Chapter 1. Introduction
1.1 Safety Precautions
When using and installing Dtrovision PureLink product, adhere to the following basic safety
precautions.
 Read and understand all instructions before using and installing this product.
 The safety and operating instructions should be retained for future reference.
 Always use the correct external power supply (indicated on the product label) when
operating this unit.
 Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners
or aerosol cleaners. Use a damp cloth for cleaning.
 Mishandling of this product may lead to a fire or explosion hazard.
 Do not place any heavy objects or equipment on top of the product.
 Keep away from wet, magnetic, and flammable surfaces or substances.
 Air vents should be kept clean and unobstructed at all times.
 Any external impact may cause damage to the operation of this unit.
 Be sure this product is properly grounded (earthed) in order to prevent the risk of
electrical shock.
 Turn off and unplug power before adding or removing Input/Output Boards.
 Input/Output Boards may be damaged when they are replaced with power turned on.
 Use surge protectors and/or AC line conditioners when powering this product.
 Only use a fuse(s) with the correct fuse rating in your enclosure.
 Make sure the product is on or attached to a stable surface.
If you experience any malfunctioning of product or have any question as to operation
of the product, please contact our customer service center.
Dtrovision LLC
Tel: [phone]
Email: [e-mail]

PureLink by Dtrovision
4
Welcome!
Congratulations on your purchase of the PureLink PureMedia Fiber Optic (1 LC) extender.
This manual contains information that will assist you in installing and operating the product.
1.2 Product Introduction
Pure fiber optic cable for video, audio, and control signal
PureMedia Fiber Optic (1 LC) extension system is designed to transmit video (DVI,
HDMI or VGA), audio (Embedded or analog stereo audio), control (RS232) over a pure
LC to LC fiber optic cable for long distance up to 32,808ft (10km). This optical
connection enables to minimize electrical noise and EMI free that is ideal for long
distance extension of high definition HDMI/DVI or VGA video signal, HDMI embedded
audio or 3.5mm stereo analog audio, and control signal.
1.3 Package Contents
Please make sure all of the following items are included in the package:
1) One of PM-FT101-U, FT102-U, FT103-U Transmitter Module or
2) One of PM-FR101-U, FR102-U, FR103-U Receiver Module
3) 3pin Phoenix Connector for RS-232
4) DC 12V Power Supply Unit with a Power Cord
5) User’s Manual
6) Option Product: TWF1 (1 LC Fiber Optic Cable with TotalWire Technology)
PI (PureLink’s PureInstall HDMI cable with TotalWire
Technology)

PureLink by Dtrovision
5
Chapter 2. Features and Specifications
2.1 Features
Zero loss & Zero noise delivery
Zero loss & zero noise delivery of digital high definition video and audio signal using
Fiber optic connection, PureMedia Fiber Optic (1 LC) extender delivers HD signals
over single fiber optic cables without loss or digital interference maintaining the clarity
and colors. Noise cancellation and error correction logic enhances HD video and
audio signals over long distance.
Compact and Robust enclosure design
Compact and robust enclosure design allows for discreet installation behind a flat-
panel display.
Uncompressed high definition video up to 4K2K@30Hz@48bits and 3D
Bi-Directional RS232 interface
Commands and data can flow in both directions via RS232, allowing status requests
and control of the destination unit.
Max. Data Rate- 10.2 Gbps
HDCP (High-bandwidth Digital Content Protection) Support
Audio transmission support LPCM 7.1@192KHz, Dolby TrueHD, DTS-HD MA
Transmitters directly compatible with PureMedia Fiber Optic Input Board
PureMedia Fiber Optic (1 LC) Transmitters can send signal directly to PureMedia
Matrix Switcher's Fiber Optic Input Board, eliminating the need of matching Receiver.
Receivers directly compatible with PureMedia Fiber Optic Output Board
PureMedia Fiber Optic (1 LC) Receivers can receive signal directly from PureMedia
Matrix Switcher's Fiber Optic Output Board, eliminating the need of matching
Transmitter.
HDMI v1.4, 3D Support
Adopting latest HDMI version 1.4 enables to support 3D, 48-Bit Deep Color, 4K x 2K
resolution and 7.1 Channel Dolby TruHD & DTS MasterHD

PureLink by Dtrovision
6
Real Time EDID
PureLink's real time EDID features failsafe, constant and continuous EDID for source
devices.
Various Transmitter and Receiver Choices
There are three different types of transmitters and three different types of receivers to
make today's sophisticated digital AV environment simple and flexible.
RF 1RU Rack Mountable Version Available
PM-FT101-U, PM-FT102-U, PM-FR101-U, and PM-FR102-U are also available in
PureLink's popular RF Rack Mountable Extension Center Modules.
Analog Support (VGA and Component)
On PM-FT102-U and PM-FT103-U series, there are two video inputs; DVI/HDMI and
VGA, which are selectable via front panel button or serial command when it is
connected PureMedia Matrix Switcher. VGA port is designed to take component
(YPbPr) signal with appropriate adapters or cables.
USB Firmware Update
Long Distance Transmission up to 32,808ft (10 km)
Plug-N-Play
2.2 Specifications
Transmitters :
PM-FT101-U : Standalone type
Input : HDMI + 3.5mm stereo audio (x1) + RS-232
Output : Fiber Optic (1 LC)
32,808ft, Compatible with PM-FIS4-U input board

PureLink by Dtrovision
7
PM-FT101-U : PureMedia HDMI to Fiber Optic (1 LC) Extender Transmitter
Front Connection Ports:
Power S/W: Power On/Off switch
Status LED: Video signal presence indicator
Firmware: USB firmware update port
Back Connection Ports:
HDMI/DVI In: HDMI/DVI input port
Audio In: Stereo audio input port
Optical: 1 LC Fiber Optic output port
RS-232: RS-232 communication port
DC In: DC 12V Power port
Model Name
PM-FT101-U (HDMI version), PM-FT102-U-D (DVI version)
Input Signal
DVI / HDMI (TMDS)
3.5mm stereo audio
Output Signal
Fiber Optical Output ( > -10dbm (after 32,808ft (10km) transmission))
Extinction Ratio
> 4db (after 32,808ft (10km) transmission)
Data Transmission
Speed
3.4 Gbps/ch, Total 10.2 Gbps Max

PureLink by Dtrovision
8
Supporting Display
Resolutions
PC: VGA ~ WUXGA
(up to 1920 x 1200 @60Hz)
HDTV: 480i ~ 1080p,
Up to Ultra HD 4K
4096 x 2160 @24/25/30Hz (RGB/YCbCr 4:4:4 8 bits, YCbCr 4:2:2
8/10/12 bits)
4096 x 2160 @50/60Hz (YCbCr 4:2:0 8 bits)
Max. Distance
Single Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p, Ultra HD 4K :
32,808 ft (10km)
Multi Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p, Ultra HD 4K :
1,650 ft (500m)
Connector Type
DVI 29P/HDMI 19P Female (x 1)
3.5mm Stereo Jack
1 LC Optical Connector
3P /3.5MM Terminal Block (for Power)
3P /3.5MM Terminal Block (for RS-232)
Mini USB (for firmware update)
Conformations
DVI 1.0 , HDMI 1.4b
HDCP Compliance
Yes, HDCP version 2.0
Power Rating
DC +12V, 4Watts Max
Dimension (W x D x H)
5.75" x 4.5" x 1.25" (144.78 x 114.3 x 31.75 mm)
Weight
0.5 lbs (0.23 Kg)
PM-FT102-U : Standalone type (2x1 switch)
Input : Selectable HDMI/DVI or VGA + 3.5mm stereo audio (x1) + RS-232
Output : Fiber Optic (1 LC)
32,808ft, Compatible with PM-FIS4-U input board

PureLink by Dtrovision
9
PM-FT102-U : PureMedia HDMI/VGA to Fiber Optic (1 LC) Extender Transmitter
Front Connection Ports:
Power S/W: Power On/Off switch
Status LED: Video signal presence indicator
HDMI LED: HDMI signal indicator
VGA LED: VGA (or component) signal indicator
VGA EDID : EDID save button for VGA input port
Firmware: USB firmware update port
Back Connection Ports:
HDMI/DVI In: HDMI/DVI input port
VGA In: VGA (or component) input port
Audio In: Stereo audio input port
Optical: 1 LC Fiber Optic output port
RS-232: RS-232 communication port
DC In: DC 12V Power port
Model Name
PM-FT102-U (HDMI version), PM-FT102-U-D (DVI version)
Input Signal
DVI / HDMI (TMDS), VGA (supports YPbPr component)
3.5mm stereo audio
Output Signal
Fiber Optical Output ( > -10dbm (after 32,808ft (10km) transmission))
Extinction Ratio
> 4db (after 32,808ft (10km) transmission)

PureLink by Dtrovision
10
Data Transmission
Speed
3.4 Gbps/ch, Total 10.2 Gbps Max
Supporting Display
Resolutions
PC: VGA ~ WUXGA
(up to 1920 x 1200 @60Hz)
HDTV: 480i ~ 1080p,
Up to Ultra HD 4K
4096 x 2160 @24/25/30Hz (RGB/YCbCr 4:4:4 8 bits, YCbCr 4:2:2
8/10/12 bits)
4096 x 2160 @50/60Hz (YCbCr 4:2:0 8 bits)
Max. Distance
Single Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p, Ultra HD 4K :
32,808 ft (10km)
Multi Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p, Ultra HD 4K :
1,650 ft (500m)
Connector Type
DVI 29P/HDMI 19P Female
VGA Female
3.5mm Stereo Jack
1 LC Optical Connector
3P /3.5MM Terminal Block (for Power)
3P /3.5MM Terminal Block (for RS-232)
Mini USB (for firmware update)
Conformations
DVI 1.0 , HDMI 1.4b
HDCP Compliance
Yes, HDCP version 2.0
Power Rating
DC +12V, 4Watts Max
Dimension
5.75" x 4.5" x 1.75" (144.78 x 114.3 x 44.45 mm)
Weight
1.0 lbs (0.46 Kg)
PM-FT103-U : Wall plate type (2x1 switch), 2 Gang Decora style, white finish.
Input : Selectable HDMI or VGA + 3.5mm stereo audio (x1) + RS-232
Output : Fiber Optic (1 LC)
32,808ft, Compatible with PM-FIS4-U input board
