Pyle PSW730S User manual

-8-
Thank you for choosing our productThank you for choosing our product
This product was designed to be installed on wood stud walls and solid concrete walls.
Before installing make sure the supporting surface will support the combined load of the
equipment and hardware. Never exceed the Maximum Load Capacity. This product is
intended for indoor use only. Use of this product outdoors could lead to product failure or
personal injury.
CAUTION
INSTALLATION GUIDE
This product contains small items that could be a choking hazard if swallowed. Keep
these items away from young children
1.Make sure these instructions are read and completely understood before attempting
installation. If you are unsure of any part of this installation, contact a professional
installer for assistance.
2.The wall or mounting surface must be capable of supporting the combined weight of
the mount and the display; otherwise the structure must be reinforced
3.Safety gear and proper tools must be used. A minimum of two people are required
for this installation. Failure to use safety gear can result in property damage, serious
injury or death.
!
.
Warning
Item No.:PSW730SItem No.:PSW730S
TV size range: 32 42
Maximum weight capacity: 35 kg /77lbs
Adjustable angle: 5 15
～
-～
""
°°
±90°
±180°
±90°
Cord management clip
Part 5-Adjusting display and using cord management
Route cords along articulating arms using cord management s(5).
Articulating arms can be adjusted to position display into desired location.
Use 6x6 wrench to tighten and loosen the tension screw. Do not overtighten
and do not loosen to the point the screws come out.
clip
Part 5-Adjusting display and using cord management
Pyle Audio
1600 63rd st , Brooklyn, NY, 11204
[phone]

-2- -7-
A-H L
IKJ M
Hardware Kit:
Hardware Kit: 1
2
4
3
4
4
4
I
J
K
L
M
4
4
Square washer
Long bolt
Wall anchor
Long bolt washer
Spacer
ID Description
1
2
A
3
4
5
B
C
1
1
1
4
1
1
4
4
Wall plate
Left bracket
Right bracket
M4 mm×12 bolt
M4 mm×16 bolt
M5× mm16 bolt
M6× mm16 bolt
M8×16mm bolt
M5×36mm bolt
M6×36mm bolt
M ×36mm8 bolt
Qty
D4
4
4
4
4
E
G
F
H
ID Description
Qty
6
Warning: Some TV require two people to lift, as we are not responsible
for any personal injury or product damage due to mishandling.
Warning:
Part 4- Hanging display
Firstly lift the bracket mounted display over the mount. And then hook
the brackets over the top of the mount. Rotate the display let the
bottom of the brackets hook over the bottom of mount. Then put safety
bolts into the bottom of the brackets and lock it.
Part 4- Hanging display
Plastic cover
Lock open
2,3
1
Knob
Lock closed
626 6 wrench×
Plastic cover
Cord management clip
Part 3-Attaching p cover to wall platelastic
Secure plastic cover over wall plate by pushing them toward each other
untiltheylockinplace.
Part 3-Attaching pcoverto wall platelastic
5

-6- -3-
Part 1a-Wood Stud Mounting
.
Use wall plate as a template, make sure it is level, and mark four mounting
holes on the wood studs. Drill 3/16
)
)..
four (5mm)dia holes 2 (50mm)
deep. Level wall plate and attach to wall with four long bolts(J and four
washers(L . Tighten bolts firmly Do not overtighten
””
Part 1a-Wood Stud Mounting
2 50mm)”(
3/16 (5mm)
”
Stud finder
Wood stud
J
L
Bubble level
Part 2b-Attaching brackets to screen with recessed back
Center brackets vertically on back of screen. Select the medium(F or G) or
large(H) screws. Attach brackets to screen using four selected screws,four
square washers(I) and four spacers(M) at the top and bottom of each bracket.
Tighten screws firmly. Do not overtighten.
Part 2b-Attaching brackets to screen with recessed back
I
F-H
M
Square washer(I)
Medium hole for
M5andM6screws
Large hole for
M8 screws

-5-
-4-
Part 1b-Concrete Wall Mounting
.
Level wall plate and use wall as a template to mark four holes. Drill four
3/8 (10mm) dia. holes 2 (50mm) deep. Insert four anchors(K) into holes
and secure wall plate with four long bolts(J) and four washers(L). Tighten
bolts firmly. Do not overtighten
””
Part 1b-Concrete Wall Mounting
2(”50mm)
Φ3/8 (10mm)”
Concrete Wall
K
J
L
Bubble level
.
Part 2a-Attaching Brackets To Screen With Flat Back
Center brackets vertically on back of screen. Select the small(A or B),medium
(C or D) or large(E) screws. Attach brackets to screen using four selected
screws and four square washers(I) at the top and bottomof each bracket.
Tighten screws firmly. Do not overtighten
Part 2a-Attaching Brackets To Screen With Flat Back
I
A-E
Square washer(I)
Small hole for
M4 screws
Medium hole for
M5andM6screws
Large hole for
M8 screws
