Puls Dimension CP Series User manual

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 1 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
CP20.481 POWER SUPPLY 1AC 48V 480W
•AC 100-240V Wide-range input
•Width on y 48mm
•Efficiency up to 96.3%
•Exce ent partia oad efficiency
•20% Output power reserves
•Safe HiccupPLUS over oad mode
•Easy fuse breaking - 3 times nomina current for 12ms
•Active power factor correction (PFC)
•Minima inrush current surge
•Fu power between -25°C and +60°C
•DC-OK re ay contact
•Current sharing feature for parallel use
•3 year warranty
PRODUCT DESCRIPTION SHORT-FORM DATA
The Dimension CP-Series are cost optimized power
supp ies without compromising qua ity, re iabi ity and
performance. The CP-Series is part of the DIMENSION
power supp y fami y. The most outstanding features
of CP20.481 are the high efficiency, e ectronic inrush
current imitation, active PFC, wide operationa
temperature range. The sma size is achieved by
a synchronous rectification, LLC techno ogy and by
many further techno ogica design detai s.
The C-Series inc udes a the essentia basic functions.
The device has a power reserve of 20% inc uded,
which may even be used continuous y at temperatures
up to +45°C. Additiona y, the CP20.481 can de iver
about 3 times the nomina output current for 12ms
which he ps to trip fuses on fau ty output branches.
High immunity to transients and power surges as
we as ow e ectromagnetic emission, a DC-OK re ay
contact and a arge internationa approva package
make this unit suitab e for near y every situation.
Output vo tage DC 48V Nomina
Adjustment range 48-56Vdc Factory setting 48V
Output current 12-10.3A Be ow +45°C ambient
10-8.6A At +60°C ambient
7.5-6.5A At +70°C ambient
Derate between +45°C and +70°C
Input vo tage AC AC 100-240V ±10%
Mains frequency 50-60Hz ±6%
Input current AC 4.26 / 2.23A At 120 / 230Vac
Power factor 0.996 / 0.98 At 120 / 230Vac
Input vo tage DC DC 110-150V ±20%
Input current DC 4.64A At 110Vdc
AC Inrush current 10 / 4.5Apeak At 120 / 230Vac
Efficiency 95 / 96.3% At 120 / 230Vac
Power osses 25.1 / 18.4W At 120 / 230Vac
Ho d-up time 32 / 32ms At 120 / 230Vac
Temperature range -25°C to +70°C
Size (w x h x d) 48x124x127mm Without DIN rai
Weight 830g / 1.83 b
ORDER NUMBERS MAIN APPROVALS
Description: Power supp y CP20.481-xx
Order Number:
CP20.481
Accessories:
ZM10.WALL Wa /Pane mount bracket
For detai s or a comp ete approva ist, see chapter 20.

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 2 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
Index
1 Intended Use....................................................... 3
2 Insta ation Instructions...................................... 3
3 AC-Input.............................................................. 5
4 DC-Input.............................................................. 6
5 Input Inrush Current.......................................... 7
6 Output................................................................. 8
7 Ho d-up Time...................................................... 10
8 DC-OK Re ay Contact......................................... 11
9 Efficiency and Power Losses.............................. 12
10 Lifetime Expectancy........................................... 13
11 MTBF.................................................................... 13
12 Functiona Diagram............................................ 14
13 Termina s And Wiring........................................ 15
14 Front Side And User E ements........................... 16
15 EMC..................................................................... 17
16 Environment....................................................... 18
17 Protection Features............................................ 19
18 Safety Features................................................... 19
19 Die ectric Strength.............................................. 20
20 Approva s and Fu fi ed Standards.................... 21
21 Regu atory Comp iance...................................... 22
22 Physica Dimensions And Weight...................... 23
23 Accessories.......................................................... 24
23.1 ZM10.Wa - Wa /Pane Mount Bracket.. 24
23.2 UF20.481 - BUFFER MODULE.................. 24
23.3 YR40.482 – Redundancy Modu e............ 25
24 App ication Notes............................................... 26
24.1 Peak Current Capabi ity.......................... 26
24.2 Output Circuit Breakers.......................... 27
24.3 Para e Use to Increase Output Power... 28
24.4 Para e Use for Redundancy.................. 29
24.5 Series Operation...................................... 30
24.6 Charging of Batteries.............................. 30
24.7 Two Phase Operation............................. 30
24.8 Use in a Tight y Sea ed Enc osure........... 31
24.9 Mounting Orientations........................... 32
The information given in this document is correct to the best of our know edge and experience at the time of pub ication.
If not express y agreed otherwise, this information does not represent a warranty in the ega sense of the word. As the
state of our know edge and experience is constant y changing, the information in this data sheet is subject to revision. We
therefore kind y ask you to a ways use the atest issue of this document (avai ab e under www.pu spower.com).
No part of this document may be reproduced or uti ized in any form without our prior permission in writing.
Packaging and packaging aids can and shou d a ways be recyc ed. The product itse f may not be disposed of as domestic
refuse.
TERMINOLOGY AND ABBREVIATIONS
PE and S mbol PE is the abbreviation for Protective Earth and has the same meaning as the symbo .
Earth, Ground This document uses the term “earth” which is the same as the U.S. term “ground”.
T.b.d. To be defined, va ue or description wi fo ow ater.
AC 230V A figure disp ayed with the AC or DC before the va ue represents a nomina vo tage with
standard to erances (usua y ±15%) inc uded.
E.g.: DC 12V describes a 12V battery disregarding whether it is fu (13.7V) or f at (10V)
230Vac A figure with the unit (Vac) at the end is a momentary figure without any additiona
to erances inc uded.
50Hz vs. 60Hz As ong as not otherwise stated, AC 230V parameters are va id at 50Hz mains frequency.
ma A key word indicating f exibi ity of choice with no imp ied preference.
shall A key word indicating a mandatory requirement.
should A key word indicating f exibi ity of choice with a strong y preferred imp ementation.

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 3 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
1. Intended Use
This device is designed for insta ation in an enc osure and is intended for commercia use, such as in industria contro ,
process contro , monitoring and measurement equipment or the ike.
Do not use this device in equipment, where ma functioning may cause severe persona injury or threaten human ife without
additiona appropriate safety devices, that are suited for the app ication. If this device is used in a manner outside of its
specification, the protection provided by the device may be impaired.
2. Insta ation Instructions
DANGER Risk of electrical shock, fire, personal injur or death.
– Turn power off before working on the device. Protect against inadvertent re-powering.
– Do not open, modify or repair the device.
– Use caution to prevent any foreign objects from entering the housing.
– Do not use in wet ocations or in areas where moisture or condensation can be expected.
– Do not touch during power-on, and immediate y after power-off. Hot surfaces may cause burns.
NOTE
Notes for use in hazardous location areas:
The device is suitab e for use in C ass I Division 2 Groups A, B, C, D T4 ocations and for use in Group II Category 3 (Zone
2) environments.
C assification: ATEX: EPS 17 ATEX 1 089 X, II 3G EX ec nC IIC T4 Gc / IECEx EPS 17.0046X
CAUTION WARNING EXPLOSION HAZARDS!
– Do not use with DC input vo tages. Do not use with AC input vo tages be ow 90Vac.
– Use on y in standard vertica mounting orientation with the input termina s on bottom of the unit. Substitution of
components may impair suitabi ity for this environment.
– Do not disconnect the device or operate the vo tage adjustment un ess power has been switched off or the area is
known to be non-hazardous.
– A suitab e enc osure must be provided for the end product which has a minimum protection of IP54 and fu fi s the
requirements of the EN 60079-0.
This device may on y be insta ed and put into operation by qua ified personne . This device does not contain serviceab e
parts. The tripping of an interna fuse is caused by an interna defect. If damage or ma function shou d occur during
insta ation or operation, immediate y turn power off and send the device to the factory for inspection.
Insta the device in an enc osure providing protection against e ectrica , mechanica and fire hazards. Insta the device
onto a DIN rai according to EN 60715 with the input termina s on the bottom of the device. Other mounting orientations
require a reduction in output current.
Make sure that the wiring is correct by fo owing a oca and nationa codes. Use appropriate copper cab es that
are designed for a minimum operating temperature of 60°C for ambient temperatures up to +45°C, 75°C for ambient
temperatures up to +60°C and 90°C for ambient temperatures up to +70°C. Ensure that a strands of a stranded wire enter
the termina connection. Use ferru es for wires on the input termina s. Unused screw termina s shou d be secure y tightened.
The device is designed for use in po ution degree 2 areas in contro ed environments. No condensation or frost is a owed.
The enc osure of the device provides a degree of protection of IP20. The housing does not provide protection against
spi ed iquids.
The iso ation of the device is designed to withstand impu se vo tages of overvo tage category III according to IEC 60664-1.
The device is designed as “C ass of Protection I” equipment according to IEC 61140. Do not use without a proper PE
(Protective Earth) connection.
The device is suitab e to be supp ied from TN, TT or IT mains networks. The continuous vo tage between the input termina s
and the PE potentia must not exceed 300Vac.
The input can a so be powered from a battery or a simi ar DC source. The continuous vo tage between the supp y vo tage
and the PE/ground potentia must not exceed 375Vdc.
A disconnecting means sha be provided for the input of the device.
This device is designed for convection coo ing and does not require an externa fan. Do not obstruct airf ow and do not
cover venti ation grid!
The device is designed for a titudes up to 5000m (16400ft). Above 2000m (6560ft) a reduction in output current and over
vo tage category is required.

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 4 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
Keep the fo owing insta ation c earances: 40mm on top, 20mm on the bottom, 5mm on the eft and right side. Increase
the 5mm to 15mm in case the adjacent device is a heat source. When the device is permanent y oaded with ess than 50%,
the 5mm can be reduced to zero.
The device is designed, tested and approved for branch circuits up to 32A (IEC) and 30A (UL) without additiona protection
device. If an externa fuse is uti ized, do not use circuit breakers sma er than 10A B- or C-Characteristic to avoid a nuisance
tripping of the circuit breaker.
The maximum surrounding air temperature is +70°C (+158°F). The operationa temperature is the same as the ambient or
surrounding air temperature and is defined 2cm be ow the device.
The device is designed to operate in areas between 5% and 95% re ative humidity.

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 5 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
3. AC-Input
The device is suitab e to be supp ied from TN-, TT- or IT-mains networks with AC vo tage. For suitab e DC supp y vo tages
see chapter 4.
AC input nom. AC 100-240V
AC input range 90-264Vac Continuous operation
264-300Vac Occasiona y for maxima 500ms
A owed vo tage L or N to
earth
max. 300Vac Continuous, according to IEC 60664-1
Input frequency nom. 50-60Hz ±6%
Turn-on vo tage typ. 82Vac Steady-state va ue, see Fig. 3-1
Shut-down vo tage typ. 72Vac Steady-state va ue, see Fig. 3-1
Externa input protection See recommendations in chapter 2.
AC 100V AC 120V AC 230V
Input current typ. 5.15A 4.26A 2.23A At 48V, 10A, see Fig. 3-3
Power factor *) typ. 0.996 0.996 0.98 At 48V, 10A, see Fig. 3-4
Crest factor **) typ. 1.65 1.63 1.63 At 48V, 10A
Start-up de ay typ. 450ms 450ms 450ms See Fig. 3-2
typ. 120ms 120ms 120ms At 48V, 10A const. current oad,
0mF oad capacitance, see Fig. 3-2
Rise time
typ. 170ms 170ms 170ms At 48V, 10A const. current oad,
10mF oad capacitance, see Fig. 3-2
Turn-on overshoot max. 500mV 500mV 500mV In sing e use mode, see Fig. 3-2
*) The power factor is the ratio of the true (or rea ) power to the apparent power in an AC circuit.
**) The crest factor is the mathematica ratio of the peak va ue to RMS va ue of the input current waveform.
Fig. 3-1: Input vo tage range Fig. 3-2: Turn-on behavior, definitions
Fig. 3-3: Input current vs. output
current at 48V output vo tage
Fig. 3-4: Power factor vs. output
current at 48V output vo tage

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 6 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
4. DC-Input
DC input nom. DC 110-150V ±20%
DC input range 88-180Vdc Continuous operation
DC input current typ. 4.64A At 110Vdc, 48V, 10A
A owed vo tage (+) or (−)
input to earth
max. 375Vdc Continuous, according to IEC 60664-1
Turn-on vo tage typ. 80Vdc Steady state va ue
Shut-down vo tage typ. 70Vdc Steady state va ue
Fig. 4-1: Wiring for DC Input
The device is suitab e to be supp ied from a DC input vo tage.
Instructions for DC use:
a) Use a battery or a simi ar DC source.
WARNING
A supp y from the intermediate DC-bus of a frequency
converter is not recommended and can cause a
ma function or damage the unit.
b) Connect (+) po e to L and (–) po e to N.
c) Connect the PE termina to an earth wire or to the machine
ground.

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 7 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
5. Input Inrush Current
An active inrush imitation circuit imits the input inrush current after turn-on of the input vo tage.
The charging current into EMI suppression capacitors is disregarded in the first microseconds after switch-on.
AC 100V AC 120V AC 230V
Inrush current I max. 15Apeak 12Apeak 5.5Apeak Temperature independent
typ. 12Apeak 10Apeak 4.5Apeak Temperature independent
Inrush energy max. 1A2s 1A2s 1A2s Temperature independent
Fig. 5-1: Typica turn-on behaviour
at nomina oad and 25°C ambient

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 8 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
6. Output
The output provides a SELV/PELV rated vo tage, which is ga vanica y iso ated from the input vo tage.
The output is designed to supp y any kind of oads, inc uding capacitive and inductive oads. If extreme arge capacitors,
such as EDLCs (e ectric doub e ayer capacitors or “U traCaps”) with a capacitance >0.25F are connected to the output, the
unit might charge the capacitor in an intermittent mode.
The output is e ectronica y protected against over oad, no- oad and short-circuits. In case of a protection event, audib e
noise may occur.
Output vo tage nom. 48V
Adjustment range 48-56V Guaranteed va ue
max. 60V This is the maximum output vo tage which can occur at
the c ockwise end position of the potentiometer due
to to erances. It is not a guaranteed va ue which can be
achieved.
Factory settings typ. 48V ±0.2% in “sing e use” mode at fu oad, co d unit
typ. 47V ±0.2% in “para e use” mode at 10A, co d unit (resu ts to
46.6V ±0.2% at 12A and 49.0V ±0.2% at no oad)
Line regu ation max. 10mV Between 90 and 300Vac input vo tage change
Load regu ation max. 150mV Between 0 and 10A in “sing e use” mode, static va ue
typ. 2000mV Between 0 and 10A in “para e use” mode, static va ue,
see Fig. 6-2
Ripp e and noise vo tage max. 50mVpp Bandwidth 20Hz to 20MHz, 50Ohm
Output current nom. 12A1) At 48V and ambient temperatures be ow +45°C,
see Fig. 16-1
nom. 10A At 48V and +60°C ambient temperature, see Fig. 6-1
nom. 7.5A At 48V and +70°C ambient temperature, see Fig. 16-1
nom. 10.3A1) At 56V and ambient temperatures be ow +45°C,
see Fig. 16-1
nom. 8.6A At 56V and +60°C ambient temperature, see Fig. 6-1
nom. 6.5A At 56V and +70°C ambient temperature, see Fig. 16-1
Derate between +45°C and +70°C
Fuse breaking current typ. 30A Up to 12ms once every five seconds, see Fig. 6-2. The fuse
braking current is an enhanced transient current which
he ps to trip fuses on fau ty output branches. The output
vo tage stays above 40V.
Over oad behavior Continuous current For output vo tage above 26Vdc, see Fig. 6-1
Intermittent current2) For output vo tage be ow 26Vdc, see Fig. 6-1
max. 14.8A Continuous current, see Fig. 6-1Over oad/
short-circuit current typ. 15A Intermitted current peak va ue for typ. 2s
Load impedance 10mOhm, see Fig. 6-2.
Discharge current of output capacitors is not inc uded.
max. 4.7A Intermitted current average va ue (R.M.S.)
Load impedance 10mOhm, see Fig. 6-2
Output capacitance typ. 2500μF Inc uded inside the power supp y
Back-feeding oads max. 63V The unit is resistant and does not show ma functioning
when a oad feeds back vo tage to the power supp y. It
does not matter whether the power supp y is on or off.
The absorbing energy can be ca cu ated according to the
bui t-in arge sized output capacitor.
1) This current is a so avai ab e for temperatures up to +70°C with a duty cyc e of 10% and/or not onger than 1 minute every 10 minutes.
2) At heavy over oads (when output vo tage fa s be ow 13V), the power supp y de ivers continuous output current for 2s. After this, the output is
switched off for approx. 18s before a new start attempt is automatica y performed. This cyc e is repeated as ong as the over oad exists. If the
over oad has been c eared, the device wi operate norma y. See Fig. 6-3.

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 9 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
Fig. 6-1: Output vo tage vs. output current, typ. Fig. 6-2: Dynamic overcurrent capabi ity, typ.
Fig. 6-3: Short-circuit on output, HiccupPLUS mode, typ.
Fig. 6-4: Output vo tage in “para e use” mode, typ.

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 10 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
7. Ho d-up Time
The ho d-up time is the time during which a power supp y’s output vo tage remains within specification fo owing the oss
of input power. The ho d-up time is output oad dependent. At no oad, the ho d-up time can be up to severa seconds.
The green DC-OK LED is a so on during this time.
AC 100V AC 120V AC 230V
Ho d-up time typ. 65ms 65ms 65ms At 48V, 5A, see Fig. 7-1
min. 54ms 54ms 54ms At 48V, 5A, see Fig. 7-1
typ. 32ms 32ms 32ms At 48V, 10A, see Fig. 7-1
min. 24ms 24ms 24ms At 48V, 10A, see Fig. 7-1
Fig. 7-1: Ho d-up time vs. input vo tage Fig. 7-2: Shut-down behaviour, definitions

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 11 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
8. DC-OK Re ay Contact
This feature monitors the output vo tage on the output termina s of a running power supp y.
Contact c oses As soon as the output vo tage reaches typ. 90% of the adjusted output vo tage eve .
Contact opens As soon as the output vo tage dips more than 10% be ow the adjusted output vo tage.
Short dips wi be extended to a signa ength of 100ms. Dips shorter than 1ms wi be
ignored.
Switching hysteresis typ. 2V
Contact ratings Maxima 60Vdc 0.3A, 30Vdc 1A, 30Vac 0.5A, resistive oad
Minima permissib e oad: 1mA at 5Vdc
Iso ation vo tage See die ectric strength tab e in chapter 19.
Fig. 8-1: DC-ok re ay contact behavior

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 12 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
9. Efficiency And Power Losses
AC 100V AC 120V AC 230V
Efficiency typ. 94.4% 95% 96.3% At 48V, 10A
typ. 94.2% 94.9% 96.2% At 48V, 12A (Power Boost)
Average efficiency*) typ. 94.1% 94.6% 95.5% 25% at 2.5A, 25% at 5A,
25% at 7.5A, 25% at 10A
Power osses typ. 2.7W 2.4W 2.4W At 48V, 0A
typ. 14.2W 12.5W 10.6W At 48V, 5A
typ. 28.5W 25.1W 18.4W At 48V, 10A
typ. 35.4W 31W 22.7W At 48V, 12A (Power Boost)
*) The average efficiency is an assumption for a typica app ication where the power supp y is oaded with 25% of the nomina oad for 25% of
the time, 50% of the nomina oad for another 25% of the time, 75% of the nomina oad for another 25% of the time and with 100% of
the nomina oad for the rest of the time.
Fig. 9-1: Efficiency vs. output current at 48V, typ. Fig. 9-2: Losses vs. output current at 48V, typ.
Fig. 9-3: Efficiency vs. input vo tage at 48V, 10A, typ. Fig. 9-4: Losses vs. input vo tage at 48V, 10A, typ.

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 13 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
10. Lifetime Expectancy
The ifetime expectancy shown in the tab e indicates the minimum operating hours (service ife) and is determined by
the ifetime expectancy of the bui t-in e ectro ytic capacitors. Lifetime expectancy is specified in operationa hours and is
ca cu ated according to the capacitor’s manufacturer specification. The manufacturer of the e ectro ytic capacitors on y
guarantees a maximum ife of up to 15 years (131 400h). Any number exceeding this va ue is a ca cu ated theoretica ifetime,
which can be used to compare devices.
AC 100V AC 120V AC 230V
Lifetime expectancy 130 000h 152 000h 180 000h At 48V, 5A and 40°C
368 000h 431 000h 509 000h At 48V, 5A and 25°C
52 000h 66 000h 110 000h At 48V, 10A and 40°C
148 000h 188 000h 311 000h At 48V, 10A and 25°C
33 000h 45 000h 89 000h At 48V, 12A and 40°C
93 000h 128 000h 251 000h At 48V, 12A and 25°C
11. MTBF
MTBF stands for Mean Time Between Fai ure, which is ca cu ated according to statistica device fai ures, and indicates
re iabi ity of a device. It is the statistica representation of the ike ihood of a unit to fai and does not necessari y represent
the ife of a product.
The MTBF figure is a statistica representation of the ike ihood of a device to fai . A MTBF figure of e.g. 1 000 000h means
that statistica y one unit wi fai every 100 hours if 10 000 units are insta ed in the fie d. However, it can not be determined
if the fai ed unit has been running for 50 000h or on y for 100h.
For these types of units the MTTF (Mean Time To Fai ure) va ue is the same va ue as the MTBF va ue.
AC 100V AC 120V AC 230V
430 000h 443 000h 540 000h At 48V, 10A and 40°CMTBF SN 29500, IEC 61709
790 000h 810 000h 973 000h At 48V, 10A and 25°C
207 000h 209 000h 244 000h At 48V, 10A and 40°C;
Ground Benign GB40
MTBF MIL HDBK 217F
279 000h 283 000h 334 000h At 48V, 10A and 25°C;
Ground Benign GB25
44 000h 45 000h 54 000h At 48V, 10A and 40°C;
Ground Fixed GF40
58 000h 59 000h 72 000h At 48V, 10A and 25°C;
Ground Fixed GF25

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 14 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
12. Functiona Diagram
Fig. 12-1: Functiona diagram

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 15 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
13. Termina s And Wiring
The termina s are IP20 Finger safe constructed and suitab e for fie d- and factory wiring.
Input Output DC-OK-Signal
T pe Screw termina s Screw termina s Push-in termina s
So id wire
Stranded wire
American Wire Gauge
Max. 6mm2
Max. 4mm2
AWG 20-10
Max. 6mm2
Max. 4mm2
AWG 20-10
Max. 1.5mm2
Max. 1.5mm2
AWG 24-16
Max. wire diameter (inc uding
ferru es)
2.8mm 2.8mm 1.6mm
Recommended tightening torque Max. 1Nm, 9 b-in Max. 1Nm, 9 b-in -
Wire stripping ength 7mm / 0.28inch 7mm / 0.28inch 7mm / 0.28inch
Screwdriver 3.5mm s otted or cross-
head No 2
3.5mm s otted or cross-
head No 2
3mm s otted to open the
spring
Instructions for Wirings:
a) Use appropriate copper cab es that are designed for minimum operating temperatures of:
+60°C for ambient up to +45°C and
+75°C for ambient up to +60°C minimum
+90°C for ambient up to +70°C minimum.
b) Fo ow nationa insta ation codes and insta ation regu ations!
c) Ensure that a strands of a stranded wire enter the termina connection!
d) Unused termina compartments shou d be secure y tightened.
e) Ferru es are a owed.
Dais chaining:
Daisy chaining (jumping from one power supp y output to the next) is a owed as ong as the average output current
through one termina pin does not exceed 25A. If the current is higher, use a separate distribution termina b ock as shown
in Fig. 13-2.
Fig. 13-1: Daisy chaining of outputs Fig. 13-2: Using distribution termina s

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 16 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
14. Front Side And User E ements
A Input Terminals
N, L Line input
PE (Protective Earth) input
B Output Terminals
Two identica (+) po es and three identica (−) po es
(+) Positive output
(−) Negative output (return)
C Output Voltage Potentiometer
Open the f ap to adjust the output vo tage. Factory set.: 48V
D DC-OK LED (green)
On, when the output vo tage is >90% of the adjusted output vo tage.
E DC-OK Rela Contact
The DC-OK re ay contact is synchronized with the DC-OK LED.
See chapter 8 for detai s.
F “Parallel Use” “Single Use” Link
Link the two termina po es when power supp ies are connected in
para e . In order to achieve a sharing of the oad current between
the individua power supp ies, the “para e use” regu ates the output
vo tage in such a manner that the vo tage at no oad is approx. 4%
higher than at nomina oad. See a so chapter 24.6.
Fig. 14-1: Front side

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 17 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
15. EMC
The EMC behavior of the device is designed for app ications in industria environment as we as in residentia , commercia
and ight industry environments.
Without additiona measures to reduce the conducted emissions on the output (e.g. by using a fi ter), the device is not
suited to supp y a oca DC power network in residentia , commercia and ight-industria environments. No restrictions
app y for oca DC power networks in industria environments.
EMC Immunit According to generic standards: EN 61000-6-1, EN 61000-6-2, EN 61000-6-3 and EN
61000-6-4
E ectrostatic discharge EN 61000-4-2 Contact discharge 8kV Criterion A
Air discharge 15kV Criterion A
E ectromagnetic RF fie d EN 61000-4-3 80MHz - 2.7GHz 20V/m Criterion A
Fast transients (Burst) EN 61000-4-4 Input ines 4kV Criterion A
Output ines 2kV Criterion A
Signa ines (coup ing c amp) 2kV Criterion A
Surge vo tage on input EN 61000-4-5 L → N 2kV Criterion A
L → PE, N → PE 4kV Criterion A
Surge vo tage on output EN 61000-4-5 (+) → (−) 1kV Criterion A
(+) / (−) → PE 2kV Criterion A
Surge vo tage on DC-OK EN 61000-4-5 Signa ines → PE 1kV Criterion A
Conducted disturbance EN 61000-4-6 0.15 - 80MHz 20V Criterion A
Mains vo tage dips EN 61000-4-11 0% of 100Vac 0Vac, 20ms Criterion A
40% of 100Vac 40Vac, 200ms Criterion C
70% of 100Vac 70Vac, 500ms Criterion C
0% of 200Vac 0Vac, 20ms Criterion A
40% of 200Vac 80Vac, 200ms Criterion A
70% of 200Vac 140Vac, 500ms Criterion A
Vo tage interruptions EN 61000-4-11 0% of 200Vac (=0V) 5000ms Criterion C
Powerfu transients VDE 0160 Over entire oad range 750V, 0.3ms Criterion A
Performance criterions:
A: The device shows norma operation behavior within the defined imits.
C: Temporary oss of function is possib e. The device may shut-down and restarts by itse f. No damage or hazards for the device wi occur.
EMC Emission
Conducted emission input ines EN 55011, EN 55015, EN 55032,
FCC Part 15, CISPR 11, CISPR 32
C ass B
Radiated emission EN 55011, EN 55032 C ass B
Harmonic input current (PFC) EN 61000-3-2 Fu fi ed for C ass A equipment
Fu fi ed for C ass C equipment in the oad
range from 4 to 12A
Vo tage f uctuations, f icker EN 61000-3-3 Fu fi ed, tested with constant current oads,
non pu sing
This device comp ies with FCC Part 15 ru es.
Operation is subjected to fo owing two conditions: (1) this device may not cause harmfu interference, and (2) this
device must accept any interference received, inc uding interference that may cause undesired operation.
Switching Frequencies
PFC converter 100kHz Fixed frequency
Main converter 80kHz to 140kHz Output oad dependent
Auxi iary converter 60kHz Fixed frequency

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 18 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
16. Environment
Operationa temperature 1-25°C to +70°C (-13°F to 158°F) Reduce output power according Fig. 16-1
Storage temperature -40°C to +85°C (-40°F to 185°F) For storage and transportation
Output derating 26.4W/°C Between +45°C and +60°C (113°F to 140°F)
12W/°C Between +60°C and +70°C (140°F to 158°F)
0.66A/1000m or 5°C/1000m For a titudes >2000m (6560ft), see Fig. 16-2
The derating is not hardware contro ed. The user has to take care by himse f to stay
be ow the derated current imits in order not to over oad the unit.
Humidity 35 to 95% r.h. According to IEC 60068-2-30
Atmospheric pressure 110-47kPa See Fig. 16-2 for detai s
A titude Up to 6000m (19685ft) See Fig. 16-2 for detai s
Over-vo tage category III According to IEC 60664-1 for a titudes <2000m
II According to IEC 60664-1 for a titudes >2000m
Degree of po ution 2 According to IEC 62477-1, not conductive
Vibration sinusoida 42-17.8Hz: ±1.6mm According to IEC 60068-2-6
17.8-500Hz: 2g
2 hours / axis
Shock 430g 6ms, 20g 11ms According to IEC 60068-2-27
3 bumps / direction 18 bumps in tota
Audib e noise Some audib e noise may be emitted from the power supp y during no oad, over oad or
short circuit.
1) Operationa temperature is the same as the ambient or surrounding temperature and is defined as the air temperature 2cm be ow the unit.
2) The derating is not hardware contro ed. The user has to take this into consideration to stay be ow the de-rated current imits in order not to
over oad the unit.
3) Do not energize whi e condensation is present.
4) Tested in combination with DIN rai s according to EN 60715 with a height of 15mm and a thickness of 1.3mm and standard orientation.
Fig. 16-1: Output current vs. ambient temp. Fig. 16-2: Output current vs. a titude

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 19 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
17. Protection Features
Output over-vo tage
protection 1
typ. 58.5Vdc
max. 60Vdc
Degree of protection IP 20 EN/IEC 60529
Penetration protection >5mm E.g. screws, sma parts
Over-temperature
protection 2
Inc uded Output shut-down with automatic restart.
Input transient protection MOV (Meta Oxide
Varistor)
For protection va ues see chapter 15 (EMC).
Interna input fuse Inc uded Not user rep aceab e s ow-b ow high-braking capacity fuse
1) In case of an interna power supp y defect, a redundant circuit imits the maximum output vo tage. The output shuts down and automatica y
attempts to restart.
2) In safety critica situations a temperature sensor, which is insta ed inside the unit on a critica component, turns the unit off (e.g. de-rating
requirements not observed, high ambient temperature, venti ation obstructed or the mounting orientation de-rating is not fo owed). There is no
corre ation between the operating temperature and turn-off temperature since this is dependent on input vo tage, oad and insta ation methods.
18. Safety Features
C ass of protection I According to IEC 61140
Iso ation resistance >500MOhm At de ivered condition between input and output,
measured with 500Vdc
>500MOhm At de ivered condition between input and PE,
measured with 500Vdc
>500MOhm At de ivered condition between output and PE,
measured with 500Vdc
>500MOhm At de ivered condition between output and DC-OK
contacts, measured with 500Vdc
PE resistance <0.1Ohm Resistance between PE termina and the housing in
the area of the DIN rai mounting bracket.
typ. 0.12mA / 0.31mA At 100Vac, 50Hz, TN-, TT-mains / IT-mains
typ. 0.18mA / 0.45mA At 120Vac, 60Hz, TN-, TT-mains / IT-mains
typ. 0.3mA / 0.76mA At 230Vac, 50Hz, TN-, TT-mains / IT-mains
max. 0.16mA / 0.38mA At 110Vac, 50Hz, TN-, TT-mains / IT-mains
max. 0.23mA / 0.55mA At 132Vac, 60Hz, TN-, TT-mains / IT-mains
Touch current ( eakage current)
max. 0.39mA / 0.94mA At 264Vac, 50Hz, TN-, TT-mains / IT-mains

CP20.481
Apr. 2021 / Rev. 1.0 DS-CP20.481-xx-EN www.pu spower.com 20 / 32
A parameters are specified at 48V, 10A, 230Vac, 25°C ambient and after a 5 minutes run-in time un ess otherwise noted.
19. Die ectric Strength
The output vo tage is f oating and has no ohmic connection to the ground.
The output is insu ated to the input by a doub e or reinforced insu ation.
Type and routine tests are conducted by the manufacturer. Fie d tests may be conducted in the fie d using the appropriate
test equipment which app ies the vo tage with a s ow ramp (2s up and 2s down). Connect a input-termina s together as we
as a output po es before conducting the test. When testing, set the cut-off current settings to the va ue in the tab e be ow.
We recommend that either the (+) po e or the (–) po e sha be connected to the protective earth system. This he ps to avoid
situations in which a oad starts unexpected y or can not be switched off when unnoticed earth fau ts occur.
A B C D
Type test 60s 2500Vac 3000Vac 1000Vac 500Vac
Factory test 5s 2500Vac 25000Vac 500Vac 500Vac
Fie d test 5s 2000Vac 2000Vac 500Vac 500Vac
Fie d test cut-off
current settings
>10mA >10mA >20mA >1mA
Fig. 19-1: Die ectric strength
B*) When testing input to DC-OK ensure that the max. vo tage between DC-OK and the output is not exceeded (co umn D). We recommend
connecting DC-OK pins and the output pins together when performing the test.
