Pulsar Axion 2 LRF XQ35 User manual

Axion 2 LRF
说明书

內容
About the device
Description
Package Contents
Features
Components and Controls
Power supply
Battery Charging
Battery Installation
External Power Supply
Precautions
Recommendations for Use
Getting Started
Powering on and Image Setting
Button Operation
Interface
Status Bar
Quick Menu
Main Menu
Enter the Main Menu
Color Modes
Smoothing Filter
User Mode
Icon Brightness
PiP Mode
Wi-Fi Activation
Wi-Fi Settings
Microphone
Rangefinder
Calibration Mode
General Settings
Defective Pixel Repair
Defective Pixel Repair
Restore Default Pixel Map
Device Information

Functions
Amplification Level
Video Recording and Photography
Laser Rangefinder
Discrete Digital Zoom
PiP Function
Display-Off Function
Wi-Fi Function
Installing the Device on a Tripod
USB Connection
Software
Stream Vision 2
Firmware Update
Maintenance
Technical Inspection
Technical Maintenance and Storage
Troubleshooting
Specifications
Legal Compliances and Disclaimers

Description
Axion 2 LRFthermal imaging monoculars are designed for use both at night-time and
during the day and provide exceptional image quality even in adverse weather conditions
(fog, smog, rain) and beyond obstacles like branches, tall grass, dense foliage, etc.
known to hinder target detection.
Unlike night-vision devices based on electron-optical converters, thermal imaging
devices do not need an external light source and are resistant to bright light.
Axion 2 LRF thermal imagers are designed for various applications including hunting,
observation, security, terrain orientation, search and rescue operations, etc.
Axion 2 LRF thermal imagers are equipped with a built-in laser rangefinder with a range
of up to 1000 m and a measurement accuracy of ± 1 m.
To get started, see the sections:
Battery Charging
Battery Installation
Powering on and Image Setting
Laser Rangefinder

Package Contents
Axion 2 LRF thermal monocular
APS 5 rechargeable battery
2 battery-locking covers
Power adapter
USB Type-C cable
Carrying case
Hand strap
Quick reference user manual
Lens cleaning cloth
Warranty information
Tripod adapter

Features
Compact and lightweight
Functional and ergonomic design
8-color display palette
3 calibration modes: Manual, Semi-Automatic, Automatic
Detection range up to 1300 m/1422 yds
Smooth digital zoom 2-8x
Three levels of sensitivity enhancement: Normal, High, Ultra
Integrated laser rangefinder
Display-Off function
Defective pixel repair
Updatable firmware
Wide operating temperature range (-25°С to +40°С / -13°F to +104°F)
Fully waterproof (IPX7 rated)
Tripod mount
Video/Audio Recording
Built-in video and sound recorder
Integration with iOS and Android devices
Wi-Fi remote control and viewing using a smartphone
Storing photos and videos in Cloud when using the Stream Vision 2 App
Battery Pack
Quick Change Li-Ion Battery Pack APS 5
Charging from USB Power Bank
Quick-Charge power delivery󰾬

Components and Controls
1. Eyepiece focus ring
2. LED indicator
3. DOWN/REC button
4. MENU button
5. UP/ZOOM button
6. Power ON/OFF/CALIBRATION button
7. Lens focus ring
8. Lens cover
9. Tripod adapter socket
10. USB Type-C connector
11. Laser rangefinder
12. LRF button

LED indicator (2) displays the current status of the device:
LED Indicator Operating Mode
Device is turned on
The device is turned on/video
recording
The device is turned on/battery
charge < 10%
The device is turned on/video
recording/battery charge < 10%

Battery Charging
The Axion 2 LRFthermal imager comes with an APS 5 rechargeable Lithium-ion battery. APS
5 batteries support USB Power Delivery fast charging technology when using a standard
charging set (charger*, USB Type-C cable, power adapter). Before first use, make sure
the battery is fully charged.
Option 1
Image not found or type unknown

Image not found or type unknown
1. Install the APS 5 battery (15) in the battery compartment (14) of the device.
2. Connect the USB cable (19) to the USB Type-C connector (9) of the device.
3. Connect the other end of the USB cable (19) to the Power Adapter (20).
4. Plug the Power Adapter (20) into a 100-240 V socket.
5. Wait until the battery is fully charged (indication in the status bar:
Image not found or type unknown
).
Option 2

Image not found or type unknown

1. Insert the APS 5 battery (15) along the guide into the APS 5 charger* (16) slot as
far as it will go.
2. Connect the plug of the USB Type-C cable (19) to the USB Type-C connector of the
Power Adapter(20).
3. Plug the Power Adapter (20) into a 100-240 V socket.
4. Connect the other end of the USB Type-C cable (19) to the USB Type-C connector
(17)of the charger.
5. LED indicators (18) will display the battery charge level (see Table).
6. Wait until the battery is fully charged (LED indication (18): ).

Note: Two batteries can be charged at the same time, a second slot is provided for it.
LED indication (18) in the battery
charging mode Battery Level
Battery charge level is from 0% to
25%
Battery charge level is from 26% to
50%
Battery charge level is from 51% to
80%
Battery charge level is from 81% to
99%
Battery is fully charged. It can be
disconnected from the charger.
Defective battery. Do not use the
battery!
LED indication (18) in the standby
mode** Battery Level
Battery charge level is from 0% to
25%
Battery charge level is from 26% to
50%
Battery charge level is from 51% to
80%
Battery charge level is from 81% to
99%
Battery is fully charged. It can be
disconnected from the charger.
Defective battery. Do not use the
battery!
* Available separately

** Standby mode is when the batteries are in the charger but the Power Adapter is not
connected. In this mode, the indicators are only on for 10 seconds.
Attention! When using a Power Adapter that does not support USB Power Delivery fast
charging technology, the flicker frequency of the LED indicators decreases by a factor
of 3 and the charge time increases.
Attention! The charger heats up during fast charging. Excess heat is removed through
the radiator and does not affect the device operation.

Battery Installation
1. Put the Lock-cover (13) on the rechargeable APS 5 battery (15).
2. Insert the APS 5 battery (15) along the guide into the battery compartment (14).
3. Lock the battery (15) by turning the Lock-cover (13)clockwise until it stops.
4. Turn the Lock-cover (13) counter-clockwise to remove the battery (15).

External Power Supply
Show device diagram
External power can be supplied from an external source, such as a Power Bank (5 V, 9 V).
1. Connect the external power source to the USB Type-C connector (9) on the device.
2. The device will switch to draw power from the external source while the АPS5
battery is gradually recharged.
3. A battery icon will appear on the display showing the percentage-charged level.
4. An icon will be displayed when the device is powered by an external power
source and the АPS5 battery is not connected.
5. The device automatically switches to the APS 5 battery when the external power
supply is disconnected.

Attention!Charging APS 5 batteries from an external source at temperatures below 0°C
(<32°F) can reduce battery life. When using external power, connect the power bank to
the device only after it has been turned on and working (warming) for at least several
minutes.

Precautions
Always use the APS 5 charger (purchased separately) to charge APS 5 batteries.
Using an unsuitable charger can cause irreparable damage to the battery and fire.
Do not charge the battery immediately after exposure to a cold environment. Let
the battery warm for at least 30 minutes before charging.
Do not leave the battery unattended while charging.
Do not use the charger if it has been modified or damaged.
Do not leave the battery in a plugged-in charger after charging is complete.
Do not expose the battery to high temperatures or open flames.
Do not use the battery as a power source for devices that do not support APS 5
batteries.
Do not disassemble or deform the battery or charger.
Do not drop or strike the battery or charger.
Protect the battery and charger from water and moisture.
Keep the battery out of the reach of children.

Recommendations for Use
The batteries should be partially charged (50 to 80 %) for long-term storage.
Charge at an ambient temperature of 0°C to +35°C (32°F to 95°F) or the lifespan of
the battery will decrease significantly.
Using the battery at sub 0°C (<32°F) ambient temperature decreases battery
capacity. This is normal and not a defect.
Using the battery at temperatures outside the range of -25°C to +40°C (-13°F to
104°F) may reduce battery life.
The battery is short-circuit protected. Any situation that may cause short-
circuiting should be avoided.
