USER MANUAL
PSTM40
Steam Vibrating Floor Mop

INTRODUCTION
Thank you for choosing Pyle for your household cleaning needs. Our floor care products
use the active power of steam without the use of chemicals; making it a green product
that is safe for the ecosystem. You have begun the first step into transforming your
house into a green, environmentally safe home. Our Pyle steam products are a modern
way of cleaning that is efficient and far more sanitary than conventional methods.
You can achieve a high level of effective cleaning by decreasing cleansing power thru
steam. When using our 100% cotton microfiber cloth pad to enhance absorbency
combined with the power of germ killing steam, dirt and grime can be eliminated in a
matter of seconds. The tiny hot vapor molecules penetrate porous surfaces being
cleaned, expanding and forcing dirt, debris, and bacteria to the surface. When used
correctly, our steam mops can kill dust mites and certain types of bacteria pathogens
such as salmonella and E-coli on contact.
Since you do not need chemicals in order to use our products, not only will you see the
savings in your wallet, but you have provided a safer place for you and your family to
live in. We encourage you to improve your way of life, better the environment, and
spend time enjoying your clean chemical free floor.
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
PSTM40 - Pure Clean Steam Vibrating Floor Mop
Vibration Function to Lift Dirt & Stains
Naturally Cleans with Hot Steam Vapor
Deodorizes and Sanitizes While you Clean
Works on All Sealed Hard Floor Surfaces
Quickly Sanitizes Carpets
Produces Superheated Steam
Simple Operation Single-Touch Steam Activation
Triangular Design for Easy Cleaning in Tight Corners
Includes Heavy-Duty Microfiber Cleaning Pads
Tested to Kill 99.9% of Germs and Bacteria
Uses Tap Water - No Chemicals or Cleaning Solutions Required
Removable 19 oz. Refillable Water Tank
Built-in 1500 Watt Heating Element
Comes with Carpet Glider Cleaning Attachment Accessory
1

2
SAFETY GUIDELINES
Steam Mops are for indoor domestic floor use only. Any
commercial use will void warranty. The steamer(s) should not be used upside down or
vertically. They are designed for sanitizing and cleaning an array of floor surfaces such
Safety Instructions:
WARNING: Be sure to read and follow all safety instructions before using
your steam mop. Proper care and maintenance will help to expand the life of
your steamer.
When using an electrical appliance, basic precautions should always be followed. To
reduce the risk of fire, electric shock, or injury:
!Be sure to unplug the electrical cord when appliance is not in use and while servicing.
!Do not leave the steamer unattended while young children, pets or infirm persons
are around.
!Children should be supervised and cautioned that the steamer is not a toy and
should not be played with.
!Do not direct steam towards people, pets, electrical appliances, or electrical outlets.
!Do not immerse the steamer in water or other liquids.
!Do not handle steamer with wet hands.
!Do not pull power cord to disconnect appliance from socket or use cord as a handle.
!Be sure to keep cord away from heat, water, and sharp edges.
!Do not use if cord or plug is damaged.
!Do not use extension cords or outlets with inadequate current carrying capacity.
!Do not use steamer on any steam sensitive material such as velvet, leather, wax
polished furniture or floors, synthetic and other delicate fabrics.
!Do not use on unsealed hardwood floors. By doing so, you may remove the sheen
from the steam. It is recommended to test an isolated area with the steam mop
before proceeding. As a precaution, you should check the manual made by the floor
manufacturer for proper care instructions.
!Never put cleaning detergents or chemicals into the steamer as it will make the
product unsafe and damage the unit.
!Do not use steamer without floor cloth pad in place.
!Use only manufacturer's recommended accessories.
!Stop using steamer if circuit breaker activates. Beware of risk of shock.
!Wear proper shoes when operating your steamer. Open-toed shoes, slippers or bare
feet may cause you to slip and fall or cause hot steam on your feet.
!Do not use steamer on stairs.
!Allow your steamer to cool down before storing in a cool, dry place.
The Pyle Pure Clean
as carpet, ceramic tile, marble, sealed hardwood, sealed laminate, stone and vinyl floors.

A.
B.
C.
D.
E.
F.
G.
H.
I.
J.
K.
L.
M.
N.
O.
P.
Q.
R.
S.
O
P
S
A
B
C
F
I
J
K
L
M
D
G
N
Q
3
E
H
R
KEY FEATURES
TRIGGER
HANDLE CORD WRAP
HANDLE
FOLDING HANDLE BUTTON
CARRYING HANDLE
LED
STEAM CONTROL
VIBRATE
WATER TANK RELEASE LOCK
WATER TANK
FILTER
STEAMER BODY
STEAMER HEAD
CARPET GLIDER
QUICK RELEASE CORD WRAP
POWER CORD
LOWER CORD WRAP
SCREW
CLOTH PAD

ASSEMBLY AND USE
1) Attach steamer head to body of the unit.
2) Secure steamer head with screw provided until fully tightened (use Philips
screwdriver.)
3) Push the steamer handle straight up by pressing on the folding handle button.
4) Set cloth pad on the floor. Be sure to loosen drawstring on the pad so that the
steamer head will fit properly inside the pad. Place steamer head onto cloth pad so
that steamer head is sitting inside pad. Pull drawstring to tighten cloth pad over the
steamer head to assure a tight fit for cleaning.
5) Push the water tank release lock backward to take out the water tank. Unscrew the
water tank cap and fill with cool tap water.
12
4
3
5
4

5
NOTE: The steamer does not require distilled water. Residents in areas with hard water
should used distilled water for better performance.
6) Twist the quick release cord wrap clockwise to un-wrap the power cord completely.
Hang the cord on the handle cord wrap for better use of the steamer when moving
and cleaning.
7) The LED will illuminate when the steamer is ready for cleaning (Aqua Laser only).
NOTE: It is recommended that another high wattage appliance is not operated on the
same circuit to avoid a circuit overload.
CAUTION: Upon initial use, please hold trigger to allow the water to flow
thru the system for approximately 30 seconds to prime the unit.
WARNING: ON SURFACES THAT HAVE BEEN TREATED WITH WAX, THE
WAX MAY BE REMOVED BY THE HEAT AND STEAM ACTION. DO NOT USE ON
UNSEALED WOOD FLOORS OR LET UNIT STAND ON ANY WOOD FLOOR FOR AN
EXTENDED PERIOD OF TIME. THIS MAY CAUSE THE WOOD GRAIN TO RISE. IT
IS RECOMMENDED THAT A SECTION BE TESTED IN AN ISOLATED AREA OF THE
FLOOR. IT IS ALSO RECOMMENDED THAT YOU CHECK THE USE AND CARE
INSTRUCTIONS FOR CLEANING FROM THE FLOOR MANUFACTURER TO ENSURE
STEAM CLEANING IS ACCEPTABLE FOR YOUR FLOOR.
8) Slowly pass over surface to be cleaned while pressing trigger to emit steam. It is
recommended to sweep or vacuum floor prior to using the steamer.
9) With steam control options, push button to choose a setting that best fits your
cleaning needs. Scrub for deep cleaning, mop for general day to day cleaning, or
dust for quick cleaning.
10) Use vibrate setting in order to provide additional cleaning power.
CAUTION: To sanitize an area of your floor, leave the steamer over the
area for a minimum of 8 seconds, but no longer than 15 seconds. Leaving the
steamer in a stationary position for a longer period than recommended may
cause build up of pail residue. This residue can be removed by using a
decalcifying product or with a few drops of vinegar.
PSTM40
Steam
control
DUST
MOP
SCRUB
Push backward to
remove water tank
Vibrate

6
11) When steamer stops emitting steam, after approximately 15 to 20 minutes of use,
simply remove the water tank, refill, and continue cleaning.
WARNING: NEVER RUN THE STEAMER WITHOUT WATER.
12) When you finish cleaning, unplug power cord from outlet. Be sure to empty water
tank and carefully remove cloth pad from steamer head. Store the unit upright in a dry
area or hang it by the storage hook.
CAUTION: The cloth pad may be very hot.
Carpet Glider
13) Lay carpet glider on the floor in an upright position with the triangular flat surface
facing downward. Place steam mop head on top of glider as illustrated below.
IMPORTANT: The carpet glider is not designed to be fixed to the floor head for safety
reasons including preventing burns. It is designed for use on soft carpet areas only, not
for hard floor surfaces.
CLEANING AND MAINTENANCE
CAUTION: Prior to cleaning or maintaining your steam mop, isolate the
unit by removing the cord from the power socket and avoid immersing the
unit in water.
1) The microfiber cloth pads can be machine washed in hot water and tumble dry. Do
not use bleach or fabric softener. Allow to dry fully before use.
2) Wipe steamer with soft cloth when/if necessary.
Product Specs:
Voltage supply: 120, 60 Hz
Output: 1500 W
Water tank capacity: max. 18.90 fl oz.
Cord: 16.4 ft.
Weight: 6.6 lbs.
Protection class: 2
Pads: SSM-0418-RCP 2PK

TROUBLESHOOTING
CAUTION: Prior to cleaning or maintaining your steam mop, isolate the unit by
removing the cord from the power socket.
SOLUTIONPROBLEM
LED is not on =Ensure steamer power cord is correctly plugged into
a 120V AC power outlet only.
=Ensure circuit breaker is operational.
=Try operating steamer from another power outlet.
=If unit is still not working, call customer service at
1-888-318-PYLE / 718-535-1800.
No steam =Ensure water tank is full.
=Calcium and mineral deposits can build up
and impact the performance of your steamer,
use distilled water if necessary.
Pale residue left on floor =This can be caused by leaving the steamer in the
same spot for too long. Residue can be removed
with household white vinegar or a decalcifying
product.
=Alternatively, reheat the area for one minute to
remove residue (do not overheat area.)
Buttons are not working
properly
=Unplug the unit from the power outlet for
5 minutes then plug back in.
Steamer is leaking water
all over the floor
=The microfiber cloth pad may be overused and
needs to be changed out with additional cloth
pad(s) provided. Cloth pads can be cleaned in
washer/dryer. Over time, however, the cloth pads
can start to wear.
=Be sure microfiber cloth pad is attached properly.
=Condensation may form inside the unit dripping
water upon initial use; continue to press the steam
release button until steam appears. If necessary,
lay a towel on the floor underneath unit during
process.
=If the unit should continue to leak water, unplug
and wait 5 minutes before trying again.
Floors are cloudy, streaky or
spotty after mopping floor
=Be sure to use light detergent when cleaning mop
pads, any residue on pad may be transferred onto
floor.
=Replace cloth pad with a new, clean one for
effective cleaning.
=If initial use of steamer, past cleaning products
may have left a residue on your floor, continue to
go over effected area until there is not residue or
steaks left behind.
7

Limited Warranty Policy
All Pyle products are carefully constructed and thoroughly tested before shipment.
Products purchased in the USA are warranted to be free of defects in material and
workmanship for one (1) year from the date of purchase. This warranty is limited
to the original retail purchaser.
Should the product fall due to factory defect in material or workmanship, your unit
will be repaired or replaced at the solo discretion of Sound Around Inc. You can
contact our customer service department at [phone].
To obtain warranty service, the unit must be carefully packed and shipped prepaid
to:
Sound Around Service Center
1600 63rd Street
Brooklyn, NY 11204
t You must also include the following items:
t A copy of your sales receipt or other proof of purchase.
t A brief letter indicating the problem you are experiencing.
t Include in your letter your return address, daytime phone number
t Must include a money order for $25.00 for return shipping, handling and
insurance or provide your Visa/ MC number with expiration date.
Our Obligation under this warranty is limited to the repair or replacement of the
defective unit when it is returned to us prepaid. This warranty will be considered
void if the unit was tampered with, improperly serviced or subject to misuse, ne-
glect or accidental damage.
Register Your Product Online
www.PyleAudio.com
How would you like to extend the warranty on your product for
three months? Simply write and post a review of the product
online. Then, register your product online at pyleaudio.com or
send an e-mail to [email protected] including your
name, address, and phone number, as well as a link to the review.

We want you listening for a lifetime
Introducing Pyle Rewards!
t Get points for registering your Pyle product, posting
text or video reviews online
t Redeem your points for cool items like Pyle-branded
t-shirts, pens, and Pyle products, including mini
speakers, sports watches, guitar pedals, iPod clock
radios, and more!
t Connect your Pyle Rewards account to your Facebook
and Twitter accounts to show o all the cool stu you
earned!
For more information, visit PyleAudio.com/rewards
Check us out on Facebook & Twitter:
www.facebook.com/pyleaudio
Twitter: @pyleaudio
