PureTools PT-PSW-41H User manual

User Manual
User Manual
Scaler Switcher Multiformat Scaling, 4K (60Hz 4:2:0), HDMI Out
Model PT-PSW-41H
Designed in Germany
© 2017 PureLink GmbH All rights reserved. VersionV1.0

User Manual
Preface
Read this user manual carefully before using the product. Pictures shown in this manual are
for reference only. Different model layouts and specifications are subject to the physical
product.
This manual is for operation instructions only, not for any maintenance usage.
In the constant effort to improve our product, we reserve the right to make changes in
functions or parameters without prior notice or obligation.
Trademarks
Product model and logo are trademarks. Any other trademarks mentioned in this manual are
acknowledged as the properties of the trademark owner. No part of this publication may be
copied or reproduced without the prior written consent.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. It has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a commercial installation.
Operation of this equipment in a residential area is likely to cause interference, in which case
the user at their own expense will be required to take whatever measures may be necessary to
correct the interference.
Any changes or modifications not expressly approved by the manufacture would void the
user’s authority to operate the equipment.

User Manual
REACH | 1907/2006/EU
ROHS | 2011/65/EU
PureLink hereby declares that this product PureTools PT-PSW-41H complies with Directives
1907/2006/EU und 2011/65/EU.
EMC / LVD (Electro Magnetic Compatibility / Low Voltage Directive)
PureLink GmbH hereby declares that this product PureTools PT-PSW-41H complies with
Directives 2014/30/EU and 2014/35/EU. The full text of the EU Declaration of Conformity is
available at the following Internet address:
http://www.purelink.de/ce/4251364706879 _CE.pdf

User Manual
SAFETY PRECAUTIONS
To ensure the best from the product, please read all instructions carefully before using the
device. Save this manual for further reference.
Unpack the equipment carefully and save the original box and packing material for
possible future shipment.
Follow basic safety precautions to reduce the risk of fire, electrical shock and injury to
persons.
Do not dismantle the housing or modify the module. It may result in electrical shock or
burn.
Using supplies or parts not meeting the products’ specifications may cause damage,
deterioration or malfunction.
Refer all servicing to qualified service personnel.
To prevent fire or shock hazard, do not expose the unit to rain, moisture or install this
product near water.
Do not put any heavy items on the extension cable in case of extrusion.
Do not remove the housing of the device as opening or removing housing may expose you
to dangerous voltage or other hazards.
Install the device in a place with fine ventilation to avoid damage caused by overheat.
Keep the module away from liquids.
Spillage into the housing may result in fire, electrical shock, or equipment damage. If an
object or liquid falls or spills on to the housing, unplug the module immediately.
Do not twist or pull by force ends of the optical cable. It can cause malfunction.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the
device before cleaning.
Unplug the power cord when left unused for a long period of time.
Information on disposal for scrapped devices: do not burn or mix with general household
waste, please treat them as normal electrical wastes.

User Manual
Contents
1. Introduction ........................................................................................................................1
1.1 Introduction to PT-PSW-41H......................................................................................1
1.2 Feature......................................................................................................................1
1.3 Package List...............................................................................................................2
2. Panel Description................................................................................................................3
2.1 Front Panel................................................................................................................3
2.2 Rear Panel ................................................................................................................ 4
3. System Connection .............................................................................................................5
3.1 Usage Precaution.......................................................................................................5
3.2 System Diagram ....................................................................................................... 6
4. Button Control ....................................................................................................................7
4.1 Signal Switching ........................................................................................................7
4.2 Volume Adjustment .................................................................................................. 8
4.3 Display Control ......................................................................................................... 8
4.4 Output Resolution Selection ....................................................................................10
5. RS232 Control ................................................................................................................... 11
5.1 RS232 Control Software ........................................................................................... 11
5.2 RS232 Command ..................................................................................................... 13
5.2.1 System Configuration .................................................................................... 13
5.2.2 Signal Switching............................................................................................14
5.2.3 Audio Setting.................................................................................................14
5.2.4 Output Resolution Selection ..........................................................................15
5.2.5 EDID Management........................................................................................15
5.2.6 Baudrate Setting ...........................................................................................16
6. Specification ..................................................................................................................... 17
7. Panel Drawing...................................................................................................................18
8. Troubleshooting & Maintenance........................................................................................19
9. After-Sales Service............................................................................................................20

User Manual
1
1. Introduction
1.1 Introduction to PT-PSW-41H
The PT-PSW-41H is a professional 4K Scaler Switcher scaling HDMI/DP/VGA video signal to an
HDMI output by selecting output resolution from 720p to 4K via OSD.
It can work with HDMI, DP, andVGA table grommets to switch source and output black screen
for display (table grommets sold separately). CEC and IR learning function is used to control
display via front panel buttons. With one built-in IR In, one IR Out and one RS232, the IR and
RS232 control signals can be used for display control.
The PT-PSW-41H supports advanced EDID management and is HDCP 2.2 compliant.Video
and audio sources can be selected via front panel button, table grommets or RS232
commands by third party control device. Moreover, it features volume buttons to turn
up/down the volume level.
1.2 Feature
Features 2 HDMI inputs, 1 DP input and 1 VGA input with auxiliary audio.
The output resolution can be selected from 720p to 4K x 2K@30Hz 4:4:4
to assure preferred output.
Supports IR learning to set button function for controlling the connected display.
Supports volume control via buttons.
Allows the connected display to be controlled via CEC, IR, RS232 commands or front panel
buttons.
Supports HDMI/VGA/DP table grommets to control source switching and black screen
showing.
Automatically switch based on video sensing.
Supports RS232 control.
Supports IR pass through.
Supports advanced built-in EDID management.

User Manual
2
1.3 Package List
1 x PT-PSW-41H 4x1 4K Scaler Switcher
1 x Power Adapter (12VDC, 2A)
2 x Mounting Ears with 4 Screws
4 x Plastic Cushions
6 x 3-pin Phoenix Connectors
Note: Please contact your distributor immediately if you found any damage or defect in the
components.

User Manual
3
2. Panel Description
2.1 Front Panel
No.
Name
Description
①
Built-in IR Receiver
Receive IR signal from IR remote.
②
Power LED
Red when powered on.
③
Signal LED
AUTO: Auto switching activity LED.
H1&H2: 1-HDMI/ 2-HDMI input activity LED.
DP: DP input activity LED.
VGA: VGA input activity LED.
④
Auto Switching
Selector
Press this to enter / exit auto switching mode.
⑤
Volume Down
Press this to decrease the output volume of scaler switcher and
display.
⑥
Volume Up
Press this to increase the output volume of scaler switcher and
display.
⑦
IR LEARNING
Press this to enter IR learning mode.
⑧
DISPLAY ON &
Activity LED
Press this to turn on the display, and it can be customized via IR
learning or RS232 commands.
FW
IR
OUTPUT RES
H1
H2
DP
VGAAUTO
SOURCE / AUTO-3s
ON OFF
IR LEARNING DISPLAY
12345 6 78910 11

User Manual
4
No.
Name
Description
⑨
DISPLAY OFF &
Activity LED
Press this to turn off the display, and it can be customized via IR
learning or RS232 commands.
⑩
OUTPUT RES
Press this to enter On Screen Display menu (OSD)
to select the output resolution.
⑪
FIRMWARE
Micro USB port, used for firmware update.
2.2 Rear Panel
No.
Name
Description
①
HDMI OUT
HDMI output port, connect with display.
②
1-HDMI IN &
2-HDMI IN
HDMI input ports, connect with HDMI source.
③
3-DP IN
DP input port, connect with DP source.
④
4-VGA IN
VGA input port, connect withVGA source.
⑤
AUDIO IN
VGA auxiliary audio input.
⑥
IR OUT
Connect with IR emitter to control display via IR.
⑦
RS232
Serial port, connect a control device (PC) to control the
PT-PSW-41H.
Connect the display to control it via front panel buttons.
DC 12VAUDIO IN4-VGA IN
3-DP IN
1-HDMI IN 2-HDMI IN IR OUT AUDIO OUT
GR1
GR2
GR3
GR4
SM OB
Tx Rx
SM OB
L R
HDMI OUT
RS232
12345 6 8
7
910

User Manual
5
No.
Name
Description
⑧
AUDIO OUT
Audio output port, connect with speaker.
⑨
GR1,GR2,
GR3&GR4
Connect with HDMI, DP or VGA table grommet to control
source switching and black screen showing.
⑩
DC 12V
Connect the including power adaptor.
3. System Connection
3.1 Usage Precaution
Verify that all components and accessories are included prior to installation.
System should be installed in a clean environment with proper temperature and humidity
(see page17 for limits).
If the scaler switcher will be permanently mounted to a surface, attach the included
mounting ears with the supplied screws.
If the scaler switcher will be sitting on a shelf, attach the included plastic cushions to the
bottom of the unit.
All of the power switches, plugs, sockets and power cords should be insulated and safe.
All devices should be connected before switched live.

User Manual
6
3.2 System Diagram
Sho w
Me
Output
Bla ck
Sho w
Me
Out put
Bla ck
Sho w
Me
Out put
Bla ck
DC 12VAUDIO IN4-VGA IN3-DP IN1-HDMI IN 2-HDMI IN IR OUT AUDIO OUT
GR1
GR2
GR3
GR4
SM OB
Tx Rx
SM OB
L R
HDMI OUT
RS232
Blu-Ray Apply TV MacBook Laptop
HDMI:
VGA:
IR:
Control:
Audio:
DP:
Gromment
Gromment Gromment
Gromment
Projector Speaker
IR
Emitter
Sho w
Me
Out put
Bla ck
PT-PSW-41H

User Manual
7
4. Button Control
Front panel buttons can be used for video switching, volume adjusting and output resolution
selection.
4.1 Signal Switching
①Manual Switching
Press the SORCE/AUTO-3s button to select the HDMI, DP or VGA source, the corresponding
green activity LED will be lighted up.
②Auto Switching
Long-press the SORCE/AUTO-3s button at least 3 seconds to enable auto switching mode,
the green activity LED (AUTO) will be lighted up. Press this button again to select next source
and exit auto mode.
The auto switching mode abides by the following principles:
New Input
Once new source is connected, the new source will be automatically switched to input signal.
Rebooting Device
The PT-PSW-41H has the ability to save the latest configuration before losing power. The
switcher automatically enters the mode as latest mode used; moreover, it detects all the
inputs and memorizes the connection status for future rebooting use. If the latest displayed
signal is still available, the unit will output the signal. Otherwise, the unit will detect all the
input signals wit priority from HDMI to VGA. When the first signal was detected, it will transfer
to output.
Signal Removing
Once removing the current display signal, PT-PSW-41H will detect all input signals with
priority from HDMI toVGA. It will transfer the signal firstly detected to be available to the
output device.

User Manual
8
4.2 Volume Adjustment
①Press the Volume Up button to increase the output volume of scaler switcher and display.
②Press the Volume Down button to decrease the output volume of scaler switcher and
display.
4.3 Display Control
For compatibility with different displays, two customizable buttons on the front panel can be
used to turn on/off the display. These two buttons can be customized by sending RS232
commands or IR learning function.
1) By sending RS232 commands
a) Connect a control PC to the RS232 port.
b) Install RS232 control software on the PC, please refer to 6 RS232 control for more
details.
c) Find the corresponding display control command in the user manual of the display, then
configure the ON or OFF button according to the below command format.
Configure ON button:
Command Format
Description & Example
Feedback
/-ax:XX XX XX XX
"x" represents the baud rate: x=0(2400)/
1(4800)/ 2(9600)/ 3(19200)/ 4(38400)/
5(57600)/ 6(115200).
" XX XX XX XX " is display control command
(HEX, max 48 byte).
For example: /-ax:30 31 32 33
XX XX XX XX
(30 31 32 33)
/+ax:XXXXXXX
"x" represents the baud rate: x=0(2400)/
1(4800)/ 2(9600)/ 3(19200)/ 4(38400)/
5(57600)/ 6(115200).
XXXXXXX
(0123456)

User Manual
9
" XXXXXXX " is display control command
(ASCII, max 48 byte).
/+ax:0123456
Configure OFF button:
Command Format
Description & Example
Feedback
/-Ax:XX XX XX XX
"x" represents the baud rate: x=0(2400)/
1(4800)/ 2(9600)/ 3(19200)/ 4(38400)/
5(57600)/ 6(115200).
" XX XX XX XX " is display control command
(HEX, max 48 byte).
For example: /-ax:30 31 32 33
XX XX XX XX
(30 31 32 33)
/-Ax:XXXXXXX
"x" represents the baud rate: x=0(2400)/
1(4800)/ 2(9600)/ 3(19200)/ 4(38400)/
5(57600)/ 6(115200).
" XXXXXXX " is display control command
(ASCII, max 48 byte).
/+ax:0123456
XXXXXXX
(0123456)
d) Disconnect the control PC, then connect the display to the RS232 port.
e) Press ON or OFF button to turn the display on or off.
2) IR Learning
a) Press the IR LEARNING button to enable IR learning mode, the ON and OFF LEDs will
light up.
b) Press one of the display control buttons, e.g. press ON button, and its LED will start to
flash.
c) Point the display remote at the front panel built-in IR receiver and the press the Power
On button on the remote, and the ON LEDs will go dark.
d) Repeat the above all three steps to set the OFF button function.
e) Press ON or OFF button to turn the display on or off.

User Manual
10
4.4 Output Resolution Selection
①Resolution Selection
Step1: Press the OUTPUT RES button to enter the following resolution list shown as below.
Step2: Press this button again to move up and down in the list.
Step3: Long-press this button at least 2 seconds to confirm the selected output resolution.
②Resolution Reset
Long-press the OUTPUT RES button at least 5 seconds to reset the output resolution to
default 720P.

User Manual
11
5. RS232 Control
Connect the control device (PC) to the RS232 port of PT-PSW-41H, The PT-PSW-41H can be
controlled by sending RS232 commands via RS232 control software installed in the PC.
5.1 RS232 Control Software
Installation: Copy the control software file to the computer connected with PT-PSW-41H.
Uninstallation: Delete all the control software files in the corresponding file path.
Basic Settings:
First connect PT-PSW-41H with all needed input and output devices, then connect it with a
computer which is installed with RS232 control software. Finally, double-click the software
icon to run this software.
Here we take the software CommWatch.exe as example.The icon is shown as below:

User Manual
12
The interface of the control software is showed as below:
Please set the parameters of COM number, bound rate, data bit, stop bit and the parity bit
correctly, then the command is ready to be sent in the Command Sending Area.
Parameter Configuration Area
Monitoring Area, indicates if the
sent command is working.
Command Sending Area

User Manual
13
5.2 RS232 Command
Communication protocol: RS232 Communication Protocol
Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none
5.2.1 System Configuration
Command
Function
Feedback
SFUD
Software upgrading
Software Update
GET VER
Check the software version
Version Vx.x.x
FRST
Restore factory default
Factor Reset
WAKE
Wake up the system
Wake Up
STBY
Turn the system to standby mode
Go To Standby
GET STA
Get the system status
Input:VGA
Resolution: 1920x1080
Manual Switching
Source Volume: 60
EDID: Initial
HDCP: ON

User Manual
14
5.2.2 Signal Switching
Command
Function
Feedback
SWIN H1
Switch to HDMI input
Switch to hdmi
SWIN H2
Switch to HDMI2
Switch to hdmi2
SWIN DP
Switch to DP
Switch to dp
SWIN VG
Switch to VGA input
Switch to vga
AUTO 01
Enable auto switching
Auto Switching
AUTO 00
Disable auto switching
Manual Switching
5.2.3 Audio Setting
Command
Function
Feedback
AUMT S1
Mute source audio
Audio Mute Source: Enable
AUMT S0
Unmute source audio
Audio Mute Source: Disable
VOLS AP
Increase the source volume to xx (xx=0~60)
Source Volume: xx
VOLS AN
Decrease the source volume to xx
(xx=0~60)
Source Volume: xx
VOLS xx
Set the source volume to xx (xx=0~60)
Source Volume: xx

User Manual
15
5.2.4 Output Resolution Selection
Command
Function
Feedback
SRES 01
Change output resolution to 3840x2160
Resolution: 3840x2160
SRES 02
Change output resolution to 1920x1080
Resolution: 1920x1080
SRES 03
Change output resolution to 1280x720
Resolution: 1280x720
VGAA
Automatic image correction for VGA input
VGA Input Auto
5.2.5 EDID Management
Command
Function
Feedback
EDID DF
EDID default
EDID: Initial
EDID MN
Get the EDID data from display
EDID: Manage
EDID US
When the command applied, system
prompts to upload the user-defined EDID
file (.bin) from U-disk.
EDID: User
