into
water or other liquids.
4. To prevent electrical shock do not use the
vacuum cleaner outdoors.
5. Always check the power cord before use.
The power cord and the plug should be in a
good condition and must not be damaged.
If the power cord is damaged or defective,
it must be replaced by the manufacturer, its
service agent, or similarly qualified persons
in order to avoid a hazard.
6. Do not unplug by pulling on the power cord.
To unplug, grasp the plug not the power
cord. Use only Australian and New Zealand
electrical safety approved extension cords.
7. Do not pull or carry the appliance by the
power cable, use the power cable as a
handle or pull the power cable around
sharp edges or corners. Avoid running the
appliance over the power cable.
8. Ensure the appliance is switched off
before unplugging.
9. Do not handle or operate the appliance
with wet hands, and follow electrical safety
precautions at all times.
10. Extreme caution should be exercised when
using the appliance on stairs.
11. Do not attempt to change the attachments
while the appliance is plugged in to mains
power supply. Switch off and remove
plug from mains power supply. Use only
manufacturer’s recommended accessories.
12. Do not operate the vacuum cleaner too
close to heaters, radiators and other hot
surfaces.
13. Do not use the appliance to pick up
hot water/ liquids, flammable items or
combustible liquids (i.e. petrol, hot ashes
cigarettes, matches, explosive materials or
anything burning) or use in areas where such
substances and items may be present.
14. Do not use the appliance to pick up toxic
materials (i.e. chlorine bleach, ammonia).
15. Ensure the appliance is disconnected from
the main power supply before connecting
the hose to the unit.
16. Do not operate or use the appliance without
dust bag and/or filters in place while dry
vacuum cleaning.
17. Before vacuuming, remove any large or
sharp objects from the floor or cleaning
surface in order to prevent damage to the
filter.
SAFETY PRECAUTIONS AND WARNING:
IMPORTANT
WHEN USING YOUR VACUUM CLEANER BASIC PRECAUTIONS SHOULD ALWAYS
BE OBSERVED, INCLUDING THE FOLLOWING;
2

1. Do not operate the vacuum cleaner too close to heaters, radiators, and other
hot surfaces.
2. Before inserting the plug into the wall, make sure your hand is dry.
3. Before turning on the vacuum cleaner, remove any large or sharp objects from
the floor or cleaning surface in order to prevent damage to the filter.
4. When you want to pull the plug from the wall, do not use the power cable, gently
pull the plug from the power socket.
5. If the hose inlet or telescopic chrome tube are blocked, you should switch off the
cleaner straight away and remove from mains power. Clear the blockage before
attempting to start the vacuum cleaner again.
18. If the hose inlet, floor tool, or the 2 piece
metal tube is blocked, switch off the cleaner
straight away and disconnect from the main
power. Clear the blockage object before
attempting to start the vacuum cleaner again.
19. Do not leave the appliance unattended when
it is connected to a mains power supply.
20. Before carrying out any maintenance service
or cleaning the filters, always switch off the
vacuum cleaner and disconnect the plug
from the power supply.
21. Keep the ends of the hose, telescopic tube
and other openings away from your face
and body.
22. Do not use the vacuum cleaner if it is
damaged or breaks down. Check the
electrical cable regularly for defects. If
cables, hose, electrical contacts
and/or metal tubes are damaged, have
them replaced immediately.
23. Never clean the vacuum cleaner or any
of the electrical parts with water or liquid
cleaners.
24. Never attempt to make any electrical
modifications to the vacuum cleaner.
25. Always store the appliance indoors in a cool
and dry place.
26. Damage caused by improper use or by not
observing the instructions in this manual will
void the warranty.
BEFORE YOU BEGIN
This machine is equipped with a cord and plug. In the event that either of these parts get
damaged, it must be repaired by a qualified technician.
3PULLMAN 60L WET & DRY CB60

KNOW YOUR PRODUCT
12. 13. 15.
1. Lid Handle
2. On/Off Switch
3. Tank
4. Hose Inlet
5. Hose
6. Castor Wheels
7. Drain Hose
8. Cord Holder
9. Connection Latches
10. 2 Piece Metal Tube
11. Carry Handles
12. Dry Pick Up Tool
(hard floor only)
13. Wet Pick Up Tool
14. Crevice Tool
15. Dusting Brush
Technical Information
Model: CB60
220-240V ~ 50Hz/60Hz
2000W
10.
11.
9.
8.
2.
1.
3.
4.
5.
6.
7.
14.
4

ASSEMBLY (WITH HOSE)
3. Connect the tube to the desired
cleaning accessory.
4. Connect the hose to the Pullman CB60.
1. Connect the 2-piece metal tube together.
Part 1
2. Connect the handle on the hose to the tube.
5PULLMAN 60L WET & DRY CB60

ACCESSORIES
Fitting dusting brush and crevice tool
To fit the accessories to the 2 piece metal tube,
gently insert the tube into the top of the dusting
brush or crevice tool.
Dusting Brush – ideal for cleaning furniture, curtains
and upholstery
Crevice Tool – ideal for cleaning in tight spaces
Crevice Tool Dusting Brush
Wet Pick Up Floor Tool
The wet pick-up tool is ideal for wet applications.
Dry Pick Up Floor Tool
The dry pick up floor tool is ideal for vacuuming
hard floors.
Do not use the dry pick up floor tool on carpets.
6

OPERATION
Closed
Fit in Place
Before turning on the Pullman CB60 Vacuum Cleaner,
please check that the Drain Hose is secure to the tank
and the cap is fully closed.
2. Ensure the cloth filter bag is always installed before
dry use.
3. Turn the switch of the vacuum cleaner to position “I”.
4. You can determine the suction by using either 1 or 2
motors. Each motor is controlled by a switch located
on the front.
5. Empty the dust tank or dust bag when it’s full or after
each use.
6. The cloth filter also needs to be cleaned accordingly.
IMPORTANT: DISCONNECT THE CLEANER BEFORE CHANGING ACCESSORIES OR TO
EMPTY THE CLEANER.
Dry Vacuum Cleaning
1. Release the connection latches to remove the
canister lid.
7PULLMAN 60L WET & DRY CB60

1. Ensure the cloth filter is removed before the cleaner is
used.
2. Turn the switch of the vacuum cleaner to position “I”.
3. You can determine the suction by using either 1 or 2
motors. Each motor is controlled by a switch located
on the front.
Wet Vacuum Cleaning
OPERATION
4. Empty the tank by the Drain Hose .
5. Empty the tank after each use. Avoid leaving
dust or dirty water in the tank.
6. Wipe the machine inside and out from time to
time, using only lukewarm water.
Before use always examine the power cable for
cuts and/or damage.
7. Wet pick up accessories should be washed
periodically.
open
Remove
8

MAINTENANCE
1. Release the connection latches to remove the
canister lid.
2. Remove the cloth filter.
3. The cloth filter bag can be washed under luke
warm water.
4. Dry by airing for at least 24 hours.
ATTENTION: DISCONNECT FROM MAINS POWER SUPPLY BEFORE DOING ANY
MAINTENANCE WORK. IF PROPER CARE IS TAKEN TO MAINTAIN YOUR CLEANER,
MOTOR MAINTENANCE IS UNNECESSARY. HOWEVER WE RECOMMEND THAT
YOUR CLEANER IS SERVICED ONCE A YEAR.
9PULLMAN 60L WET & DRY CB60

SPECIFICATIONS
TROUBLESHOOTING
TROUBLE POSSIBLE CAUSE REMEDY
Suction weakens or
cleaner runs hot
Clogged filter Brush dirt from filter. If condition
continues, change filter.
Air leak Check all fittings for tight fit (floor tool,
hoses, etc.). Check that tank cover is
sealed properly.
Obstruction in hose
or floor tool
Check floor tool, hose, etc. for
obstructions, and remove if present.
Misting in the exhaust air Saturated filter Replace saturated filter and the
filter mesh.
Voltage: 220V-240V 50Hz/60Hz
Function: Wet & Dry
Cooling Mode: Cycle
Vacuum: 250mbar
Volume: 60L
Power: 2000W
Airflow: 106L /S
Barrel body diameter: 440mm
Accessories: 40mm
Cable: 8m
Noise: <75DB
Net Weight: 24.5KGS
10

CUSTOMER CARE
For customer service or product enquiries please contact 1800 815 270 (AU) or 0800 282 288 (NZ)
PRODUCT NUMBER PRODUCT DESCRIPTION
33500316 Small Castor Wheels
33500315 Rear Wheels
31150 055 Squeegee Replacement
33200523 On/Off Switch
31110125 Combination Floor Tool (OPTIONAL)
3111012 6 Hard Floor Squeegee Tool
31150 014 Hard Floor Tool
31220267 Hose Assembly
31300392 2-Piece Chrome Tube
31130 061 Dusting Brush
31120 070 Crevice Tool
33701473 Float Cage
33400126 Cloth Filter
33101028 Pipe, Drain Assembly
33101026 Trolley Base
11PULLMAN 60L WET & DRY CB60

Electrical Home-Aids Pty. Ltd.
ABN 62 007 539 577
Ground Level, Building 3, Brandon Business Park
530 Springvale Road, Glen Waverley, Victoria 3150
Pullman is a registered trademark.
Contact Electrical Home-Aids Pty. Ltd. for your nearest authorised
service centre on 1800 815 270 (AU) or 0800 282 288 (NZ).
[email protected]
V1 0217
Your Pullman cleaner has a
one year parts and labour
warranty against product
defects and failures when the
product is used in accordance
with the terms and conditions
of this warranty statement.
The cleaner must be operated in accordance with
these instructions. This cleaner is not designed for
the collection of vitreous building material including
particle board, construction products and similar
products such as wood/fibres, cement, fillers,
fibre glass etc or excessive or frequent sand. The
infrequent pick-up of these materials in these
circumstances may be harmful to your cleaner
and may void the manufacturer’s warranty.
Accessories and consumables including dust
bags and filters, unless defective in manufacture,
are not subject to this warranty. In order to prolong
the life of accessories and consumables, regular
care and maintenance is recommended.
When properly used and cared for, your cleaner
will render excellent service; refer to the instruction
manual for further details, as misuse or failure to
follow the instructions makes this warranty void.
In the event of service or advice being needed,
please contact Electrical Home-Aids Pty Ltd, ABN
62 007 539 577, Ground Level, Building 3 Brandon
Business Park, 530 Springvale Rd, Glen Waverley,
VIC 3150. Customer Care: 1800 815 270.
The decision to repair or replace the cleaner is at
the sole discretion of Electrical Home-Aids Pty Ltd.
If International Cleaning Solutions Pty Ltd decide
to repair or replace the cleaner, it will do so at its
own cost.
Electrical Home-Aids Pty Ltd is unable to accept
responsibility under this warranty for any repair
work not carried out by an authorised Electrical
Home-Aids Service Agent or from the use of
non-genuine parts. If any part is no longer
available or manufactured, International Cleaning
Solutions will replace it with a genuine functional
replacement part. This warranty does not apply
to the cost of replacing any parts of the product
due to normal wear and tear, alterations, improper
installation, physical abuse, misuse or accidental
damage. Any transportation costs involved in the
repair of defective parts shall be borne by the
claimant.
If proof of purchase cannot be provided at the time
of a warranty claim or service, any work carried
out on the cleaner is chargeable. The repair or
replacement of the cleaner under this warranty
does not extend the original period of warranty.
The benefits conferred by this warranty are in
addition to all other rights and remedies in respect of
the product as outlined under the Competition and
Consumer Act and other State and Territory laws.
“Our goods come with guarantees that cannot
be excluded in the Australian Consumer Law.
You are entitled to a replacement or refund for a
major failure and for compensation for any other
reasonably foreseeable loss or damage. You are
also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.”
Conditions of warranty
