PURE SENSIA 200D CONNECT User manual

IT
DE
ES
NL
DA
ENGLISH
FR
1
Thank you for choosing Sensia 200D
Connect. This manual will get you up
and running in no time and explains
how to make the most of Sensia 200D
Connect’s great features. If you need
additional help with topics not covered
in this manual, please visit the Pure
support pages at www.pure.com.

2
1. Read these instructions – All the safety and
operating instructions should be read before
this product is operated.
2. Keep these instructions – The safety and
operating instructions should be retained for
future reference.
3. Heed all warnings – All warnings on the
appliance and in the operating instructions
should be adhered to.
4. Follow all instructions – All operating and use
instructions should be followed.
5. Do not use this apparatus near water – The
appliance should not be used near water or
moisture – for example, in a wet basement or
near a swimming pool, and the like.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9. Do not defeat the safety purpose of the
polarized or grounding plug. A polarized
plug has two blades with one wider than the
other. A grounding plug has two blades and
a third grounding prong. The wide blade or
the third prong is provided for your safety. If
the provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10. Only use attachments/accessories specified
by the manufacturer.
11. Unplug the apparatus during lightning storms
or when unused for long periods of time.
12. Refer all servicing to qualified personnel.
Servicing is required when the apparatus
has been damaged in any way, such as
power supply cord or plug is damaged, liquid
has been spilled or objects have fallen into
the apparatus has been exposed to rain or
moisture, does not operate normally, or has
been dropped.
13. Do not install this equipment in a confined or
built-in space such as a bookcase or similar
unit. The ventilation should not be impeded by
covering the ventilation openings with items
such as newspaper, tablecloths, curtains etc.
14. WARNING: To reduce the risk of fire or electric
shock, do not expose this apparatus to rain
or moisture. The apparatus should not be
exposed to dripping or splashing. Objects
filled with liquids, such as vases, should not be
placed on the apparatus.
15. WARNING: The direct plug-in adapter is used
to disconnect the device and should remain
readily operable.
16. WARNING: The remote batteries should
not be exposed to excessive heat such as
sunshine, fire or the like.
17. This equipment is a Class II or double
insulated electrical appliance. It has been
designed in such a way that it does not require
a safety connection to electrical earth.
18. Separation distance of at least 20cm must
be maintained between the antenna of the
product and all persons.
19. The power rating marking is located on the
rear of the main unit.
Safety Instructions

3
EN
Contents
4 Getting started
4 Introduction
4 Network setup
4 Touch screen interface
5 Controls and connectors
6 Control buttons
6 Remote Control
7 Switching on Sensia for the first time
8 Connecting Sensia to your
network
8 Preparing Sensia for Wi-Fi Setup
8 Using the Wi-Fi wizard
9 Changing Sensia views
9 Browse view
10 Now Playing view
11 Full Screen view
12 Listening to digital or FM radio
13 Listening to Pure Lounge
content
13 Selecting Internet radio
14 Listening to other internet content
15 Pure Music
15 Accessing Pure Music on Sensia
15 Pure Tag
16 Media Panel options
16 Displaying a slide show of your pictures from a
media server
16 Adjusting slide show settings
17 Listening to audio from a USB
memory stick
17 Streaming audio from a Media
Server
18 Controlling audio playback
18 Recording radio programmes
18 Instant recordings
18 Timed recordings
19 Setting alarms and timers
19 Setting an alarm
19 Switching an alarm on/off
19 Skipping an alarm
19 Snoozing a sounding alarm
19 Cancelling a sounding alarm
20 Changing the snooze time
20 Setting the sleep timer
20 Using the auxiliary input
21 Basic settings
21 Autotune
21 Display
21 Language
21 Changing time/date settings
21 Changing the time format/time zone
22 Advanced settings
22 Manual Wi-Fi setup
22 Connecting Sensia to the Internet with an
Ethernet cable
23 Static IP address configuration
23 Clearing network settings
24 Updating the software
24 Software update options
24 Updating the software using the network
connection
24 Updating the software using the USB port
24 Displaying details on the current software
version
25 Installing the ChargePAK F1
26 Technical specifications

4
Introduction
Thank you for purchasing Sensia 200D Connect. This manual should help you get your product up and
running in no time and tells you how to use all the great features. If you need any further assistance, please
visit the support pages on our website at www.pure.com.
You can use Sensia 200D Connect to:
• Listen to FM/digital radio.
• Act as a media player by streaming music from your PC or network.
• Access the Pure Lounge for thousands of internet radio stations, podcasts and more.
• Connect a USB memory stick to record live radio or play any stored music.
• Access the Pure Music streaming service.*
• Identify and purchase songs by using the Pure Tag and Buy service.*
• View photos from your network or the internet.
• Monitor and update Facebook and Twitter.
• View a news feed or the weather.
Note: Sensia 200D Connect will be referred to as Sensia throughout the rest of this user guide.
Network setup
In order to access the Pure Lounge service or use media streaming you will need to connect Sensia to your
network. You can connect Sensia to your network using a wireless (Wi-Fi) or wired connection. If you want to
use the wired connection method, you will need to plug the optional USB Ethernet adapter into the USB port
on the back of Sensia. See page 8.
We recommend using the wireless connection method, which allows you to position your Sensia anywhere
within range of your wireless connection. The wireless connection method also has the advantage of leaving
the USB port free, enabling you to carry out USB and playback. See page 18.
Touch screen interface
The touch screen on Sensia 200D Connect features a number of common controls:
Options Lists
Use your finger to scroll/
up down the list and tap
the option that you want to
choose.
Buttons
Tap the button with your
finger to select the required
option.
*Subscription required. Only in countries where Pure Music is available.
Getting started

EN
5
EN
Controls and connectors
Control buttons
See page 6
DC In
Connector for
supplied mains
power adapter.
Aux In
Connector for analogue
stereo input for MP3
player or similar.
USB
Connector for USB
Ethernet adapter or
USB memory stick for
recording/playback.
ChargePAK
cover
Touchscreen
interface
FM/digital aerial
Headphone
Stereo headphones
connector.
Stand

6
Standby
Short press to put Sensia in sleep mode,
which will display the clock.
Long press to switch Sensia in/out of
standby (the screen will turn off when
Sensia is in standby).
Mute
Press to mute volume.
- Vol +
Press to adjust volume up or down.
and
Skip to beginning of current track or go
to previous or next track. Hold to rewind
or fast forward.
Play/pause current track.
Source
Press to switch between Digital radio, the
Pure Lounge, Network/USB media, FM
radio and Auxiliary input.
Favourites
Press to scroll through the stations in
your favourites list for the selected radio
source or your Pure Lounge favourites.
Record
Press to record digital or internet radio to
a USB memory stick. See page 18.
Tag
Press to use Pure Tag to identify the song
that is playing on a digital, FM or internet
radio station. See page 15.
Remote Control
Volume Up
Standby
Short press to put Sensia in sleep
mode, which will display the clock.
Long press to switch Sensia in/out
of standby (the screen will turn off
when Sensia is in standby).
Volume Down
Mute
Control buttons

EN
7
EN
Switching on Sensia for the first time
Note: If you have a ChargePAK F1 rechargeable battery (sold separately) fit it now before plugging Sensia in.
See page 25 for more information.
1. Connect the power lead into the power socket on the back of Sensia.
2. Plug the mains adapter into a live mains socket.
3. Sensia will switch on.
4. Tap the language that you want to use on the user interface.
5. Scroll down to the region you are in and tap to confirm the time zone for your region.
6. Scroll to your nearest city and tap to confirm the time zone for your city.
7. Tap an option to turn demo mode on/off. Demo mode is a screensaver that runs after two minutes of
inactivity.
8. Sensia will perform an autotune for digital stations and tune to a station when complete.
9. Sensia will display the Now Playing view when the autotune has completed.

8
Connecting Sensia to your network
To listen to internet radio, connect to a media player, access Twitter, Weather, RSS Newsreader, Picasa
and Facebook, you will need to connect Sensia to your network. We recommend using the Wi-Fi wizard to
connect Sensia to your network. To setup your network manually see ”Advanced settings” on page 22.
Note: The Wi-Fi wizard will automatically start if you have not set up your network settings and you select The
Pure Lounge or Network/USB media as the audio source.
Preparing Sensia for Wi-Fi Setup
1. Tap the Browse button in the top right-hand corner of the screen to
display the Browse view.
2. Position Sensia in range of your wireless network.
3. Tap Settings to display the Settings menu.
4. Tap Network to display the Network Settings menu.
5. Tap the icon next to Network type to display .
6. A summary of your wireless settings will display on Sensia.
7. To set up the wireless connection on Sensia using the wizard, tap
the Wizard button and follow the steps outlined below.
Using the Wi-Fi wizard
1. Tap the name of the wireless network you want to connect to.
2. If your wireless network has security enabled, enter the security key
using the on-screen keyboard.
Note: Your Wi-Fi key can normally be found on your router. If
unsure, contact your Internet Service Provider.
Note: Your Wi-Fi key is case sensitive so you will need to enter it
exactly as shown. To change between upper/lower case, tap the
key.
3. Wait while Sensia connects to your network.
4. Sensia will return to Browse view after connecting to your wireless
network.

EN
9
EN
Changing Sensia views
Sensia has three main views, Browse, Now Playing and Full Screen. The Browse view allows you to select
sources and browse for content, the Now Playing view shows the media panel and controls, the Full Screen
view maximises the media panel so that it takes up the whole screen. When you select a new source, Sensia
defaults to the Now Playing view.
Browse view
No. Item Description
1 List Panel To navigate the list panel use your fingertip to scroll the list panel up or down and tap a station/track to begin
listening.
2 Home Tap the Home icon to go back to the home for the current source.
3 Back Tap to return to the last view.
4 Quick Jump Tap the Quick Jump icon to open the Quick Jump Box.
Tap a letter to jump to the first station or track beginning with that letter.
5 Search Tap the Search icon to search for stations or tracks.
6 Media Panel Displays screens associated with the media playing, or other visuals of your choice such as photos, weather,
Facebook, Twitter or a news feed. Slide left/right and/or up/down.
7 View controls Tap these buttons to change the Sensia view (Browse view, Now Playing view, and Full screen view).
8 Information panel Displays any data associated with the radio station or media file.
9 Power Indicates if Sensia is connected to mains or if it is using a ChargePAK. If Sensia is using a ChargePAK, this
indicates the amount of power left in the ChargePAK.
10 Signal Strength Tap to display more information about the strength of the FM/Digital and Wi-Fi signal.
11 Audio Tap to adjust the bass, treble and boost the auxiliary input volume.
12 Settings Tap to view/change settings, including network, display and language.
13 Source Tap to change the audio source.
14 Alarms Tap to set the alarms and change the timer settings.
15 Recordings Tap to set timed recordings.
16 Clock/Date Tap to change the time and date settings on Sensia.
17 Icon Bar Displays the time and icons that relate to the function being used.

10
Now Playing view
The controls in the Now Playing view differ depending on the Source that has been selected.
No. Item Description
1 Icon Bar Displays the time and icons that relate to the media being listened to.
2 Playback controls/
Recording space
Tap the icon of the control you want to use. These controls are only active if the media being played can be
controlled, e.g. music files from a USB memory stick, Media Player or from Pure Music, or Podcasts. If you are
carrying out a timed recording to a USB memory stick, the amount of time left before the timed recording will
end is indicated by the bar above the playback controls.
3 Media Panel Displays screens associated with the media playing, or other visuals of your choice such as photos, weather,
Facebook, Twitter or a news feed. Slide left/right and/or up/down.
4 Media Title When playing music, displays the name of the track. When listening to a radio station, displays the name of the
radio station.
5 View controls Tap these buttons to change the view (Browse view, Now Playing view, and Full screen view).
6 Media Information When playing music, displays information about the artist and album. When listening to a radio station displays
information about the radio show.
7 Record Tap to instantly record the live radio broadcast (digital and Internet radio only). See page 18.
8Tag Tap to use the Pure Tag service to identify the name of the song that is being played. See page 15.
9 Favourites Tap to add the radio station to your favourites. See page 14.
10 Clock/Date Tap to change the time and date settings.

EN
11
EN
Full Screen view
No. Item Description
1 View controls Tap these buttons to change the Sensia view (Browse view, Now Playing view, and Full screen view).
2 Media Panel Displays any artwork associated with the radio station/music playing.

12
Listening to digital or FM radio
Selecting digital/FM radio
1. Tap Source to display the Source menu.
2. Tap Digital radio or FM radio.
Changing digital stations
1. Tap Browse to display the Browse view.
2. Tap Stations to display a list of available digital radio stations.
3. Scroll to the radio station that you want to listen to and tap to
tune into the station.
Changing FM stations
Tap the seek buttons to automatically scan for the next
station. The scan will stop when a station with a strong signal is found.
Alternatively, tap the manual tuning buttons to manually scroll
to the required frequency.
Saving your favourite stations
1. Tap the Now Playing icon in the Media panel.
2. Tap the Favourite icon so that it highlights in red
3. The radio station will be added to your favourites.
Selecting a favourite FM station
1. Tap Source to display the Source menu.
2. Tap FM radio.
3. Tap Browse to display the Browse view.
4. Tap the name of the radio station that you want to listen to in the list
panel.
Selecting a favourite digital station
1. Tap Source to display the Source menu.
2. Tap Digital radio.
3. Tap Browse to display the Browse view.
3. Tap the Digital radio favourites folder.
4. Tap the name of the radio station that you want to listen to in the list
panel.
Digital radio FM radio

EN
13
EN
Selecting Internet radio
1. Tap Source to display the Source menu.
2. Tap The Pure Lounge.
Searching for internet stations
1. Tap Browse to display the Browse view.
2. Tap the Live radio icon.
3. Tap the search icon on the top right of the list panel. This will
open the search options in the visual panel to the right. You can
search for stations based on the criteria described below:
Name
Tap to search for a radio station by name. Type the name that you
want to search for using the on-screen keyboard. Tap to
confirm.
Genre
Tap to search for a radio station based on the genre, e.g, station
content. Tap the genre to confirm.
Language
Tap to search for a radio station based on its broadcasting
language. Tap the language to confirm.
Country
Tap to search for a radio station based on the country that it is
broadcasting from. Tap the country to confirm.
Quality
Tap to search for a radio station based on the audio quality. Tap the
audio quality level that you want from one (low) to five (high).
4. Tap the Search button when you have finished specifying the
search criteria. Any radio stations that have been found matching
the specified criteria will display in the List Panel.
Listening to Pure Lounge content
The Pure Lounge allows you to explore thousands of radio stations, BBC listen again programmes, podcasts
and Pure Sounds. To use the Pure Lounge, you will need to connect Sensia to your network. See page 8
for more information.
After connecting Sensia to your network, you can register your radio on the Pure Lounge website. We
recommend registering your radio as this allows you to manage your radio and Pure Lounge favourites and
access subscription services like Pure Music and Pure Tag.
To register your Sensia:
1. Go to www.thelounge.com on your PC or Mac.
2. Login with your account details or register for an account.
3. After logging in, follow the instructions to receive your registration code. You will be asked to enter this
code into your Sensia when you try to select the Pure Lounge as a source.
The Pure Lounge

14
Using Quick Jump
Tap the Quick Jump icon at the top left of the list panel to open the Quick Jump box. Tap a letter to jump
to the first station or track beginning with that letter.
Saving your favourites stations/Pure Lounge favourites
1. Tap the Favourite icon so that it highlights in red
2. The radio station will then be listed in the My favourites list. If you have multiple folders/devices in your
Pure Lounge account then your Pure Lounge favourites will be saved under the folder associated with this
Sensia (default name “Sensia 200D Connect”)
Listening to other internet content
1. Tap Source to display the Source menu.
2. Tap The Pure Lounge.
3. Then tap on one of the following content types:
Listen again
Tap this option to access the BBC Listen Again service, which lets you catch up with any BBC radio
shows that you might of missed. These archived radio programmes are available to listen to for a set
period of time after the live broadcast.
Podcasts
Podcasts are pre-recorded audio shows on a wide variety of subjects such as comedy, arts, business
and culture, for you to enjoy anytime.
Pure Sounds
Our library of sounds, from birdsong to cityscapes, rolling thunder to sports cars.
Pure Music
Pure Music is a cloud-based on-demand subscription service that gives you instant access to millions
of music tracks. You can only see this option when you have an active Pure Music subscription. See
page 15 for more information.
Selecting a favourite internet station
1. Tap Source to display the Source menu.
2. Tap The Pure Lounge.
3. Tap the My favourites icon.
4. Tap the name of the folder that your favourite radio station is located in.
5. Tap the name of the radio station that you want to listen to in the list panel.

EN
15
EN
Pure Music
Pure Music is a cloud-based on-demand subscription service that gives you instant access to millions of
music tracks.
Pure Music enables you to find and play as many tracks and albums as you want on multiple devices,
including Pure’s wide range of wireless music and radio systems, PCs and Macs via the Pure Lounge website,
and smartphones running the free Pure Lounge app.
Pure Music also incorporates Pure Tag, a unique, free, tagging service which lets you identify radio and on-
demand tracks on your Sensia, and bookmark them for easy access. With a Pure Music subscription you
can play tagged tracks on all your Pure wireless music and radio systems and use the Pure Lounge website’s
powerful search function to find and listen to other tracks by the same artist, explore related podcasts and
discover music by similar artists.
You can also use the Pure Lounge website to organise tracks or albums by dragging and dropping them into
playlists which are synchronised across all your Pure Music listening devices. You can also share your playlists
using Facebook and Twitter
Pure Music is only available in certain countries. Please see http://www.thelounge.com for details.
Accessing Pure Music on Sensia
1. Tap Source to display the Source menu.
2. Tap The Pure Lounge.
3. Tap Pure Music.
3. Tap one of the following icons:
My Tracks
Tap this icon to access the tracks that you have purchased from the Pure Lounge.
Catalogue
Tap this icon to browse or search the complete Pure Music catalogue on your Sensia.
By playlist
Tap this icon to listen to playlists created by you at www.thelounge.com.
Pure Tag
The Pure Tag service can be used to identify, bookmark and purchase tracks that are playing on a digital,
FM or internet radio station. In addition to accessing your favourite music tracks, the Pure Tag service also
automatically back catalogues any music by similar artists that you might be interested in, allowing you to
explore something completely new or rediscover forgotten favourites.
Note: To access your tagged tracks list, you will need to log in to your Pure Lounge account at
www.thelounge.com.
1. Tap the Tag icon in the icon bar.
2. Sensia will identify the name of the song that is being played and allow you to buy it (or stream it if you
have Pure Music).
Note: To use the Pure Tag service, your Sensia will need to be connected to your network and you will need a
Pure Lounge account. See page 13 for more information on setting up a Pure Lounge account.

16
By default the Media Panel will display pictures related to the radio station you are listening to, or artwork
related to the track being played. Alternatively you can choose to display a slide show of your own
photographs from a media server or access internet content from Twitter, Weather, RSS Newsreader, Picasa
or Facebook. Sensia needs to be connected to your network to access most of these options and you will
need to be a member of Facebook, Twitter or Picasa if you want to use them.
Accessing Facebook, Twitter, Picasa and more
Swipe the Media Panel to the left or right until Twitter, Weather, RSS
Newsreader, Picasa or Facebook is displayed then swipe up or down to
choose which one you want to access.
Changing settings and getting help
To edit settings or the login details, tap the cog icon in the bottom
left hand corner of the Media Panel.
To view help information (where available) tap the help icon in the Media
Panel.
Displaying a slide show of your pictures from a
media server
You can view pictures on Sensia from a media server on your network.
The pictures are displayed in the form of a slide show. To view pictures
from a media server, carry out the following:
1. Tap the Browse view button.
2. Tap Source.
3. Tap Network/USB media.
4. Wait while Sensia searches for pictures on any available media
servers on your network.
5. The list panel will display a list of the media servers that have been
found on your network.
6. Tap the media server that you want to connect to.
7. Navigate to the area where the pictures are located.
8. Tap the play icon to start viewing the pictures.
Adjusting slide show settings
1. Tap the Media Panel.
2. Tap the cog icon that appears in the bottom left hand corner.
3. Adjust the slide duration by tapping on the top and bottom of the
photo timer to select the required number of seconds.
4. Tap
photo timer to select the required number of seconds.
to save the slide show settings.
Media Panel options

EN
17
EN
To listen to tracks from a media server, ensure that Sensia is in Browse
view and carry out the following:
1. Tap Source.
2. Tap Network/USB media.
3. Wait while Sensia searches for available media servers.
4. The list panel will display a list of the media servers that have been
found on your network.
5. Tap the server that you want to connect to.
6. Navigate to the area where the audio is located.
You can stream music stored on your computer or on a UPnP-compatible Network Attached Storage device
to Sensia. To stream music from your computer you will need to install media server software on it.
We recommend that you download our Pure Flowserver software from www.thelounge.com. Alternatively, you
can use another media server, such as Windows®Media Player 11.
For help with downloading and installing Flowserver, for both Mac and PC, or on setting up Windows Media
Player as a server, follow our step-by-step guides at http://support.pure.com.
Streaming audio from a Media Server
To listen to tracks from a USB memory stick:
1. Tap Source.
2. Tap Network/USB media.
3. Wait while Sensia searches for available media servers.
4. The list panel will display a list of the media servers that have been
found on your network.
5. The contents of your USB memory stick will be shown.
6. Navigate to your tracks and tap to play.
Sensia can be used to play music by connecting a USB memory stick to the USB port on the back of Sensia.
The audio file types that Sensia supports include WMA (Standard V9), AAC, MP3 and MP2. By default, Sensia
looks for audio on your network if you have not connected a USB memory stick to the back of Sensia.
Listening to audio from a USB memory
stick
Network/USB media

18
Recording radio programmes
Sensia allows you to record live radio from the Pure Lounge and digital radio. You can either schedule
recordings or record instantly. To record, you need to connect a USB memory stick to the USB port on the
back of Sensia. The length of time that you can record depends on the amount of space available on your
USB memory stick and the station that you are recording. If your USB memory stick runs out of space during
a recording, Sensia will stop recording and display a message.
Instant recordings
To record instantly you will need to:
1. Tap Source to display the Source menu.
2. Tap The Pure Lounge or Digital radio.
3. Tune into the station that you want to record to and tap the Record
icon in the icon bar or on the remote to begin recording.
Timed recordings
Note: To use timed recording, the radio station must be set up as a
favourite. For more information on creating a favourite internet radio
station, see page 14. For more information on creating a favourite
digital station, see page 12.
1. Tap Recordings to display the Recordings menu and tap the icon
of the timer that you want to set.
2. To record from a digital radio station, tap Digital radio favourites
and select the station from the list. To record from an internet radio
station, tap Pure Lounge favourites and select the station from
the list.
3. Tap the button at the top to toggle the recording on or off
.
4. Tap the Occurrence drop-down menu to specify how often the
recording should occur.
5. Tap Start to specify the recording start time.
6. Adjust the recording start time by tapping on the top and bottom of
the clock to flip through the minutes and hours.
7. Tap End to specify the recording end time.
8. Adjust the recording end time by tapping on the top and bottom of
the clock to flip through the minutes and hours.
9. To exit and save the recording tap . To exit and discard all
changes tap .
Note: When you are scheduling a recording, the amount of space that
is currently available on your USB memory stick is indicated in black on
the free space bar at the bottom of the Timed recording screen.
Controlling audio playback
If you are streaming audio on Sensia from either a USB memory stick or Media Server, you can control the
playback using the remote or on Sensia as follows:
1. Tap the Now Playing icon in the information panel.
2. You will now be able to play, pause and skip tracks by clicking the respective icons.
