Pyle PLCMDVR47 User manual

PLCMDVR47
PLCMDVR47
Rear View
Front View

OK
Switch
Menu/Emergency
Mode
Down
Up
Host Keys
•OK: In the video mode, short press the key to start recording and short press the key again
to stop recording; In the photo mode, short press the key to take picture; In the file browser
mode, short press the key to play video and short press the key again to stop play; In the
Menu mode, short press the key to confirm.
•Switch:
In the working state, long press the key, the DVR will automatically save the video file
and user settings and shutdown; Under the standby mode, short press the key to switch
the screen.
In the shutdown state, long press the key, the DVR will power on and start working;
•Menu/Emergency: Under the standby mode, short press the key to switch to different modes
and long press the key to enter to main menu interface, short press the key
to exit interface after setting; In the video mode, short press the key to lock
the video, the video file will not be covered;
•Mode: For inter-camera mode key/camera/playback switch.
•Down: In the menu and playback mode, select the function key down; In the playback mode, long press the
key to rewind when playing the video.
•Up: In the menu and playback mode, select the function key up; In the playback mode, long press the
key to fast forward when playing the video; In the video mode, short press the key to stop record
sounds and short press the key again to start to record sounds.

USB
For connecting a PC to transfer data; Power connector
AV-IN
AV cable is used to connect the video output to AV equipment
TF-CARD
TF memory card slot
DC-IN
DC cable connector
RESET
System restart the reset button
MIC
Recording receiving port
USB AV input TF card Power supply
Reset Micphone
PLCMDVR47
TF

“MENU”
PLCMDVR47
HD Rearview Mirror Monitor and Dual Camera System with Hi-Res Video Recording,Built-in 4.3" Screen Display,
Built-in Distance Scale Lines, Parking Assist, (2)Cameras,Motion Impact Recording, Waterproof Camera
Feature:
•Dual DVR Camera Recording System
•Rearview Mirror Monitor with (2) Cameras
•Easily Mounts to Your Existing Rearview Mirror Assembly
•Camera + Camcorder: Snap Pictures and Record Video
•Transfer Files to Computer to Save & Share
•(1)Camera Located on the Mirror(Front Vehicle Recording)
•(1)Exterior Mount Waterproof Camera(Rear Vehicle Recording)
•Support TF Card up to 32GB (* Not Included)
•Switchable to View Either Camera on the Video Screen Display
•Marine Grade Waterproof Construction, IP68(Exterior Mount Camera)
•Convenient Parking Assist System Adds Safety & Reliability
•Record Video from One or Both Cameras
•Auto Record Function: Automatically Records on Vehicle Start
•Includes All the Necessary Cables & Wiring
•Brightness, Exposure and Color Adjustment Settings
•Quickly Mount and Un-Mounts
•Time Water mark: ON/OFF
•120 Degree Wide Angle Camera Lens
•Anti-Glare Rearview Mirror
•Can be hard-wired or Powered via Included Cigarette Lighter
Accessory Cable
•Power: DC 12V
LCD Display:
•Hi-Res 4.25" Full Color Video Display
•Monitor is Built-into the Rearview Mirror Assembly
•Display Screen Can Be Powered Off for Full Mirror Use
•Instantly Preview Your Images and Video On the Display Screen
Video Recording:
•Choose Between HD and FHD
•HD(1080P): 1920X1080 Pixels
•FHD(720P): 1280X720 Pixels
•Record Modes: Front,Back or Double Record
•Video File Format:.AVI
Image Capture:
•Choose Between 1,2,5 or 8 Mega Pixel Images
•Image File Format: .jpeg

HD Rearview Backup Camera System
PLCMDVR47
PLCMDVR47
