Pyle PLCAP50R User manual

1
        
                
         


Model: PLCAP50R
5 Farad SQUARE Hybrid Super Capacitor
With Blue Digital Voltage Display, Blue Flash LED, BlueNeon Ring
Capacitance .................................……......5,000,000 micro farad
Working Voltage ...............................…….….. 21DC
Surge Voltage .......................................……… 24DC
E.S.R. (Equivalent Series Resistance)------ 0.0015 ohm @120hz/ 25°C
Capacitance Tolerance------------------------ ± 10%
DETAILED FEATURES:
a) 3 digits hi-end blue light display DC voltage meter that can measure
0.1 DCV range.
b) Reverse pole connecting PCB buzz warning function. If the capacitor is
connected incorrectly by reversing the positive and negative wires
during the installation process the PCB will issue a 45 second noise to
warn you.
c) Hi-end platinum plated 100% brass solid parts and chrome plated metal
cover
d) Over voltage limit and low battery voltage limit warning. When the
system voltage peeks over 17.5 DCV or LESS than 10 DCV. The
buzzer on the PCB will issue an audible noise warning.
e) Multiple small capacitance capacitors linked to provide the lowest
inner E.S.R. and largest moment discharge power.


2





                 
                                  
                  


You must first attach the mounting tabs to the capacitor before mounting
it. Use the supplied hardware shown in the picture to the right. Notice the
small mounting screw hole in the capacitor chassis.

                     
                                          
                     


The capacitor must be charged before connecting the Power and Ground
cables to the capacitor. Failure to charge the capacitor will result in a
large spark generated from the rapid inflow of current.

3
BATTER Y
--
( ) +
( )
To Charge the capacitor:
1. Make Capacitor positive terminal connections with amplifier and
tighten the bolt. Do not over-tighten the bolts!
Caution: Stripped terminals are not covered under the capacitor’s warranty.
2. Connect the ground cable with battery, amplifier, then refer to the
attached drawing.
3. Place the supplied charging bulb between positive terminal of the
capacitor and the battery’s positive terminal. Do this for 2 ~ 3
minutes or until the charging bulb goes out.
Caution: The charging bulb will get hot!
4. Immediately take out the charging bulb from the connecting wire
after the charging process. And connect the positive cable of the
battery directly to the positive terminal on the capacitor.









              
                            
               




When you want to take out the capacitor after you finish the installation
process from original car audio system. You must do discharge process
when you want to move the capacitor. It will be safe to release the power
of the capacitor.

4
To Discharge the capacitor: With battery power disconnected, place the
light bulb or resistor across the capacitor’s positive and negative terminals
until light goes out or for three minutes if using a resistor.
                       ! 
                       !                        ! 
                       ! 
            "
            "            "
            " 
One Year Warranty from the date of purchase.
   
      
    ##
####
##


           
         
             

