PureTools PT-HDBT-703-TXWP User manual

User Manual
PT-HDBT-703-TXWP
User Manual
3x1 HDBaseT Wallplate Transmitter, 2 x HDMI & 1 x USB C Inputs
Model PT-HDBT-703-TXWP
Designed in Germany
© 2018 PureLink GmbH All rights reserved. V1.0

User Manual
PT-HDBT-703-TXWP
Preface
Read this user manual carefully before using the product. Pictures shown in this
manual are for reference only. Different model layouts and specifications are subject
to the physical product.
This manual is for operation instructions only, not for any maintenance usage.
In the constant effort to improve our product, we reserve the right to make changes in
functions or parameters without prior notice or obligation.
Trademarks
Product model and logo are trademarks. Any other trademarks mentioned in this
manual are acknowledged as the properties of the trademark owner. No part of this
publication may be copied or reproduced without the prior written consent.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. It has been tested
and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a commercial installation.
Operation of this equipment in a residential area is likely to cause interference, in
which case the user at their own expense will be required to take whatever measures
may be necessary to correct the interference.
Any changes or modifications not expressly approved by the manufacture would void
the user’s authority to operate the equipment.
REACH | 1907/2006/EU
ROHS | 2011/65/EU
PureLink hereby declares that this product PureTools PT-HDBT-703-TXWP complies
with Directives 1907/2006/EU and 2011/65/EU.

User Manual
PT-HDBT-703-TXWP
EMC / LVD (Electro Magnetic Compatibility /
Low Voltage Directive)
PureLink GmbH hereby declares that this product PureTools PT-HDBT-703-TXWP
complies with Directives 2014/30/EU and 2014/35/EU. The full text of the EU
Declaration of Conformity is available at the following Internet address:
http://www.purelink.de/ce/ PT-HDBT-703-TXWP_CE.pdf

User Manual
PT-HDBT-703-TXWP
SAFETY PRECAUTIONS
To ensure the best performance from the product, please read all instructions
carefully before using the device. Save this manual for further reference.
Unpack the equipment carefully and save the original box and packing material
for possible future shipment.
Follow basic safety precautions to reduce the risk of fire, electrical shock and
injury to persons.
Do not dismantle the housing or modify the module. It may result in electrical
shock or burn.
Using supplies or parts not meeting the products’ specifications may cause
damage, deterioration or malfunction.
Refer all servicing to qualified service personnel.
To prevent fire or shock hazard, do not expose the unit to rain, moisture or install
this product near water.
Do not put any heavy items on the extension cable in case of extrusion.
Do not remove the housing of the device as opening or removing housing may
expose you to dangerous voltage or other hazards.
Install the device in a place with fine ventilation to avoid damage caused by
overheat.
Keep the module away from liquids.
Spillage into the housing may result in fire, electrical shock, or equipment
damage. If an object or liquid falls or spills on to the housing, unplug the module
immediately.
Do not twist or pull by force ends of the optical cable. It can cause malfunction.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power
to the device before cleaning.
Unplug the power cord when left unused for a long period of time.
Information on disposal for scrapped devices: do not burn or mix with general
household waste, please treat them as normal electrical wastes.

User Manual
PT-HDBT-703-TXWP
Table of Content
1. Product Introduction ..................................................................................................................1
1.1 Features ..............................................................................................................................1
1.2 Package List .......................................................................................................................2
2. Specification.................................................................................................................................3
3. Panel Description........................................................................................................................4
3.1 Front Panel.........................................................................................................................4
3.2 Rear Panel ..........................................................................................................................5
3.3 Side Panel...........................................................................................................................6
4. System Connection.....................................................................................................................7
5. Button Control..............................................................................................................................8
5.1 Source Switching..............................................................................................................8
5.2 Display Control .................................................................................................................9
6. RS232 Control........................................................................................................................... 10
6.1 RS232 Connection..........................................................................................................10
6.2 RS232 Control Software ...............................................................................................11
6.3 RS232 Command............................................................................................................13
6.3.1 Device Control.................................................................................................... 13
6.3.2 Source Switching ............................................................................................... 13
6.3.3 EDID Management............................................................................................. 14
6.3.4 CEC Control ......................................................................................................... 15
7. Button User-defined................................................................................................................ 16
8. Panel Drawing........................................................................................................................... 18
9. Troubleshooting & Maintenance.......................................................................................... 19
10. After-Sales Service ................................................................................................................ 20

User Manual
PT-HDBT-703-TXWP
1
1. Product Introduction
Thanks for choosing the PT-HDBT-703-TXWP 3x1 Wallplate Transmitter Switcher,
which is designed to switch and extend HDMI or Slimport input signal to far-end
display device, and the transmission distance is up to 131ft/40m at 4K and
229ft/70m at 1080P video by using a single CATx cable.
The switcher features two HDMI and one Type-C USB inputs, it can be selected by the
SOURCE AUTO button on the front panel. The switcher supports CEC. The DISPLAY
ON/OFF button on front panel is used to control the far-end display device, and it can
be programmed by IR learning or RS232 command to ensure the compatibility with
various display devices. Moreover, 12V-48V PoC allows the switcher can be powered
from the compatible HDBaseT receiver.
1.1 Features
Supports HDMI signal up to 4K@60Hz 4:2:0, Slimport signal up to 4K@30Hz
4:4:4.
Supports HDMI 1.4 standard and HDCP 2.2 compliant. Ensures display of
content-protected media and interoperability with other HDCP compliant
devices.
Active input automatic detective.
Extending HDMI signal 4K@60Hz up to 131ft/40m and 1080P@60Hz up to
229ft/70m.
Supports RS232 pass-through with HDBaseT connection and local control.
Supports IR pass-through to extend IR signal to control display device.
The DISPLAY ON/OFF button can be programmed by IR learning feature or
RS232 command.
The HDBT port supports 12V-48V PoC input, the switcher can be powered from
the compatible HDBaseT receiver by the CATx cable, and it also supports 12V-
24V PoC output to provide power supply for other device like WP series Control
Panel.
Firmware upgrade by Micro-USB port.

User Manual
PT-HDBT-703-TXWP
2
1.2 Package List
1x PT-HDBT-703-TXWP
1x 2-pin Terminal Block
2x 3-pin Terminal Blocks
1x Power Adapter (24V 1.25A)
1x User Manual
Note: Please contact your distributor immediately if any damage or defect in the
components is found.

User Manual
PT-HDBT-703-TXWP
3
2. Specification
Input
Input
(2) HDMI, (1) USB-C (Slimport)
Input Connector
(2) Female type A HDMI, (1) Type-C USB
HDMI Input Resolution
Up to 4K/UHD@60Hz 4:2:0
Slimport Input
Resolution
Up to 4K/UHD@30Hz 4:4:4
Output
Output
(1) HDBT OUT
Output Connector
(1) RJ45
HDBT Output Resolution
Up to 4K/UHD@60Hz 4:2:0
Control
Control Ports
(1) IR, (1) FIRMWARE, (1) RS232, (1) IR IN
Control Connector
(1) Built-in IR sensor, (1) Micro-USB,
(2) 3-pin terminal block
General
Bandwidth
10.2Gbps
Transmission Mode
HDBaseT
HDMI Version
1.4
HDCP Version
2.2
Transmission Distance
4K@60Hz≤40M, 1080P@60Hz≤70M
External Power Supply
Input:100V~240V AC; Output: 24VDC 1.25A
Power Consumption
5W max. (408TU only –add extra for HDBaseT
receiver)
Operation Temperature
-10 ~ +40℃
Storage Temperature
-15 ~ +55℃
Relative Humidity
10% ~ 90%
Dimension (W*H*D)
151mm x 80mm x 39mm
Net Weight
230g

User Manual
PT-HDBT-703-TXWP
4
3. Panel Description
3.1 Front Panel
①IR: Built-in IR sensor for IR learning feature. It doesn’t support IR pass-through.
②HDMI IN 1: Type-A HDMI port to connect HDMI source.
③HDMI IN 2: Type-A HDMI port to connect HDMI source.
④USB-C: Type-C USB to connect the Macbook or other device with SlimPort output.
⑤SOURCE AUTO:
Press the backlit button to select the next input source.
Press and hold the button at least 3 seconds to enable auto switching mode.
For more details, please refer to the 5.1 Source Switching on the page 8.
⑥Input LED:
U: The LED illuminates green to indicate the USB-C input is selected.
H 1: The LED illuminates green to indicate the HDMI 1 input is selected.
H 2: The LED illuminates green to indicate the HDMI 2 input is selected.
⑦DISPLAY ON/OFF: Turn the display ON or OFF via CEC or RS232 (Programming
required). For more details, please refer to the 5.2 Display Control on the page 9.
123
478
56

User Manual
PT-HDBT-703-TXWP
5
⑨LINK LED: The LED illuminates green to indicate a successful data link with the
HDBaseT receiver.
3.2 Rear Panel
①HDBT (POC): RJ45 HDBaseT output port to connect to the HDBT IN port of the
receiver by a CATx cable. It supports 12V-48V PoC to enable the switcher can be
powered from a compatible receiver.
②RS232: Either 3-pin terminal block to connect a control device (such as PC) to
send the RS232 command to control this unit, or to connect a third party device
which needs to be controlled by RS232 pass-through. For more details, please
refer to the 6. RS232 Control on the page 10.
③DC IN: Power port to connect 24V DC power adapter.
④IR IN: 3-pin terminal block to connect an IR receiver.
1
234

User Manual
PT-HDBT-703-TXWP
6
3.3 Side Panel
①FIRMWARE: Micro-USB port for firmware upgrade.
FIRMWARE
1

User Manual
PT-HDBT-703-TXWP
7
4. System Connection
Usage Precautions
Make sure all components and accessories included before installation.
System should be installed in a clean environment with proper temperature and
humidity.
All of the power switches, plugs, sockets, and power cords should be insulated
and safe.
All devices should be connected before power on.
The following diagram illustrates typical input and output connection that can be
utilized with the switcher:
Note: We recommend CATx cabling with alien crosstalk prevention technology to ensure
the performance of HDBaseT link.
MacBook
PoC
HDBT OUT
RS232
Tx Rx
DC IN IR IN
Sig 5V24V
RXTX
Projector
Laptop Blu-ray
Projector Screen
Power In
HDMI:
HDBaseT:
USB:
Power:
RS232: PoC

User Manual
PT-HDBT-703-TXWP
8
5. Button Control
5.1 Source Switching
1) Press the SOURCE AUTO button to switch to next source device, and then the
corresponding input LED will turn green.
2) Press and hold the SOURCE AUTO button at least 3 seconds to enable auto
switching mode, and it abides by the following principles:
New Input
Once detecting a new input signal, the switcher will automatically switch to this
new signal, and the far-end display device will receive command to be switched
on. If source input is not detected, the far-end display device will automatically
turn off within two minutes.
Source Removed
When an active source is removed, the switcher will switch to the first available
active input starting at HDMI IN 1.
Reboot
The switcher can save the last configuration before losing power. If the last
switching mode is auto switching, the switcher will automatically enter auto
switching mode once rebooted, then detect all inputs and memorize their
connection status for future rebooting using. If the last selected input source is
still available, the switcher will switch to this input. If not, it will switch to the first
available active input source starting at HDMI IN 1.
Exit auto switching mode
Press and hold the SOURCE (AUTO) button for 3 seconds again to exit the auto
mode, and the input source will not be changed.

User Manual
PT-HDBT-703-TXWP
9
5.2 Display Control
1) Press the DISPLAY ON/OFF button to turn on/off the display.
2) If the incompatible display device needs to be used with this switcher, the
DISPLAY ON/OFF button can be programed by IR learning or RS232 command. For
more details, please refer to the 7 Button User-defined on the page 16.

User Manual
PT-HDBT-703-TXWP
10
6. RS232 Control
6.1 RS232 Connection
According the RS232 control mode, there are two types of RS232 connection can be
selected.
①When only control the local switcher, connect a control device (e.g. PC) to the
RS232 port of the switcher, the connection diagram shown as below:
PoC
HDBT OUT
RS232
Tx Rx
DC IN IR IN
Sig 5V24V
Laptop

User Manual
PT-HDBT-703-TXWP
11
②When control the far-end third party device from local control device (e.g. PC),
connect the PC to the RS232 port of the switcher, and then connect the third party
device (e.g. projector) to the RS232 port of receiver. The connection diagram
shown as below:
6.2 RS232 Control Software
Installation: Copy the control software file to the control PC.
Uninstallation: Delete all the control software files in corresponding file path.
Basic Settings:
Connect the PT-HDBT-703-TXWP with all input devices and output devices needed,
then to connect it with a computer which is installed with RS232 control software.
Double-click the software icon to run this software.
Here take the software CommWatch.exe as example. The icon is showed as below:
PoC
HDBT OUT
RS232
Tx Rx
DC IN IR IN
Sig 5V24V
RXTX
Projector
Power In
PoC
Laptop

User Manual
PT-HDBT-703-TXWP
12
The interface of the control software is showed as below:
Please set the parameters of COM number, bound rate, data bit, stop bit and the
parity bit correctly, and then you are able to send command in command sending
area.
Parameter configuration area
Monitoring area, show the commands
and its feedback information.
Command sending area

User Manual
PT-HDBT-703-TXWP
13
6.3 RS232 Command
Communication protocol: RS232 Communication Protocol
Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none
6.3.1 Device Control
Command
Function
Feedback Example
50617%
Restore factory default
FACTORY RESET
50699%
Get firmware version
VERSION Vx.x.x
50740%
Disable DISPLAY ON/OFF button.
DISABLE DISPLAY ON/OFF
KEY
50741%
Enable DISPLAY ON/OFF button.
ENABLE DISPLEY ON/OFF
KEY
6.3.2 Source Switching
Command
Function
Feedback Example
50701%
Switch to HDMI 1.
SWITCH TO HDMI1
50702%
Switch to HDMI 2.
SWITCH TO HDMI2
50704%
Switch to USB-C.
SWITCH TO USB-C
50710%
Enable auto switching mode.
AUTO SWITCHING
50711%
Enable manual switching mode.
MANUAL SWITCHING
50712%
Get the Source Switching mode.
AUTO SWITCHING
MANUAL SWITCHING

User Manual
PT-HDBT-703-TXWP
14
6.3.3 EDID Management
The input resolution (EDID setting) can be set using RS232 commands to one of the
options given in the following table.
Command
EDID
Feedback Example
50768%
720P PCM 2CH
EDID:720P, PCM 2CH
50769%
720P Dolby/DTS PCM 6CH
EDID:720P, DOLBY/DTS PCM
6CH
50770%
1080P PCM 2CH
EDID:1080P,PCM 2CH
50771%
1080P Dolby/DTS PCM 6CH
EDID:1080P, DOLBY/DTS
6CH
50772%
4K@30Hz PCM 2CH
EDID:4K30, PCM 2CH
50773%
4K@30Hz Dolby/DTS 5.1
EDID:4K30, DOLBY/DTS 5.1
50774%
1280x720@60Hz DVI
EDID:1280x720@60, DVI
50775%
1920x1080@60Hz DVI
EDID:1920x1080@60, DVI
50776%
1920x1200 PCM 2CH 6CH
EDID:1920x1200, PCM 2CH
6CH
50777%
3840x2160@60Hz 4:2:0 8 bit
EDID:3840x2160@60, 4:2:0
8BIT
50782%
Enable EDID user-defined mode.
Uploading the user-defined EDID file
by Micro-USB port within 10 seconds.
EDID: USER
50783%
EDID bypass
EDID: BYPASS
50784%
Get the current EDID.
EDID:720P, PCM 2CH
EDID:720P, DOLBY/DTS PCM
6CH
EDID:1080P,PCM 2CH
EDID:1080P, DOLBY/DTS
6CH
EDID:4K30, PCM 2CH
EDID:4K30, DOLBY/DTS 5.1
EDID:1280x720@60, DVI
EDID:1920x1080@60, DVI

User Manual
PT-HDBT-703-TXWP
15
EDID:1920x1200, PCM 2CH
6CH
EDID:3840x2160@60, 4:2:0
8BIT
EDID: USER
EDID: BYPASS
6.3.4 CEC Control
The switcher also supports sending of a few common CEC commands using RS232
command code. Specific CEC command can also be sent from the switcher. The RS232
commands are as given in the following table. Please note that only CEC enabled
devices that have the specified logical address will respond to CEC commands.
Command
Function
Feedback Example
50730%
Volume up.
CEC VOLUME INCREASE
50731%
Volume down.
CEC VOLUME DECREASE
50732%
Volume mute toggle.
CEC VOLUME MUTE
50733%
Display on.
CEC DISPLAY ON
50734%
Display off.
CEC DISPLAY OFF
CEC
<xx:xx:xx....>
Send CEC command “xx:xx:xx…” to
control display device.
CEC <xx:xx:xx…>
