PureEffect ULTRA-UC-DISINFECT User manual

1
Thank you and Congratulations on your purchase of The PureEffectTM ULTRA-UC-DISINFECT
Advanced CITY-WATER Filtration System Featuring: Our 0.05 Micron UltraFiltration Membrane(Microbe
Filter), FluorSorb-MAXTM (Fluoride Filter), AntiRad-PlusTM (Radiation Filter), SuperBlockTM (Wide-Range
Chemical/Sediment Filter), KDF55®(Heavy Metal Filter) and Natural Alkalization Technologies.
INSTALLATION INSTRUCTIONS
IMPORTANT! - BEFORE YOU START:
Failure to follow proper installation instructions voids all warranties and liabilities.
- If your PSI is over 80 and/or has a tendency to Spike: please ensure there is a pressure
regulator installed and is in proper working order before proceeding. At no time should the
filter housings be subject to more than 80PSI (most common PSI range is between 40-80). You
should contact a licensed plumber if you are not able to check this on your own. Excessive
water pressure could cause damage to the system and water to leak out. Included Leak-
Stopper MUST be properly installed to maintain warranty.
- Do not expose the system to direct sunlight and/or freezing or hot (over 120F)
temperatures. Do not install the system where if would cause damage if leakage occurred.
1. Unpack your system, remove and set aside cartridges (by unscrewing chambers) and
inspect system for any transportation damage. If damage is found, please contact us right
away.
2. Find the (2) individually wrapped White Elbows. Locate the words “IN” and “OUT”
on the unit’s water connection ports. Screw 1 elbow into the “IN” port and the additional
elbow into the “OUT”port of the filter system. (You may use a 2-Way output splitter for
the output instead, if you ordered it).
Customer Support:
Tel: [phone]
Email: [e-mail]
www.PureEffectFilters.com
Blue
Output
Red
Input

2
(NOTE: The full Installation Diagram can be seen on page 4.)
3. Turn-Off Cold water supply via your Cold Water Shut-Off Valve (Angle Stop) and
verify it’s off by opening the cold water on your faucet.
4. Disconnect your existing connection (e.g. Kitchen Faucet Hose) from the cold-water
Angle Stop.
5. Connect our included John Guest®Angle Stop Valve Adapterto the cold-water Angle
Stop, see example pictured below. Note: Applying Plumbers Tape on the threading can
add extra protection from leaks.
6. Reconnect your Kitchen Faucet Hose to our John Guest®Angle Stop Valve Adapter
7. Position unit where you’d like, and ensure that the blue output and red water input
tubing will adequately reach the unit on the In/Out sides. Hang the filter system under the
sink at least 4” above floor (to allow for removal of chambers for cartridge changes). You
may also stand the unit on itself if you don’t wish to hang it.
If you purchased our 1. Pressure Regulator 2. Leak-Stopper or 3. *Gallon Meter:
Connect the red tube to these first in the order they are listed here before connecting
to filter INPUT. Ensure to follow the flow-direction indicator arrows on each
device to ensure the flow is in proper direction.
*Setting Gallon Meter: Please see instructions included with it.
8. Push-in one end of the Red tube into the Push-Connect port of the John Guest®Angle
Stop Valve Adapter until it “pops-in” as far as it can go & push the other end into the
INPUT of the Leak-Protector (included w/separate instructions). Then, connect the
OUTPUT from the Leak-Protector into the Input Elbow of the filter system (please
ensure it pushes in as far as it can go). Diagram can be seen on page 4.
9. Install the dedicated faucet into the sink. (See instructions on next page).
Angle Stop Valve
(cold water)
Angle Stop Valve Adapter
Kitchen Faucet Hose
Red “IN” Tube
Push-Connect Port

3
FAUCET INSTALLATION INSTRUCTIONS
1. Use existing spray hose / soap dispenser hole or drill a new 1-3/8” diameter hole in sink.
(If your sink is ceramic, granite or some other fragile material please consult with an
expert to avoid cracking it during drilling).
2. Attach parts 9-11 to the
faucet above the sink as shown
on diagram to the right and
insert faucet into the hole in
your sink.
3. Attach parts 12-15 to the
faucet below the sink as shown
on diagram to the right.
Note: Hand-Tighen part #15
to avoid damaging it with
instruments. Plumbers tape
can be added before screwing
it on for extra leak proofing.
4. Plug the Blue Input tube
into Part #15 (Push-Connect
Fitting) as far as it can go.
5. Plug the other end of the
Blue tube into the filter
OUTPUT side elbow as far as
it can go.
*To Disconnect the tubing from
any connections:

4
UNDERSINK INSTALLATION DIAGRAM
See Next Page for Proper Cartridge Placement & Flush Procedure

5
INITIAL CARTRIDGE FLUSH AND SYSTEM LEAK TEST
IMPORTANT! –ENSURE CARTRIDGES ARE INSERTED IN CORRECT ORDER!
Note: You may want to place a towel under the unit to catch the water, which is released when
you unscrew the last chamber for Step D.
D. You may notice the water is cloudy; this is just mineral/carbon fines being
released. Allow the cold water to run on full for 5minutes then turn off faucet & shut off
water supply to filter via the Angle Stop Adapter Valve, then open filter's faucet to release
pressure. Remove Shrink Wrapping and Insert the UltraFiltration Membrane into
Chamber #2and AntiRad-PlusTM Cartridge into Chamber #4. Flush the entire system
again for 10 additional minutes.
Congratulations! Your System is now ready for use.
A. Remove Shrink Wrapping and insert the
cartridges in the following order:
Chamber #1 - SuperBlockTM
Chamber #2 - Close Empty for now
Chamber #3 –FluorSorb-MAXTM
Chamber #4 -Close Empty for now
*We recommend to hand tighten housings when closing
to prevent over tightening.
B. Ensure area is dry and connect the Leak-
Stopper according to its instructions. If water gets
under the leak stopper, it will trigger it to shut off flow to
the filter, if so, please replace it’s moisture detection
pad.
C. Slowly turn the cold water valve back on, check
newly installed faucet and all connections for a
watertight seal. *Note: you may hear a slight “hissing”
sound when the filter is working; this is normal.
Note: Water may be cloudy for about a week as the natural minerals in the cartridges adapt, to speed
the adaptation period up, turn the system on 15-20 seconds at a time more often throughout the day.
Do not flush for longer periods, as it won’t be as effective as smaller bursts.
Red
Input
Blue
Output
1
2
3
4
SuperBlockTM

6
THE FILTER SYSTEM IS DESIGNED FOR COOL - COLD WATER USE ONLY.
FOR CARE & OPTIMAL PERFORMANCE:
*If you have high sediment in your water, we recommend letting the kitchen faucet run for a
few seconds each time before using the filter, this may extend the filter life by flushing out
large accumulated sediment from the plumbing.
PRECAUTIONS:
ALWAYS make sure to first shut off the unit’s main water supply line and open
filters’ faucet to release pressure before servicing the system.
Never connect hot water to the filter, as the filtration process will not be effective.
Use only cold/cool water. Throughout usage you may notice the water level fluctuate
in the clear chambers, this is a normal effect and does not interfere with proper filter
function.
MAINTENANCE SCHEDULE:
a. Filter Cartridge Replacement (Every 500 gallons for consistently superior water
quality)*: a. Every 6 months: If using up to 2-3 gallons (32-48 cups)/day
b. Every 12 months: If using up to 1-2 gallons (16-32 cups)/day
*Based upon one of the most difficult to remove contaminants (Fluoride) at the federally
recommended levels of 0.7mg/L. For greater Fluoride levels, replace the Fluoride
cartridge sooner:
a. If Fluoride Concentration: apx. 2.2ppm = Replace Every 150 gallons
b. If Fluoride Concentration: apx. 1.2ppm = Replace Every 300 gallons
b. Wipe unit/housings inside with non-toxic dish soap and rinse well. Do Not over tighten
housings when closing them.
c. Lubricate the rubber o-rings inside the housings, on the spout and in UV Chamber Caps
with an FDA & NSF Compliant Food-Grade Silicone lubricant (included) once a year to
help maintain leak-free performance.
UltraFiltration Membrane: Replace every 3 years, but soak in 3% Hydrogen Peroxide
in a tall container (so the membrane is fully submerged) for 12 hours during every
cartridge change or, 45 minutes in 10% Hydrogen Peroxide, rinse well with warm water
and place back into the system, flush system for 10 minutes.

7
RETURN POLICY & WARRANTY
1. If the filter arrived damaged, please call us immediately to get an exchange: 1-347-492-4014
2. If you choose to return the filter for any reason other than damage upon arrival, we will be happy to issue a
full purchase price refund or exchange within: 14 days of delivery date, minus shipping cost. The return
policy applies to water filter systems and any unused (sealed) filter media cartridges. If cartridges have
been opened and used, we will deduct the price of the cartridges from the refund, as they will no longer be re-
sellable.
3. If you decide to return past the 14-day return period, we will still accept the item for up to 30 days
from delivery date, however, there will be a reasonable 10% restocking fee applied. Please call us or
send an email to initiate the return process or if you have any further questions.
Once you’ve experienced your new system, feel free to share your positive experience by going to
our website product page and writing a review. Thank You! - The PureEffect Team
NO-HASSLE 2-YEAR WARRANTY
SURVIVE & PROSPER, INC. dba PureEffectFilters.com, warrants its water filter systems to be free of defects
in parts and workmanship for a period of: two (2) years from the date of purchase.
All our systems are made of high-quality components (not made in china) and are designed to last for many
years beyond the warranty period, but if any manufacturing defect is present, it will make itself know well
within the warranty period.
In the rare case that it should become necessary to repair or replace the filtration system or one of it's
components, please take a photo of the damaged part and email it along with your order # and a detailed
description of the defect to: [e-mail] or contact our Customer Service Department at: 1-
888-891-4821. We will handle your claim promptly, and as hassle-free as possible.
This warranty does not apply to defects resulting from action/s of the user such as: misuse, accidents,
improper installation, operation outside of specification (e.g. over the indicated PSI limit, exposure to direct
sunlight, freezing temps, UV light), improper maintenance or repair and unauthorized modification.
Survive & Prosper, Inc.’s total liability is limited solely to repair or replacement of the product. The warranty
set forth above is inclusive and no other warranty, whether written or oral, is expressed or implied.
