Pyle PLTVD7P User manual

OWNER’S MANUAL
Mobile Video System
• Digital Audio Out-Coaxial
• DVD Player With TV Tuner
• Multi Color TFT Monitor
• Multi-subtitle Languages Function
• Multi-audio Languages Function
• Multi-angle Function
• Parental Control
• Remote Control
PLTVD7P

2
FEATURES
Compatible with PAL DVD (Video
CD) and NTSC DVD (Video CD)
This player can play discs recorded in
either PAL or NTSC format.
• A single LSI chip now integrates all
major DVD playback circuit functions
including MPEG2 decoder, video D/A
converter, and audio decoders.
• L/R stereo analog audio outputs for
connection to existing head unit aux
inputs. Video output is composite
video.
• Supplied remote handles multi-function
software (multi-language audio-
track/subtitle, multi-angle, multi-
story, etc.), plus all basic functions.
Built In TV Tuner
• PLL Tuning System
•I
2C Bus Control
USE THIS PRODUCT
SAFELY
When Driving
Keep the volume level low enough to be
aware of road and traffic conditions.
When Car Washing
Do not expose the product to water or
excessive moisture. This could cause
electrical shorts, fire or other damage.
When Parked
Parking in direct sunlight can produce
very high temperatures inside your
vehicle. Give the interior a chance to
cool down before starting playback.
Use the Proper Power Supply
This product is designed to operate with
a 12 volt DC, negative ground battery
system (the regular system in a North
American car).
Protect the Disc Mechanism
Avoid inserting any foreign objects into
the slot of this player.
Failure to observe this may cause
malfunction due to the precise
mechanism of this unit.
Use Authorized Service Centres
Do not attempt to disassemble or adjust
this precision product. Please refer to
the Service Centre list included with this
product for service assistance.
For Installation
The unit should be installed in a
horizontal position with the front end up
at a convenient angle, but not more than
30°.

Safety Information ........................................................................................4
Disc Notes .....................................................................................................5
The Player......................................................................................................6
Installation .....................................................................................................8
Open/Close the Monitor and Angle Adjustment........................................9
Electric Connection ....................................................................................10
Remote Control...........................................................................................11
Preparing the Remote Control..............................................................................13
Loading a DVD/VCD/CD Disc...............................................................................13
Ejecting a Disc ......................................................................................................13
Basic Operation ..........................................................................................14
On-Screen Display Function.................................................................................16
Multi-audio Language Function............................................................................17
Menu Function......................................................................................................17
Title Menu Function ..............................................................................................17
Multi-subtitle Language Function .........................................................................17
Multi-angle Function .............................................................................................17
MP3 Disc Play.......................................................................................................18
TV Operation.........................................................................................................18
Setup ............................................................................................................19
Initial Setup ...........................................................................................................19
General Setup.......................................................................................................19
Speaker Setup ......................................................................................................21
Audio Setup ..........................................................................................................21
Preferences Setup ................................................................................................22
Defaults Table .......................................................................................................24
Specifications..............................................................................................25
3
CONTENTS

4
CAUTION:
MOBILE DVD PLAYER IS A CLASS I
LASER PRODUCT. HOWEVER THIS
MOBILE DVD PLAYER USES A
VISIBLE/INVISIBLE LASER BEAM
WHICH COULD CAUSE HAZARDOUS
RADIATION EXPOSURE IF DIRECTED.
BE SURE TO OPERATE THE MOBILE
DVD PLAYER CORRECTLY AS
INSTRUCTED.
USE OF CONTROLS OR
ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND - DO NOT
REPAIR YOURSELF. REFER SERVICING
TO QUALIFIED PERSONNEL.
WARNING:
•TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR
MOISTURE.
•TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, AND ANNOYING
INTERFERENCE, USE ONLY THE
RECOMMENDED ACCESSORIES.
•THIS DEVICE IS INTENDED FOR
CONTINUOUS OPERATION.
This product incorporates copyright
protection technology that is protected
by method claims of certain U.S. patents
and other intellectual property rights
owned by Macrovision Corporation and
other rights owners. Use of this copyright
protection technology must be authorized
by Macrovision Corporation, and is
intended for home and other limited
viewing uses only unless otherwise
authorized by Macrovision Corporation.
Reverse engineering or disassembly is
prohibited.
Region Management Information
Region Management Information:
This Mobile DVD Player is designed and
manufactured to respond to the Region
Management Information that is recorded
on a DVD disc. If the Region number
described on the DVD disc does not
correspond to the Region number of this
Mobile DVD Player, this Mobile DVD
Player cannot play this disc.
SAFETY INFORMATION

DISC NOTES
5
Disc formats supported by this player
DVD
12 cm disc
(Single-sided disc only)
VIDEO CD
12 cm disc
CD
12 cm disc
MP3
12 cm disc
Discs which cannot be played with this
player
•DVD-ROM
•DVD-R/DVD-RAM
•CDV
•CD-G
Handling and Cleaning
•Dirt, dust, scratches and warping disc
will cause misoperation.
•Do not place stickers or make
scratches on discs.
•Do not warp discs.
•A disc should always be kept in its
case when not in use to prevent from
damaging.
•Do not place discs in the following
places:
1. Direct sunlight
2. Dirty, dusty and damp areas
3. Near car heaters
4. On the seats or dashboard
Disc Cleaning
Use a dry soft cloth to wipe the surface.
If the disc is quite dirty, use a soft cloth
slightly moistured with isopropyl (rubbing)
alcohol. Never use solvents such as
benzine, thinner or conventional record
cleaners as they may mar the surface of
the disc.
Note:
A disc may become somewhat scratched
(although not enough to make it
unusable) depending on your handle it
and conditions in the usage environment.
Note these scratches are not an
indication of any problem with the player.
Preparing New Discs with Rough Spots
A new disc may have rough edges on its
inside and outside edges. If a disc with
rough edges is used, the proper setting
will not be performed and the player will
not play the disc. Therefore, remove the
rough edges in advance by using a ball
point pen or pencil as shown on the right.
To remove the rough edges, press the
side of the pen or pencil against the
inside and outside edges of the disc.
Rough spots
on inside edge
Ball point pen
or pencil
Rough spots on
outside edge
Label side up
Do not touch
the underside
of the disc
Do not bend
Wipe the disc from center
toward the outside edge

6
THE PLAYER
1. Power ( )
2 IR (Remote Sensor)
3. EJECT ( )
4. Disc Slot
5. PLAY/PAUSE
6. STOP ( )
7. PREV ( )
8. NEXT ( )
9. VIDEO INPUT
10. AUDIO INPUT
11. MODE
12. Indicator Light for DVD
13. Indicator Light for TV
14. Indicator Light for AV
15. SPEAKER ON/VOLUME
16. MULTI COLOR TFT MONITOR
17. COLOR Adjustment knob
18. BRIGHTNESS Adjustment knob
19. CONTRAST Adjustment knob
FRONT VIEW
5-INCH MULTI COLOR TFT MONITOR
4
1
14
11
7
12
13
15 2
10
9
5
3
6
8
19
18
17
16
7-INCH MULTI COLOR TFT MONITOR

7
THE PLAYER
20.
This jack is for earphone. You can connect an earphone to the jack to receive
sound signal.
21. VOLUME
Slide the knob to change the volume of the earphone.
22. Antenna
This antenna can receive TV signal.
BACK VIEW
23. DC 12V Power Input Socket
24. DC 12V Power Output Socket
25. Remote Control Socket
26. Digital Audio Out - Coaxial
27. AUDIO/VIDEO OUTPUT
28. Diversity Antenna Input
29. OPEN Button (Press to eject the
screen display from the base at a
little angle)
SIDE VIEW
20
21
22
29
23 24 25 26 27 28

8
INSTALLATION
1. Remove the two transport screws
Press OPEN button on the back of the unit to eject the screen display from the
base at a little angle then turn the monitor upward to display the two screw. And
then use the screwdriver to remove the two screws.
2. Push the monitor back into the monitor base unit until the screen engages with
OPEN button. Then attach the brackets on both sides of unit with screws (M4x5),
last install the unit with screws (M5x25). When fix the unit, you can slide the
screw (M5x25) to left side or right side to meet your needed position. In the figure
below, select two holes among the positions that marked 1, 2, 3 and 4 to fix the
bracket.
Remove the transport scerws
Open Button
SCREW
M5 x 25
SCREW
M4 x 5
SCREW
M4 x 5

9
OPEN/CLOSE THE MONITOR AND ANGLE ADJUSTMENT
Opening the monitor
Press the OPEN button on the back of the unit to eject the screen display from the
base at a little angle. Then you can easily turn the monitor upward.
Adjusting the angle of the monitor
Rotate the monitor counter-clockwise to let the front view of the monitor appear. Then
you can also adjust the monitor left and right from the central viewing position at a
certain angle range. Don’t rotate the monitor forcibly to avoid mechanical damage.
Note: When the monitor is in upright position to the base, you can adjust the monitor
left or right. Otherwise, the monitor may scrape the base surface when rotated.
Closing the Monitor
Rotate the monitor left and let the back of the monitor upward, then return the monitor
to the central viewing position. Then push the monitor back into the monitor base unit
until the screen engages with OPEN button.
OPEN BUTTON

10
ELECTRIC CONNECTION
AC/DC
ADAPTOR
(OPTIONAL)
YELLOW
VIDEO OUT
RED
AUDIO R OUT
WHITE
AUDIO L OUT
DIVERSITY ANTENNA INPUT
CIGARETTE LIGHTER
REMOTE CONTROL RECEIVER
(OPTIONAL)
DC 12V
INPUT OUTPUT
REMOTE
AUDIO/VIDEO
OUTPUT
DIVERSITY ANTENNA
INPUT
DIGITAL AUDIO

11
REMOTE CONTROL
6
1
3
7
11
4
8
10
5
9
12
13
14
16
15
17
20
18
19
2421
28
22
32
23
25
29
2726
3130
2

12
REMOTE CONTROL
1. POWER Press POWER to turn the unit ON or OFF.
2. EJECT Press to eject the disc.
3. MUTE Press to mute the sound.
4. SUBTITLE Changing of the SUBTITLE language on multi-subtitle language
DVD disc.
5. ANGLE Changing of the view angle on multi-angle DVD disc.
6. DISPLAY Display statistical disc information during playback.
7. MODE Changing between DVD mode, TV mode and AV mode.
8. SETUP Display the SETUP menu.
9. PAL/NTSC Switch between PAL mode and NTSC mode.
10. AUDIO Changing of the AUDIO soundtrack on multi-audio soundtrack
DVD disc. Changing of the sound mode of the VCD/CD disc.
11. TITLE Display the TITLE menu that is stored in DVD disc.
12. MENU Display the root menu that is stored on the DVD disc.
In TV mode, press it to enter into search state, then pressing
button to start searching TV channels.
13. / , / In case of MENU mode, / , / , buttons served as cursor
buttons to select item left/right, ahead/back..
14. ENTER Confirm the Track/Chapter selected with the numeric buttons or
selected with the cursor buttons on TV screen.
15. / Changing for slow forward/reverse playback motion.
16. Press to play the disc.
17. / Press to start forward rapidly & to reverse rapidly.
18.
(CH+) / (CH-) Press to skip to the next track & press to skip back one
track. In TV mode, press (CH+) button or (CH-) button to
choose channel upward or downward.
19. Press it to stop playback.
20. Press it to pause playback..
21. 0 - 9 Numeric buttons
22. 10+ (-/--) Digital selecting button, cooperatively used with numeric buttons.
23. CLEAR When you input a number in error, press the button to clear it.
24. VOLUME+/- Press VOLUME+/- button to increase or decrease the volume
level.
25. ZOOM Allows the picture to be increased or decreased in size.
26. RESUME When in stop mode, press the button, the play can be resumed
from the stop point.
27. GOTO Disc search button, cooperatively used with numeric buttons.
28. PBC Changing between PBC ON and PBC OFF on the VCD disc.
29. RANDOM Allows the track played in random order.
30. PROGRAM Allows the track played in the order you programmed.
31. REPEAT Switch the Repeat mode of discs.
32. A-B A-B repeat allows a passage to be repeated continuously.

13
REMOTE CONTROL
Preparing the Remote Control
Inserting the Batteries
1. Open the battery compartment cover.
2. Insert the new batteries. Make sure
that the positive and negative
terminals of the batteries are oriented
indicated.
3. Close the cover
Battery: Two AAA size battery.
Using the Remote Control
Face the remote control towards the
player front face IR mark (remote control
signal receiver).
Operation angle: About ±30 degree in
each the direction of the front of the IR
mark.
To prevent damage to the unit, be sure
to follow the connection diagram
(page 11).
Loading a DVD/VCD/CD Disc
1. Turn the ignition on the accessory
position.
2. Press the POWER button (1).
3. Insert the disc with printed side facing
up into the disc slot (2).
4. The player starts playback
automatically.
Ejecting a Disc
Press (EJECT) button (3) to eject the
disc.
1 2 3

14
BASIC OPERATION
Stopping Play
- Brief press the (Stop) button to stop
the unit playback, when press the
(Play) button it can continuous normal
playback.
- Press (Stop) button twice, it will stop
the playback and go back to initial
Track/Chapter.
Rapid Forward/Rapid Reverse
Press & during play. Each time the
button is pressed, the speed of rapid
forward/reverse changes according to
the disc as follow.
DVD:
VCD/CD:
MP3:
Skipping Track
Press / on the remote handset or
/ buttons on the front panel during
playback.
Press to skip to next track, and to
back one track.
Note: For some VCD2.0 discs (PBC-
playback control), / buttons may
be unavailable.
Slow Motion Play
Press / during play.
Each time the button is pressed, the speed of
slow forward/reverse changes according to
the disc as follow.
DVD:
Pause (still picture)
Pressing on the remote control or
on the front panel during playback will
stop play temporary. Return to normal
Normal Playback 2X 4X 6X 8X
playback, press on the remote control
or on the front panel.
MUTE
Will mute the sound, but the disc
continues playing. When you unmute the
sound (press MUTE again), a later
passage will be playing.
Repeat
FOR DVD:
Press the REPEAT button to select repeat
mode as follow.
FOR VCD/CD:
Press the REPEAT button to select repeat
mode as follow.
1. Continuously repeat at the current
chapter/track, when selected REP-
ONE mode.
2. Select REP-ALL mode to continuously
repeat all chapter/track on the current
disc.
3. When the player finish playback the
current disc last chapter/track, it will
stop display the elapsed time. When
selected REPEAT OFF mode, REP-
ONE & REP-ALL disappear at the
screen display.
4. REPEAT feature not support VCD2.0
(with PBC ON).
A-B
A-B repeat allows a passage to be
repeated continuously. Press A-B button
at the start of the required passage, then
press A-B button again at the end of the
passage. To revert to normal playing,
press A-B button again. Each time the
button pressed, the screen will display
as follows:
A TO B SET A ➝ A TO B SET B ➝ A TO B CANCELLED
CHAPTER REPEAT ON TITLE REPEAT ON
REPEAT OFF
REP-ONE REP-ALL REPEAT OFF
Normal Playback 2X 4X
Normal Playback 2X 4X 8X
Normal Playback 1X 2X 3X 4X

When select one mode, the
corresponding indicator will be illuminated.
SPEAKER ON/VOLUME CONTROL
KNOB
Rotate the SPEAKER ON/VOLUME
knob clockwise or counter-clockwise to
increase or decrease the volume level of
the speakers on the base of the unit.
When rotate the knob in the direction of
volume decreasing to the end, it will turn
off the speakers.
COLOR
Slide the COLOR knob upward or
downward to increase or decrease the
color of the screen display.
BRIGHTNESS
Slide the BRIGHTNESS knob upward or
downward to increase or decrease the
screen brightness.
CONTRAST
Slide the CONTRAST knob upward or
downward to increase or decrease the
contrast lever of the screen display.
OPEN (Monitor Release Button)
Press the OPEN button on the back of
the unit to eject the screen display from
the base at a little angle. Then you can
easily turn the display upward or
downward for good viewing.
Remote Sensor (IR)
Point the remote handset to the remote
sensor on the front panel. Receive the
signal from remote handset.
Turning the player on/off
Press the (POWER) button on front of
panel or on remote control to turn the
player on or off.
Reset Function
When the function buttons are operated
in error state, please unplug the DC 12V
INPUT plug then put the plug in the socket
again.
15
Disc Search (GOTO)
FOR DVD
Press GOTO button twice, the screen will
display the following message:
You can select the item you want to
watch through TIME setting by using
numeric buttons and ENTER key.
FOR CD/VCD (WITH PBC OFF):
Press GOTO button once, the screen will
display the following message:
Use numeric buttons to input the time
directly.
ZOOM
Allows the picture to be increased or
decreased in size. Press ENTER to
toggle among 1.5 scale, 2.0 scale and
3.0 scale.
RANDOM
Press RANDOM button, track selection
will be made in random order. The display
screen will show “SHUFFLE ON”on the
right-top corner. Press RANDOM button
again, “SHUFFLE OFF”appears and
release the mode.
PROGRAM
In stop mode, press PROGRAM button,
the screen will display “PROGRAM
P00:00”. For example: press numeric
button 4 and button, “PROGRAM
P01:04”appears. It means track 4 will be
played first.
MODE SELECTION
Press MODE button on the front panel
of the unit or on the remote control to
select among DVD, TV and AV mode.
TITLE 01/01 TIME -- : -- : --
00:00:25
GOTO -- : --
00:00:25
BASIC OPERATION

16
BASIC OPERATION
(2) Press DISPLAY for the second time:
SINGLE REMAIN
00:03:15
(3) Press DISPLAY for the third time:
TOTAL ELAPSED
00:00:25
(4) Press DISPLAY for the fourth time:
TOTAL REMAIN
00:40:35
(5) Press DISPLAY for the fifth time:
The message on the screen will be cleared.
CD:
(1)Press DISPLAY for the first time:
SINGLE ELASPED
00:00:25
TOTAL TRACK : 14
TRACK : - 01
(2)Press DISPLAY for the second time:
SINGLE REMAIN
00:03:15
TOTAL TRACK : 14
TRACK : - 01
(3)Press DISPLAY for the third time:
TOTAL ELASPED
00:00:25
TOTAL TRACK : 14
TRACK : - 01
On-Screen Display Function
Press the DISPLAY button during
playback to display the contents of the
current disc on the screen.
Example:
DVD:
(1) Press DISPLAY for the first time:
TITLE 01/03 CHAPTER 002/025
00:02:25
Title Number, Total Title Number, Chapter
Number, Total Chapter Number of this
Title of the disc currently being played
will be shown on the screen, along with
the elapsed time.
(2) Press DISPLAY for the second time:
TITLE REMAIN
01:46:58
(3) Press DISPLAY for the third time:
CHAPTER ELAPSED
00:00:24
(4) Press DISPLAY for the fourth time:
CHAPTER REMAIN
00:01:39
(5) Press DISPLAY for the fifth time:
The message on the screen will be cleared.
VCD:
(1) Press DISPLAY for the first time:
SINGLE ELAPSED
00:00:25

17
between monaural and stereo sound.
MONO LEFT MONO RIGHT STEREO
MENU Function (For DVD Only)
Press MENU button while the disc is
playing and the disc menu will be
displayed. You can navigate with the
remote control navigation keys and
select a feature with the ENTER key.
TITLE Menu Function (For DVD only)
If the DVD has multiple titles recorded on
the disc. It can select preferred title from
the title menu to start playback.
- Press TITLE during playback.
The title menu is display.
- Press the cursor button shown in TV
screen, select preferred title by the
cursor button and confirmed by
ENTER key.
Multi-subtitle Language Function
(For DVD only)
Press SUBTITLE during playback.
Each time the button is pressed, number
of the subtitle language changes in
sequential order.
Notes:
- The language number is different
according to the disc.
- Some discs only contain one subtitle
language.
- When no different subtitle language
are recorded, will be displayed at
screen left top corner.
Multi-angle Function (For DVD only)
Press ANGLE during playback.
Each time the button is pressed, number
of the angle changes in sequential order.
Notes:
- The angle number is different
according to the disc.
- The function only works for discs
having scenes recorded at different
angles.
- When no different angle are recorded,
will be displayed at screen left top
corner.
BASIC OPERATION
(4) Press DISPLAY for the fourth time:
TOTAL REMAIN
00:40:35
TOTAL TRACK : 14
TRACK : - 01
(5) Press DISPLAY for the fifth time:
The message on the screen will be cleared.
MP3 (When set to NO MENU in SMART
NAV item):
(1) Press DISPLAY for the first time:
CHAPTER ELASPED 00:00:25
TOTAL TRACK : 123
TRACK : - 01
(2) Press DISPLAY for the second time:
CHAPTER REMAIN 00:04:25
TOTAL TRACK : 123
TRACK : - 01
(3) Press DISPLAY for the third time:
The message on the screen will be cleared.
Multi-audio Language Function
For DVD:
Press AUDIO during playback.
Each time the button is pressed, number
of the audio soundtrack language
changes on sequential order.
Notes:
- The language number is different
according to the disc.
- Some disc only contain one language
soundtrack.
- When no different language
soundtrack are recorded will be
displayed at screen left top corner.
For VCD/CD:
Press AUDIO during playback.
It is possible to switch the sound

18
MP3 Disc Play
MP3 disc is playing as the format of
FOLDER.
For example:
Use / , / to select the item or
folder, then press ENTER button.
Pressing REPEAT button repeatedly can
select three kinds of repeat play mode.
REP-ONE:
Play the same song over and over again.
FOLDER REPEAT:
Play all songs in the current directory in
sequence, over and over again.
FOLDER:
Play all songs in the current directory
once.
When select PLAY MODE, press / to
change between the following mode:
In the playback, use or to skip an
item ahead or back.
: Rapid reverse, : Rapid advance
Note: The FOLDER cannot be selected
during playing. It can be selected after
(Stop) button pressed.
ROOT 0
MP3 MUSIC 1
SKY
MP3 HEAR YOUR
DISC
BASIC OPERATION
ROOT
SMART NAVI
PLAY MODE
TV Operation
Press the MODE button on the remote
control to switch among DVD mode, TV
mode an AV mode.
When in TV mode, the function of the
buttons served in DVD mode is locked.
Searching channels
Press MENU button will enter into
searching mode. Then press (CH+)
button to start searching TV channels
and press (CH-) button to stop
searching.
Selecting channels
- Press (CH+) button or (CH-)
button to choose channel upward or
downward.
- The numeric buttons (0, 1~9) allow
you to select the corresponding
channel directly.
-
Press digital select button 10+ (-/--)
cooperatively used with numeric
buttons to select channel desired.
Volume Adjustment
Press VOLUME+ or VOLUME- to adjust
volume level.
SINGLE REP-ONE FOLDER FOLDER REP
DISC SCAN DISC DISC REP RANDOM
SHUFFLE ON PROGRAM PXXX

19
SETUP
INITIAL SETUP
SETUP MENU --- MAIN PAGE
1. Press SETUP in the stop mode.
(Press the stop button twice to ensure
the player under STOP mode.)
2. The initial SETUP menu is displayed.
3. Select the preferred item by using the
/ buttons.
4. Press ENTER buttons.
a. GENERAL SETUP
This setup page includes all the
item of TV display & audio output
feature. The detail please refer to
GENERAL SETUP MENU.
b. SPEAKER SETUP
This is to activate the audio output
from DOLBY AC3 5.1 DOWNMIX
to 2 channel mode. Please refer to
SPEAKER SETUP MENU.
c. AUDIO SETUP
This setup page includes all the
items for AUDIO. Please refer to
AUDIO SETUP MENU.
d. PREFERENCE SETUP
This setup page includes all the
configuration of support feature.
The detail please refer to
PREFERENCES SETUP MENU.
GENERAL SETUP
--- GENERAL PAGE ---
TV display setup
This is to select the appropriate TV
aspect (4:3 or 16:9) according to the
connected TV set.
Normal/PS (For 4:3 TV)
Played back in the PAN & SCAN style.
(If connected to wide-screen TV, the left
and right edges are cut off.)
Normal/LB (For 4:3 TV)
Played back in letterbox style.
(If connected to wide-screen TV, black
bands appear at top and bottom of the
screen.)
Wide (For 16:9 TV)
Select when a wide-screen TV set is
connected.
Video Material
Normal
TV Screen
Pan Scan Letter-box
4:3 Wide (16:9)
4:3
16:9
GENERAL SETUP
SPEAKER SETUP
AUDIO SETUP
PREFERENCES
EXIT SETUP
TV DISPLAY
PIC MODE
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
NORMAL/PS
NORMAL/LB
WIDE

20
SETUP
--- GENERAL PAGE ---
PIC mode setup
Select AUTO, the player PIC mode will
depend on DVD disc.
Select HI-RES format for best image
resolution.
Select N-FLICKER format on image or
picture under noise affect.
--- GENERAL PAGE ---
ANGLE MARK display setup
If it is set to ON, when the multi-angle
DVD disc is playing, (the angle mark)
will appears on the screen; if is set to
OFF, the mark will not appear.
--- GENERAL PAGE ---
OSD LANG type setup
Select the preferred OSD language by
using the / buttons.
--- GENERAL PAGE ---
CAPTIONS setup
Activate the CAPTIONS feature by
selecting ON. And release this feature
by selecting OFF.
TV DISPLAY
PIC MODE
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
AUTO
HI-RES
N-FLICKER
TV DISPLAY
PIC MODE
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
ENGLISH
TV DISPLAY
PIC MODE
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
ON
OFF
TV DISPLAY
PIC MODE
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
ON
OFF
